Olympus CAMEDIA D-535 ZOOM User manual

Thank you for purchasing an Olympus digital camera. Before you
start to use your new camera, please read these instructions care-
fully to enjoy optimum performance and a longer service life. Keep
this manual in a safe place for future reference.
We recommend that you take test shots to get accustomed to your
camera before taking important photographs.
Screen and camera illustrations shown in this manual may differ
from those of the actual product.
DIGITAL CAMERA
D-535 ZOOM
C-370 ZOOM
X-450
REFERENCE MANUAL

2
For customers in North and South America
For customers in Europe
Trademarks
• IBM is a registered trademark of International Business Machines Corporation.
• Microsoft and Windows are registered trademarks of Microsoft Corporation.
• Macintosh is a trademark of Apple Computer Inc.
• All other company and product names are registered trademarks and/or
trademarks of their respective owners.
• The standards for camera file systems referred to in this manual are the “Design
Rule for Camera File System/DCF” standards stipulated by the Japan Electronics
and Information Technology Industries Association (JEITA).
“CE” mark indicates that this product complies with the European
requirements for safety, health, environment and customer protection.
“CE” mark cameras are intended for sales in Europe.
For customers in USA
Declaration of Conformity
Model Number : D-535 ZOOM/C-370 ZOOM/X-450
Trade Name : OLYMPUS
Responsible Party :
Address : Two Corporate Center Drive, PO Box 9058, Melville,
New York 11747-9058 U.S.A.
Telephone Number :1-631-844-5000
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
For customers in Canada
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.

3
Composition of the manual
1
2
3
4
5
6
7
8
10
11
For playing back and erasing
pictures.
Getting started
About the menus
Shooting
Playback
Useful functions
Print setting (DPOF)
Miscellaneous
Troubleshooting and other
information.
Contents P.4
P.8
P.31
P.36
P.62
P.76
P.84
P.91
P.124
Direct printing (PictBridge)
Specifications
Glossary of terms
P.137
P.139
Settings that make the
camera easier to operate.
Printing pictures.
Downloading images to a PC
for displaying.
Index P.141
Introduction of the camera’s
functions.
Connecting to a computer
9
P.103
Basic and advanced photography
for various subjects.

4
Contents
Composition of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1 Getting started 8
Names of parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Monitor indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Attaching the strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Loading the batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Selecting optional batteries or an AC adapter. . . . . . . . . . 17
About the internal memory and the card . . . . . . . . . . . . . . . . . 19
Internal memory basics . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Relationship between the internal memory and the card
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Inserting a card (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Card basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Power on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Switching between the shooting mode and the playback mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Selecting a language . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting the date and time . . . . . . . . . . . . . . . . . . . . . . . . 28
2 About the menus 31
How to use the menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Shooting mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Playback mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

5
Contents
3 Shooting 36
Shooting mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Taking still pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
If correct focus cannot be obtained . . . . . . . . . . . . . . . . . . . . . 42
Determine the position of the subject after focusing
(Focus Lock)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Subjects that are difficult to focus on . . . . . . . . . . . . . . . . 44
Recording movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using the flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Macro mode shooting . . . . . . . . . . . . . . . . . . . . . . . . . 53
Self-timer shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Selecting a record mode . . . . . . . . . . . . . . . . . . . . . . . . . 57
Varying the image brightness (Exposure compensation)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4 Playback 62
Viewing still pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Close-up playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Picture rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Index display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Selecting the number of pictures . . . . . . . . . . . . . . . . 67
Slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Playback on TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Viewing movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Protecting pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Erasing pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Single-frame erase . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
All-frame erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

