Omega DP18-P9 User manual



An OMEGA Te chn olo gie s Co m p an y







M2113/1294
INSTRUCTION
SHEET
DP18 Series
Model DP18-P9
Differential Process Indicator
CCD1294APC1B
1
10
D
C
B
A
+
-
REARVIEW
Setpoint R1
(option)
Setpoint R2
(option)
FRONTVIEW
FIG. 2
FIG. 1
SIGNAL
INPUT
SPAN:ADJUSTTHEMAXIMUMREADING.
OFFSET:NOTINSERVICE
SPAN ADJUSTMENT IS ACCESSIBLE BEHIND THE LOW DOOR.
Isolated digital output
(option)
HOLD,latchthereading
display, while these pins
are linked
ANALOG OUTPUT
(OPTION)
POWERSUPPLY
see instrument label
DISPLAYS. . . . . . . . . . . . . . . . . . . . . . 3 digits, 7 segment, red LED
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . 0.56" (14.2 mm.)
SYMBOLS. . . . . . . . . . . . . . . . . . . . . . ± 1.8.8.8
DECIMALPOINTS . . . . . . . . . . . . . . . . Selectable by jumpers
OVERRANGEINDICATION . . . . . . . . . Display flashes 1999
INPUTCONFIGURATION . . . . . . . . . . . Bipolar single
ZERO . . . . . . . . . . . . . . . . . . . . . . . . . Automatic
SPANADJUSTMENT . . . . . . . . . . . . . . ± 5 %
CONVERTER . . . . . . . . . . . . . . . . . . . . Dual-slope, average value
POLARITY. . . . . . . . . . . . . . . . . . . . . . Automatic ±
SIGNALINTEGRATIONPERIOD . . . . . 80 ms.
READRATE . . . . . . . . . . . . . . . . . . . . 3.12 / sec.
HOLD . . . . . . . . . . . . . . . . . . . . . . . . . Optional
NOISEREJECTIONNMR . . . . . . . . . . . 50 dB. 50/60 Hz.
ACCURACY . . . . . . . . . . . . . . . . . . . . 0.15 % ± 1 count
WARMUPTORATEDACCURACY . . . 2 minutes
SPANTEMPCO . . . . . . . . . . . . . . . . . . 100 ppm.
ZEROTEMPCO . . . . . . . . . . . . . . . . . . 2.5 µV/°C.
OPERATINGTEMPERATURE . . . . . . . 0 to 50 °C (32 to 122 °F)
STORAGETEMPERATURE . . . . . . . . . -40 to 80 °C (-40 to 176 °F)
WEIGHT . . . . . . . . . . . . . . . . . . . . . . . . 310 gr. (0.68 lb)
CASEMATERIAL . . . . . . . . . . . . . . . . ABS, DIN 43700, black color
STANDARDPOWER . . . . . . . . . . . . . . 115 Vac. ± 10 %, 50/60 Hz.
POWERCONSUMPTION . . . . . . . . . . . 5.5 VA for AC.
ELECTRICALCONNECTIONS . . . . . . . Push-in cable connectors
BURN-IN . . . . . . . . . . . . . . . . . . . . . . . 24 h.
½
SPECIFICATIONS
SPAN OFFSET
FIG. 3
A
B
C
SPANADJUST
ZEROADJUST
B
A
SIGNALCONDITIONER COMPONENTSVIEW
THIS SIGNAL CONDITIONER INPUT ALLOWS THE DISPLAY IN ENGINEERING UNITS OR PERCENTAGES, THE DIFFERENCE BETWEEN TWO
PROCESS SIGNALS OF 0-20 mA OR 4-20 mA.
SIGNALINPUT "A" MUST CORRESPOND,THEORETICALLY TO THEHIGHER SIGNAL,IN ORDERTHAT THEDISPLAYREADING BEPOSITIVE.
IF THE SIGNAL "B" IS HIGHER THAN "A", THE DISPLAY READING WILL BE NEGATIVE.
CLOSE THE APPROPRIATE DECIMAL POINT JUMPER (FIG.5), CORRESPONDING TO THE RANGE SELECTED.
INSTRUMENTTOREADTHEDIFFERENCEBETWEENTWOPROCESSSIGNALSANDDISPLAYIN
ENGINEERINGUNITS.
SIGNALS CAN BE : 0-20 mA. or 4-20 mA.
Signallow
Signallow
Signalhigh
Signalhigh
out
out
TRANSDUCER"A"
TRANSDUCER"B"



























DP18 Series
96
(3.78)
44.5
(1.75)
48
(1.89)
MECHANICALDIMENSIONSmm(in)
D3 = 1.XXX
D2 = 1X.XX
D1 = 1XX.X
DECIMALPOINTSSELECTOR
D3 D1D2
INSTALL THE JUMPER IN
THE INDICATED PLACE,
ACCORDING TO THE
RANGESELECTED.
SIGNAL
CONDITIONER
(solderside)
MOTHERBOARD
COMPONENTS
SIDE
POWER SUPPLY
CONNECTOR
FIG.6
FIG.4
FIG.5
SELECTIONOF:DECIMALPOINTSANDSPECIALOPTIONS
OPTIONSAND POWERSUPPLIESAVAILABLE FORDP18Series
BCD PARALLELBCD,OPTOISOLATED A01 ANALOGOUTPUT,mA SINK
R1 SINGLESETPOINT,3Amp.Relay A02 ANALOG OUTPUT,mASOURCE
R2 DUALSETPOINT,3Amp:Relays A03 ANALOGOUTPUT,VOLTAGE
APH1 ANALOGPEAKHOLD APH2 ANALOGPEAKHOLD
232 ISOLATEDSERIALOUTPUTRS-232
OPTION DESCRIPTION OPTION DESCRIPTION OPTION POWER OPTION POWER
CONTROLOUTPUT/COMMUNICATIONSOPTIONS
Select a maximum of one option from each column POWERSUPPLYOPTIONS
115
115
230
AL
J1
J2
JUMPERS SELECTION FOR SPECIAL OPTIONS
AL:OPEN ONLYWHENALARMSETPOINT CARDOPTIONIS ADDED
J1: OPENTOELIMINATETHELEAST-SIGNIFICANTDIGIT(LSD)
J2: OPENTOELIMINATETHE INDICATION ±
PANELCUTOUT
CONNECTOR FOR ANALOG OUTPUT
(OPTIONAL)
13
(0.51)
102
(4.02) 15
(0.59)
5 max. (0.20)
92.5
(3.64)
230 230Vac 50/60Hz
STD 115 Vac 50/60 Hz 15/30Vdc 15...30Vdc.-10%(3.5W)
24 24Vac 50/60Hz 24/65Vdc 24...65 Vdc(4 W) isolated
48 48Vac 50/60Hz
isolated
MOTHERBOARD
SOLDERSIDE

