Oldfields Treco User manual

DOUBLE
HINGED DOOR
WORKSHOP
1015HDDA, 1019HDDA - 1.78m WALL HEIGHT
1015HDDA2, 1019HDDA2 - 2m WALL HEIGHT
15’
19’
TRECO SHEDS ARE MANUFACTURED TO COMPLY WITH ALL AUSTRALIAN STANDARDS
www.oldfields.com.au/treco/index.htm TR1519HDD - 08/05/07
OPTIONAL SINGLE HINGED DOOR INSTRUCTION MANUAL INCLUDED
(AVAILABLE IN AUSTRALIA ONLY)

1
BEFORE STARTING CONSTRUCTION
Pack A Pack D Pack C
B
Pack
E
Pack
NOTE Throughout this manual all doubled up codes refer to 10x15 shed code first followed by the
10x19 shed code.
eg (B7/B9) B7= Short Side Base Rail for 10x15 shed
B9 = Short Side Base Rail for 10x19 shed.
Codes for sheds with 1.78m wall height may differ from codes with shed with a 2m wall height.
Shed codes for 1.78m wall height will be followed by shed codes for 2m wall height.
eg (K/K2) K = 1.78m wall sheet
K2 = 2m wall sheet
The 10x15 and 10x19 sheds consist of three frame packs and two flat packs.
1015E or 1019E is the LONG FRAME
1315192C or 131519C is the CENTRE ‘A’ FRAME ( Portal Frame )
1015B or 1019B is the SHORT FRAME
Please do not mix the contents of the frame packs up as they look very similar but change
in length. The easiest way not to mix them up is to place them on the foundation diagonally
in order as above then open them and identify the parts.
The large flat packs contain the sheeting etc for the shed. These can be opened up away
from the foundation to identify the parts.
BEFORE YOU START, IT IS IMPORTANT THAT YOU READ THE FOLLOWING INSTRUCTIONS.
• When selecting a site, choose an area that is firm and level yet allows drainage away from the site.
• Although this shed when installed according to instructions, is designed to withstand greater wind loads than other
conventional sheds, do not assemble it in areas subject to high winds or erect on a windy day. Any building left partially
constructed may be seriously damaged if left in this state. It is your responsibility to safely and securely anchor the shed,
having regard to the windiest conditions in the area. The shed could possibly blow away causing damage and possible injury
if not properly attached to the ground foundation.
• Do not backfill against the walls or base of the shed as this will cause corrosion and void the warranty.
• The prevention of condensation inside the shed will assist in keeping the contents dry as well as minimising any possible
corrosion of the shed itself, the following hints may prove useful.
There is always dampness in soil, and this may rise into the shed if there is no barrier. A heavy duty polythene sheet may be
placed under the concrete slab to prevent evaporation into the shed.
Seal the space between the bottom frame and the concrete slab with a silicone.
• You will need a few tools, as indicated in the section HOW TO READ THIS MANUAL. Most holes for screws are predrilled. A
power screw driver or cordless drill equipped with a magnetic Philips tip will hasten assembly. Take care not to over-tighten
self-tapping screws.
• Sort, separate and identify all parts and hardware before construction. Check against the illustrations shown.
Framing components are labelled.
NOTE The Optional Single Hinged Door (available in Australia only) is packed in the A
or D Packs if it is unassembled or it will be in a separate box if it is assembled. Not all
1015 / 1019 models are provided with the Optional Single Hinged Door. This item is an
extra if you require an Optional Single Hinged Door they are available from your local
Treco Agent. If your shed contains the Optional Single Hinged Door Please read the
installation instructions on page 27 BEFORE starting construction of the shed.
Not all holes are pre-punched for hinged door construction, use the self tapping
screws provided with a battery drill or pre-drill using a 2.8mm drill bit.

