Odorox Slimline User manual

SLIMLINE™
THE ODOROX®SLIMLINE™UNIT IS THE
RIGHT CHOICE FOR CLINICAL,
INSTITUTIONAL, COMMERCIAL, OR
RESIDENTIAL USE.
The SLIMLINE™unit is finely tuned to treat
bacteria, allergens, viruses, and chemicals
commonly associated with Sick Building
Syndrome. The unit is ideal for:
∙ Medical offices,
∙ Long term care facilities
∙ Commercial offices
∙ Homes, apartments and RV’s
The unit is designed to decontaminate up to a
1500 sq-ft. of space.
SPECIFICATIONS:
•Dimensions: 18” x 5.2” x 25”
(457mm x 133mm x 635mm)
•Weight: 17.6lbs, 7.9kg
•Voltage: 120V @ 60Hz / 220V @ 50/60Hz
•Power: 170 Watts (Max)
•Control: Speed Control
•Mobility: Handle / Stand Brackets
•Finish: Black or Beige powder coat
•Noise Level: <55dBa
•Number of Optics: 1
•Air Inlet / Outlet: Louvered panel
•Fans & Rating: One 500 CFM
•Fan Speed: 200ft³/m
(based on 230VAC, 50Hz fan set on high speed)
•Filters: One, 5” x 12.5” x 0.25”
(127mm x 317.5mm x 6.4mm), Washable
•Certification: Meets Canada / US – CSA & UL Standards, Meets
CE, REACH, & RoHS, Residual O3/ Non-accumulative
SLIMLINE™
GREEN TECHNOLOGY AT WORK
190 Summerhill Road | Spotswood NJ 08884 | [phone] ext. 21125
[email protected] | www.OdoroxAir.com
OWNER'S MANUAL

TABLE OF CONTENTS
Warning 1
Package Contents 2
Operating the Slimline 3
System Placement 4
Wall Mount Instructions 5
Caring for your Slimline 10
Optic Replacement Instructions 10
Specification and Warranty 11

PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock, and injury to
persons, including the following:
• Read all instructions before using the
generator.
•To avoidfire orshock hazard,plugthe equipment
directly into a grounded 120V AC electrical
outlet.
• If the generator is covered by a bag when
shipped: Remove plastic bag before use.
• Keep the cord out of heavy traffic areas. To avoid
fire hazard, NEVER put the cord under rugs, near
heat registers, radiators, stoves, or heaters.
• To protect against electrical hazards, DO NOT
immerse in water or other liquids. Do not use near
water.
• Close supervision is necessary when any
generator is used by or near children, or disabled
persons.
• WARNING! Always unplug the generator before
moving it, cleaning, or whenever the generator is
not in use. Be sure to pull by the plug and not
the cord.
• NEVER drop or insert any object into any
openings.
• DO NOT use an extension cord. Doing so can
create potential safety hazards.
• DO NOT operate any generator with a damaged
cord or plug, if motor fan fails to rotate, after the
generator malfunctions, or if it has been dropped
or damaged in any manner. Return generator
to manufacturer or authorized repair facility for
examination, electrical or mechanical adjustment,
or repair.
•Usegeneratoronlyforintendeduseasdescribed
in this manual. Any other use not recommended
by the manufacturer may cause fire, electric
shock, or injury to persons. The use of non-
recommended attachments may cause hazards
and should NOT be used..
• DO NOT use outdoors.
• NEVER block the air openings, grills/outlets or
place on a soft surface such as a bed or sofa, as
this could cause the unit to tip over, blocking the
Air Intake Opening/Grill.
• Keep unit away from heated surfaces and open
flames.
• CAUTION: For General Ventilating Use Only.
Do Not Use to Exhaust Hazardous or Explosive
Materials and Vapors.
• DO NOT attempt to repair or adjust any electrical
or mechanical functions on this unit. Doing so will
void your warranty. The inside of the unit contains
no user serviceable parts. All servicing should be
performed by qualified personnel only.
• WARNING! To reduce the risk of fire or electric
shock, DO NOT use this generator with any solid-
state speed control device.
• DO NOT place anything on top of generator.
• DO NOT plug the cord in with wet hands: electric
shock could result.
• NEVER use detergents, gasoline, glass cleaner,
furniture polish, paint thinner or other household
solvents to clean any part of the generator.
• To avoid a shock, plug the unit’s three-prong
plug into a grounded outlet.
•DONOTunder any circumstances cut or remove
the third (Ground) prong from power cord. For
personal safety, this generator must be properly
grounded.
WARNING!
IMPORTANT SAFETY INFORMATION. READ ALL
INSTRUCTIONS BEFORE USING.
Use this hydroxyl generator only for its intended
purpose as described in this Owner’s Manual.
1

