OCTANORM M 1497-4 User manual

1
Mini wireless-sync-control led dimmer with touch remote
Controller adopts the most advanced PWM (Pulse Width
Modulation) digital control technology, it is used for controlling
constant voltage LED lamps. For instance, point source of
light, flexible light strip, led modules, led strings and so on.
2. TECHNICAL PARAMETERS
Controller
Working temperature: -20 - 60°C
Static power consumption: <1W
Grayscale: infinitely variable
External dimension: L 48 × W 26 ×H 13 mm
Net weight: 20g
RF frequency: 2.4GHz
Output color order settable: Yes, RGB/RGBW
Output: DIM 1 CH
PWM frequency: 1.95KHz
Supply voltage: DC 12V-24V
Speed stage: infinitely variable
Packing size: L 100 ×W 65 ×H 40 mm
Gross weight: 40g
RF distance: ≤20m
Memory function: Yes
Output current: ≤6Am (total) DIM:1 ×6A
Max. Output power: 12V: <72W, 24V: <144W
1. PRODUCT FEATURES
Designed for M 1497 wallwasher
DC12-24V, output current: 1ch*6A(DIM)
Adopts RF remote control, no need line-of-sight
Wireless-sync-control in both static color and dynamic modes, unlimited by remote control distance
Batch-operation is available for RF code matching/clearing between remote control and receivers
Memory function, each time power-on reserve the mode which stop in the last power-off
Perfect control effect, soft dim function
Long-press the brightness and speed key can get the fast adjustment, convenient for operation
Also adopts Button function for switch on/off and change color
Warranty of this product is one year, exclude the artificial situation of damaged or overload working
M 1497-4 DIMMER FOR WALLWASHER
User Manual M-OWP 1.1
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
Touch remote control
Working temperature: -20 - 60°C
Standby current: 8uA
Standby power: 36uW
Net weight: 65g
RF distance: ≤20m
Supply voltage: 4.5V (AAA 3pcs)
Working current: 30mA
Working power: 135mW
External dimension: L 150 ×W 40 ×H 20 mm
RF frequency: 433.92MHz

2
3. DIMENSION
4. INTERFACE SPECIFICATIONS
Button:
5. DIRECTION FOR USE
Wireless-synchronization function
Receivers will transmit the control signals from the remote
control and self-inspection the work statues for each other,
so multiple receivers in same zone will wireless-sync-work
completely, not only static mode but also dynamic mode, to
achieve wired-like operation experience.
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
Input port: DC plug (2.1/5.5) Output port: DC plug for DIM
M 1497-4 DIMMER FOR WALLWASHER
User Manual M-OWP 1.1

3
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
Button control function
1. Short pressing to switch on/off the light in any time.
2. Long-pressing during the controller in working state, the output light brightness, just release press when
you get the correct brightness.
6. TOUCH REMOTE
Adopts RF full touch control, with one dimming ring and 5 function buttons.
Tips: Without any operation more than 20 seconds, the touch remote will enter the sleep state, please SHAKE
the remote to wake up it before the next using.
NAME OF KEY INSTRUCTION REMARKS
Off Off in any time
On On in any time
Mode The mode will go to next, when you
touch the key each time
2 modes in total: fade or flash (speed is
adjustable, brightness is unadjustable)
Speed/Brightness + The speed/brightness will +1, when
you touch the key each time
Speed for dynamic modes, brightness for
static modes
Speed/Brightness - The speed/brightness will -1, when
you touch the key each time
Speed for dynamic modes, brightness for
static modes
Dimming Ring For brightness selection
M 1497-4 DIMMER FOR WALLWASHER
User Manual M-OWP 1.1

