OEM Tools 24860 Service manual

UNPACKING
After unpacking unit, inspect carefully
for any damage that may have
occurred during transit. Check for
loose, missing, or damaged parts. If
any damage is observed, a shipping
damage claim must be filed with
carrier. Do not use Strut Compressor
if broken, bent, cracked or damaged
parts (including labels) are noted.
Any Strut Compressor that appears
damaged in any way, operates
abnormally or is missing parts
should be removed from service
immediately. If you suspect that the
Strut Compressor was subjected
to a shock load (a load that was
dropped suddenly, unexpectedly,
etc.) immediately discontinue use
until it has been checked by a factory
authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions
could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24860
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
AIR OPERATED
STRUT COMPRESSOR
Explanation of Safety Signal Words
CAUTION
Notes
CAUTION
WARNING
The following safety information is provided as guidelines to help you operate your Air Operated Strut Compressor
under the safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety
or safe handling instructions are not known or not followed. The following safety instructions are to provide the user
with the information necessary for safe use and operation. Please read and retain these instructions for the continued
safe use of your service system. Failure to follow instructions listed below may result in serious injury. In addition, make
certain that anyone that uses the equipment understands and follows these safety instructions as well.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm.
WARNING
: Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
: Used without the safety alert symbol indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
: Provide clarity and helpful information.
09/14
2014 ©OEM-TOOLS

2
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
Thank you very much for choosing an OEMTOOLS
Product!
For future reference, please complete the owner’s
record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is
important that you read the entire manual to become
familiar with this product before you begin using it.
This machine is designed for certain applications
only. OEMTOOLS cannot be responsible for issues
arising from modification. We strongly recommend
this machine is not modified and/or used for
any application other than that for which it was
designed. If you have any questions relative to a
particular application, DO NOT use the machine until
you have first contacted OEMTOOLS to determine if
it can or should be performed on the product.
For technical questions please call 1-866-458-2472.
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn
the tool’s applications and limitations, as well as,
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept
away from the work area. Never let a child handle
a tool without strict adult supervision.
4. Do not operate this tool if under the influence
of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should
be worn at all times when operating this
tool. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses.
Dust mask, non-skid safety shoes, hard
hat or hearing protection should be used in
appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-
ties, rings, bracelets or other jewelry may present a
potential hazard when operating this tool. Keep all
apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance
at all times when operating this tool.
8. Check for damage. Check your tool regularly. If
part of the tool is damaged it should be carefully
inspected to make sure that it can perform its
intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified
technician. Consult your dealer for advice.
9. Keep away from flammables. Do not attempt
to operate this tool near flammable materials
or combustibles. Failure to comply may cause
serious injury or death.
10. Store idle tools out of the reach of children and
untrained persons. Tools may be dangerous in the
hands of untrained users.
• Maintain tools with care.
• Keep tools dry and clean.
• Properly maintained tools are less likely to
bind and are easier to control. Do not use a
damaged tool. Tag damaged tools “Do not
use” until repaired.
• Check for misalignment or binding of moving
parts, breakage of parts, and any other condition
that may affect the tool’s operation.
• If damaged, have the tool serviced before
using. Many accidents are caused by poorly
maintained tools.
• Use only accessories that are recommended by
the manufacturer for your model. Accessories
that may be suitable for one tool may become
hazardous when used on another tool.
• Tool service must be performed only by qualified
repair personnel. Service or maintenance
performed by unqualified personnel could result in
a risk of injury.
• When servicing a tool, use only identical
replacement parts. Use of unauthorized parts or
failure to follow maintenance instructions may
create a risk of injury.
• Maintain a safe working environment. Keep the
work area well lit. Make sure there is adequate
surrounding workspace. Keep the work area free
of obstructions, grease, oil, trash, and other debris.
Do not use this product in a damp or wet location.
• Maintain labels and nameplates on this product.
These carry important information. If unreadable or
missing, contact OEMTOOLS for a replacement.