2
IMPORTANT SAFETY FEATURES
• Observe all special notes which indicate differences between various types of sheds.
• You should not try to assemble the shed on your own. Get a second person to help you.
• The statutory requirements of the local building authorities must be observed.
• Safety gloves should be worn during assembly.
• Safety glasses should be worn during assembly.
• Preferably in a long sleeve shirt.
• Beware of sharp edges.
• WINTER SERVICE: The roof is designed for a snow load of 75 kg/m2. In order to avoid overload of the roof, timely removal
of snow from the roof area is recommended.
If the garden shed is unattended for lengthy periods during the winter months, the roofs should be propped up as a safety
precaution.
INSTALLATION ADVICE
MODEL
NO.
APPROX. ROOF
DIMENSIONS
OVERALL
HEIGHT
APPROX. BASE
DIMENSIONS
APPROX. FOUNDATION
DIMENSIONS
DYNABOLT
6.5mm x 40mm
FE FEET ET MM FEET MM FEET MM FEET MM QTY
1015A 10' x 15' 3070 x 4637 79.92" 2030 9'8" x 14'8" 2960 x 4540 10' x 15' 3070 x 4640 27
1015A2 10' x 15' 3070 x 4637 88.5" 2250 9'8" x 14'8" 2960 x 4540 10' x 15' 3070 x 4640 27
1019A 10' x 19' 3070 x 5880 79.92" 2030 9'8" x 18'8" 2960 x 5780 10' x 19' 3070 x 5885 29
1019A2 10' x 19' 3070 x 5880 88.5" 2250 9'8" x 18'8" 2960 x 5780 10' x 19' 3070 x 5885 29
THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE
NOT ERECTED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS OR ACTS OF GOD. PARTS
MAY CONTAIN SHARP EDGES & CORNERS. CARE MUST BE TAKEN WHEN HANDLING VARIOUS PIECES TO AVOID
AN ACCIDENT, FOR SAFETY SAKE, PLEASE USE A PAIR OF WORK GLOVES & EYE PROTECTION WHEN
ASSEMBLING OR PERFORMING ANY MAINTENANCE ON THE BUILDING.
6
24
7
3
5
1
8
9
TOOLS REQUIRED
All the tools listed are required for the erection of the shed. These tools should be at hand before starting work.
1. Step ladder
2. Masonary Drill Bit 6.5mm and suitable power drill
3. Tape measure
4. Cordless power screw driver
5. Phillips No. 2 Screwdriver tip
6. Dyna bolts 6.5mm x 40mm
7. Multi grips
8. 2.8mm and 10mm Steel Drill Bit
9. Hacksaw or Tin Snips

