OMEZ LIGHTING TitanPar36x3w User manual

TitanPar™ 36x3w
User Manual
Version 4
Introduction
Thank you for purchasing the OMEZ TitanPar™36x3w. This par can is
characterized by its exceptionally bright wash. The OMEZ TitanPar™
36x3w is controlled by DMX 512 in 3 or 6Ch. Mode, standalone, master
slave, and sound active
The OMEZ TitanPar™ 36x3w features (36) LED’s that project a high quality
long range wash.
TheOMEZTitanPar™ 36x3w features;RGBcolor mixing,colorpulse, color
change, and color scroll. This fixture is designed for easy transport for
mobile DJ’s, VJ’s, KJ’s, and Production companies.
TheOMEZTitanPar™ 36x3w is theindustrystandardinT.V.,realityshows,
Arenas, Concert halls, Banquet halls, Performing arts theaters, Nightclubs,
and Entertainment venues.
Omez Guarantee
This OMEZ TitanPar™ 36x3w has met all quality control requirements
when tested in our factory and is known to be in perfect condition when
shipped to our warehouse in El Monte, California. In order to guarantee the
condition of the fixtures, we conduct final QC inspections upon arrival to
our facility before deeming the product salable. In order to ensure the safe
operation of this OMEZ TitanPar™ 36x3w, it is absolutely necessary for the
user to follow the safety instructions and warnings written in this user
manual.

2 Safety Information
Contents
Intro/Omez Guarantee .…….…...………………....1
Safety information …………………….………..2
Included in package ………………………………3
Features ..…………………….……….4
LCD ……………………………….5
DMX Channels .………………………………6
Installation ...…………………………….7
Cleaning & maintenance .……………………………….8
(Before plugging in the fixture, please read the manual)

3. Included InPackage
This box includes items listed below
Item
QTY
UNIT
Mounting Bracket
1
PCS
Power Cable
1
PCS
DMX cable
1
PCS
4. Features

Modes: 3 or 6 Channels
Lamp Type: LED 36 x 3 Watt (12 Red, 12
Green, 12 Blue)
Life Span: 50,000 Hours
0-100% Linear Dimming
Strobe Speed: 20 FPS
Colors: RGB Color Mixing
Internal Effects: Color Scroll, Color Pulse,
Color Change
LCD Display
Power Supply: 90-240V ~,50/60Hz
Power: 108
Size: 254*254*381mm (10”x10”x15”)
Net weight: 4kg (8.8 lbs.)
CE & RoHS Compliant

5.2 Home Screen
In the home screen you will find 8 menus
d001 –3 Chanel mode
d.001 –6 channel mode
FF.00 –Color Scroll
CC00 –Color Change
EE00 –Color Macro
dE00 –Internal Mode
Soud –Sound Active
SLAv –Slave Mode
6. 3 Chanel Mode
Option
Instruction
Red
Ch1
0-255
Green
Ch2
0-255
Blue
Ch3
0-255
Option
Instruction
Red
Ch1
0-255
Green
Ch2
0-255
Blue
Ch3
0-255
Dimmer
Ch4
0-255
Speed
Ch5
0-255
Effect
Ch6
0-2 Off
3-49 Strobe
50-100 Color Macro Use Speed Fader
101-150 Color scroll
151-200 Color Pulse
201-250 Color change Use Dimmer Fader
251-255 Sound Active
5. LCDScreen
5.1 LCD
The LCD has 4 corresponding buttons menu, up,
down, and enter. Press the menu button once, use
the up, down buttons to scroll through the menu,
Press enter sub menu.
6.1 6 Channel Mode

Mounting the fixture in areas away from reach by unauthorized
personnel is always recommended. Before mounting the fixture
make sure that the area you are using can hold a minimum load
of 5x the Fixtures weight. You must always use a secondary
safety attachment, such as a safety cable. The TitanPar™
36x3w is fully operational in any install position, including:
hanging upside down on a truss or by setting it on a flat level
surface. Always make sure that all fixture are kept at least 0.5m
away from any flammable materials.
For best results this TitanPar™ 36x3w requires routine cleaning and
maintenance. Excessive dust, smoke fluid, and particulate buildup
will degrade the performance and will cause the fixture to overheat.
The damage from this is not covered in the manufacture warranty.
Always make sure you unplug the fixture before opening any covers
for cleaning. Optical components should be cleaned carefully and do
not use any harmful solvents to avoid damage. Remember to keep
all air vents clean and freefrom clutter that will prevents constant air
flow.
8. Cleaning & Maintenance
7. Installation

Omez Lighting reserves the right to make changes and/or improvements in
design upon its products without any obligation to include these changes to
any products theretofore manufactured. Please check our website,
www.OmezLighitng.com, regularly for any updates to manuals.
Warraty
Omez Lighting is dedicated to providing quality, affordable lighting products around the
world. We stand behind all of our products and offer a 3 year warranty. Please read below for
the terms and conditions of our warranty.
Omez Lighting, hereby warrants that this products shall be free of manufacturing defects in
material and workmanship for a period of 3 years from the date of purchase. This warranty
shall be valid only if the product is purchased from an authorized Omez Lighting dealer. Please
contact OMEZ Lighting directly for all warranties. It is the purchaser’s responsibility to provide
acceptable proof of purchase that includes date and location of purchase.
For Warranty service please contact OMEZ lighting to obtain a Return Merchandise
Authorization number (RMA#). You must include the RMA# when shipping product back to
Omez. To contact the Omez Lighting Service Department, please email [email protected]
or call 888-683-OMEZ. All shipping charges must be prepaid. If the requested repairs or
services (including parts replacement) are within the terms of this warranty, Omez Lighting will
pay return shipping charges (within the United States). Products must be shipped in the
original package. It is recommended that accessories not be shipped with the product. Should
any accessories arrive with the product, Omez Lighting is not liable for loss of or damage.
The warranty will be considered void if:
•There appears to be any tampering, altering, or removal of the original serial number;
•The product is modified or altered in any way, including the removal or covering of the Omez
Branding;
•Any modifications are made that affects the reliability of the product;
•The product has been repaired or serviced by anyone other than Omez (unless prior written
authorization by Omez);
•Or if the product is damaged because improper maintenance as set forth in the instruction
manual.
Omez Lighting will replace or repair defective parts with new or refurbished parts, and will
cover expenses for warranty services and repair caused by defects in material or
workmanship. The responsibility of Omez Lighting under this warranty shall be limited to the
repair or replacement of the product, including parts, at the sole discretion of Omez Lighting.
Omez Lighting reserves the right to make changes and/or improvements in design upon its
products without any obligation to include these changes to any products theretofore
manufactured. This warranty is the only written warranty applicable to Omez Lighting
Products and supersedes all prior warranties and written descriptions of warranty terms and
conditions heretofore published.
OMEZ
