Office Star Products Designlab ROG25 User manual

2
1
© Office Star Products April 2020
ROG25
ROGUE GAMING CHAIR
OPERATING INSTRUCTIONS
OSP FURNITURE LIMITED PRODUCT WARRANTY
Design Lab Products
• 3 years on gaming desks and chairs
• Upholstery is not warranted against routine scratching and scuffing
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two
year warranty on all parts applies. Fabric and foam is warranted for one year. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty
will be paid by Office Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@officestar.net, by Fax [phone], or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time.
WARNING
1. Use this product only one person at a time.
2. Do not use this product unless all bolts screws and knobs are
securely tightened.
3. Check that all bolts screws and knobs are tight every three
months or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic cover as
head covering. It may cause suffocation.
6. Do not use product as a stepladder.
7. Use this product for its intended purpose only.
8. Use mild detergent only for cleaning.
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and pull lever (1) up.
To lower seat height sit on chair and pull lever (1) up.
NOTE: It is normal for chair to slightly lower under body weight.
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped with an
adjustment that will allow the user to change the tension of the
tilting feature. Turn knob (2) clockwise to increase tension and
counter-clockwise to decrease or ease the tension. To lock return
chair to the upright position and push lever (1) in. To unlock pull
lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob completely.
• LED LIGHTING & ADJUSTMENT
Use LED controller to change the LED light colors.

Remove all the parts from carton, separate them into part numbers indicated on the list and make sure part quantities are correct.
STEP 1 Insert five casters (B) into base (A), push hard until you feel or hear the caster (B) snap into place. Insert pneumatic cylinder (C) into base (A) and
slip bellows (D) over pneumatic cylinder (C).
STEP 2 Attach seat plate (E) to seat cushion (H) with the arrow towards the front of the chair using two bolts (3) for front holes and two bolts (2) for
rear holes. FULLY TIGHTEN BOLTS.
STEP 3 Attach backrest (G) to rear of seat cushion (H) using three bolts (1). FULLY TIGHTEN BOLTS (1).
STEP 4 Attach arms (FL & FR) to seat cushion (H) using three bolts (2) for each arm (F). FULLY TIGHTEN BOLTS (2).
STEP 3
STEP 4
(1)
(H)
(G)
(2)
(FR)
(2)
(FL)
(G)
STEP 1
STEP 2
(D)
(C)
(A)
(B)
(H)
(E)
(3)
(2)
ROG25
ROGUE GAMING CHAIR
ASSEMBLY INSTRUCTIONS
ROG25
ROGUE GAMING CHAIR
ASSEMBLY INSTRUCTIONS
PART QTY
A. Base ..............................1
B. Caster .............................5
C. Pneumatic Cylinder...................1
D. Bellows ........................... 1
E. Seat Plate ..........................1
F. Left and Right Arm....................2
G. Backrest ...........................1
H. Seat Cushion .......................1
I. Power Adapter .......................1
HARDWARE QTY
1. Bolt ...............................3
2. Bolt ...............................8
3. Bolt ...............................2
4. Allen Wrench (not shown) ..............1

STEP 5
STEP 6
(I)
a
d
e
3.5mm connector
b
c
3.5mm connector
b
c
e
d
a
(C)
STEP 5 Place the assembled seat on top of pneumatic cylinder (C) and apply downward pressure.
STEP 6 Connect cords b to c and d to e. Connect power adapter (I) to cord a.
ATTENTION: MAKE SURE ALL BOLTS AND SCREWS ARE FULLY TIGHTENED BEFORE USING PRODUCT.
A
B
Lighting Controller
Operation Instructions
Press switch to on position
Press MODE button to change LED color,
the 8th press will cycle all colors.
Battery Operation
Charge 4 hours to fully charge the batteries before operation.
2.5 hours of operation using just the battery.
The LEDs will function when charging.
The LEDs will flash rapidly when the battery is low.
Plug in the charger when this happens.
If the LEDs do not work, please contact the seller.
Input: AC 100-240V ~ 50/60Hz 0.3A
Output: 5V/2A
Battery capacity: 1800 mA 3.7 V
A. MODE (change LED color)
B. Power switch
ROG25
ROGUE GAMING CHAIR
ASSEMBLY INSTRUCTIONS
ROG25
ROGUE GAMING CHAIR
ASSEMBLY INSTRUCTIONS