• Keep the handle dry, clean, and free from brake

3
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
fluid, oil, and grease.
• Before use, read and understand all warnings,
safety precautions, and instructions as outlined
in the vehicle manufacturer’s service manual. It
is beyond the scope of this manual to properly
describe the correct procedure and test data for
each vehicle.
• Always perform vehicle service in a properly
ventilated area. Never run an engine without
proper ventilation for its exhaust. Stop work
and take necessary steps to improve ventilation
in the work area if you develop momentary
eye, nose, or throat irritation as this indicates
inadequate ventilation.
• Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. When
working near moving engine parts, wear snug fit
clothing and keep hands and fingers away from
moving parts. Keep hoses and tools clear of
moving parts. Always stay clear of moving engine
parts. Hoses and tools can be thrown through the
air if not kept clear of moving engine parts.
• The unexpected movement of a vehicle can injure
or kill. When working on vehicles always set the
parking brake or block the wheels.
• Avoid accidental fire and/or explosion. Do not
smoke near engine fuel and battery components.
• The warnings, precautions, and instructions
discussed in this manual cannot cover all possible
conditions and situations that may occur. The
operator must understand that common sense and
caution are factors which cannot be built into this
product, but must be supplied by the operator.
• For safety purposes and the prevention of damage
to expensive components it is advised that
the user have an understanding of basic
automotive repair and a working knowledge of
automotive systems.
• We believe the information contained herein to be
reliable. However, general technical information
is given by us without charge and the user shall
employ such information at their own discretion
and risk. We assume no responsibility for results or
damages incurred from the use of such information
in whole or in part. Always refer to specific
instructions and technical information supplied by
vehicle manufacturer.
• The manufacturer declines any and all
responsibility for damage to vehicles or
components if said damage is the result of
unskillful handling by the operator or of failure
to observe the basic safety rules set forth in the
instruction manual.
• This equipment is intended only for professional
use by personnel trained in performing the service
functions for which it is has been designed.
• This equipment is designed for servicing a variety
of vehicles in a safe, convenient manner. However,
differences in vehicle makes and models may
make it impossible to use this equipment as it is
intended. Do not attempt to force the use of this
equipment on an application for which it is not
designed to perform.
• The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
• In addition to these guidelines, always follow the
manufacturer’s recommended procedures when
servicing each unique vehicle.
• The use of this equipment is simple and
straightforward if you follow the instructions. When
operating this equipment, use common sense,
and always stop to think before using a Strut
Compressor or lifting a vehicle.
WARNING
Spring compression creates a potentially dangerous
situation because of the energy stored between the
spring mounts. Failure to correctly position the strut
assembly in the tool could result in serious injury from
a sudden release of strut assembly parts. To prevent
personal injury.
• Study, understand, and follow the safety
precautions and operating instructions included
with the strut spring compressor. If the operator
cannot read these instructions, operating
instructions and safety precautions must be read
and discussed in the operator’s native language.
• Wear eye protection that meets ANSI Z87.1 and
OSHA standards.
• Use this equipment for automotive strut springs only.
• Check the condition of the strut spring compressor
before each use; do not use the equipment if it is
damaged, worn, or modified.
• Align the strut assembly before compressing. The
spring should be parallel to the forcing screw and
on the centerline of the foot support.
• Release and reposition the strut assembly if it is
difficult to compress the spring, or if the spring bows.

4
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
• Compress the spring only until it is loose in its mounts.
• Stop compressing if the spring or the arms bottom out.
• Do not remove the piston rod nut until the spring is
compressed enough to be loose in the mount.
SPECIFICATIONS
Maximum Load 2200 Lbs.
Upper Yoke Travel 16.5”
Spring Diameters 4-6.5”
Operation
Foot Controlled Valve
Maximum Air Pressure 116 Psi
PRODUCT DESCRIPTION
Quickly, easily, and safely compress and remove
springs for replacement and repair of automotive strut
components. This Strut Compressor comes with two
interchangeable plastic coated lower yokes and a
suspension strut clamp. It fits a wide range of spring
configurations and diameters. Also features a strut lo-
cating platform for easy movement of the strut to avoid
unnecessary lifting.