3
PARTS LIST Qty 1015HDD2
(2M WALL) Qty 1015HDD (1.78M WALL) Qty 1019HDD2 (2M WALL) Qty 1019HDD (1.78M WALL)
CONTENTS OF PACK “A” (FLAT PACK)
Right hand gable 2 O1 2 O1 2 O1 2 O1
Left hand gable 2 N1 2 N1 2 N1 2 N1
Hinged door 2 SCHDX2 2 SCHDX 2 SCHDX2 2 SCHDX
Roof end panel 4 RQ1 4 RQ1 4 RQ1 4 RQ1
Door jamb 2 L62 2 L6 2 L62 2 L6
Door jamb supporter 2 HD52 2 HD5 2 HD52 2 HD5
K frame 2 H1270A 4 H4A 2 H1270A 4 H4A
K frame 2 H4A - - 2 H4A - -
Top door support 1 C1525 1 C1525 1 C1525 1 C1525
Gable base rail ( split ) 2 A6 2 A6 2 A6 2 A6
Roof panel 6 S1 6 S1 6 S1 6 S1
Wall panel 9 K2 9 K 9 K2 9 K
Full corner panel 4 F2 4 F 4 F2 4 F
Hardware kit bag
Corner gusset 4 X20 4 X20 4 X20 4 X20
Gable - door track bracket 2 X26 2 X26 2 X26 2 X26
Gable - roof beam bracket 4 X15A1 4 X15A1 4 X15A1 4 X15A1
Portal - roof beam bracket 4 X15 4 X15 4 X15 4 X15
Portal anchor bracket 2 TR01074A 2 TR01074A 2 TR01074A 2 TR01074A
Rafter bracket 4 X34 4 X34 4 X34 4 X34
Portal midwall bracket 4 PB2 4 PB2 4 PB2 4 PB2
Roof ridge end cap 2 X10 2 X10 2 X10 2 X10
Roof corner cap 4 X8 4 X8 4 X8 4 X8
Roof washer sheet 10 X11 10 X11 10 X11 10 X11
Padbolt 3 HA01000A 3 HA01000A 3 HA01000A 3 HA01000A
Padbolt Spacer 2 HA01002A 2 HA01002A 2 HA01002A 2 HA01002A
Hinge 9 HA01001A 9 HA01001A 9 HA01001A 9 HA01001A
Self tapping screws 800 X12 800 X12 800 X12 800 X12
Nuts and bolts 450 X13 450 X13 450 X13 450 X13
CONTENTS OF PACK “D” (FLAT PACK)
Roof panel 8 S1 8 S1 12 S1 12 S1
Wall panel 8 K2 8 K 12 K2 12 K
Skylight (optional minus 1 Roof Panel if in Kit) Sky10 Sky10 Sky10 Sky10
CONTENTS OF PACK “C” (MEDIUM LONG PACK)
Portal frame column 2 PF12 2 PF1 2 PF12 2 PF1
Portal frame rafter 2 PF2 2 PF2 2 PF2 2 PF2
Portal frame sealing strip 2 PF3 2 PF3 2 PF3 2 PF3
Portal frame bottom chord 2 PF4 2 PF4 2 PF4 2 PF4
CONTENTS OF PACK “HDE” (LONG PACK)
Gable top rail 1 I1 1 I1 1 I1 1 I1
Gable end midwall 2 RM1 2 RM1 2 RM1 2 RM1
Long roof beam 6 P8 6 P8 6 P1 6 P1
Long side base rail 2 B8 2 B8 2 B1 2 B1
Long side midwall 4 SM8 4 SM8 4 SM1 4 SM1
Long side top rail 2 H8 2 H8 2 H1 2 H1
CONTENTS OF PACK “B” (LONG PACK)
Gable top rail 1 I1 1 I1 1 I1 1 I1
Gable base rail 1 A1 1 A1 1 A1 1 A1
Gable end midwall 2 RM1 2 RM1 2 RM1 2 RM1
Short roof beam 6 P7 6 P7 6 P9 6 P9
Short side base rail 2 B7 2 B7 2 B9 2 B9
Short side midwall 4 SM7 4 SM7 4 SM9 4 SM9

4
PARTS - PACK A
FRAME IN
PACK A
HARDWARE KIT BAG
Note: Packing procedures may differ for larger items in packs A & D however they
will still contain the correct amount of parts.
Models containing the optional skylight will consist of one less roof sheet.
X8 X10 X11 X15
X15A1
X34 X20 PB2
HA01002A HA01000A HA01001A TR010074A
TR01031Q
X12
SELF TAPPING
SCREW
X13A
BOLT
A6 - Gable Base Frame
C1525 - Top Door Support
H4A/H1270A - K Frame
HD5/HD52 - Door Jamb Supporter
Packed separately
X13B
NUT

5
PARTS - PACK A - Continued
L6/L62 - Door Jamb
K/K2 - Wall Panel
SCHDX/SCHDX2 - Door
S1- Roof Panel
RQ1
N1 01
RQ1
K/K2 - Wall Panel
S1 - Roof Panel
F/F2 - Corner Panel
Packed in bottom of box
PARTS - PACK D
Roof Ends
Gables
SKY10 - Skylight Optional