1. One OdoroxTM Slimline Hydroxyl Generator
2. Two base brackets
3. Four 8-32 x ¾ inch Phillips (Star) machine screws
4. One 0.05 inch hex key
5. One Owner’s Manual
6. One Warranty Card
PACKAGE CONTENTS
2

POWER ON
The main power for the Slimline can be switched on by turning the rotary switch clockwise.
POWER OFF
The main power for the Slimline can be switched off by turning the rotary switch counter clockwise to
the “OFF” position.
FAN SPEED
The Slimline is equipped with an air mover fan, which runs between 100 and 400 cubic feet per
minute.
In order for the fan to turn on, the rotary switch must be rotated clockwise. Once turned on, the fan
speed can be controlled by turning the rotary switch clockwise to decrease the speed, or counter
clockwise to increase the speed.
PROCESSOR
The Slimline is equipped with one hydroxyl generating optic. In order for the optic to turn on, the
rotary switch must be turned on.
With the rotary switch in the OFF position, the optic will likewise be off.
OPERATING THE SLIMLINE
3

There are two options available when considering system placement:
OPTION ONE: PORTABLE FLOOR STAND
The Slimline may be used as a portable, free-standing unit, with the use of the enclosed
base brackets (see fig. 1)
OPTION TWO: WALL MOUNT
The Slimline may be installed to a wall (see “Wall Mount Installation Instructions”).
SYSTEM PLACEMENT
4

WARNING
1. ALL ELECTRICAL WORK MUST BE DONE IN ACCORDANCE WITH LOCAL OR NATIONAL
ELECTRICAL CODE AS APPLICABLE. FOR SAFETY, THIS PRODUCT MUST BE GROUNDED. IF
YOU ARE UNFAMILIAR WITH METHODS OF INSTALLING ELECTRICAL WIRING, SECURE THE
SERVICES OF A QUALIFIED ELECTRICIAN.
2. WHEN WIRING, SERVICING OR CLEANING THIS UNIT, TURN OFF POWERAND LOCK OUT
SERVICE PANEL. FAILURE TO DO SO COULD ALLOW OTHERS TO TURN ON POWER UNEX-
PECTEDLY WHICH MAY CAUSE FATAL ELECTRICAL SHOCK.
3. TO AVOID ELECTRICAL SHOCK:
• DO NOT INSTALL GENERATOR IN ATUB OR SHOWER ENCLOSURE OR ANY
LOCATION WHERE IT MAY COME IN CONTACT WITH WATER.
• NEVER PLACE A SWITCH WHERE IT CAN BE REACHED FROM A TUB OR SHOWER.
4. DO NOT INSTALL THIS GENERATOR IN AN AREA WHERE CHEMICALS OR OTHER FLAM-
MABLES ARE STORED OR USED. EXPLOSION AND FIRE MAY RESULT.
CAUTION
1. Install Hydroxyl Generator at least 6” from floor or any adjacent vertical surface.
2. DO NOT locate Hydroxyl Generator behind a door, furniture, drapes, etc., where the air flow to the
unit would be restricted.
3. DO NOT CONNECT HYDROXYL GENERATOR TO DIMMER SWITCH OR SPEED CONTROL.
4. Please read specification label on product for further information and requirements.
PLAN THE INSTALLATION
1. Carefully unpack Slimline and remove from plastic.
2. Remove ON/OFF knob by loosening the two allan (Hex) key set screws using the supplied 0.05
inch hex key.
5
WALL MOUNT INSTALLATION

3. Remove four screws on side of unit, then tilt and remove cover.
4. Remove optic reflection plate.
5. Remove lamp optic following these instructions:
Caution: Use clean leather gloves and eye protection when handling the optics in this generator
• Hold lamp base with one hand, and lamp connector with other hand.
• Gently ‘wiggle’ connector while pulling from lamp base.
• Gently pull lamp from three lamp supports.
Do not put any pressure on side of lamp with no support.
• Temporarily store lamp in a safe, clean location.
6
WALL MOUNT INSTALLATION

