Omni 4000 Series Operating manual

Series 4000/7000
Operations & Maintenance Guide

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
i
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
Table of Contents
1. The OMNI 4000/7000 Series............................................................................................ 1-1
1.1 Users of this Guide ....................................................................................................................1-1
1.2 Where Installed and Operated...................................................................................................1-1
1.3 Certifications and Standards......................................................................................................1-1
1.3.1 IEC Test Procedure Compliance................................................................................1-3
1.3.2 Measurement Security and Firmware Downloads (WELMEC 7.2 Extension D) .......1-4
1.4 Calculations ...............................................................................................................................1-4
1.5 Equipment Overview..................................................................................................................1-6
1.6 Safety.........................................................................................................................................1-8
1.6.1 Basic Electric Safety...................................................................................................1-8
1.6.2 Electrical Grounding Requirements ...........................................................................1-8
1.6.3 Safety Labels..............................................................................................................1-9
2. OMNI 4000/7000 Overview.............................................................................................. 2-1
2.1 Hardware ...................................................................................................................................2-1
2.2 Firmware....................................................................................................................................2-2
2.3 Software.....................................................................................................................................2-2
3. OMNICONNECT®Operations.......................................................................................... 3-1
3.1 Communications........................................................................................................................3-1
3.2 Security......................................................................................................................................3-1
3.2.1 Enter Password..........................................................................................................3-1
3.2.2 Lost Password............................................................................................................3-2
3.2.3 User Permissions .......................................................................................................3-2
3.3 Application Types.......................................................................................................................3-2
3.4 Configurations............................................................................................................................3-3
3.4.1 Meter Run Configurations ..........................................................................................3-3
3.4.2 Station Configurations................................................................................................3-5
3.4.3 Products Configuration...............................................................................................3-6
3.5 Proving Functions....................................................................................................................3-16
3.5.1 Prove Types .............................................................................................................3-16
3.5.2 Prove Configuration..................................................................................................3-17
3.5.3 Prove Sequence.......................................................................................................3-28
3.5.4 Auto Prove Setup.....................................................................................................3-30
3.5.5 Manual Prove Request.............................................................................................3-30
3.5.6 Remote Prove Request............................................................................................3-31
3.5.7 Print Prove Passes...................................................................................................3-32
3.6 Batch Operations.....................................................................................................................3-33

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
ii
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
3.6.1 Batch Setup and Scheduling Configuration .............................................................3-34
3.6.2 Adjust Batch Size .....................................................................................................3-35
3.6.3 Batch Stack Control..................................................................................................3-36
3.6.4 Ending a Batch.........................................................................................................3-40
3.6.5 Batch Preset Counters.............................................................................................3-42
3.6.6 Product Interface Detection......................................................................................3-45
3.7 PID Configuration.....................................................................................................................3-45
3.7.1 Primary and Secondary Variable Configuration.......................................................3-46
3.7.2 PID Tuning Configuration.........................................................................................3-48
3.7.3 PID Ramp Control Configuration..............................................................................3-51
3.8 User Displays...........................................................................................................................3-53
4. OMNICONNECT®Reports............................................................................................... 4-1
4.1 Printer Setup..............................................................................................................................4-1
4.1.1 Ethernet Printer Connection.......................................................................................4-1
4.1.2 Local Printer Connection............................................................................................4-3
4.2 Report Setup..............................................................................................................................4-5
4.3 Custom Report Templates.........................................................................................................4-5
4.4 Current Reports .......................................................................................................................4-10
4.5 Historical Reports and Audits ..................................................................................................4-11
4.5.1 Alarm Reports ..........................................................................................................4-13
4.5.2 Measurement Audit Trail and System Audit Trail Reports.......................................4-13
4.5.3 Last Local Snapshot Reports...................................................................................4-14
4.5.4 OMNI Initialization Reports ......................................................................................4-14
4.5.5 Batch, Daily and Prove Reports...............................................................................4-14
5. OMNICONNECT®Data Retrieval..................................................................................... 5-1