PARTS - PACK B
6
PF2 PF3
PF1/PF12
PF4
P7/P9
H7/H9
I1
SM7/SM9
RM1
B7/B9
A1
T6
P8/P1RM1I1
H8/H1SM8/SM1
B8/B1
U3
U2
PARTS - PACK C
PARTS - PACK E

100mm
S 714 21 28
M 18 15 22 29
T 29 16 23 30
W 310 17 24
T 411 18 25
F 512 19 26
S 613 20 27
CALENDAR
Allow 7 days
for concrete
to cure
X = Y
Roof
Roof Y
X
Recommended
Slab width = 3.170m
1015HDDA / 1015HDDA2
1019HDDA / 1019HDDA2
Recommended
Slab depth = 5.980m
1019HDDA
1019HDDA2
Recommended
Slab depth = 4.740m
1015HDDA
1015HDDA2
Roof Width = 3.07m
1015HDDA / 1015HDDA2
1019HDDA / 1019HDDA2
Roof depth = 5.88m
1019HDDA
1019HDDA2
Roof depth = 4.64m
1015HDDA
1015HDDA2
Note: The foundation size recommended is 100mm wider than the shed roof.
This gives an extra 50mm each side which prevents water from the roof digging a
trench and splashing soil against the side of the shed. Check the table on page 2
for exact roof dimensions.
Lay a heavy duty polythene sheet between the ground and the concrete to reduce
condensation in the shed.
FOUNDATIONS
7

8
WALL PANEL LAYOUT
Note: Codes for sheds with 2m wall height may differ from codes with shed with a
1.78m wall height. eg K = 1.78m wall sheet as shown in 1015HDDA diagram
K2 = 2m wall sheet as shown in 1019HDDA2 diagram
As shown in the diagrams below the Double Hinged Doors can be placed on any
side of the shed where there is a 3 Wall Panel K/K2 space.
eg Under the Gables as shown in 1015HDDA diagram
On long side as shown in 1019HDDA2 diagram
DOOR
PORTAL FRAME
Du cadre de portique
K K K K K K K
K K K K
F
K
K
K
FF
F
PORTAL FRAME
K
K
K
DOOR
MODELS: 1015HDDA (shown)
1015HDDA2
PORTAL FRAME
PORTAL FRAME
PORTAL FRAME
K2 K2 K2 K2 K2 K2 K2 K2 K2
F2
K2
K2
K2
F2
K2 K2 K2
F2
F2
DOOR
DOOR
K2
K2
K2
L62
L62
K2 K2 K2
L6
L6
MODELS: 1019HDDA
1019HDDA2 (shown)

9
STEP 1 PRE-AssEmBLE ALL PARTs IN sTEP 1 - 8 BEfORE EREcTING sHED.
Note: X15A1 (Long) Gable Brackets to be fixed to front and back gables.
Fix Gables 'O1' and 'N1' to the Top Rail 'I1' from the centre towards each end with screws 'X12'.
Note If Double Hinged Doors are to be placed underneath the Gable fix 'X26' bracket to centre of
Gable as shown in diagram below as this gives support to the Gable over the door opening.
There is no 'X26' brackets required on the opposite Gable. If Double Hinged Doors are to be
placed down the long side 'X26' brackets are not required.
Fix together each Gable in the centre with Bolts 'X13A' and Nuts 'X13B'.
X12
X13A
X26
X13B
O1
N1
I1
Note: Do not fix
'X12' to end holes 'I1' has no holes
facing inside of shed