6. Knock out four pre-punched holes on back panel.
7. If wiring unit from back, knock out pre-punched 7/8 inch hole for electrical connector. If wiring from
the side, knock out pre-punched hole on the side of the back panel.
7
WALL MOUNT INSTALLATION

8. Determine the desired installation location. This location must conform to the Warnings and Cau-
tion instructions discussed earlier. This Slimline unit must be anchored securely to a wall or ceiling.
The mounting screw locations are designed for standard wood/metal framing with studs on 16 inch
centers. Using the back panel as a template, mark the screw locations onto the mounting surface
so that unit can be screwed directly to the main studs. If there is not sufficient support at the desired
location, support members must be added.
Installer is responsible for the proper installation of this Hydroxyl Generator as per local building and
electrical codes
9. If wiring from back of unit, also mark the 7/8 inch hole onto the mounting surface for the main
electrical connection.
10. Set back panel aside.
11. If wiring from back of unit, cut out hole size as needed for electrical connector, and install electrical
service.
12. Ensure electrical service to this unit is turned off and locked out before continuing. Install electri-
cal connector (not supplied) onto back panel, and make proper electrical connections.
13. Secure back panel to mounting surface using #10, 1 ½ inch wood screws (not supplied) for typical
wood frame construction. If construction type is different, ensure proper support as per construction
type and weight of Hydroxyl Generator.
14. If wiring from the side, install electrical service and make proper electrical connections.
15. Re-install lamp optic following these instructions:
Caution: Use clean leather gloves and eye protection when handling the optics in this unit
• Gently press lamp into the three lamp supports.
• Re-connect lamp connector holding the lamp base with one hand, and lamp connector with
other hand. Note: Lamp connector is keyed. If unable to connect lamp connector with lamp
base, rotate lamp connector 180 degrees and try again.
• Ensure lamp connector and lamp base are firmly pressed together.
8
WALL MOUNT INSTALLATION

16. Re-install optic reflection plate.
17. Re-install cover by first latching the top behind the back panel. Gently lower the bottom of the
cover until all four screw holes line up. Secure cover with four screws removed in Step 3.
18. Re-install ON/OFF knob and tighten the two set screws. Do not over-tighten set screws.
19. Turn on electrical service.
20. Turn on Slimline Hydroxyl Generator and set for desired airflow.
9
WALL MOUNT INSTALLATION

CARING FOR YOUR SLIMLINE
10
Warning: DISCONNECT the unit from an electrical power source before performing
any maintenance or cleaning on the unit.
SYSTEM CASE CLEANING
Exterior
The exterior of the Slimline can be cleaned with mild dishwashing detergent and a clean damp cloth.
DO NOT use any all-purpose cleaners with harsh detergents or abrasives, as these may damage
the decals and the exterior finish. Care should also be taken to avoid spraying or otherwise directing
detergent or water into or around electrical components.
Interior
The interior of the Slimline can be cleaned in the same manner as the exterior.
OPTIC CLEANING
Cleaning of the optics is recommended to maintain peak processing efficiency. Fingerprints, smudg-
es, dirt, dust particles, etc. will interfere with the hydroxyl production and should be removed.
Note: Remove the optics from the optic chamber prior to cleaning to avoid any damage to
the optics during the cleaning process (refer to the Optic Replacement Instructions for proper
removal).
To clean the optics, use a solution of 10% Isopropyl Alcohol (Isopropyl Alcohol strength of 70% or
90%) and 90% filtered/distilled water on a clean lint-free cloth and wipe gently. Do not use any type
of commercial glass cleaner. Using another lint-free cloth, gently wipe the optic until completely dry.
Allow the optic to dry completely (20 minutes) before operating the system.
Replacing the optics (see “Wall Mount Installation” on pages 5 - 9).
OPTIC REPLACEMENT INSTRUCTIONS

SPECIFICATION AND WARRANTY
11
SPECIFICATIONS
Dimensions: 18” x 24” x 5” (45.7cm x 61cm x 12.7cm)
Weight: 17lbs (7.7kg)
Power Requirements: 120 Volt AC, 1.7 Amp
Starting: Variable Speed Switch
Fan Control: Variable Speed Control 100 to 400 cfm
LIMITED WARRANTY
HGI Industries, Inc. warrants that this Slimline (excluding spare parts and consumables) shall be free
from defects in workmanship or materials for a period of one (1) year from the date of purchase.
CONTACT INFORMATION
For replacement parts, warranty service, or any questions regarding the operation and maintenance
of your Slimline, please contact your local authorized dealer.