5.1 Dashboard .................................................................................................................................5-1
5.2 Custom Data Screens................................................................................................................5-2
5.3 Archives .....................................................................................................................................5-4
5.3.1 Configure Archives.....................................................................................................5-4
5.3.2 Run Archives..............................................................................................................5-5
5.3.3 Retrieve Archives.......................................................................................................5-7
6. Front Panel Operations.................................................................................................... 6-1
6.1 Observing Flow..........................................................................................................................6-1
6.1.1 Meter Runs.................................................................................................................6-1
6.1.2 Stations ......................................................................................................................6-3
6.2 Batch Status...............................................................................................................................6-4
6.3 Proving Functions......................................................................................................................6-5

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
iii
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
6.3.1 Manual Prove Request...............................................................................................6-5
6.3.2 Edit Prove Transducers..............................................................................................6-6
6.4 Front Panel Reports...................................................................................................................6-7
6.5 User Displays.............................................................................................................................6-9
6.6 Operate Features.......................................................................................................................6-9
6.6.1 Edit Meter Factor........................................................................................................6-9
6.6.2 Edit Density Correction Factor .................................................................................6-10
6.6.3 Edit Products............................................................................................................6-12
6.6.4 Edit Transducers ......................................................................................................6-14
6.6.5 Batch Operations......................................................................................................6-16
6.6.6 PID Control...............................................................................................................6-22
6.6.7 Other Operations......................................................................................................6-31
6.7 Firmware..................................................................................................................................6-32
7. Maintenance .................................................................................................................... 7-1
7.1 Software and Firmware Updates...............................................................................................7-1
7.2 OMNICONNECT®Diagnostics ..................................................................................................7-1
7.2.1 I/O Overview...............................................................................................................7-1
7.2.2 Calibration ..................................................................................................................7-2
7.2.3 Calibration Verification ...............................................................................................7-8
7.2.4 System Information ..................................................................................................7-11
7.2.5 System Resets .........................................................................................................7-14
7.2.6 Test Communications...............................................................................................7-21
7.3 Front Panel Maintenance.........................................................................................................7-23
7.3.1 System Date/Time....................................................................................................7-23
7.3.2 Calibration ................................................................................................................7-24
7.3.3 Calibration Verification .............................................................................................7-32
7.3.4 Maintenance Mode...................................................................................................7-36
7.3.5 System Resets.........................................................................................................7-39
7.3.6 Licensing ..................................................................................................................7-40
7.3.7 Disable Download ....................................................................................................7-40
7.3.8 Communications.......................................................................................................7-41
7.3.9 Check Modules.........................................................................................................7-41
7.3.10 Secure Digital Card..................................................................................................7-43
7.3.11 Diagnostic Data........................................................................................................7-45
7.4 Component Maintenance.........................................................................................................7-46
7.4.1 Inspection.................................................................................................................7-46
7.4.2 Change Modules......................................................................................................7-47
7.4.3 Fuse Service and Replacement...............................................................................7-54

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
iv
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
OMNI Flow Computers Inc.
Our Mission
OMNI Flow Computers Inc. sets the world’s standard for the design, development and
manufacture of flow computers. For more than 30 years, we have supplied high-integrity
equipment to offshore production facilities, oil and gas pipelines, terminals, refineries and
petrochemical and gas plants worldwide.
We are determined to be the best in what we do, which is driven by our commitment to providing
an excellent customer experience. We offer a multi-tiered promise to our customers, employees
and business partners, which includes:
•Actively communicating with customers, integrators and original equipment manufacturers.
•Collaborating with our customers to determine the best solutions.
•Providing superior performance based on quality metrics.
•Operating with integrity and traceability.
•Providing continuous, relevant innovation that builds upon, rather than obsoletes, previous
generations.
Our Users
Our products are currently being used worldwide at:
•Offshore oil and gas production facilities.
•Crude oil, refined products, liquefied petroleum gas (LPG), natural gas liquids (NGL) and gas
transmission lines.
•Storage, truck and marine loading/offloading terminals.
•Refineries, petrochemical and cogeneration plants.
Contact Us
We are committed to our products, our people and our customers. To contact our corporate
headquarters:
Visit:
OMNI Flow Computers, Inc.