X13A
X13B
Note: Top
holes for roof
fixing must be
parallel
P7
P8
}
For 10x15
3x
P9
P1
}
For 10x19
3x
Note: The Roof Beams 'P' have THREE OVAL SLOTS AT EACH END not
round holes as the Side Midwalls 'SM'.
Do not fix nuts and bolts in these slots.
Leave the three end slots of 'P's' empty on both ends for fixing on step 11.
STEP 2 - Roof Beams - P
10
From the 'E' pack join together three pairs of Long Roof Beams (P8 for 10x15) or (P1 for 10x19)
to make three Long Roof Beams 'P'. Ensure when joining the pairs together that the roof fixing
holes are parallel on top of the Roof Beams as shown in the diagram.
Always place the joined Long Roof Beams at one end of the foundation, so not get them mixed up
with the Short Roof Beams.
From the 'B' pack join together three pairs of Short Roof Beams (P7 for 10x15) or (P9 for 10x19)
to make three Short Roof Beams 'P'. Ensure when joining the pairs together that the roof fixing
holes are parallel on top of the Roof Beams as shown in the diagram.
Always place the joined Short Roof Beams at the opposite end of the foundation, so not to get
them mixed up with the Long Roof Beams.
P
P

STEP 3 - Side Midwall Brace - SM
X13A
X13B
Note: Line up
the four end
holes
SM7
SM8
}
For 10x15
2x
SM9
SM1
}
For 10x19
2x
Note: The Side Midwall Braces 'SM' have FOUR ROUND HOLES AT EACH
END not oval slots as the Roof Beams 'P'.
Do not fix nuts and bolts in these holes.
Leave the four end holes of 'SM's' empty on both ends for fixing on step 13.
From the 'E' pack join together two pairs of Long Side Midwall Braces (SM8 for 10x15) or
(SM1 for 10x19) to make two Long Side Midwall Braces 'SM'. Ensure when joining the pairs
together that the end round holes are lined up at each end of the Side Midwall Braces as shown in
the diagram.
Always place the joined Long Side Midwall Braces at the same end of the foundation as the rest of
the frame from the 'E' Pack, so not get them mixed up with the Short Side Midwall Braces.
From the 'B' Pack join together two pairs of Short Side Midwall Braces (SM9 for 10x19) or
(SM7 for 10x15) to make two Short Side Midwall Braces 'SM'. Ensure when joining the pairs
together that the end round holes are lined up at each end of the Side Midwall Braces as shown in
the diagram.
Always place the joined Short Side Midwall Braces at the same end of the foundation as the rest of
the frame from the 'BPack', so not to get them mixed up with the Long Side Midwall Braces.
11
P
P

STEP 4 - Gable End Midwall Brace - RM1
X13A
X13B
Note: Line up
the two end
holes
Note: The Gable End Midwall Brace 'RM1' have TWO ROUND HOLES AT
EACH END not four round holes as the Side Midwall Braces 'SM'.
Do not fix nuts and bolts in these holes.
Leave the two end holes of 'RM1' empty on both ends for fixing on step 13.
From the 'E' and 'B' Packs join together two pairs of Gable End Midwall Braces 'RM1's' to make
two Gable End Midwall Braces 'RM1'. Ensure when joining the pair together that the end round
holes are lined up at each end of the Back Midwall Braces as shown in the diagram.
Always place each of the joined Gable End Midwall Braces at opposite ends of the foundation
where the Gables are to be.
RM1 For
}
1x 10x15
10x19
12
P
P

STEP 5 - Base Rails
NOTE Throughout this manual all doubled up codes that refer
to 10x15 shed code first followed by the 10x19 shed code.
eg (B7/B9)
B7= Short Side Base Rail for 10x15 shed
B9 = Short Side Base Rail for 10x19 shed.
A1
A6 + A6 = A1
LONG SIDE BASE RAIL (B8/B1)
SHORT SIDE BASE RAIL (B7/B9)
X20
X20
X20
B7/B9
Gable End Base Rail
A1
X12
Overlap the Gable End Base Rail 'A1' on
top of the Short Side Base Rail 'B7/B9'.
Fix the Corner Gusset 'X20' using three
'X12' Screws.
Wall holes
Outside View
Step 2
Fasten self tapping screws 'X12'
into the top of the 'A6' anywhere
in the overlap.
1
2
Step 1
Fasten screws 'X12'
in the overlapped
wall holes first.
Step 3
Remove 'X12’s' from Step 1
when installing wall panels.
Outside View
X12
X12
A6
A6
A6
A6
Join the two 'A6' Gable Base Rails from
'Pack A' by overlapping the two end wall
holes to make one 'A1' Gable Base Rail.
X20
X20
3
13
Leave gap of approx 150mm between
Long Side and Short Side Base Rail
for the Portal Frame.

