OfficeSource PL139T User manual

OFFICE FURNITURE
MODEL NO. PL139T
OFFICESOURCE.COM
Last Updated: 10/2021
ASSEMBLY INSTRUCTIONS
Please follow these instructions for easy assembly.
Z:\Office Furniture\ECONOWISE\OLD\Performance_logo.jpg
Thank you for purchasing the Office Source Race Track / Boat Shape Conference Table.
PAGE 1 OF 5
See Page 3 See Page 3
See Page 4 See Page 4
See Page 5 See Page 5
Option 1
Option 2
Option 3
Option 1
Option 2
Option 3
See Page 5
Option 4
®
MODEL NO. PL139T
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

OFFICE FURNITURE
MODEL NO. PL139T
OFFICESOURCE.COM
Last Updated: 10/2021
ASSEMBLY INSTRUCTIONS
D
Please follow these instructions for easy assembly.
Z:\Office Furniture\ECONOWISE\OLD\Performance_logo.jpg
E
Thank you for purchasing the Performance Race Track / Boat Shape Conference Table.
PAGE 2 OF 5
Housing
Cap (Long)
4 Pcs
Screw
#6 x 58"
48 Pcs
D1 D2 D3 D4 D5
6 Hole
L-Bracket
6 Pcs
D6
Flat Bracket
2 Pcs
HARDWARE PACK PL 137 T/PL 237 T
FA B C
Screw
#6 x 58"
66 Pcs
A4 A5
6 Hole
L-Bracket
5 Pcs
A6
Flat Bracket
6 Pcs
HARDWARE PACK PL 139 T
D7 D8
Fitting-GL
Screw
2 Pcs
Wrench
1 Pc
M4 x 65
Allen-Key
1 Pc
Housing
Cap (Short)
4 Pcs
Housing
Cap (Long)
6 Pcs
Adjustable
Glide
4 Pcs
E8
Screw
#6 x 58"
24 Pcs
E1 E2 E3 E4 E5 E7
6 Hole
L-Bracket
4 Pcs
E6
HARDWARE PACK PL 3678 EP2
M4 x 65
Allen-Key
1 Pc
Housing
Cap (Short)
2 Pcs
Housing
Cap (Long)
4 Pcs
Adjustable
Glide
2 Pcs
F8
Screw
#6 x 58"
24 Pcs
F1 F2 F3 F4 F5 F7
6 Hole
L-Bracket
4 Pcs
F6
HARDWARE PACK PL 389 CP1 x 2
AK
I JA G H
K1 K2 K3
HARDWARE PACK PL CUBE20
M4 x 65
Allen-Key
1 Pc
Adjustable
Glide
6 Pcs
K4 K5 K6
JCBC Screw
M6 x 40mm = 4pcs
14Washer = 4pcs
Housing
Cap (Long)
16 Pcs
M4 x 65
Allen-Key
1 Pc
Housing
Cap (Short)
4 Pcs
Housing
Cap (Long)
6 Pcs
Adjustable
Glide
4 Pcs
J8
Screw
#6 x 58"
24 Pcs
J1 J2 J3 J4 J5 J7
6 Hole
L-Bracket
4 Pcs
J6
HARDWARE PACK PL 3678 EP2
M4 x 65
Allen-Key
1 Pc
Housing
Cap (Long)
6 Pcs
Adjustable
Glide
4 Pcs
I7
Screw
#6 x 58"
24 Pcs
I1I2I3I4I6
6 Hole
L-Bracket
4 Pcs
I5
HARDWARE PACK PL 36 ELPBASEEP2
I8
CSK Scew
M3.5 x 20MM
16 Pcs
A
D
D
®
MODEL NO. PL139T
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