6
Contents
5 Useful functions 76
RESET - Resetting the settings to the default . . . . . . . . . . . . . 76
Formatting the internal memory/card. . . . . . . . . . . . . . . . . . . . 78
BACKUP - Copying pictures to a card. . . . . . . . . . . . . . . . . . . 80
SLEEP - Setting the time period to switch to the sleep mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
PIXEL MAPPING - Checking the image processing functions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
VIDEO OUT - Setting the output signal type . . . . . . . . . . . . . . 83
6 Print setting (DPOF) 84
With print reservation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
All-frame reservation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Single-frame reservation . . . . . . . . . . . . . . . . . . . . . . . . . 88
Resetting print reservation data . . . . . . . . . . . . . . . . . . . . 90
7 Direct printing (PictBridge) 91
Using the direct printing function . . . . . . . . . . . . . . . . . . . . . . . 91
Connecting the camera to a printer . . . . . . . . . . . . . . . . . . . . . 92
Printing pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Using the simple print method. . . . . . . . . . . . . . . . . . . . . . 94
PRINT mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
PRINT ORDER mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Exiting direct printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
If an error code is displayed . . . . . . . . . . . . . . . . . . . . . . . . . 102

7
Contents
8 Connecting to a computer 103
Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Using OLYMPUS Master. . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
What is OLYMPUS Master? . . . . . . . . . . . . . . . . . . . . . . 105
Installing OLYMPUS Master . . . . . . . . . . . . . . . . . . . . . . 106
Connecting the camera to a computer . . . . . . . . . . . . . . . . . 112
Starting up OLYMPUS Master. . . . . . . . . . . . . . . . . . . . . . . . 114
Displaying camera images on a computer . . . . . . . . . . . . . . 116
Downloading and saving images . . . . . . . . . . . . . . . . . . 116
Viewing still pictures and movies. . . . . . . . . . . . . . . . . . . . . . 119
Printing pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Saving images to a computer without using
OLYMPUS Master . . . . . . . . . . . . . . . . . . . . . . . . . . 123
9 Miscellaneous 124
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
List of menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
List of factory default settings . . . . . . . . . . . . . . . . . . . . . . . . 134
List of items by shooting mode . . . . . . . . . . . . . . . . . . . . . . . 135
Camera maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Glossary of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

8
1
Getting started
1 Getting started
Names of parts
Camera
Flash P.49
Self-timer lamp
P.56
Connector cover
P.17, 69, 92, 112
VIDEO OUT jack
P.69
USB connector
P.92, 112
Lens
Extends automatically when the
power switch is pressed.
Battery compartment/
card cover
P.15, 21
DC-IN jack P.17
Lock button P.15, 21
Shutter button
P.39
Power switch
P.24, 39, 62
Tripod socket

9
Names of parts
1
Getting started
Self-timer button ( )
P.55
Monitor P.10
Macro mode button ( )
P.53
Mode dial
P.36
Flash mode button ( )
P.49
Arrow pad
()
P.31, 62
Arrow pad
OK button ( )
P.31
Buttons on the arrow pad have their respective functions. They are also
used as direction buttons. , , and indicate which button to
be pressed.
Erase button
()
P.74
Zoom button
(W/T• )
P.47, 64, 66
Strap eyelet
P.14
Exposure compensation
button ( )
P.60
Reset button
()
P.76
Shooting button ( ) P.25, 62
Orange lamp P.24
Green lamp P.25
Menu button ( )
P.31
Playback button ( ) P.25, 62

10
1
Names of parts
Getting started
Monitor indications
Shooting mode
* The [IN] indicator is displayed when you are storing pictures in the
camera’s internal memory. The [xD] indicator is displayed when the card is
inserted.
Items Indications Ref. Page
1 Battery check , P.12
2 Green lamp P.39
3 Flash standby
Camera movement warning/ Flash charge
(Lit)
(Blinks)
P.50
4 Shooting mode , , , , , P.36
5 Macro mode , P.53
6 Flash mode , , P.49
7 Self-timer P.55
8 Exposure compensation -2.0 – +2.0 P.60
9 Record mode SHQ, HQ, SQ1, SQ2 P.57
10 Resolution 2048×1536, 1600×1200, 640×480,
etc.
P.57
11 AF target mark [ ] P.39
12 Current memory * [IN], [xD] P.19
13 Number of storable still pictures
Remaining recording time
5
00:36
P.39
P.45
2
1
12
5
11
12
11
13
5
7
9
1
Still picture Movie
4
3
4
6
10
9
8
6
8
13
10
7

