Panasonic Matsushita QA91K22CAU6 User manual

4.2
4.4
4.6
4.8
5.0
5.2
5.4
5.6
5.8
30 35 40 45 50 55 60
Current (A)
300
350
400
450
500
550
30 35 40 45 50 55 60
Input Power (W)
2,000
2,500
3,000
3,500
4,000
4,500
5,000
30 35 40 45 50 55 60
Evaporating Temperature (°F)
Capacity (BTU/H)
120°F 130°F 140°F
Rated Performance Data
Capacity . . . . . . . . . . . . . . 3,175 Btu/h ±10% *
E.E.R. . . . . . . . . . . . . . . . . . 7.40 Btu/Wh ±10% *
Current . . . . . . . . . . . . . . . 4.85 Amps *
Nominal Motor Data Motor Input . . . . 429 Watts*
Rated Current . . 3.99 Amps
Type . . . . . . . . . CSIR, Current relay
Start Current . . . . . . . . . . 23.1 Amps
Coil Resistances Run . . . . 1.41 Ohms
@ 68°F (20°C) Start . . . 7.93 Ohms
*Test Conditions for Performance Specifications
Test Oil . . . . . . . . . . . . . . . . Freol α 22
Shell Temp . . . . . . . . . . . . . . 170.0°F / 76.0°C
Condensing Temp . . . . . . . . . 130.0°F / 54.4°C
Evaporating Temp . . . . . . . . . 45.0°F / 7.2°C
Ambient Temp . . . . . . . . . . . . 95.0°F / 35.0°C
Gas Superheat . . . . . . . . . . . 95.0°F / 35.0°C
Liquid Sub-Cooling . . . . . . . . 115.0°F / 46.1°C
Electrical Accessories†
Overload Protector
Nominal Operating Characteristics
Model Name MSP24ALZ
Manufacturer Texas Instruments
Temperature To . . . . . . . . . . . Open: 248°F ± 9°F / 120°C ± 5°C
Close: 142°F ± 20°F / 61°C ± 11°C
Trip Current . . . . . . . . . . . . . . @158°F (70°C) 6.7 Amps ± 7.5%
@77°F (25°C) 17.5 Amps @ 18 sec. max.
Current Relay Model
Nominal Operating Characteristics
Model Name MM5-D2CH
Manufacturer Matsushita
Pick Up Current 13.2 max. Amps
Drop Out Current 11.1 max. Amps
Start Capacitor 80 µF 160 V (min.)
†Although these accessories are listed by UL/CSA for use with this compressor,
Matsushita assumes no responsibility whatsoever for these or any other components
sourced by the refrigeration system manufacturer from third parties.
Panasonic Industrial Company
Refrigeration Products Department
Tel: 201 - 392 - 4249
Fax: 201 - 392 - 4315 Rev#1-5/9
Evaporating Temp.
Condensing Temp. Rating +30°F +45°F +59°F
140°F Btu/h 2,141 3,073 4,196
Watts 374 448 525
Amps 4.41 5.00 5.65
E.E.R. 5.72 6.86 7.99
130°F Btu/h 2,229 3,175 4,357
Watts 363 429 497
Amps 4.32 4.85 5.42
E.E.R. 6.14 7.40 8.77
120°F Btu/h 2,305 3,295 4,500
Watts 347 409 470
Amps 4.21 4.69 5.20
E.E.R. 6.64 8.06 9.57
MATSUSHITA Compressor Single Phase 115V
MODEL# QA91K22CAU6 (80µF Start Cap.) R-134a 60
Hz
Performance Curves
Voltage Range . . . . . . . . . 103 Volts to 127 Volts @ 60 Hz
Application . . . . . . . . . . . . High Back Pressure
Compressor Cooling . . . . Fan Cooling
Refrigerant Control . . Capillary Tube
Evaporator
Temp. Range . . . . . . . 23°F to 59°F / -5°C to 15°C
9 – Point Data
P
a
na
s
o
n
ic
®

Tube
Discharge
Suction Tube
Process or
4 holes
19mm (0.75") DIA
(3.46")
88mm
F
B
A
C
DE
12.2mm (0.48")
(3.46")
88mm
(4.92")
125mm
(5.18")
131.6mm
(4.00")
101.6mm
(3.50")
89mm
205.1mm (8.07")
165.1mm (6.50")
(2.13")
54mm
(3.50")
84mm
Process or
Suction Tube
184mm DIA
(7.24")
Current Relay
M
C
S
~
1 2
3
Starting
Capacitor
Compressor
Motor
M
S
1
2
C.S.I.R.
Dimensions*
mm inches
A . . . . . . . . . . . . . . . . . . . . . 208.6 . . . . . . . . . . . . . . . . . . . 8.21
B . . . . . . . . . . . . . . . . . . . . . 92.8 . . . . . . . . . . . . . . . . . . . . 3.65
C . . . . . . . . . . . . . . . . . . . . . 115.8 . . . . . . . . . . . . . . . . . . . 4.56
D . . . . . . . . . . . . . . . . . . . . . 77.0 . . . . . . . . . . . . . . . . . . . . 3.03
E . . . . . . . . . . . . . . . . . . . . . 62.2 . . . . . . . . . . . . . . . . . . . . 2.45
F . . . . . . . . . . . . . . . . . . . . . 77.0 . . . . . . . . . . . . . . . . . . . . 3.03
* All dimensions are for reference only
Tubes Tube O.D. Wall Material
Suction . . . . . . . . . . 0.39 in. / 10 mm 0.035 in. / 0.9 mm Copper
Process . . . . . . . . . 0.39 in. / 10 mm 0.035 in. / 0.9 mm Copper
Discharge . . . . . . . . 0.33 in. / 8.3 mm 0.035 in. / 0.9 mm Copper
U.L. File # . . . . . . . . . SA 4615
C.S.A. File #’s . . . . . . LR - 34080
LR - 36593
LR - 100738
General Data Oil Charge . . 250 cc ± 5 cc / 15.3 cu.in. ± 0.3 cu.in.
Net Weight With Oil . . . . . . . . . . . . 21.4 lbs, 9.7 kg
Approved Oils . . . . . . . . . . . . . . . . . . FREOL α 22
Residual Moisture . . . . . . . . . . . . . . . 120 mg max.
Impurities . . . . . . . . . . . . . . . . . . . . . . 10 mg max.
Displacement . . . . . . . . . . . 9.07 cc. / 0.553 cu. in.
Panasonic Industrial Company
Refrigeration Products Department
Tel: 201 - 392 - 4249
Fax: 201 - 392 - 4315 Rev#1-5/9
This document sets forth certain operational parameters and conditions for
operation of this product. If this product is operated outside of the parameters
and conditions stated herein, buyer assumes sole and full responsibility and
shall indemnify seller with respect to all product failures and all consequences
thereof. Operation of the product outside of the parameters and conditions
specified herein shall serve to invalidate all seller warranties, if any, with respect
to the product. This document is for reference only. For specifications, please
contact Panasonic’s engineering department.