12320 Cardinal Meadow Dr.
Suite 180
Sugar Land, TX 77478
http://www.omniflow.com/
Phone:
281-240-6161
Fax:
281-240-6162
E-mail (Sales):
[email protected]m
E-mail (Support):
[e-mail]

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
v
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
Copyright Information
OMNI Flow Computers, Inc. owns the content of this user manual in its entirety, including but not
limited to pictures, logos, trademarks and resources. OMNI Flow Computers, Inc. authorizes its
customers to download and print this manual for professional information purposes only.
OMNI Flow Computers, Inc. expressly prohibits the usage, copy, storage, distribution,
modification or printing of this manual or its content for any other purpose without written consent.
OMNI Flow Computers, Inc. believes that the information contained in this manual is accurate in
all respects. However, OMNI Flow Computers, Inc. assumes no responsibility for any error or
omissions in this document. OMNI Flow Computers, Inc. reserves the right to revise this
document and to make changes from time to time in the content hereof without obligation of
OMNI to notify any person or company of such revision or changes. This does not constitute in
any way a commitment by OMNI to make such changes. OMNI Flow Computers, Inc. may issue
a revision of this manual or a new edition of it to incorporate such changes.
The OMNI Flow Computers, Inc. logo, “OMNI,” “OMNICOM”, “OMNICONNECT” and “Measure
the Difference” are registered trademarks of OMNI Flow Computers, Inc., in the United States
and other countries. All other trademarks are the property of their respective owners.
Warranty, Licenses and Product Registration
See the Terms and Conditions associated with your purchase order for the OMNI 4000/7000 flow
computer warranty, licenses and product registration.
Document Conventions
Document conventions help you navigate through the information in this manual. Instructions are
contained inside grey tables and use the following conventions:
1.
Labeled cables and connections are
bolded in the instructions:
Connect I/O Cable A connector to CONN A
on the motherboard.
2.
Front panel screen and function key
selections are bolded in the instructions:
•Scroll to select Meter Run 1.
•Press the Reports function key to run a
report.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
vi
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of America
3.
OMNICONNECT®screen, window, field
and button labels are bolded:
•Click Apply to save any selections or
any edits made to fields before moving
to the next screen.
•In the Setup Sites window, click Add
Site to open the Setup
Communications window.
4.
A white box outlined in blue in an
instructional step provides information that
you need to know.
5.
F1 in an instruction step is a prompt for
you to go to OMNICONNECT Help for
additional details to perform an action.
Your cursor must be on the
OMNICONNECT screen for F1 to open to
the correct help content.
Boxes with icons provide information. When an icon alerts you to a potential safety concern,
observe these precautions to prevent injury to people or damage to equipment.
The tip icon indicates additional information about the current topic.
The bookmark icon indicates a reference to another guide in this series.
WARNING:
The warning icon indicates a definite risk of danger to personnel or damage to
equipment. Failure to observe and follow proper procedures could result in serious
or fatal injury to personnel or significant property loss or equipment damage.
CAUTION:
The caution icon indicates a potential risk of injury to personnel or damage to
equipment. Take extreme care when performing operations or procedures preceded
by this symbol.
This will help you complete the
action.
Press F1 to access
OMNICONNECT Help
for assistance.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
vii
© Copyright 2016-2020 OMNI Flow Computers, Inc. All rights reserved.
Electronically published by OMNI Flow Computers, Inc. in the United States
of AmericaThe OMNI 4000/7000 Series
Earth Ground Requirements:
The Earth Ground requirements icon reminds operators to verify that grounds are
connected when there is a possibility of electrical shock.
The electrostatic icon reminds operators to observe the precautions for handling
electrostatic-sensitive devices.
The recycle icon provides recycling instructions for the item.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-1
The OMNI 4000/7000 Series
1.The OMNI 4000/7000 Series
The Operations and Maintenance Guide for the OMNI 4000 and OMNI 7000 series of flow
computers includes:
•An overview of the OMNI 4000/7000 flow computer.
•OMNICONNECT software operations.
•Front panel operations.
•Maintenance instructions.
•Hardware component troubleshooting.
Review these instructions and guidelines to ensure a safe installation and startup of your OMNI
4000/7000 flow computer.