NEVER use for any purpose other than those uses
outlined above!
WARNING
• Verify that the product and application are compatible,
if in doubt call OEMTOOLS at 1-866-458-2472.
• Before using this product, read the operator’s
manual completely and familiarize yourself
thoroughly with the product, its components and
recognize the hazards associated with its use.
• Wear appropriate safety gear, including heavy-duty
work gloves and ANSI-approved safety goggles
during use.
• Do not exceed the capacity of the Strut
Compressor. Make sure load is evenly distributed.
Be aware of dynamic loading! Sudden load
movement may briefly create excess load causing
product failure. Exceeding the maximum capacity
for this product is dangerous and can lead to
serious injury or property damage.
• Always evaluate your task before using this Strut
Compressor. Use as intended only.
WARNING
• If you are working and the load becomes off-
balance and/or the Strut Compressor begins to tip
over, DO NOT ATTEMPT TO CATCH OR LIFT THE
LOAD WHEN FALLING. SERIOUS PERSONAL
INJURY CAN RESULT! In this event, clear the area
as quickly and safely as possible in order to avoid
injury from the falling load, including getting hit
with flying fragments.
• Before each use, inspect the general condition of
the Strut Compressor. If a problem occurs, have
the problem corrected before further use.
WARNING
• TO PREVENT SERIOUS INJURY: DO NOT USE
A DAMAGED OR MALFUNCTIONING STRUT
COMPRESSOR.
• If in doubt about the safety of your project, we advise
you to have the work done by a professional familiar
with applicable safety practices.
ASSEMBLY
Unpack the spring compressor carefully; it will be
necessary for two people to do this.
1. Lay out all of the parts ready for assembly.
2. Fit the two feet to the bottom of the frame with
the wheels facing rearwards. Use four allen
bolts, flat washer, spring washers and domed
nuts to secure in place.
3. NOTE: the longer bolt is installed in the positon
shown in (Fig. 1).
4. Using the help of another person, stand the unit
onto its feet taking care when the wheels come
into connect with the floor as the unit might
become unstable.
5. Attach the guard lock to the front of the unit using
four cross headed bolts (Fig. 4).
6. Attach the guard by dropping it into the bottom
pivot and then fitting the large pin and spring into
the top pivot holes and installing a nylon nut (Fig.
2). Some pressure will be needed to push down on
the pin to allow the nut to be threaded.
7. Fit the chain to the left hand side using a nut and
bolt. Remove the clip from the end of the chain
and clip it on the hook on the other side of the
compressor, the chain can then be attached to the
clip at the appropriate link as required (Fig. 3).

5
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
8. Install the locating platform by threading it onto
the long metal rod and securing it by attaching the
knob. The top of the rod fits through the hole in
the frame and is held in place using a domed nut
and washer. The bottom of the rod is secured by
attaching the metal arm to it and securing with a
nut. Then undo the domed nut previously installed
(Fig. 1) and install the metal arm over the bolt and
reinstall the domed nut. Tighten all nuts in turn
ensuring that the metal rod hangs vertically from
the frame also squarely to the metal arm (Fig. 5).
9. Install the handle to the top of the unit using two
domed nuts, spring washers and washers.
10. There are pre-drilled holes in the feet to bolt the
unit to the floor if desired.
11. Hang two of the strut brackets to the sides of
the frame and locate the third bracket on the
compressor using the locking pin to hold it in
position (Fig. 7).
12. Position the unit in a suitable location near an
air supply.
13. The recommended air hook-up procedure is
shown in (Fig. 6).
14. Ensure the foot control lever is in the “Off” position
before connecting to the air supply.
15. Maximum Air Pressure is 116 Psi.
WARNING
Ensure the air supply is clean and dry and does not
exceed 116 Psi. Too high pressure, moisture or trash in
the line will shorten the life of the compressor and may
be dangerous, causing damage or personal injury.
