SHM-755AII_SSM-742AII_Rev11/2007
SHM-755AII
SSM-742AII
Operational Manual
True Day & Night IR Color Camera
*If it is for an outdoor application, you need to put it in a housing
and turn off the LED light to avoid the reflection.
z1/3” Sony Super HAD CCD
z550 TV Lines SHM-755AII
z420 TV Lines SSM-742AII
zBuilt-in 10 IR LED
z2.9mm~10.0mm Aspherical Vari-Focal Lens
Auto Iris IR D&N Lens – Made in Japan
z0.45 Lux @ F1.2
zIndoor IR Distance up to 40ft / 12m
zMechanical IR Cut Filter / True Day & Night
z12V DC
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may
damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could
damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The allowable
temperature range for operation of this camera is between -10°C ~ 50°C
and the allowable humidity is 85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before lens
installation or whenever the lens is changed. Cleaning should be done by
using a chamois, a very fine soft cloth, lens tissue, or cotton tipped
applicator and ethanol to carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera
must meet the specifications). Camera must be connected to a surge
protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch
dangerous voltage points of short out parts that could result in a fire or
electric shock. Never spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all service to qualified servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to
qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video
product.
c. If the video product has been dropped or the cabinet has been
damaged.
d. When the video product exhibits a distinct change in
performance.
OKIUSA Products are covered under warranty for one year from the date
of purchase. The warranty will automatically be voided if any of the
following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any
information regarding when and where the product was purchased.
We have no other way to verify the purchase record without the serial
number on the camera sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not
described in this manual, the warranty will be voided immediately. It is
the customer’s responsibility to keep the camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with.
Cutting or modifying of the cables will result in termination of the
warranty.
FEATURES
Please read the Operational Manual
before attempting to use this product.
CAUTIONS
WARRANTY
DIMENSIONS (Unit: mm)

SHM-755AII_SSM-742AII_Rev11/2007
IR LED OFF IR LED ON
④①
③
1. Lens Adjustment
2. IR LED On / Off
3. Description of Function
1. Video Connector
2. Power Input
3. Vari-Focal Lens Level Adjustment
4. Control Switch
SW1. AES: Auto Electronic Shutter OFF / ON Switch
SW2. BLC: Back Light Compensation OFF / ON Switch
SW3. FL: Flickerless NOM / FL Switch
SW4. AGC: Automatic Gain Control OFF / ON Switch
The camera can be attached to a tripod fixer or other mounting device
from either the top or bottom side by using the mounting screw holes
(1/4-inch, 20UNC) of the tripod set base plate.
CAUTION: The tripod set base plate is moved by removing the two
screws first and then attaching the base plate to the top(or bottom).Do not
use any screws other than those of the tripod set base plate of this camera.
Use of longer screws can cause the camera to be damaged.
List of Components:
zOne (1) SHM-755AII or SSM-742AII Camera with video/power cable
zOne (1) Operational Manual
Model SHM-755AII SSM-742AII
Image Sensor 1/3” Sony Super HAD CCD
DSP Sony HQ-1 Sony
Total Pixels NTSC: 811(H)×508(V
PAL: 795(H)×596(V) NTSC: 537(H)×505(V) PAL: 537(H)×597(V)
Synchronization Internal
Video Output 1.0Vp-p composite / 75ohms
Resolution 550 TV Lines 420 TV Lines
Minimum
Illumination 0.45 Lux @ F1.2 Controlled by a CDS sensor
Day/Night
Switching Mechanical IR Cut Filter
S/N Ratio More than 50dB
(AGC OFF) More than 48dB (AGC OFF)
Auto Electronic
Shutter ON/OFF Switchable
Back Light
Compensation ON/OFF Switchable
Flickerless ON/OFF Switchable
Auto Gain Control ON/OFF Switchable
Auto White
Balance AWB ATW
IR LED Built-in 10 IR LED
IR Distance
(Indoor) Up to 40ft / 12m
Lead Free Yes N/A
Lens 2.9mm~10.0mm Aspherical Vari-Focal Lens
Auto Iris IR D&N Lens – Made in Japan
Power Supply 12V DC
Power
Consumption 4.5 Amp 3.5 Amp
Operation
Temperature -10°C ~ +50°C
Storage
temperature -20°C ~ +60°C
Storage Humidity RH85% or less
Dimensions 55mm(W) x 47mm(H) x 140mm(L)
Weight 300g
SPECIFICATION
NOMENCATURE AND FUNCTION
PUSH HERE BEFORE OPEN IT
②
CAMERA MOUNTING