1.1 Users of this Guide
As a user reference guide, the OMNI 4000/7000 Operations and Maintenance Guide is intended
for an audience with knowledge of liquid and gas flow measurement technology. The user does
not need to be an expert to use certain portions of this manual. However, some flow computer
features require a certain degree of expertise and/or advanced knowledge of liquid and gas flow
instrumentation and electronic measurement.
This manual is written for:
•Operators.
•Advanced Technicians.
•System and Project Managers.
•Engineers and Programmers.
Only qualified personnel should operate, configure and calibrate OMNI flow computers.
1.2 Where Installed and Operated
The OMNI 4000/7000 should have previously been installed in a climate-controlled environment
that has access to stable back-up power. It can be operated locally from the front panel or
remotely through Modbus communications.
1.3 Certifications and Standards
OMNI 4000/7000 flow computers have earned the following certifications:
Nederland Meetinstituut (NMi)
2004/108/EC
Electromagnetic Compatibility Directive
2004/22/EC
Measuring Instruments Directive
OIML R117-1
Dynamic Measuring Systems for Liquids Other Than Water Standard,
Edition 2007; part of MID Software Guide–Measuring
WELMEC 7.2
Software Guide Measuring Instruments Directive, Chapter P and
Extensions L, T, S, D and I5, Edition 2015

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-2
The OMNI 4000/7000 Series
Nederland Meetinstituut (NMi)
WELMEC 8.8
General and Administrative Aspects of the Voluntary System of
Modular Evaluation of Measuring Instruments under the MID, Edition
2:2012
EN 55011:2009+
A1:2010
Industrial, Scientific and Medical (ISM) Equipment–Radio-Frequency
Disturbance Characteristics
EN 61326-1:2013
Electrical Equipment for Measurement, Control and Laboratory Use–
EMC Requirements–Part 1: General Requirements
EN 12405-1:2005+
A2:2010
Gas Meters - Conversion Devices - Part 1: Volume Conversion, Edition
2005+A2:2010
European Conformity (CE)
2011/65/EU
Restriction of Hazardous Substances in Electronic Equipment
(RoHS2) Directive
CE 93/68/EEC
Marking as per European Conformity Directive
TÜV Rheinland
UL 60950-1:2007
Information Technology Equipment–Safety–Part 1: General
Requirements
UL 61010-1
Issued: 2004/07/12 Ed: 2 Rev: 2008/10/28 UL Standard for Safety
Electrical Equipment for Measurement, Control, and Laboratory Use;
Part 1: General Requirements
CSA C22.2 61010-1
Issued: 2004/07/12 Ed: 2 (R2009) Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use Part 1:
General Requirements, with general instruction No. 1:2008/10/28–
(R2009)
ISO 9001:2015
Issued: 2018/08/15 Quality management system–Requirements
American Petroleum Institute (API)
Manual of Petroleum Measurement Standards (MPMS)
Chapter 4
Proving Systems
Chapter 5
Metering
Chapter 6
Metering Assemblies
Chapter 8
Sampling
Chapter 9
Density Determination
Chapter 11
Physical Properties Data (Volume Correction Factors)
Chapter 12
Calculation of Petroleum Quantities
Chapter 13
Statistical Aspects of Measuring and Sampling
Chapter 21
Flow Measurement Using Electronic Metering Systems

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-3
The OMNI 4000/7000 Series
1.3.1 IEC Test Procedure Compliance
To meet the standards/directives in Section 1.3, the OMNI 4000/7000 models comply with the
IEC test procedures listed in this section.
