Oki DX-200 Series Troubleshooting guide

12151 Monarch Street, Garden Grove, CA 92841 •[phone] •[phone] fax •www.okinternational.com
8
7
6
1
3
2
5
4
9
10
11
12
13
14
15
BDX-300
A
1
2
3
4
Items Description
1 Power Button
2 Mode Button
3 Set up/Save Button
4 Display
5 Air Pressure Gauge
6 Air Pressure Regulator
7 Pulsed Air Outlet
8 Vacuum Control
9 Foot Switch Receptacle
10 Power Receptacle
11 I/O Connection
12 Exhaust Port
13 Constant Air Outlet
14 Air Inlet
15 Cord Lock
Items Description
1 To Air Source
2 Air Filter (Not Included)
3 Power Adapter
4 Foot Switch
DX-200 Series
Digital Dispenser/Controller
QUICK START UP GUIDE
Installing the Bracket and Air Hose Holder:
1. Align the bracket over the power and Foot
switch cord
2. Place the Air Hose Holder in the center of
bracket
3. Tighten the two mounting screws
Bracket
Air Hose
Holder
Power and
Foot Switch
Cord
Front View Back View
FEATURES
CONNECTING THE UNIT

12151 Monarch Street, Garden Grove, CA 92841 •[phone] •[phone] fax •www.okinternational.com
1. Press Power Button to turn on unit 2. Press Mode Button to select “PURGE” Mode
3. Rotate Air Pressure Regulator knob clockwise
(CW) until desired pressure is indicated on the
pressure gauge
Pressure
Gauge
Air
Regulator
Knob
4. Attach Receiver Head Assembly to syringe
5. Connect plug end of Receiver Head Assembly
to the control air outlet
If Vacuum “Pull Back” is needed, rotate
the vacuum knob counter clockwise
Vacuum
Control
Knob
6. Depress Foot Switch to activate dispense cycle
HOW TO SET-UP PURGE DISPENSE CYCLE

12151 Monarch Street, Garden Grove, CA 92841 •[phone] •[phone] fax •www.okinternational.com
HOW TO SET-UP DISPENSE TIME
1. Push Mode Button to select “CONTINUE” or
“INTERRUPT” Mode 2. Press and hold Set Button for two seconds to enter
“SETUP” mode.
(The last digit is highlighted with a blinking cursor)
5. Press and hold Set Button for 2 seconds to
save data
3. Press Set Button to move cursor to
next position
4. Press (+) or (-) Activation Button to set
dispense time
6. Depress Foot Switch to activate
dispense cycle

12151 Monarch Street, Garden Grove, CA 92841 •[phone] •[phone] fax •www.okinternational.com
HOW TO RESET CYCLE COUNTER
1. Press Set Button to enter “SETUP” mode 2. Press and hold Set Button for 4
seconds to reset counter
Counter
CONTINUE
P1 2.250 00004
INTERRUPT
P1 2.250 00004
PURGE
*************************
CONTINUE
P 2.250 00004
OFF
CONTINUE
P1 2.250 00004
Normal Operation
Power ON/OFF
Change Mode
MODE
Prog Time Counter
Setup
CONTINUE
P1 2.250 00004
SETUP MODE
P1 00004
SETUP MODE
P1 00004
Save and Exit...
SETUP MODE
P1 00004
SETUP MODE
P1 00004
SETUP MODE
P1 00004
SETUP MODE
P1 00004
SETUP MODE
P1 00004
SETUP MODE
P1 00004
CONTINUE
P1 2.251 00004
CONTINUE
P1 2.251 00000
2.250 22.25022.250
22.250 22.251 22.250
22.251
Save and Exit...
22.251
TIME SETTING
COUNTER RESET
:Press then release :Press and hold for approximately 2 seconds then release
POWER MODE SET
P1
Time setting in
in CONTINUE mode
:Press and hold for approximately 4 seconds then release
OPERATION DIAGRAM
