Omcan SE-KR-0450 User manual

Revised - 12/06/2018
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com
Wrapping Machine
Model SE-KR-0450
Item 43486
Instruction Manual

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
-------------------------------------------------------------------------- 6
------------------------------------------------------------------------ 6
------------------------------------------------------------------------------------- 7
------------------------------------------------------------------------------- 7 - 8
------------------------------------------------------------------------------ 9
------------------------------------------------------------------------------------------------ 10
---------------------------------------------------------------------------- 11
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation and Operation
Troubleshooting
Parts Breakdown
Electrical Schematics
Notes
Warranty Registration
Model SE-KR-0450

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
General Information
Safety and Warranty
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.
1. Read all the instructions.
2. Do not touch hot surfaces.
3. Keep the cord and the plug away from water or liquid to prevent an electric shock.
4. Plug in the properly grounded outlet.
5. Unplug the machine when it’s not in use for a long period of time or before cleaning.
6. Cool it down before cleaning.
7. Do not operate the machine if the cord or the plug is damaged.

5
Safety and Warranty
8. If the machine is malfunctioning or is damaged, call the nearest authorized service provider for reparation.
9. Do not use any unauthorized attachments or accessories. Doing so may cause injuries.
10. Indoor use only.
11. Do not let the cord hang over the edge of table or counter.
12. Do not let the cord touch the hot surfaces.
13. Move the machine unplugged and with extreme caution.
14. Attach the plug to the machine before plug it in.
15. Turn o󰀨 all power switch before unplugging the machine.
16. Do not use the machine for any purpose other than wrapping.
GROUNDING
The machine must be grounded all the time. When it is malfunctioning or is damaged, the grounding provides a
path of least resistance for electric current to reduce the risk of an electric shock. The machine is equipped with
a cord having a product-grounding conductor and a grounding plug. The plug must be plugged in the properly
installed and grounded outlet in accordance with all local codes and ordinance.
DANGER
Improper connection of the product-grounding conductor may cause an electric shock. Let a qualied
electrician or a serviceman check if the machine is properly grounded. Do not modify the provided plug under
any circumstances. If the plug does not t the existing outlet, have a qualied electrician to install a proper
outlet.
1 YEAR PART AND LABOUR BENCH WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop o󰀨 to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
Please see https://omcan.com/disclaimer for complete info.
WARNING:
The packaging components (cardboard, polyethylene, and others) are classied as normal solid urban waste
and can therefore be disposed of without di󰀩culty.
In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Installation and Operation
INSTALLATION
1. Place the machine with clearance of 10 CM from the wall.
2. The machine must be grounded to prevent an electric shock.
3. Keep the machine in dry area. Condensation may cause short circuit.
HOW TO USE
1. How to feed lm.
- Place the lm on the roller and pull the vinyl down under the feeding rollers toward cutter blade.
2. Elasticity of lm.
- Turn the tension bolt located on the back of the right side to adjust speed of lm feeding.
3. Power.
- Check the electric specication before plugging in.
4. Switch.
- Turn on the Heating Cutter switch and Plate switch.
- Heating Cutter and Plate are operated independently.
5. Temperature of heating plate.
- Turn the Temp. Control knob to adjust the plate temperature according to the thickness of lm.
6. Operation.
- After putting a product on the work table, pull the lm and wrap the product entirely.
- Pull the wrapped product properly and cut the lm by contacting the cutter.
- After trimming the wrapped lm, press the product lightly on the heating plate.
7. Maintenance.
- Clean the machine with a soft cloth to avoid scratching the stainless steel body and the Teon coated
heating plate.
- If the heating plate doesn’t heat up, change the fuse (2A fuse).
Technical Specications
Model SE-KR-0450
Material Stainless Steel
Power Consumption 155W
Heat Cutter Size 17.7” / 450mm
Machine Size 20.3” x 24.4” x 6.3” / 515 x 620 x 160mm
Weight 14.3 lbs. / 6.5 kgs.
Item Number 43486

7
Troubleshooting
Problem Possible Cause Action
The indicator lamp does not light
or cutter and heating plate do not
get hot.
The electric wire is damaged. Replace the electric wire.
Burnt fuse. Replace the fuse.
REFERENCE
Item Number Model Number Description Manufacturer Model
Number
43486 SE-KR-0450 Wrapping Machine Single Roll 110V/60/1
CE QPSus SW-450X
Parts Breakdown
Model SE-KR-0450 43486
Item No. Description Position Item No. Description Position Item No. Description Position
62756 Heat Cutting Lamp for SW450X 1 62761 Safety Catch for SW450X 6 62766 Work Table for SW450X 11
62757 Cutter Lamp for SW450X 2 62762 Cutter Safety Cover for SW450X 7 62767 Feed Roller for SW450X 12
62758 Heat Board On/Off Switch for SW450X 3 62763 AC Input for SW450X 8 62768 Heat Cutter for SW450X 13
62759 Temperature Control for SW450X 4 62764 Unwinding Speed for SW450X 9 62769 Heat Board for SW450X 14
62760 Heat Board Lamp for SW450X 5 62765 Film Roller for SW450X 10 62770 Fuse for SW450X 15

8
Parts Breakdown
Model SE-KR-0450 43486

9
Electrical Schematics
Model SE-KR-0450 43486

10
Notes
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________

11
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
https://omcan.com/warranty-registration/
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour di󰀨usion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North
American food service industry. Our success over these many years can be attributed to our commitment
to strengthen and develop new and existing relationships with our valued customers and manufacturers.
Today with partners in North America, Europe, Asia and South America, we continually work to improve
and grow the company. We strive to offer customers exceptional value through our qualied local sales
and service representatives who provide convenient access to over 5,000 globally sourced products.
Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et
matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces
nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles
et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en
Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et
développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à
nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000
produits provenant du monde entier.
Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros
de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir
a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos
clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan
continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor
excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un
fácil acceso a más de 5,000 productos con origen a nivel mundial.