IEC 60068-2-1
Environmental testing–Part 2-1: Tests–Test A: Cold
IEC 60068-2-2
Environmental testing–Part 2-2: Tests–Test B: Dry heat
IEC 60068-2-47
Environmental testing–Part 2-47: Test–Mounting of specimens for vibration,
impact and similar dynamic tests
IEC 60068-2-64
Environmental testing–Part 2-64: Tests–Test Fh: Vibration, broadband
random and guidance
IEC 60068-3-1
Environmental testing–Part 3: Background information–Section One: Cold
and dry heat tests
IEC 60068-3-4
Environmental testing–Part 3-4: Supporting documentation and guidance–
Damp heat tests
IEC 60654-2
Operating conditions for industrial-process measurement and control
equipment–Part 2: Power
IEC 61000-2-1
Electromagnetic Compatibility (EMC)–Part 2: Environment–Section 1:
Description of the environment–Electromagnetic environment for
low-frequency conducted disturbances and signaling in public power supply
systems
IEC 61000-4-1
Electromagnetic Compatibility (EMC)–Part 4-1: Testing and measurement
techniques–Overview of IEC 61000-4 series
IEC 61000-4-2
Electromagnetic Compatibility (EMC)–Part 4-2: Testing and measurement
techniques–Electrostatic discharge immunity test
IEC 61000-4-3
Electromagnetic Compatibility (EMC)–Part 4-3: Testing and measurement
techniques–Radiated, radio-frequency, electromagnetic field immunity test
IEC 61000-4-4
Electromagnetic Compatibility (EMC)–Part 4-4: Testing and measurement
techniques–Electrical fast transient/burst immunity test
IEC 61000-4-5
Electromagnetic Compatibility (EMC)–Part 4-5: Testing and measurement
techniques–Surge immunity test
IEC 61000-4-6
Electromagnetic Compatibility (EMC)–Part 4-6: Testing and measurement
techniques–Immunity to conducted disturbances, induced by
radio-frequency fields
IEC 61000-4-8
Electromagnetic compatibility (EMC)–Part 4-8: Testing and measurement
techniques–Power frequency magnetic field immunity test
IEC 61000-4-17
Electromagnetic Compatibility (EMC)–Part 4-17: Testing and measurement
techniques–Ripple on D.C. input power port immunity test
IEC 61000-4-29
Electromagnetic Compatibility (EMC)–Part 4-29: Testing and measurement
techniques–Voltage dips, short interruptions and voltage variations on D.C.
input port immunity tests
IEC 61000-6-1
Electromagnetic compatibility (EMC)–Part 6-1: Generic standards–
Immunity for residential, commercial and light-industrial environments
IEC 61000-6-2
Electromagnetic compatibility (EMC)–Part 6-2: Generic standards–
Immunity for industrial environments
IEC 61000-6-4
Electromagnetic compatibility (EMC)-Part 6-4: Generic standards–Emission
standard for industrial environments

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-4
The OMNI 4000/7000 Series
1.3.2 Measurement Security and Firmware Downloads (WELMEC 7.2 Extension D)
The OMNI 4000 and 7000 models have 16 password-protected access levels for protecting
configuration parameters and for firmware downloads. When software sealing for parameters and
firmware is applied, the highest level is reserved for Weights and Measures Agents and other
agencies that act in the same way. Through software sealing, all communication ports can be set
to “read-only.”
Only licensed firmware files can be transmitted.
This method of firmware transmission meets all requirements of WELMEC 7.2 2015 Extension D,
Software Guide—Measuring Instruments Directive.
1.4 Calculations
The OMNI 4000/7000 includes, but is not limited to, support for the following calculations:
Liquid (U.S. Units)
API MPMS CH. 11.1 (2007)
Commodity Types:
•Crude Oil
•Refined Products
•Lubricating Oil
•Special Applications
Crude Oil Historical Tables
(API STD 2540/ASTM D1250, 1952
edition)
•Table 23/24
•Table 5/6
ASTM D1555 Aromatic Hydrocarbons
LPGs and NGLs
•API MPMS CH. 11.2.4 - 23E/24E –
(GPA TP27)
•API MPMS CH. 14.7/14.4 –GPA 2145-
16*
Mass Calculation
Liquid (Metric Units)
API MPMS CH. 11.1 (2007)
•Crude Oil
•Refined Products
•Lubricating Oil
•Special Applications
Crude Oil Historical Tables
(API STD 2540/ASTM D1250, 1952
edition)
Table 53/54
ASTM D1555M Aromatic Hydrocarbons
LPGs and NGLs
•API MPMS CH. 11.2.4-53E/54E-(GPA
TP27M)
Mass Calculation
Alcohols
•Alcohol (ABNT NBR 5992:2008)