OFFICE FURNITURE
MODEL NO. PL139T
OFFICESOURCE.COM
Last Updated: 10/2021
ASSEMBLY INSTRUCTIONS
1 2 3
A
B
F
F
E
D
E
TOP
C
C
Attach the Flat-Bracket (A5/D5) to
two Top Panel (D) and
Top Panel (A) as shown.
Tighten Screws (A6/D6) securely.
D
Attach the L-Bracket (A4/D4/E6/F6)
from Top Panel (A/D) to Modesty
Panel (B/C) and End Base (E) and
Center base (F) as shown. Tighten
Screws (A6/D6/E7/F7) securely.
TOP
D
D
A
B
E
E
F
F
C
C
PAGE 3 OF 5
Screw Adjustable Glide
(E5/F5) into bottom of End
Base (E) and Center Base (F).
Attach Center Base (F) to Modesty Panel (B)
by using Cam Lock (E1/F1) and Klix Cam (E2/F2).Attach Modesty Panel (C) to Center Base (F) by using Cam Lock
(E1/F1) and Klix Cam (E2/F2).Attach End Base (E) to Modesty Panel (C) by using Cam Lock (E1/F1) and Klix Cam
(E2/F2).Attach Top Panel (A) & Top Panel (D) to Center Base (F) & End Base (E) & Modesty Panel (B/C)
by using Cam Lock (E1/F1) and Klix Cam (E2/F2).
(A4/D4/E6/F6)
(A6/D6/E7/F7)
(A5/D5)
(A6/D6)
BOTTOM
FACE
®
MODEL NO. PL139T
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

OFFICE FURNITURE
MODEL NO. PL139T
OFFICESOURCE.COM
Last Updated: 10/2021
ASSEMBLY INSTRUCTIONS
1 2 3
A
G
D
TOP
H
H
Attach the Flat-Bracket (A5/D5) to
two Top Panel (D) and
Top Panel (A) as shown.
Tighten Screws (A6/D6) securely.
D
Attach the L-Bracket (A4/D4/J6/I5)
from Top Panel (A/D) to Modesty
Panel (G/H) and Eleptical Base (I)
and Center Eleptical base (J) as
shown. Tighten Screws
(A6/D6/J7/I8) securely.
TOP
D
D
A
B
E
E
F
F
C
C
PAGE 4 OF 5
Attach Center Eleptical Base (J) to Modesty Panel (G)
by using Cam Lock (J1/I1) and Klix Cam (J2/I2).Attach Modesty Panel (H) to Center Base (I) by using Cam Lock (J1/I1)
and Klix Cam (J2/I2).Attach Eleptical Base (J) to Modesty Panel (H) by using Cam Lock (J1/I1) and Klix Cam
(J2/I2).Attach Top Panel (A) & Top Panel (D) to Center Eleptical Base (I) & End Base (J) & Modesty Panel (G/H)
by using Screw (J7/I8).
(A4/D4/E6/F6)
(A6/D6/E7/F7)
(A5/D5)
(A6/D6)
BOTTOM
FACE
J7/I8
Attach Top Panel (A) & Top Panel (D) to
Center Eleptical Base (I) & End Eleptical
Base (J) & Modesty Panel (G/H)
by using Screw (J7/I8).
®
MODEL NO. PL139T
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023

OFFICE FURNITURE
MODEL NO. PL139T
OFFICESOURCE.COM
Last Updated: 10/2021
ASSEMBLY INSTRUCTIONS
Z:\Office Furniture\ECONOWISE\OLD\Performance_logo.jpg
PAGE 5 OF 5
K4
Attach the Flat-Bracket
(A6/D6) to two Top
Panel (D) and
Top Panel (A) as shown.
Tighten Screws (A5/D5)
securely.
K6
D
D
K
K
K
K
(A5/D5)
(A6/D6)
BOTTOM
FACE
Attach Cube Base (K) by
using Cam Lock (K1) and
Klix Cam (K2).
Screw Adjustable Glide
(K5) into bottom of End
Base (K).
KK
Attach Cube Base
Support (K) by using
Cam Lock (K1) and Klix
Cam (K2).
Attach Top Panel (A) to
Cube Base (K) by using
JCBC Screw (K4) and
tighten with Allen Key
(K6).
A
BOTTOM
FACE
A
®
MODEL NO. PL139T
OFFICESOURCE.COM
ASSEMBLY INSTRUCTIONS
Last Updated: 3/2023