OPERATION
Compressing and disassembling a Strut Spring
.
WARNING
Note: Before removing the strut from the vehicle it
is recommended that the upper strut lock plate nut
be loosed a quarter turn. DO NOT loosen more than
a quarter turn. Do not loosen if loosening may release
the nut from shaft.
Use extreme care when working with a compressed
spring.
Spring compression creates a potentially
dangerous situation because of the energy stored
between the spring mounts. Failure to correctly
position the strut assembly in the tool could result
in serious injury from a sudden release of strut
assembly parts. To prevent personal injury.
Never remove the piston rod nut when there is any
spring pressure on the lower spring seat.
Release and reposition the strut assembly if it is
difficult to compress the spring, or if the spring bows.
Compress the spring only until it is loose in its
spring mounts. Stop compressing if the spring or
the arms bottom out.
Do not remove the piston rod nut until the spring is
compressed enough to be loose in the mount.
1. With the strut and spring assembly removed from
the vehicle, select the most suitable sized bracket
or the strut clamp depending on the size of the
spring and install it into the compressor using the
locking pin to hold it (Fig. 7).
2. Position the lowest coil of the spring in the lower
bracket and rotate the strut and spring so that the
coil is held as low as possible.
3. Swing the small upper arms into position and
locate the upper brackets on the uppermost coil
(Fig. 9). Ensure that the coil is placed inside the
recesses of the brackets to ensure that the coil will
not break free under compression.
4. After correctly positioning the spring on the
lower and upper brackets, tighten all the locking
knobs (Fig. 10).
5. Relocate the locating platform if required, so that
it is just underneath the bottom of the strut and
secure it in place.
Figure 1 Figure 2 Figure 3 Figure 4 Figure 5
Figure 6
Figure 7 Figure 8
Figure 9 Figure 10

6
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
6. Use the chain to secure the spring by pulling it
across the spring and hooking it onto the clip. Shut
the safety guard ensuring that it locks in place.
7. Check to make sure the spring is safely secured
and then start to compress the spring coils.
Gradually press the foot pedal to start the
compression, stopping to check that the spring
is still securely held.
WARNING
Keep Hands and Feet away from the spring while
compressing. Stop Compressing the spring before
the coils bottom out (touch each other).
DO NOT OVER COMPRESS THE SPRING!
If the strut assembly is not positioned correctly in
the jaws, it is possible that the strut retaining cap
could be subject to sideways forces. Watch closely
as the spring reaches its full compression and
ensure the retaining cap assembly rotates freely
before attempting to remove it.
8. When the strut is loose within the spring, unscrew
the strut locking plate nut and remove the locking
plate from the top of the strut, gradually release
the pressure on the spring by operating the foot
pedal. When all the pressure has been released
take care to support the strut and spring assembly.
Move the platform and remove the strut and
release spring from the brackets if needed.
Strut Reassembly.
1. With the spring properly installed in the brackets
as described in steps 1-6, insert the strut inside
the spring and move the locating platform just
underneath the bottom of the strut to support and
secure it in place by turning the knob.
2. Use the chain to secure the spring by pulling it
across and hooking the clip. Shut the safety guard,
ensuring that it locks in place.
3. Compress the spring using the foot control
pedal, ensuring that the spring is securely held
in place and located properly with the bracket
recesses at all times.
WARNING
Keep Hands away from the spring while compressing
Stop Compressing the spring before the coils
bottom out (touch each other).
4. Once the spring is sufficiently compressed, install
the lock plate to the strut and using a new nut
secure it into position. NUT MUST BE FULLY
ENGAGED ON PISTON ROD THREADS!
5. Decompress the spring carefully and slowly, using
the foot pedal, stopping to ensure the spring
locates properly in the strut housing and lock plate.
6. Remove the strut spring assembly from the
spring compressor.
7. After reinstalling the strut to the vehicle the
lock plate nut will need to be tightened to
manufacturer’s specs using a torque wrench.