STEP 5 - Base Rails STEP 6 - Portal Frame
14
X13A
X34
PF1/PF12
PB2
X15
PF4
Note: Repeat
5
-
6
on second 'PF1/PF12'.
12
3
4
PF4
5
6
X15
X15
PF2 PF2
PF4
PF2 PF2
PF2 PF2
7
X15
PF2
PF4
PB2
PF1/PF12
TR01074A
PF1/
PF12
TR01074A
PB2
PB2
PF1/PF12
X13B
Side profile
of PF2
Note: Repeat
1
-
4
on both sides of 'PF2'.
PF1 = 1.78m Wall Height
PF12 = 2m Wall Height

15
F/F2
Corner Panel
PORTAL
FRAME
X12
H7/H9
H8/H1
Fix Corner Panel F/F2 with the long
side to be fastened to Gable End Base Rail A1.
Attach Short Top Rail H7/H9 to the Corner
Panel. This will stabilise panels when attaching
Portal Frame.
Fix the opposite corner panel F/F2 to opposite
Gable End Base Rail A1.
Attach Long Top Rail H8/H1 to the Corner Panel.
This will stabilise panels when attaching
Portal Frame.
Repeat steps 1-4 on the other side.
Place pre-assembled Portal Frame in centre
of the shed as shown in the diagram.
Corners 'F/F2' are supplied with a 45° bend. With
a supporter (any sized straight edge that is longer
than the panel NOT SUPPLIED) bend the panels
90° manually. (Do not over bend).
F/F2
Supporter
H8/H1
H = Top Rail
Curved side of Hrail is
for roof fixing, flat side
for wall fixing
X12
1
234
F/F2
STEP 7 - Corner Panels and Portal Frame
F/F2
Corner panel
A1
Gable End
Base Rail
1
2
3
4
A1
Gable End Base Rail
5
F/F2
Note: When fastening
corner panels attach
screws in order as shown.
6
1
2
3
4

A1
Gable End Base Rail
H7/H9
H8/H1
PF3
H8/H1
PF3
X12
PF1/PF12
B8/B1
B7/B9
B8/B1
STEP 8 - Wall Panels and Gables
I1
1
PF2
PF1/PF12
23
Note: The wall panel overlaps the PF1/PF12 towards the long side by half a panel as shown in
diagram 1. Please study the screw fixing procedure in step one closely. You may need to squeeze
the bottom of the PF1/PF12 to line it up with the holes in the PF3 correctly.
Fix screws through bottom of the wall panel-'K/K2', 'PF3', (PF1/PF12) and into the Base
Rails -(B7 and B8) or (B9 and B1)
Fix screws through top of the wall panel - 'K/K2, 'PF1, (PF1/PF12) and into the Top Rail -
(H7 and H8) or (H9 and H1)
Repeat 1 and 2 on both sides
Fix pre-assembled Gables to front and back of shed.
1
2
3
Long Side Base Rail
B7/B9
K/K2
K/K2
16
Short Side Base Rail

