Okina USA ECO Series Quick start guide

ESDX-3420W_rev010509
Operational Manual
3-AXIS Dome Color Camera
z1/3” Sony Super HAD CCD
z420 TV Lines
z3.6mm Board Lens
z0.2 Lux @ F2.0
z3-AXIS design for any angle
z12V DC, 75mA
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this
may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling
could damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor use. The allowable
temperature range for operation of this camera is between
14°F ~ 122°F / -10°C ~ 50°C and the allowable humidity is
85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned
before lens installation or whenever the lens is changed. Cleaning
should be done by using a chamois, a very fine soft cloth, lens
tissue, or cotton tipped applicator and ethanol to carefully
remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range.
(Camera must meet the specifications). Camera must be
connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may
touch dangerous voltage points of short out parts that could
result in a fire or electric shock. Never spill any kind of liquid on
the video product.
7. Servicing
Do not attempt to service this video product by yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all service to qualified servicing
personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service
to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has
been damaged.
e. When the video product exhibits a distinct change in
performance.
OKINA USA Products are covered under warranty for one year from
the date of purchase. The warranty will automatically be voided if
any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm
any information regarding when and where the product was
purchased. We have no other way to verify the purchase record
without the serial number on the camera sticker; therefore, it
should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner
not described in this manual, the warranty will be voided
immediately. It is the customer’s responsibility to keep the
camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered
with. Cutting or modifying of the cables will result in termination
of the warranty.
FEATURES
CAUTION
WARRANTY
Please read the Operational Manual
before attempting to use this product.
DIMENSIONS
3-AXIS
ESDX-3420W
ESDX-3420WP

ESDX-3420W_rev010509
* Specifications are subject to change without notice
1. Remove the dome cover from the mounting base by
rotating the dome cover clockwise.
2. Adjust the camera viewing angle by first tilting it, and then
rotate the camera module. Then turn the horizontal
adjustment ring to correct the image and achieve proper
orientation.
3. Once the installation is complete, replace the dome cover
over the camera and tighten it by turning counter
clockwise.
4. Connect the video output to the monitor or other video
device through a 75 Ohm type coaxial cable and the
DC-Jack or AC/DC-Terminator to the power source.
Note: Power adapter is sold separately.
zOne (1) ESDX-3420W/ESDX-3420WP Dome Camera with
power/video cable
zFour (4) Mounting Screws
zOne (1) Operational Manual
Model ESDX-3420W ESDX-3420WP
TV System NTSC PAL
Image Sensor 1/3” Sony Super HAD CCD
DSP Sony
Total Pixel 510(H) x 492(V) 500(H) x 582(V)
Synchronizing
System Internal
Resolution 420 TV Lines
Minimum
Illumination 0.2 Lux @ F2.0
S/N Ratio More than 48dB
Auto Gain Control Auto
White Balance Auto
Gamma 0.45
Electronic Shutter
Speed 1/60~1/100,000s 1/50~1/100,000s
Video Output 1Vp-p composite / 75 Ω
Lens 3.6mm Board Lens / F2.0
Power Supply 12V DC
Power
Consumption 75mA
Operating
Temperature 14°F ~ 122°F / -10°C ~ 50°C
Dimension 3.56”(H) x 4.20”(Ø)
90.5mm(H) x 106.8mm(Ø)
SPECIFICATIONS
INSTALLATION
LIST OF COMPONENTS
Top
Rotate
Tilt
Top
Top
Camera
Module Horizontal
Adjustment
Ring