•Alcohol (OIML) R22

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-5
The OMNI 4000/7000 Series
Gas (U.S. Units)
Flow Calculations
DP Meters
•API MPMS CH. 14.3 (AGA-3): 2012
•ASME MFC 3M (Non-Flange DP
types)
Pulse Meters
•AGA-7: 2006
Density Calculations
AGA-8 1994
•Method 1-Detailed Analysis
•Method 2-HV/SG/CO2
•Method 3-SG/N2/CO2
Heating Value Calculation
•GPA 2172 2009
•ISO 6976 60/60F
•AGA 5 2009
Speed of Sound
•AGA-10
Viscosity Calculation
•LBC
Isentropic Exponent Calculation
•Estimated
•AGA-10
Gas (Metric Units)
Flow Calculations
DP Meters
•ISO 5167:2003
•API MPMS CH. 14.3 (AGA-3): 2012
Pulse Meters
•AGA-7: 2006
Density Calculations:
AGA-8 1994
•Method 1-Detailed Analysis
•Method 2-HV/SG/CO2
•Method 3-SG/N2/CO2
Heating Value Calculation
•ISO 6976 (1995)
•GPA 2172 (2009)
•AGA-5 (2009)
SGERG 1988
•Method 2-HV/N2/SG/H2
•Method 3-N2/CO2/SG/H2
•Method 4-HV/N2/CO2/H2
Viscosity Calculation
•LBC
ISO 12213-3 2006 (SGERG)
•Method 1-HV/N2/SG/H2
Isentropic Exponent Calculation
•Estimated
•AGA-10
Speed of Sound
•AGA-10
*API MPMS CH. 14.7/14.4 is available with Firmware version 2.11 and higher for the US Liquid K-
Factor Linearization Application. It requires the purchase of an Advanced firmware license with
the API MPMS CH. 14.7/14.4 feature enabled.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-6
The OMNI 4000/7000 Series
1.5 Equipment Overview
OMNI 4000s and 7000s are microprocessor-based flow computers that perform liquid and gas
flow calculations in accordance with the methods listed in Section 1.4 Calculations.
The flow computer connects to field transmitters in single and multiple Meter Run applications
to monitor:
•Liquid and gas flow measurements in the pipeline.
•Custody transfer applications.
The flow computer calculates flow values and displays additional data and measurement
information. This data and information can be transmitted over communication channels and
printed, as needed.
In addition, audit trail logs are available for registering changes to measurement parameters and
firmware updates. The audit trail can be printed directly from the front panel of the flow computer
or viewed with the OMNICONNECT software when connected to a computer.
All input/output (I/O) modules are quality tested and temperature trimmed to optimize analog
inputs before the flow computer is shipped. A label containing information such as the system
serial number and model number is located on the inner chassis or on the outer cover in the case
of the panel mount configuration.
On-site, OMNI 4000/7000 flow computers are configurable, but the firmware code is not user
programmable. We do this to prevent the modification of WELMEC-approved metrologically
relevant areas of the software code. If firmware modifications were allowed, they would render an
existing EC-evaluation certification invalid.
With an OMNI flow computer, the factory-programmed software does not need modification in the
field. This preserves the integrity of existing certifications and provides assurance that software
and firmware have been validated and cannot be modified.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-7
The OMNI 4000/7000 Series
Every OMNI 4000/7000 flow computer has the following components and features:
Hardware
•7201 central processing unit (CPU)
•4.3-inch (10.922 cm) Color LCD with 800
x 480 resolution
•USB Mini-B port on the front panel for
configuring the flow computer using
OMNICONNECT
•USB-A Host port on the front panel for
updating the OMNI CPU firmware using a
memory stick
•USB Mini-B port on the CPU for
configuration or updating the OMNI CPU
firmware using OMNICONNECT
•Dual Ethernet (DE) module with:
−2 onboard RJ-45 100 Mbps Ethernet
jacks
−10 Mbps using the back panel
•Expandable to allow for 2 DE modules (4
physical Ethernet ports for a total of 32
virtual connections).
•Expandable to allow for up to 10 Serial
ports with different combinations of DE
and S cards. Must purchase separately.
•Digital I/O Multiplexer (DM) module with
10 independent channels
•Digital I/O channels that support up to 3
externally installed Digital Terminals
(DTs), which can be used in sequence.
