Oceanic Systems NMEA2000 3410 User manual

NMEA2000® DC MONITOR
Part Numbers: 3410
USER MANUAL
Document revision 2.00

1 of 14
1. Introduction................................................. 2
1.1 Product Features........................................... 2
2. Installation.................................................. 3
2.1 Unpacking the box........................................ 3
2.2 Mounting the unit.......................................... 3
2.3 Connecting the NMEA2000 Cable......................... 3
2.4 Connecting the sensor cables to the WAGO socket. 4
3. Calibrating the DC Current Transformer & Shunt... 6
4. Conguration.................................................... 7
4.1 Device Instance................................................. 7
4.2 Battery Type..................................................... 7
4.3 Nominal Voltage................................................ 7
4.4 Equalisation...................................................... 7
4.5 Calibrate to full battery.................................... 7
4.6 Peukert Exponent.............................................. 7
4.7 Charge Efciency Factor..................................... 8
4.8 Battery Capacity............................................ 8
5. State of Charge Resetting................................... 9
6. Maintenance..................................................... 10
7. Technical Specication....................................... 11
8. Warranty.......................................................... 13
9. Technical Support ............................................ 14

INTRODUCTION
1
2 of 14
The Oceanic Systems NMEA2000® 3410 DC Monitor is designed to monitor any DC source
including batteries, PV Cells or Wind Generators on the NMEA2000® network.
This unit is designed to operate in a protected marine environment such as an engine room. It is
very important that it is installed and set up correctly according to this manual. Please read and
follow the installation and setup instructions carefully to achieve the best results.
1.2 PRODUCT FEATURES
The NMEA2000® 3410 DC Monitor has the following features:
● Inputs from battery voltage, 200 Amp DC Current Transformer,500 Amp
50mV Shunt, 1200 Amp 50mV Shunt
● User Settable Device Instance using rotary switch
● Heartbeat blue LED conrming NMEA transmission.
● NMEA2000 micro C interface plug
● Panel or DIN rail mounting option
The unit reports DC Voltage, DC Current and state of charge. It uses Peukart’s Constant and the
Charge Efciency Factor for the battery to ensure the most accurate state of charge reporting.

INSTALLATION
2
3 of 14
2.1 UNPACKING THE BOX
You will nd the following items in the 3410 shipping box:
1 x 3410 NMEA2000® DC Monitor
1 x 3410 User Manual (This document)
2.2 MOUNTING THE UNIT
The unit should be mounted to a at surface using 4 mounting screws. The unit dimensions and
mounting hole locations are shown on the following drawing.
Note: Mount away from sources of condensation and moisture
2.3 CONNECTING THE NMEA2000 CABLE
The unit is connected to the NMEA2000 network by the 5 way micro C socket on the front.
Carefully attach the network drop cable to this plug and hand tighten until it it is fully seated.
Take care to match the orientation of the pip inside the socket to the recess inside the drop
cable plug. The other end of the drop cable should be connected to a suitable Tee connector on
the NMEA2000 network backbone cable.

4 of 14
2.4 CONNECTING THE SENSOR CABLES TO THE WAGO SOCKET
WARNING: Risk of Electric Shock
This device contains potentially hazardous voltages. Ensure that power is removed from all DC
circuit that will be connected to the DC monitor. Do not attempt to disassemble the device.
This device contains no user serviceable parts. Connecting the DC monitor must be performed
by QUALIFIED ELECTRONICS ENGINEER ONLY.
The cables from the power-source to the external sockets are connected using the 6 x 2way
WAGO Cage Clamp terminal block. The wire should be stripped for 8 mm and then the cage
clamp opened with a small screwdriver in the slot above the wire connection. Then simply
insert the wire into it’s connection slot and release the cage clamp by removing the small screw
driver. This will produce a secure gas tight connection on wire sizes from 0.08 – 2.5 mm²
2 4 6 8 10 12
1 3 5 7 9 11

5 of 14
V
Please note the following important notes:
• If you are using the 200A DC Current Transformer then do NOT install a current
shunt as well.
• If the DC Current Transformer shows a charge when discharging or vice versa
then reverse the direction of the current transformer on the DC Power cable.
• If the current shows a charge when discharging or vice versa simply exchange
the sense wires on the shunts.
Terminal 1 Battery Negative - Must be installed
Terminal 2 Battery Positive – Must be installed
Terminal 3 Current Transformer Black Wire
Terminal 4 Current Transformer Green Wire
Terminal 5 Current Transformer White Wire
Terminal 6 Current Transformer Red Wire
Terminal 7 Shunt Negative
Terminal 8 Shunt Positive
Terminal 9
Terminal 10
Terminal 11 No Connection
Terminal 12 No Connection
2 4 6 8 10 12
1 3 5 7 9 11
The terminal connections are numbered as follows:

CALIBRATING THE DC CURRENT TRANSFORMER & SHUNT
3
6 of 14
Before using the DC Monitor Current Transformer or Shunt for the rst time the current input
needs to be calibrated for the best accuracy. This is done by ensuring that there is NO current
owing through the center of the transformer or the shunt.
Note that if a current transformer is connected, the device will detect it at power up.
To select the type of a shunt set the rotary switch to either A or B, then press and hold down
the pushbutton for 5 seconds. To calibrate the current transformer or the shunt, set the rotary
switch to C, ENSURING THERE IS NO CURRENT FLOW PRESENT, press and hold pushbutton for 5
seconds.
When the button is released then the unit will be calibrated and the blue LED will remain
illuminated for a longer 2 second ash.
Rotary switch setting Selection
A 1200 Amp Shunt
B 500 Amp Shunt
CCalibrate

CONFIGURATION
4
7 of 14
The following items can be congured on the 3410.
4.1 DEVICE INSTANCE
It is possible to install 16 3410 DC Monitors on a NMEA2000® network so they need to each have
a unique Device Instance Address. The Device Instance of each unit is set by turning the small
rotary switch with a small screw driver. Valid Device Instances range from “0” through to “F”.
4.2 BATTERY TYPE
This can be set to either “Flooded/Wet”, “Gel”, “AGM” or “Other”. The unit is set to ooded as
it leaves the factory and if it is desired to change it to a different value this can be done with a
suitable Oceanic Systems Display Unit.
4.3 NOMINAL VOLTAGE
This is the voltage reported over the NMEA2000 network and can be set to 12,24 or 32 Volts.
It comes preset to 12 volts and can be changed to a different value with a suitable
Oceanic Systems Display Unit.
4.4 EQUALISATION
Used only for reporting over the NMEA2000 network this comes set to “Not Supported”. It can
also be set to “Supported” with a suitable Oceanic Systems Display Unit.
4.5 CALIBRATE TO FULL BATTERY
You must calibrate the device to report 100% charge at full charge. When the battery is fully
charged, set rotary switch to F and press & hold for 5 seconds the pushbutton. When the button
is released then the unit will be calibrated and the blue LED will remain illuminated for a longer
2 second ash.
4.6 PEUKERT EXPONENT
This can be set to a value between 1.0 and 1.5 and controls the state of charge calculation for
the best accuracy. This can be set using a suitable Oceanic Systems Display Unit. The default
value is 1.25

8 of 14
4.7 CHARGE EFFICIENCY FACTOR
This can be set to a value between 5% and 100% to reect the charging efcieny of the battery
for the best state of charge accuracy. This can be set using a suitable Oceanic Systems Display
Unit. The default value is 95%.
4.8 BATTERY CAPACITY
This can be set using a suitable Oceanic Systems Display Unit. For better accuracy, if Peukert
exponent is greater than 1.0, the capacity set must be at 20 hour discharge. The default value
is 100 Ah

STATE OF CHARGE RESETTING
5
9 of 14
The 3410 always calculates the remaining state of charge even when the NMEA2000 network is
not powered. It resets the state of charge to 100% automatically, when the charging current
drops below 5A whilst the charging voltage is above a threshold for 15 MINUTES. The unit can
also be forced to the 100% value by setting rotary switch to F and pressing the small button
next to the Device Instance switch for 5 seconds.

MAINTENANCE
6
10 of 14
• Clean the unit with a soft cloth.
• Do not use chemical cleaners as they may remove paint or markings
or may corrode the enclosure or seals.
• Ensure that the unit is mounted securely and cannot be moved
relative to the mounting surface. If the unit is loose, tighten
the mounting screws.
• Check the security of the cables connected to the NMEA 2000 connector,
tighten if necessary.
• Check the security of the cables connected to the WAGO terminal block,
reseating them if necessary.

TECHNICAL SPECIFICATION
7
11 of 14
As Oceanic Systems are constantly improving their products specications are subject to
change without notice. Oceanic Systems products are designed to be accurate and reliable
however they should only be used as aids to navigation and not as a replacement for traditional
navigation aids and techniques.
Certications
NMEA2000® Parameter Group Numbers (PGNs)
Electrical and Mechanical
Parameter Comment
NMEA2000 Level B
Maritime Nav and RadioComm Equipment IEC60945
CE and FCC Electromagnetic Compatibility
Type PGN No PGN Name
Monitor PGN127506 DC Detailed Status
PGN127508 Battery Status
PGN127513 Battery Conguration Status
Protocol PGN126464 Tx/Rx PGN List
PGN126996 Product Information
PGN059392 ISO Acknowledge
PGN059904 ISO Request
PGN060928 ISO Address Claim
PGN126208 Command/Request Group
Parameter Value Comment
Battery Voltage Range 9~40 Volts DC Voltage
NMEA2000 Voltage 12~24 Volts DC Voltage
Power Consumption 30mA Average Operating
Load Equivalence Number 1LEN
Reverse Battery Protection Yes Indenately
Load Dump Protection Yes SAE J1113
Size mm 96 x 84 x 35
Weight gr 120