17
SM8/SM1
RM1
STEP 9 - Wall Panels and Midwalls
NOTE The Double Hinged Door can be placed on any side of the shed where there is a three wall
sheet gap between the corner panels or the portal frame.
Do not fix the Midwall to the shed where the Double Hinged Doors are to be placed until STEP 10.
To attach the Long Side Midwalls 'SM8 = 1015', 'SM1 = 1019'. Slide one end of the pre-assembled Long
Side Midwall over the Portal Midwall Bracket 'PB2' and fix a screw through the side of the Corner Panel
'F/F2' fixing the screw into the top half wall holes of the joined 'SM8/SM1'.
The 'RM1' Midwall that is positioned under the Gables is to be fitted to the shed after the first Long Side
Midwall is fitted as it slotted between the two halves of the Side Midwalls. Then the opposite Long Side
Midwall can be slotted over the fixed 'RM1' and the Portal Midwall Bracket 'PB2' and fixed to the shed
as done with the first Side Midwall.
Repeat the same procedure with the Short Side Midwalls 'SM7 = 1015', 'SM9 = 1019' and the second
'RM1' at the other end of the shed.
1
11
2
7
9
10
8
3
5
6
4
12
WALL PANEL
FIXING SEQUENCE
X12
No washers 'X11'
needed on wall
panels.
Note: Do not
connect with
nuts and bolts.
This allows
movement in the
shed when fixing
roof sheets. RM1
SM7 FOR 10x15
SM9 FOR 10x19
PB2
PF1/PF12
SM8 FOR 10x15
SM1 FOR 10x19
Fix the Wall Panels 'K/K2' using screws in
the fixing sequence shown in the diagram.
When fixing the Wall Panels to the shed, start
from the back of the side and continue sheeting
laying them on top of each other towards the front.
When you reach the previously fixed Wall Sheet at the
portal frame and the Front Corner Panel underlap the Wall
Panel to conceal all the seams and to give the appearence
of the wall being one continuious form.

STEP 10 - Double Door Frame Construction
L6/L62
Door Jambs
K/K2
Wall Panel
L6/L62
Door Jambs
Attach cut midwalls SM
to either side of the door
opening with screws 'X12'
through the wall sheet
then attach each end into
either the RM1 or the PB2
with nuts and bolts. Only
connect the two cut SM
pieces. As this will not
restrict movement in the
shed when fixing the roof
sheets. Do not connect any
other SM's to RM1's or
PB2's until Step 13.
CUT LONG
SIDE MIDWALL
'SM8/SM1'
CUT LONG
SIDE MIDWALL
'SM8/SM1'
K/K2
L6/L62
K/K2
L6/L62
F/F2
RM1
'PF1/PF12'
Shown with no wall panel 'K/K2'
for viewing purposes only.
PB2
Connect the cut 'SM' with
the 'PB2' with nuts & bolts
PB2
Connect the
cut 'SM1' with
the 'RM1' with
nuts & bolts
18
L6/L62
K/K2
Cut Midwall
Place pre-assembled
Midwall into position
and mark where
to cut using the
diagram above.
Cut with Hacksaw
or Tin snips
FIX WITH THE SELF
TAPPING SCREWS 'X12' OR
PRE-DRILL HOLES USING A
2.8mm DRILL BIT
Note. The diagrams below show construction of the door fame on the long side of the shed.
Adjust codes if the door opening is to be placed elsewhere on the shed
F/F2
Corner Panel
TOP VIEW
Place rib of door jamb 'L6/L62' under
rib of wall panel 'K2/F2' screw to Top
Rail 'H8/H1' and Base Rail 'B8/B1'.

STEP 11 - Roof Beams
PF2
PF2
PF4
PF4
GABLE END
Use nuts and bolts for step 11.
Slide the pre-assembled Centre Roof Beams 'P' down over each side of the 'X34' on the Portal
Frame and down over each side of the join in the gable.
Fix the pre-assembled Centre Roof Beams 'P's into position using nuts and bolts in the end slots
as in diagram
1
,
2
and
3
.
Fix back centre 'P'. Following the instructions above as in diagram 3.
Fix pre-assembled Side 'P's down over each side of the 'X15A1's on the gables and the X15's
on the portal frame.
Pre-assembled
Centre Roof
Beams 'P'
X34
3
2
1
END VIEW
GABLE END
19
Pre-assembled
Centre Roof
Beams 'P'
Pre-assembled
P8/P1
Pre-assembled
P7/P9