11
Names of parts
1
Getting started
Playback mode
* The [IN] indicator is displayed when you are storing pictures in the
camera’s internal memory. The [xD] indicator is displayed when the card is
inserted.
• After the camera is left idle for 3 seconds, indications such as the
number of frames, date and time disappear automatically.
• The indications that appear on a movie picture that has been selected
and displayed from the index display are different from those that appear
when the movie picture is displayed using the movie playback function.
Items Indications Ref. Page
1 Battery check , P.12
2 Current memory * [IN], [xD] P.19
3 Print reservation,
Number of prints
x 10 P.84
4 File number 100-0018 P.84
5Protect P.73
6 Record mode SHQ, HQ, SQ1, SQ2 P.57
7 Resolution 2048×1536, 1600×1200, 640×480,
etc.
P.57
8 Exposure compensation -2.0 – +2.0 P.60
9 Date and time ’04.10.10 12:30 P.28
10 Number of frames
Elapsed time/Total recording time (movie)
18
00:00/00:15
–
P.71
11 Movie P.71
2
1
46
2
6
8
9
7
5
5
10
7
8
Still picture Movie
3
10
11
1
9
4
Note

12
1
Names of parts
Getting started
Battery check
If the remaining battery power is low, the battery check indication on the
monitor changes as follows while the camera is turned on.
Lit (Green)
(The indicator turns
off after a while)
Remaining power
level: high.
The green lamp and the orange
lamp on the camera blink.
Remaining power level: exhausted.
Replace with new batteries.
Blinks (Red)
Remaining power level: low.
Prepare new batteries.

13
1
Getting started
How to use this manual
This sample page is only for your reference. It may differ from the actual page
in this manual.
Indications used in this manual
Important information on factors which may lead to malfunctions or
operational problems. Also warns of operations that should be
absolutely avoided.
Useful information and hints that will help you get the most out of
your camera.
Reference pages describing details or associated information.
Provides the operation procedures. Follow the steps in the order
as indicated.
The buttons for functions
and their location are
clearly illustrated.
and indicate which
button to press on the arrow pad.
(The up or down buttons are used
in this example.)
Note

14
1
Getting started
Attaching the strap
1Thread the short end of the
strap through the strap
eyelet.
2Thread the long end of the
strap through the loop that
has already gone through
the eyelet.
3Pull the strap tight, making
sure that it is securely
fastened and does not come
loose.
• Be careful with the strap when you carry the camera, as it can easily
catch on stray objects, causing serious damage.
• Attach the strap correctly following the procedure so that the camera
does not fall off. If the strap is attached incorrectly and the camera falls
off, Olympus is not responsible for any damages.
Strap eyelet
Note

15
1
Getting started
Loading the batteries
This camera uses 2 AA (R6) NiMH batteries or alkaline batteries.
When you use rechargeable batteries, charge the batteries before use.
1Make sure the camera is turned
off.
• The monitor is off.
• The green lamp and the orange lamp
on the camera are off.
• The lens is not extended.
2Holding the lock button, slide
the battery compartment/card
cover in the direction of , and
then lift it in the direction of .
• Use the ball of your finger to slide the
cover. Do not use your fingernail as
this could result in injury.
• With the bottom of the camera facing
up, open the battery compartment/card
cover as shown in the illustration.
Important
Manganese (zinc-carbon) batteries and lithium battery packs (CR-V3)
cannot be used.
Orange lamp
Green lamp
Monitor
Lock button
Battery compartment/card
cover

16
1
Loading the batteries
Getting started
3Insert the batteries, making
sure that they are correctly
oriented as shown in the
illustration.
• The battery insertion direction is
indicated in the battery compartment
and on the bottom of the camera.
4Holding the batteries down
with the battery compartment/
card cover, close the cover in
the direction of and slide it in
the direction of .
• If the battery compartment/card cover is
hard to close, do not force it. With the
battery compartment/card cover shut,
press the mark firmly and push it in
the direction of .
• If the camera is left for about 1 day with the batteries removed, the date
and time setting will revert to the factory default setting.
Note
The amount of power consumed varies considerably depending on the
operations performed on the digital camera. If you use exhausted
batteries or alkaline batteries, the camera may turn off without displaying
the battery level warning (P.12).
Precautions when using batteries