12 of 14
Parameter Value
IEC 60954 Classication Protected
Degree of Protection IP40
Operating Temperature -25°C to 50°C
Storage Temperature -40°C to 70°C
Relative Humidity 93%RH @40° per IEC60945-8.2
Vibration 2-13.2Hz @ ±1mm, 13.2-100Hz @ 7m/s2 per IEC 60945-8.7
Electromagnetic Emission Conducted and Radiated Emission per IEC 60945-9
Electromagnetic Immunity Conducted, Radiated, Supply, and ESD per IEC 60945-10
Safety Precautions Dangerous Voltage, Electromagnetic Radio Frequency per IEC
60945-12
Environmental

WARRANTY
8
13 of 14
Oceanic Systems warrants this product to be free from defects in materials and workmanship for
one year from the date of original purchase. If within the applicable period any such products shall
be proved to Oceanic Systems satisfaction to fail to meet the above limited warranty, such products
shall be repaired or replaced at Oceanic Systems option. Purchaser’s exclusive remedy and Oceanic
Systems sole obligation hereunder, provided product is returned pursuant to the return requirements
below, shall be limited to the repair or replacement, at Oceanic Systems option, of any product not
meeting the above limited warranty and which is returned to Oceanic Systems; or if Oceanic Systems
is unable to deliver a replacement that is free from defects in materials or workmanship, Purchaser’s
payment for such product will be refunded. Oceanic Systems assumes no liability whatsoever for
expenses of removing any defective product or part, or for installing the repaired product or part or
a replacement therefore or for any loss or damage to equipment in connection with which Oceanic
Systems products or parts shall be used. The foregoing warranties shall not apply with respect to
products subjected to negligence, misuse, misapplication, accident, damages by circumstances
beyond Oceanic Systems control, to improper installation, operation, maintenance, or storage, or to
other than normal use or service.
THE FOREGOING WARRANTIES ARE EXPRESSLY IN LIEU OF AND EXCLUDES ALL OTHER EXPRESS
OR IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE.
Statements made by any person, including representatives of Oceanic Systems, which are inconsistent
or in conict with the terms of this Limited Warranty, shall not be binding upon Oceanic Systems
unless reduced to writing and approved by an ofcer of Oceanic Systems.
IN NO CASE WILL OCEANIC SYSTEMS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES,
DAMAGES FOR LOSS OF USE, LOSS OF ANTICIPATED PROFITS OR SAVINGS, OR ANY OTHER LOSS
INCURRED BECAUSE OF INTERRUPTION OF SERVICE. IN NO EVENT SHALL OCEANIC SYSTEMS
AGGREGATE LIABILITY EXCEED THE PURCHASE PRICE OF THE PRODUCT(S) INVOLVED. OCEANIC
SYSTEMS SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARISING
OUT OF BREACH OF CONTRACT OR WARRANTY, TORT (INCLUDING NEGLIGENCE), OR OTHER THEORIES
OF LAW WITH RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY OCEANIC SYSTEMS, OR ANY
UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.
Oceanic Systems does not warrant that the functions contained in any software programs or products
will meet purchaser’s requirements or that the operation of the software programs or products will
be uninterrupted or error free. Purchaser assumes responsibility for the selection of the software
programs or products to achieve the intended results, and for the installation, use and results
obtained from said programs or products. No specications, samples, descriptions, or illustrations
provided by Oceanic Systems to Purchaser, whether directly, in trade literature, brochures or other
documentation shall be construed as warranties of any kind, and any failure to conform to such
specications, samples, descriptions, or illustrations shall not constitute any breach of Oceanic
Systems limited warranty.
WARRANTY RETURN PROCEDUREe
To apply for warranty claims, contact Oceanic Systems or one of its dealers to describe the problem
and determine the appropriate course of action. If a return is necessary, place the product in its
original packaging together with proof of purchase and send to an Authorized Oceanic Systems
Service Location. You are responsible for all shipping and insurance charges. Oceanic Systems will
return the replaced or repaired product with all shipping and handling prepaid except for requests
requiring expedited shipping (i.e. overnight shipments). Failure to follow this warranty return
procedure could result in the product’s warranty becoming null and void.
Oceanic Systems (UK) Ltd reserves the right to modify or replace, at its sole discretion, without prior
notication, the warranty listed above.

TECHNICAL SUPPORT
9
14 of 14
If you require technical support for any Oceanic Systems products you can reach us using any of
the following ways:
● Tel (UK): [phone]
● Tel (USA): (844)8986462
● Fax: [phone]
● Email: [e-mail]
●Web: www.osukl.com
● Post: Oceanic Systems (UK) Ltd
Unit 10-11 Milton Business Centre
Wick Drive, New Milton, Hampshire BH25 6RH
Oceanic Systems (UK) Ltd
Unit 10 -11 Milton Business Centre, Wick Drive,
New Milton, Hampshire, BH25 6RH, United Kingdom
Tel (UK): [phone] Tel (USA): [phone]
Fax: [phone] Email: [e-mail]
Web: www.osukl.com
Copyright © 2019 Oceanic Systems(UK) Ltd. All rights reserved. Our policy is one of continuous product improvement so product
specications are subject to change without notice. Oceanic Systems products are designed to be accurate and reliable. However,
they should be used only as aids to vessel monitoring, and not as a replacement for traditional navigation and vessel monitoring
techniques. NMEA2000® is a registered trademark of the National Marine Electronics Association.