Follow manufacturer’s guidelines. Your application
may require special tools, not included.
CAUTION
Use caution when troubleshooting a malfunctioning
Strut Compressor. Stay well clear of the supported
load. Completely resolve all problems before use. If the
Strut Compressor is malfunctioning, have a qualified
technician inspect and repair the Strut Compressor
before use.
MAINTENANCE
A periodic coating of light lubricating oil to pivot
points, adjusting points, etc. will help to prevent rust
and assure that all components move freely.
Disconnect the air supply when not in use.
If the compressor will be stored and not used for a
while, drop a little air tool oil into the air inlet and cover
to protect from debris.
Storage
Always store the Strut Compressor in a well-
protected area where it will not be exposed to
inclement weather, corrosive vapors, abrasive dust,
or any other harmful elements.

7
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
FIGURE DESCRIPTION QTY FIGURE DESCRIPTION QTY FIGURE DESCRIPTION QTY
24860-K1 Handle 1 24860-K24 Lower Strut Support 1 24860-K47 Moving Arm Cover 1
24860-K2 End Plug 4 24860-K25 Base(1) 1 24860-K48 Bolt 2
24860-K3 Washer 4 24860-K26 Bolt 3 24860-K49 Beam Assembly 1
24860-K4 Bolt 4 24860-K27 Bolt 4 24860-K50 Locking Pin 1
24860-K5 Nut 2 24860-K28 Wheel 2 24860-K51 Moving Arm 1
24860-K6 Lock Washer 2 24860-K29 Base(2) 1 24860-K52 Support 1
24860-K7 Washer 4 24860-K30 End Plug,Base 2 24860-K53 Knob Screw 1
24860-K8 Frame Assembly 1 24860-K31 Bolt 2 24860-K54 Split Washer 1
24860-K9 Bar 2 24860-K32 Connection Rod for Air
Cylinder
1 24860-K55 Chain 1
24860-K10 Nut 8 24860-K33 Air Cylinder Assembly 1 24860-K56 Ring 2
24860-K11 Pin 1 24860-K34 Bolt 4 24860-K57 Pin For Chain 1
24860-K12 Upper Strut Support 1 24860-K35 Hose Clip 4 24860-K58 Bolt 1
24860-K13 Control Assembly 1 24860-K36 Protective Casing 1 24860-P13 Nut 2
24860-K14 Bolt 1 24860-K37 Foot Pedal 1 24860-P14 Lock Washer 6
24860-K15 Chain 1 24860-K38 Safety Valve 1 24860-P15 Washer 6
24860-K16 Shackle 2 24860-K39 Valve Block 1 24860-M1 Hose 1 1
24860-K17 Hook 1 24860-K40 Valve Block Connector 1 24860-M2 Hose 2 1
24860-K18 Copper Bushing 1 24860-K41 Shaft For Plate 1 24860-M3 Hose 3 1
24842-K19 Nut 1 24860-K42 Plate 1 24860-M7 Split Washer 2
24860-K20 Bolt 1 24860-K43 Connecting Rod 1 24860-N13 Retaining Ring 2
24860-K21 Hook Assembly 1 24860-K44 Safety Locking Guard 1 24860-P24 Hose Connector 1
24860-K22 Bolt 4 24860-K45 Spring 1
24860-K23 Nut 1 24860-K46 Washer 1
PARTS LIST

8
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
Beam ass'y
Connecting rod
Description
Handle
B
D
D
G
F
G
E
B
F
C
C
C
C
D
D
E
B
A
A
K9
K22
K20
K21
K14
K17
K19
K18
K15
K16
K13
K12
K11
K10
K7
K8
K6
K5
K4
K1
K3
K2
2
1
1
1
1
1
1
1
1
8
4
1
2
2
4
1
4
4
K24
K23
1
4
1
1
1
K1
K2
K3
K4
K12
K44
K11
K46
K45 K48
K13
K8
K9
K28
M7
K42
K40
K38
K39
K32
K25
K30
K29
K24
K51
K51
K48
K47
K41
B8
K33
K31
K17
K15
K14 K7
K18 K19
K20
K21 K22
K23
K7
K6
K5
K37 K36
M1
M2
M3
K34
K35 K26
K27
K26
K26
K10
P14
P15
P24
K10
P14
P15
P15
P14
P13
K43
K58
K10
P14
P15
P13
P14
P15
K16
K49
K50
N13
K55
K56
K57
K25
K27
K26
1
3
1
K28
K30
K29
2
1
2
K51
K49
K50
K44
K47
K48
K45
K46
K43
1
1
2
1
1
1
K53
K52
1
1
1
1
2
K54
P13
1
2
6
P24
6
1
1
P14
P15
M1 1
M3 1
2M7
N13 2
M2 1
K52
K53
K54
K56
K55
K57
1
1
1
K39
K42
K41
K40
K37
K38
K36
K35
K34
K33
K32
1
1
1
1
1
1
1
4
4
1
1
K31 2
1K58
K7
End plug
