Omega TENS User manual

Omega Wireless
(with Remote)
User Manual

1
Introduction
You've made a great choice with your purchase of the
wireless OMEGA device. The OMEGA is a remote-
controlled and totally wire-free pain relief unit that utilizes
cutting-edge TENS technology to target pain in various
areas of the body. The OMEGA is wireless, user-friendly,
safe to use, and best of all, is completely drug-free! This
allows users to manage pain and lead a more active
lifestyle without the use of medication.
Massage Area
Users can customize the massage area for a personally-
tailored experience. Treatment areas include:
Back, Hip, Back & Hip, Shoulder, Knee & Shoulder,
Shoulder, Knee

3
Notice
•This device is not safe to use for people who have a
cardiac pacemaker, implanted defibrillator, or any implanted
metallic or electronic device. Use with these conditions can
result electric shock, burns, electrical interference and
death.
Warning
•TENS & EMS treatments may cause rhythmic
disturbances to the heart. Do not place electrode pads on or
near the chest. If you are prone to rhythmic disturbances of
the heart or have a heart condition, only utilize this device
under the observation of a medical professional.
•Certain skin may be irritated by use of this device. Do not
use if you have: areas where skin is not intact, any atypical
skin condition, open sores or wounds, rashes, swollen,
discolored, or inflamed skin, skin eruptions (i.e. phlebitis,
thrombophlebitis, or varicose veins), or cancerous lesions.
•Use of electrical stimulation during activities can increase
risk of injury. Do not use this device in water (i.e. the bath or
shower), while sleeping, driving, or operating heavy
machinery or other activity that could place you at risk of
injury while using this device.
•Use of this device in proximity to electronic monitoring
equipment (i.e. cardiac monitors, ECG alarms) may result in
equipment 2
malfunction. Do not use this device near to any kind
of electronic monitoring equipment.
•This device is not intended for use on or by children. Do
not allow children to handle this device. Do not use this
device if you are are or suspect that you might be pregnant.
Any use of this device during pregnancy must be at the
discretion of and under the supervision of a doctor.
Possible Reactions
1) Electrical stimulation or the use of electrode pads can
cause isolated instances of burns and other irritations to the
skin.
2) Immediately discontinue the use of this unit and seek
medical attention if you experience any adverse side effects.
Included Materials
1 Wireless device
1 Charger and USB extension line
1 remote controller
2 pairs of gel electrode pads
1 user manual

Device Setup
1. Prepare the area that will be treated with a thorough
washing and drying of the skin. The targeted treatment
area must be clear of any dirt and excess oils to proceed.
Do not use electrode pads on damaged skin.
2. Insert 2 AAA batteries into the remote control device.
3. Connect electrode pads with the wireless device and
place pads on desired treatment location. Do not activate
device before placing electrodes
4. The unit is now ready for use. It is recommended that
this unit be charged for more than ten hours after the
45
power supply is depleted to prolong the life of the built-in
lithium ion battery. Unplug charger from power outlet
when charging is complete. DO NOT operate this device
while it is charging.
Device Operation
Proper Usage Guidelines
1. Peel and remove the clear protective film placed over
each electrode pad. Retain the protective film strips as
they must be reapplied to the electrodes to store them
after use. Do not touch or allow any object or surface to
come in contact with the electrodes as this can cause the
adhesive to lose its grip.
M
T
Power On/Off
Intensity Down Intensity Up
Timing
Mode Selection

6 7
2. Place the device over the desired treatment area.
Ensure that the electrodes are in contact with the skin.
3. Press the power button on the Wireless host. Blue
lights will activate.
4. Press the remote contol's power button.
The light will be on and the device will be set to Mode 1
by default. This unit has 6 modes. Once the host device
is successfully connected to the remote control, the Wi-Fi
symbol will display on the remote control screen. If the
remote control is not operated or connected within two
minutes, it will automatically power down.
5. Treatment will end on its own after 30 minutes.
Treatment can be stopped anytime by pressing power
button on the host or remote control. DO NOT attempt to
remove the device from the body during treatment.
6. Set the Mode. Press the “M” button on remote control to
set the mode or quickly tap the power button on the host
device and then set the mode. For safety, when the mode
is changed, the intensity will automatically decrease to the
lowest setting. To Change the Intensity: On the host or
remote device, press the “+” to increase intensity or the”-”
button to decrease intensity.
7. Time setting. Press remote's "T" button to set time.
Treatment can be set between 10-60mins in increments of
10 mins. Pause Unit: Press the on remote control to
pause and/or continue the treatment.
7. To safely power off device during stimulation, you may
long press the power button on the remote control or
press and hold the power button on the host device for 3
seconds. Replace protective film over electrodes to store.
Note:
1. The control unit is compatible with all Omega Wireless
Pads.
2. When host is used by itself the remote control can be
added mid-treatment, and the strength will reset to the
default starting value after the remote is connected.
Unit Storage & Maintenance
•Use a damp cloth with mild soap to gently wipe down
and clean the unit.
Note: This unit has water detection technology. Do not
expose or submerge this unit in water or any other liquids.
Water damage to the device or its components will void
the warranty.
• This unit should be operated, transported and stored at
temperatures between 50° F and 104° F (10° C and 40°
C), with relative humidity between 30% - 85%. All values
have+/- 10% tolerance.
• Store the device, remote control, and electrodes in
original packaging between treatment sessions.

8 9
•Immediately discontinue use if the device is not working
proerly. Do not modify or disassemble this unit.
Technical Specifications
Product Model: OMEGA
Wireless TENS Unit
Product Name: Wireless TENS
Working Mode: 6 modes
Working Strength: 20 levels
Output Current: 40mA
Power Voltage: 3.7V
Pulse Frequency: 110Hz
Pulse Width: 100μs
Timer Control: 10-60 minutes
Control Range: 10 m
Power Supply:
1)Remote Control: two pcs
AAA battery
2)Wireless unit: DC 3.7V
lithium battery
What Does TENS Treatment Feel Like?
Users may experience different sensationswith Omega
Wireless treatments. Most users will feel a slight tingling
sensation and the feeling of being warmed or massaged
on and around the treatment area. Small contractions of
muscles are not uncommon, but the Omega Wireless
works best at a level of intensity where pain relief is
achieved but before muscles begin to contract.
You may notice that while this unit maintains a steady
intensity, the pulsation pattern will vary to achieve the
maximum effectiveness during treatment.
Learn More!
Please visit www.Tensunits.com for further
information. For Questions, please contact us by phone
at: 1-866-237-4013 or email us at [email protected]
