OLI Side Vision User manual

OLI eBIKE SYSTEMS
-
SIDE VISION DISPLAY –user manual
SUMMARY
1. SPECIFICATION
2. DIMENSIONS
3. WARRANTY
4. OPERATIVE BUTTONS
5. SWITCH ON AND OFF THE SYSTEM
6. CHANGE ASSISTANCE LEVEL
7. READ RIDE INFORMATIONS
8. ACCESS AND OPERATE THE MENU
9. WALK MODE
10. OPERATE LIGHTS
11. ERRORS

1) Specifications
•36V Power Supply
•Rated working current :22m
•Operating temperature: -20℃~ 60℃
•Storage temperature: -30℃~ 70℃
•Water resistance: IP66
2) Dimensions
Expressed in mm
3) Warranty
•Warranty will be valid only for products used in normal usage conditions.
•Warranty is valid for 24 months after the shipment or delivery to customers
The following cases do not belong to our warranty scope.
1. The display is demolished
2. The damage of the display is caused by wrong installation or operation
3. If the display has been opened or attempted to open
4. Wire of the display is broken
5. The fault or damage of the display is caused by the force majeure (incident, fire,
immersion in liquid, etc.)
6. Beyond Warranty period.
Warnings
•Use the display with caution. Don’t attempt to release or link the connector when battery is
on power
•Try to avoid hitting the display
•Don’t modify system parameters to avoid parameter disorder
•Contact your local Service Center when error code appears

4) Operative buttons
①+
- SHORT PRESS: increases assistance level
- LONG PRESS: turns lights on/off
②–
- SHORT PRESS: decreases assistance level
- HOLD PRESS: activates walk mode. Pushes the bike at 5km/h
③i
- SHORT PRESS: cycles through ride’s information
- LONG PRESS: enters menu
④
- SHORT PRESS: switch on the system.
- LONG PRESS: switch off the system
⑤CONNECTOR’S PLUG
⑥DISPLAY
⑦2.5mm CLAMP SCREW

5) Switch on and off the system
System is switched ON by pressing button ④for 2 seconds.
Loading page shows the OLI eBike Systems logo.
The system turns on by default on assistance level 3, but it might be there variation
according to bike manufacture’s specifications.
System is switched OFF by pressing ④button for 4 seconds
6) Change assistance level
Each short press of button + ①increases assistance level by 1 step
Each short press of button –②decreases assistance level by 1 step
Every level has different setups defined by the bicycle manufacturer.
This may include variation on:
- Maximum motor’s torque
- Percentage of increased power
- Reactiveness of the power supply
Please refer to your bicycle manufacturer for further details
+
2s
+
+
–
–
–
–
4s
+
+
–

7) Read ride information
By short clicking button i③, ride’s information cycle in the top-right corner of the display.
Shown information are:
- Trip since last erase
- Ride time since last erase
- Odometer
8) Access and operate menu
To access the system’s menu, hold press button i③
Inside the MENU, the sub-menu can be selected by using the +① and –② buttons
TRIP information can be reset by pressing i ③button
System INFO contains important information about:
- HMI and motor’s firmware version
- Battery’s voltage
- Average consumption in Wh/km
Select BACK and press i③button to exit the MENU
i
i
i
i
i
2s

9) Walk mode
To help pushing the bike uphill while walking, the system features a WALK MODE that
pushes the bike up to 5km/h without the need of pedalling.
To operate the WALK MODE, hold press button –②
The system remains in WALK MODE until button –②is released
Walk mode function may only be used when pushing the E-bike. Be aware of danger of
injury when bike wheels do not have ground contact while using the Walk mode function.
Do not use Walk mode when you are riding the bike.
10) Operate lights
Lights are switched on and off by hold pressing the + ①button.
When lights are on, the icon on the display turn into yellow.
11) Errors
In case of a System’s error or failure, the following page is shown
*example
Please refer to the error list to find the solution.
If the error persists after restarting the system, please contact your local Service
Center for support.