17
Loading the batteries
1
Getting started
Selecting optional batteries or an AC adapter
In addition to the batteries provided with the camera, the following types of
battery or AC adapter can be used. Choose the power source best suited to
the situation.
NiMH batteries (Rechargeable batteries)
Olympus NiMH batteries are rechargeable and economical. However,
charging the batteries repeatedly before using up their capacity will shorten
the life of the batteries per charge gradually.
AA (R6) alkaline batteries
When you need batteries in a hurry, you can use AA (R6) alkaline batteries,
which are easy to obtain anywhere. However, the number of pictures that you
can take may vary considerably depending on the battery manufacturer,
shooting conditions, etc.
AC adapter
An optional Olympus CAMEDIA-brand AC adapter allows you to power your
digital camera from a common AC wall outlet. Be sure to use the specified AC
adapter. An AC adapter is useful for time-consuming tasks such as
downloading or printing out of images.
Use an AC adapter designed to operate on the AC voltage in the area the
camera is being used.
Consult your nearest Olympus dealer or Service center for details.
DC-IN jack (black)
AC wall outlet
Power plug
Connector cover
Connection cord plug
AC adaptor

18
1
Loading the batteries
Getting started
• Manganese (zinc-carbon) batteries and lithium battery packs (CR-V3)
cannot be used.
• If the battery power runs out while the camera is connected to a PC or
printer, the image data may be lost or damaged. You are recommended
to use the AC adapter when transferring images to a PC. Do not connect
or disconnect the AC adapter while the camera is communicating with
the PC or printer.
• Do not remove or load the batteries or connect or disconnect the AC
adapter while the camera is turned on. Doing so could affect the
camera’s internal settings or functions.
• The life of batteries may vary according to the type of battery,
manufacturer, shooting conditions, etc.
• Power is consumed continuously during the conditions below. This
could shorten the life of the batteries.
• When the monitor is in the playback mode for an extended period
of time.
• Repeated zoom adjustments.
• Repeated auto-focus by depressing the shutter button halfway.
• When the camera is connected to a PC or printer.
• Carefully read the AC adapter’s instructions before use.
• When using an AC adapter, the AC adapter supplies power to the
camera even if batteries are loaded in the camera. The AC adapter does
not charge batteries in the camera.
Note

19
1
Getting started
About the internal memory and the card
Images taken are stored in the internal memory.
You can also use an optional xD-Picture Card (referred to as “card” in this
manual) to store images. The card has greater capacity than the internal
memory, and so, is able to store more images. The card is convenient, for
example, when you are traveling and you want to take a lot of pictures.
Internal memory basics
The internal memory corresponds to a film of normal camera for recording
pictures you have taken.
Pictures recorded and stored in the internal memory can easily be erased,
overwritten, and/or edited on a PC. The internal memory cannot be replaced
or removed from the camera.
Relationship between the internal memory and the card
The monitor displays which type of the memory (internal or card) is being
used for shooting and displaying images.
• The internal memory and the card cannot be used at the same time.
• When the card is inserted, the internal memory is disabled.
• When you want to use the internal memory, remove the card.
• You can copy all the image data stored in the internal memory to a card.
"BACKUP - Copying pictures to a card" (P.80)
Monitor
indications Shooting mode Playback mode
[IN]
Stores to the internal memory. Plays the images stored in the internal
memory.
[xD] Stores to the card. Plays the images stored on the card.
Shooting mode Playback mode
Current memory

20
1
Getting started
Inserting a card (Optional)
An optional card (xD-Picture Card) is available for this camera.
Card basics
The card corresponds to a film of normal camera for recording the pictures
you have taken.
Pictures recorded and stored on the card can easily be erased, overwritten,
and/or edited on a PC.
Using a card with larger capacity increases the number of images you can
record.
1 Index area
You can write down the card’s contents.
2 Contact area
Comes into contact with the camera’s signal read
contacts.
Compatible cards
• xD-Picture Card (16 to 512 MB)
• This camera may not recognize a non-Olympus card or a card that was
formatted on another device (such as a PC, etc.). Before use, be sure to
format the card on this camera. "Formatting the internal memory/
card" (P.78)
1Make sure the camera is turned
off.
• The monitor is off.
• The green lamp and the orange lamp
on the camera are off.
• The lens is not extended.
1
2
Note
Orange lamp
Green lamp
Monitor