Each DT contains 16 I/O points. DTs are
optional purchase items.
•2 local printers, which can be connected
to any RS-232 Serial port
Firmware
•All firmware applications in one
programming file
•Daily, Batch, and Prove Historical
Reports and for gas applications, a
Detailed Daily report:
−The 35 most recent reports are
stored in the CPU memory.
−Older reports are stored on the SD
card, which has capacity of 8 GB
of data.
−2 GB is allocated for each
report type.
•Audit trail and alarm reports
•User database mapping providing
standardization of local data maps or
custom interfacing*
•Programmable Boolean and variable
statements–128 statements with a
32-character length allowing technical
flexibility for adding custom functions
•Support for 6 Meter Runs, which can be
configured for Liquid and Gas
measurement independently
•2 sets of detector switches for dual
prover volumes
•Proves based on run repeatability or
random uncertainty**
•Selectable Master Meter prove meter
•Programmable security settings:
−1 Administrator and 16 users with
separate permissions
−Different passwords for users and
data system connections
•A full audit feature, with separate reports
for the system and measurement audits
•Support for:
−SSL*
−Dual Stations*
−User Database Mapping*
−A Gas/Liquid combination mode*
*These features require the Standard firmware license (not included in the Basic firmware license).
**Random Uncertainty is available with Firmware version 2.11and higher for the US Liquid K-Factor Linearization Application. It requires the
purchase of an Advanced firmware license with the Prover Uncertainty feature enabled.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-8
The OMNI 4000/7000 Series
1.6 Safety
1.6.1 Basic Electric Safety
Observe precautions for handling electrostatic-sensitive devices.
Take basic electrical safety precautions to prevent injury and equipment damage:
☐Keep the area around the equipment clean and free of clutter.
☐Verify that the power is not connected to the system when installing or removing main
system components, including I/O modules.
CAUTION:
Do not hot swap I/O modules. Electrical shock may occur, resulting in injury to
personnel and damage to the flow computer or connected field devices/control
systems.
☐Connect the power using a readily accessible disconnect device certified as being safe for
the area.
☐If an electrical accident occurs, disconnect the power to the system by removing the plug(s)
from the outlet(s). Some systems may have multiple power cords that connect to more than
one outlet.
1.6.2 Electrical Grounding Requirements
Follow these requirements for grounding equipment:
☐The rack or cabinet that will house the flow computer must be properly Earth Grounded before
installation.
☐An Earth-Grounded electrical outlet must be available for all power cables.
☐If using a power cable other than the factory-supplied cable, the power cord must include an
Earth-Grounding pin.
Earth Ground Requirements: Do not apply power before confirming that grounds
are connected. Electrical shock can cause serious or fatal injury. Follow the National
Electrical Code (NEC) and local codes for the safe installation of this equipment.
☐To minimize the effects of electrical transients, the outer chassis of the flow computer must
have a secure Earth Ground.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
1-9
The OMNI 4000/7000 Series
1.6.3 Safety Labels
Table 1-1 describes the safety labels that are posted on the OMNI 4000/7000 flow computer.
Table 1-1: Safety Label Descriptions
The No Vertical Mount safety label is located on the side of the National Electrical
Manufacturers Association (NEMA) chassis where the I/O ribbon cables are connected and
provides recommendations for mounting the NEMA chassis.
The label reads:
CAUTION: NO Vertical Mount!
•Mount the NEMA Chassis horizontally for proper heat transfer.
•Mount chassis to bonded metal surface.
•Bonded metal surface shall be provided with a safety earth path.
•Avoid mounting in drafts that cause fluctuations in temperature.
The Earth Ground safety label is located below the Earth Ground connection on the chassis.
It indicates where to connect the flow computer to safety Earth Ground.
The alternating current (AC) voltage safety label is located below the Serial Number label on
the Panel mount chassis and on the side of the NEMA chassis.
It denotes the specified AC voltage at which the flow computer operates.