4
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
7. TYPICAL APPLICATIONS
Application Circuit 1: Single color (DC plug 2.1/5.5)
8. ABOUT RF CODE
The biggest advantage of this system is that it can not only solve the cabling problem in engineering wireless-
ly, but also realize a wired-like operation experience. In order to facilitate the early testing and debugging of
the project, the factory status of the receiver is normally unpaired and each remote controller has a unique
code value. The user should perform the matching work of the remote controller and the receiver during
the installation of the project to avoid the mutual influence of the radio frequency remote control technology
during the later use.
Please pay attention to the following 3 points before operation:
All equipment in the complete system after installation should have a unified and unique code value, so
as to achieve the security and stability of the system.
The receiver can only store one code value and cannot be overwritten. Before learning the new code
value, it is necessary to clear the original code of the receiver; the remote controller can only save one
code value but can be overwritten and can also restore the factory settings. In order to facilitate the later
maintenance, the three components that may be involved in the system (including receivers, handheld
remote controllers, and panel remote controllers) can realize mutual learning of code values.
Since the receiver performs code value learning in the power-on state, batch-operation is available
(power-one the all receivers which will be in same zone, and operate the matching/clearing the RF code
all of them at the same time). And in order to avoid confusion in the area, it is recommended that each
area has an independent power switch so that the power of other areas can be easily cut off when
the code is being operated.
M 1497-4 DIMMER FOR WALLWASHER
User Manual M-OWP 1.1

5
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
1. Code pairing operation (means that the receiver will only be controlled by the value code remote controller)
2. Code clearing operation (means that the original code value of the receiver will be cleared and returned to
the factory state. Then it can be controlled by any compatible remote control, and can learn to a new code)
STEP OPERATION INSTRUCTIONS
1 Connecting the load to the receiver and power
on it.
1.It is necessary to clear the code first, if the
receiver was coded before.
2.Batch operation can be performed within the
remote control range.
2 Press and hold “ON” on the remote control for 5
seconds, the indicator of the remote control will
flash quickly, means it enters the pairing code
transmission status.
Will automatically exit code transmission status
after 60 seconds, or pressing any key to exit.
3 See the load light flashes 3 times and return to
the initial state.
2 modes in total: fade or flash (speed is adjusta-
ble, brightness is unadjustable)
STEP OPERATION INSTRUCTIONS
1 Connecting the load to the receiver and power
on it.
1. The clearing operation should be finished
within 1 minute after the receiver is powered on.
If exceeds the time, can be powered on again.
2. Batch operation can be performed within the
remote control range.
2 Press and hold the remote control “Off” for 5
seconds. The indicator of the remote control
flashes quickly, means it enters the clearing
code transmission status.
1. Will automatically exit code transmission sta-
tus after 60 seconds, or pressing any key to exit.
2. If the original remote control is lost, the new
remote control can be used for clearing opera-
tions.
3 See the load light flashes 3 times and return to
the initial state.
Clearing coding is finished successfully.
M 1497-4 DIMMER FOR WALLWASHER
User Manual M-OWP 1.1

6
T. [phone]
F. [phone]
[email protected]
www.octanorm.com
OCTANORM®Germany
Head Office
Raiffeisenstraße 39
70794 Filderstadt
3. Code learning operation between remote controls (used to unify system code values or copy a new remote
controls)
Since each remote control has its own unique code at the time of delivery, when there are multiple remote
controls in one system, one of them (for example, remote control A) must be selected as the system code
value, and the code value of the rest remote controls (for example, remote control B) should be copied to the
same one.
4. The remote controller restores the factory setting (it means that the remote control will be restored to the
factory‘s unique code value)
Attention!
1. In order to extend the life of the battery, the remote control will enter sleep mode without any operation
for 10 seconds, please pressing any key to wake up it before using.
2. The signal of the touch ring/buttons is continuously transmitted for a maximum of 30 seconds, please
release it and operate again if times out.
STEP OPERATION INSTRUCTIONS
1 A remote control: Press and hold “ON” on the
remote control for 5 seconds, the indicator of the
remote control will flash quickly, means it enters
the pairing code transmission status.
Will automatically exit code transmission status
after 60 seconds, or pressing any key to exit.
2 B remote control: long press „mode key“ for 5
seconds, the remote indicator light changes from
100% light to off light, means entering the code
value receiving state.
Will automatically exit the code value receiving
state after 30 seconds, or exit after learning the
code value successfully.
3 See the B remote control indicator light flash 3
times.
Code copying is finished and exit code value
receiving status.
STEP OPERATION INSTRUCTIONS
1 Long press „mode“ for 20 seconds. The remote indicator light dim down and flashes
continuously until the 20th second and then
back to 100% light. Means this step is finished.
2 Press „Off“ to confirm, the remote indicator light
flashes 3 times
Restore factory settings successfully.
