1 6 .0
6 4 .0
1 3 8 .0
8 6 .0
6 .0 11 4 .0 6 .0
1 5 0 .0
8 0 .0
1 6 0 .0
MECHANICAL DRAWING: OCZ-Z1000M
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
Black (GND)
Black (GND)
Black (GND)
Black (GND)
1
2
3
4
5
6
7
8
6/8 PCI Express Video
23” from case
YELLOW (+12V)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
23” 29” 35” from case
ALL CASE MEASUREMENTS ARE IN mm
5.9" X 3.4" X 6.3” (W X H X D)
ALL WIRE LENGTHS ARE IN INCHES
4 X 6-32
Orange (+3.3V)
Blue (-12V)
Black (GND)
Green (PS-ON)
Black (GND)
Black (GND)
Black (GND)
Not Used
Red (+5V)
Red (+5V)
Red (+5V)
Black (GND)
(+3.3V) Orange
(+3.3V) Orange
(GND) Black
(+5V) Red
(GND) Black
(+5V) Red
(GND) Black
(PG) Gray
(+5VSB) Violet
(+12V) Yellow
(+12V) Yellow
(+3.3V) Orange
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
21” from case
23” from case
Motherboard Power
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
Yellow (+12V)
(GND) Black
(GND) Black
(GND) Black
(GND) Black
(GND) Black
(GND) Black
(GND) Black
(GND) Black
1
2
3
4
1
2
3
4
5
6
7
8
5
6
7
8
23” from case CPU Power
4/8 CPU Power
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
Black (GND)
Black (GND)
Black (GND)
Black (GND)
1
2
3
4
5
6
7
8
Power Supply’s Modular Connectors
Serial ATA
Peripheral/Floppy
Yellow (+12V)
Black (GND)
Black (GND)
Red (+5V)
YELLOW (+12V)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
YELLOW (+12V)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
YELLOW (+12V)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
19” 25” 31” from case
19” 25” 31” from case
19” 25” 31” from case
21” 27” 33” 39” from case
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
(+12V) Yellow
(+12V) Yellow
(+12V) Yellow
(GND) Black
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
Black (GND)
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
5
6
7
8
5
6
7
8
5
6
7
8
5
6
7
8
6/8 PCI Express Video
23” from case
PCI-E VIDEO DRIVE
