Office Star Products EC22070-EC3 User manual

EC22070-EC3
EXECUTIVE ECO LEATHER CHAIR
OPERATING INSTRUCTIONS
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and
knobs are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Do not overturn back tilt knob when decreasing
tension.
5. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
2
1
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and pull lever (1) up.
To lower seat height sit on chair and pull lever (1) up.
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped
with an adjustment that will allow the user to change
the tension of the tilting feature. Turn knob (2)
clockwise to increase tension and counter-clockwise
to decrease or ease the tension. To lock return
chair to the upright position and push lever (1) in. To
unlock pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment
knob completely
LIMITED WARRANTy
Office Star chairs are warranted from the date of purchase against failure due to material and workmanship as follows:
• 5 Years on all non-moving metal parts.
• 2 Years on component parts including Control mechanisms, pneumatic cylinders, wood, plastic parts, base and casters.
• 1 Year on upholstery fabric and foam against wear and deterioration.
• We cannot warrant leather against routine scratching and scuffing, as all leather is subject to minor blemishes in normal
use.
To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and
obtain return authorization. At it’s option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component. The customer must prepay freight on any components returned to the factory. Return
freight on components still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal Residential usage by persons weighing 200 lbs. or less. This warranty will not cover labor,
freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of Office Star
Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential damages is excluded. The
user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts
are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail
parts@officestar.net, by Fax [phone], or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00
p.m. Pacific Time.

EC22070-EC3
EXECUTIVE ECO LEATHER CHAIR
ASSEMBLY INSTRUCTIONS
© Office Star Products February 2010
STEP 1
2
3
5
4
10
9
8L
6
1
PART QTY
1. Base .......................1
2. Casters .....................5
3. Cylinder .....................1
4. Bellows .....................1
5. Seat Plate ...................1
6. Seat Cushion . . . . . . . . . . . . . . . . . 1
7. Back Cushion . . . . . . . . . . . . . . . . 1
8. Arms (8L & 8R) . . . . . . . . . . . . . . . 2
9. Screws .....................12
10. Plastic Caps . . . . . . . . . . . . . . . . . 8
11. Allen Wrench (not shown) . . . . . . 1
9
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 Insert five Casters (2) into Base (1), push hard until you feel or hear the Caster (2) snap into place. Insert Pneumatic Cylinder (3) into Base (1) and slip
Belows (4) over Pneumatic Cylinder (3).
STEP 2 Attach Seat Plate (5) to Seat Cushion (6) with the arrow towards the front of the chair, using four Screws (9), FULLY TIGHTEN SCREWS (9).
STEP 3 Align holes of Arms (8L & 8R) with holes of Seat Cushion (6) and Back Cusion (7), secure Arms (8L & 8R) using four Screws (9) for each Arm,
FULLY TIGHTEN ALL SCREWS (9). Cover holes in Arms (8L & 8R) using eight Plastic Caps (10).
STEP 4 Place the assembled seat on top of Pneumatic Cylinder (3) and apply downward pressure.
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
STEP 2
STEP 3 STEP 4
3
8R
6
7