Washer
Bolt
Nut
Lock washer
Washer
Frame ass'y
Bar
Nut
Pin
Upper strut support
NO
Control ass'y
Bolt
Chain
Shackle
Hook
Copper bushing
Nut
Bolt
Hook ass'y
Bolt
Nut
Lower strut support
Base(1)
Bolt
Bolt
Wheel
Base(2)
End plug,base
Bolt
Connection rod for air cylinder
Air cylinder ass'y
Bolt
Hose clip
Protective casing
Foot pedal
Safety valve
Valve block
Valve block connector
Shaft for plate
Plate
Q'TY Description
NO Q'TY
Safety locking guard
Spring
Washer
Moving arm cover
Bolt
Locking pin
Moving arm
Support
KNOB screw
Split washer
Chain
Ring
Pin for chain
Bolt
Nut
Lock washer
Washer
Hose 3
Split washer
Retaining ring
Hose connector
Hose 1
Hose 2
PARTS LIST
Note: Not all components of the Strut Compressor
are replacement items, but are illustrated as a
convenient reference for location and position in
the assembly sequence.
The manufacturer and/or distributor have provided the
parts list and assembly diagram in this manual as a
reference tool only. Neither the manufacturer nor
distributor makes any representation or warranty of
any kind to the buyer that he or she is qualified to
make any repairs to the product, or that he or she is
qualified to replace any parts of the product. In fact,
the manufacturer and/or distributor expressly states
that all repairs and parts replacements should be
undertaken by certified and licensed technicians,
and not by the buyer. The buyer assumes all risk and
liability arising out of his or her repairs to the original
product or replacement parts thereto, or arising out of
his or her installation of replacement parts thereto.

9
Operating Instructions and Parts Manual 24860
09/14
2014 ©OEM-TOOLS
AIR OPERATED
STRUT COMPRESSOR
OEMTOOLS™ LIMITED 90 DAY WARRANTY
Please read the following carefully
From 90 days from the original purchase of this product, OEMTOOLS will warranty this item. If you find any
defect in material or workmanship, through normal usage, return it to the place of purchase or to OEMTOOLS
for repair or replacement at our discretion. In order to obtain this service send your tool and proof of purchase,
transportation pre-paid, to OEMTOOLS Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118. We will not
be responsible for lost or damaged goods during transportation, please insure your package. If our inspection
verifies the defect, we will either repair or replace the product at our election, or we may elect to refund the
purchase price if we cannot readily and quickly provide you with a replacement. We will return repaired products
at our expense, but if we determine there is no defect, or that the defect resulted from causes not within the
scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS does not provide warranty for products labeled other than OEM or OEMTOOLS. OEMTOOLS will
not provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not limited to,
abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not
cover bits, blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or
replace blades, bits, files, and batteries as necessary. OEMTOOLS reserves the right to makes any changes in
construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold.
OEMTOOLS makes every effort to assure that its products meet high quality and durability standards, and
warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS
WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
