OfficeSource Orion OSTW8002 Quick reference guide

Model #: OSTW8002
Name: Orion
Description: Mesh Managers Chair
Assembly & Operating Instructions
ocesourcefurniture.com
Please read the instruction sheet(s) completely before assembly.
Maximum Weight Load: 275lbs
Customer Service
Tel: [phone] (Mon-Fri | 9am-5pm EST.)

Customer Service
Tel: [phone] (Mon-Fri | 9am-5pm EST.)
ocesourcefurniture.com
Distributed exclusively by COE Distributing! Distributed exclusively by COE Distributing!

Distributed exclusively by COE Distributing! Distributed exclusively by COE Distributing!
Parts List
Hardware List
Seat Cushion x1 Back x1
A B
Mechanism x1
C
Nylon Base x1
E F
Gas lift x1
D
1/4"*3/2" ×2PCS 1/4"*1" ×2PCS
① ②
Ø20*Ø9*1.5 ×3PCS
③④
⑤
M5 ×1PC
Casters x5
G
(L) (R)
Armrest x1
1/4"*5/4" ×6PCS
Ø16*Ø6.5*1.5 ×10PCS ⑥
⑧
Ø25*Ø11*10 ×2PCS
⑦
M8*16 ×3PCS
TILT TENSION ADJUSTMENT
360° SWIVEL
Adjust lever C to slide the seat
cushion forward and backward.
Your chair can rotate around 360°.
CNote: Clear cover for L arm
Red cover for R arm

Distributed exclusively by COE Distributing! Distributed exclusively by COE Distributing!
Installation Steps
STEP 1
E
F
G
STEP 2
3
5
FRONT
A
D -R
D -L
ARM HEIGHT ADJUSTMENT
TILT ANGLE ADJUSTMENT
To adjust arm height, push the button on
the outside of each arm and move the
arm up or down. Release the button to
set the height.
Rotate the lumbar support to a comfortable
angle.
R
D -R
L
D -L

Distributed exclusively by COE Distributing! Distributed exclusively by COE Distributing!
Installation Steps
STEP 3
STEP 4
FRONT
1
5
7
C
FRONT
2
5
SEAT HEIGHT ADJUSTMENT
While seated, lean forward and
reach under the right side of the
chair to find the handle. Lift the
handle and raise your body up
slightly to allow the chair to rise to
the desired height. Once desired
height is reached, release handle to
lock chair at desired height. To
lower the seat, lift the handle while
seated. The chair will descend until
the handle is released or the chair
reaches the bottom position. The
seat height adjustment range is
approxiately 3.23".
BACK TILT ADJUSTMENT
While seated, pull the lever B on
the left side of the seat out to
unlock the tilt function. Push
backwards to tilt. To lock in the
upright position, sit back up
straight and push the lever in,
which can be locked to 4 positions.
A
B

Distributed exclusively by COE Distributing! Distributed exclusively by COE Distributing!
Installation Steps
STEP 5
4
6
Installation Steps
STEP 6
FRONT