The fuse safety label is located on the panel mount back panels and provides the proper fuse
specifications for the OMNI 4000/7000.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
2-1
OMNI 4000/7000 Overview
2.OMNI 4000/7000 Overview
The OMNI 4000/7000 flow computer is supplied with firmware and Windows PC configuration
software that allow a single flow computer to perform a wide range of flow measurement tasks
simultaneously, including:
•Multiple Meter Run totalizing, batching, proving and data archiving.
•Flow and control.
•Communications protocols (selectable) to directly interface with Distributed Control Systems
(DCSs), Programmable Logic Controllers (PLCs) and Supervisory Control and Data
Acquisition (SCADA) host systems.
The flow computer Modbus database numbers thousands of data points and provides tight
communications coupling between the SCADA and the metering system.
2.1 Hardware
Front Panel
The front panel of the flow computer features an active alarm Light-emitting Diode (LED), a color
graphics display and a 25-key keypad for navigation of the menu system, data selection and data
entry. The front panel provides the capability to configure system parameters, view flow data,
perform I/O calibrations and print reports.
Back Panel
All signal I/O terminals and power connector/terminals are located on the back panel. The
OMNI 4000 has four I/O terminal blocks and the OMNI 7000 has ten I/O terminal blocks.
All flow measurement inputs are first received at the back panel and then through plug-in I/O
combination (combo) modules. Four types of combo modules are available: A, B, E and E/D.
Flow computers may be used to interface with any approved compatible 4-20 mA or 1-5 V
temperature, pressure and differential pressure transmitter from the back panel. They can also
receive direct inputs from 4-wire, 100-ohm Resistance Temperature Detectors (RTDs), which
conform to either Deutsches Institut für Normung (DIN) IEC 751 or American curves.
Pulse inputs from any approved turbine, positive displacement, or Coriolis mass flow meter may
be used.
Chassis
The chassis houses the I/O modules, the motherboard, the CPU and the power supply.
CPU Module
All custody transfer measurement programs and configurations can be stored in non-volatile
memory for up to 10 years without power. This method prevents damage caused by electrical
noise or tampering with the integrity of calculation specifications, and it does not rely on a battery.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
2-2
OMNI 4000/7000 Overview
2.2 Firmware
Real-time Operating System
The real-time operating system and dual Ethernet adapt to load placement, which creates a
high-speed, multitasking environment and quick turnaround on all communications. The operating
system adapts to meet increased demand, and its pre-packaged, certified and standardized code
makes the software easier to maintain.
Cycle Time
The flow computer performs all time-critical measurement functions every 500 milliseconds or
less. For example, the Digital MUX, pulse density and double chronometry critical functions occur
every 10 milliseconds. This cycle time makes measurement calculations more accurate and
permits faster pipeline operations response for critical control functions such as opening or
closing valves.
On-line Diagnostics and Calibration
Diagnostic software is built into the system so that a technician can debug a possible problem
remotely without interrupting on-line measurement. Technicians can also remotely test Modbus
communications through a unique Modbus register master simulator that is built into the software.
The flow computer has an automatic, two-point calibration system. The operator inputs the high
and low points of the calibrator into the flow computer, which then calculates the calibration.
CPU Firmware
Firmware is stored in flash memory, which is located in the CPU module. The firmware contains
the liquid and gas flow calculations for both metric and US standard units.
Firmware can be updated in two ways:
•With a factory-provided Universal Serial Bus (USB) flash drive
•Through OMNICONNECT when connected to the USB port on the CPU
2.3 Software
OMNICONNECT®
Online or offline configuration of OMNI 4000 and 7000 models is possible using a personal
computer that can run the OMNICONNECT software. This software manages the flow computer’s
configuration, operation, security setup, and supports the updating of the CPU’s firmware.
OMNICONNECT can connect to the flow computer via the Ethernet ports, Serial ports, the front
panel USB port and the CPU USB port.
OMNICONNECT requires a license to run. OMNICONNECT is licensed to the individual PC or
laptop.

OMNI 4000/7000 Operations and Maintenance Guide –Rev F
2-3
OMNI 4000/7000 Overview
Figure 2-1: OMNICONNECT®
OMNIPANEL
The OMNIPANEL software remotely replicates all the functionality of the OMNI 4000/7000 flow
computer’s front panel for times when physical access to the flow computer is not possible.
