Office Star Products SC66 User manual

SC66
MANAGER’S CHAIR
OPERATING INSTRUCTIONS
FEATURE
• HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and lift lever
(1). To lower seat height sit on chair and lift lever(1).
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped
with an adjustment that will allow the user to change
the tension of the tilting feature. Turn knob (2)
clockwise to increase tension and counter-clockwise
to decrease or ease the tension. To lock return chair
to the upright position and push lever (1) in. To unlock
pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob
completely.
• ARM HEIGHT ADJUSTMENT
To adjust arm height, pull button (3) up to allow the
arms to move up or down freely. Release the button
(3) once the desired height is reached.
1
2
3
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and
knobs are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Do not overturn back tilt knob when decreasing
tension.
5. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
LIMITED WARRANTy
Office Star chairs are warranted from the date of purchase against failure due to material and workmanship as follows:
• 5 Years on all non-moving metal parts.
• 2 Years on component parts including Control mechanisms, pneumatic cylinders, wood, plastic parts, base and casters.
• 1 Year on upholstery fabric and foam against wear and deterioration.
To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and
obtain return authorization. At it’s option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component. The customer must prepay freight on any components returned to the factory. Return
freight on components still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal Residential usage by persons weighing 200 lbs. or less. This warranty will not cover labor,
freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of Office Star
Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential damages is excluded. The
user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts
are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail
parts@officestar.net, by Fax [phone], or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00
p.m. Pacific Time.

SC66
MANAGER’S CHAIR
ASSEMBLY INSTRUCTIONS
© Office Star Products October 2009
Remove all the parts from carton, separate them into part numbers indicated on the list and
make sure part quantities are correct.
STEP 1. Insert five Casters (2) into Base (1). Insert Pneumatic Cylinder (3) into Base (1) and slip Bellows (4) over cylinder shaft.
STEP 2. Attach adjustable Seat Plate (5) to Seat Cushion (6) with the arrow towards the front of the chair. Use two 1 1/4” Screws (8) and two Washers (10)
on the front of the Seat Cushion (6). Use two 1 1/8” Screws (9), and two Washers (10) on the rear of the Seat Cushion (6). TIGHTEN ALL FOUR SCREWS
COMPLETELY.
STEP 3. Align the holes in the Arms (11L and 11R) with the holes in the Seat Cushion (6), Using 1 1/8” Screws (9) and Washers (10) attach Arms (11L and
11R). FULLY TIGHTEN ALL SCREWS.
STEP 4. Attach the Back Support Plate (12) to Seat Cushion (6) using four 11/8” Screws (9) and Washers (10). FULLY TIGHTEN SCREWS.
IMPORTANT NOTE: MAKE SURE YOU HAVE ASSEMBLED THE BACK SUPPORT (12) OVER THE SEAT PLATE (5) THAT YOU
ATTACHED TO THE SEAT CUSHION IN STEP 2. (SEE DETAIL A)
STEP 5. Place the assembled seat on top of Pneumatic Cylinder (3) applying downward pressure.
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
7
9,10
11L
11R
9,10
1
3
4
9,10
8,10
2
5
6
9,10
DETAIL A:
Assemble the back support over the
seat plate
12
9,10
9,10
Part QTY
1. Base ......................... 1
2. Casters ....................... 5
3. Pneumatic Cylinder .............. 1
4. Bellows ....................... 1
5. Seat Plate ..................... 1
6. Seat Cushion ................... 1
7. Back Cushion .................. 1
8. 1 1/4” Screws ................... 2
9. 1 1/8” Screws ................... 12
10. Washers ..................... 14
11. Arms Left (11L) Right (11R) ...... 2
12. Back Support (pre-Installed) ...... 1
13. Allen Wrench (not shown) ........ 1
