Omlet Eglu Conversion Kit User manual

Page1
Omlet Limited
Tuthill Park
Wardington
Oxon OX17 1RR
www.omlet.co.uk
[email protected]
Helpdesk: 0845 450 20 56
Chicken To Rabbit
Eglu Conversion Kit
Water Bottle Hay Rack
Bedding tray
Eglu Pet Base
Stabilising Screws
Feed Bowl
M6 Washers
Front Face Screw Guide to keeping rabbits
What you have received
A Phillips ScrewdriverAround 20 minutes
Other things you will need
A 5mm drill bit

Page2
a. Remove the two screws and washers in
the front of the front face.
b. Remove the two screws holding the
front face to the base.
Step 1 - Remove Screws And Washers From Front Face
NOTE: Please take care when tightening and untightening the screws. Be careful not to damage
the head of the screw. TIP - Press hard when screwing and unscrewing.
Remove the Chicken Base. At this point
the locking bar will fall free.
Slot the Rabbit Base onto the Front Face.
Step 2 - Exchange Chicken Base for Rabbit Base
Step 3 - Insert Locking Bar And Do Up Front Screws
a.
b.
a. Slide the locking bar through the slot.
b. Replace the two screws and washers in
the front of the front face.
a.
b.

Page3
Step 4 - Tighten Front Face Screws
Tighten the screws until the faces in the
circle butt up against each other.
Tighten
Step 5 - Replace Screws Holding Front Face to Base
Pull back on the front face while replacing
the two screws. Stop turning the screws
as soon as they become tight so as not to
damage the thread. Pull
Step 6 - Drill Two Holes For Hay Rack
Using a 5mm drill bit, drill a hole at the
bottom of each recess in the front face.
You have now nished the conversion and
can put the tray, feed bowl, hay rack and
water bottle into place.
Drill
If you have any problems converting your eglu call us on
0845 450 20 56 or email [email protected]
