Omnia OSYT-C01 User manual

Wireless RF Wall Panel
OSYT-C01,2,3

F igure1: Open the bac k c over of the
transmitter.
F igure2: Put t he battries i n.
F igure3: Cover the bac k c over.
CR2032
1.Open the back cover of the transmitter, put the two batteries
(CR2032) into the battery compartment and cover the back cover.
See figures below:
Installation of Wireless RF Wall Panel
Transmitter

Ways to Install the Transmitter
Fix with double-sided
adhesive type Fix with screws
The distance between the two
mounting holes is 60mm
Clean the wall surface from dust and
wall shedding before fixing
(The adhesive force od double-sided
adhesive tape is weakened when used
repeatedly. Please do not use it more
than once)
60MM
2.Two ways to fix the transmitter:
a.Use double-sided adhesive tape and secure in the desired posi-
tion.
b.Fix on the wire box with screws.

Working v oltage: DC 3.3V
Working f requenc y:433MHz
S tandby power: < 1UA
Working c urrent: 6 .5 mA @ + 10 d Bm
E nc oding: E V1527
Modulation c ode:AS K
Working t emperature:-10℃～+70℃Power supply:C R 2032 b attries*2
A: Paring process: Directly on the OMNIA Smart Switch WiFi/RF that you want
to pair long press the desired button until a small LED indicator turns Red.
Release and then press the OMNIA Wireless RF Wall Panelbutton to
complete the paring process.
Now the Wireless RF Panel will trigger the Smart Switch.
B.Erase paring: On the OMNIA Smart Wall Switch WiFi/RF long press the
previously paired button. The LED indicator will turn red, and then it will turn
blue. When in blue release IMMEDIATELY. Paring successfully erased.
Note: You don't have to do anything to erase the paring on the Omnia
Wireless RF Panel (OSYT-C01,2,3)
1.Switch buttons always on:
The touch chip is in automatic calibration, do not touch the key when this
happens, for 5 seconds, the system will recalibrate.
2.Cannot control lights with buttons on:
This problem is generally caused by the battery power shortage, because
the POWER consumption of the RADIO frequency emission is higher than
that of the LED lighting. If you encounter this problem, please replace the
battery.
Pairing mode:
Specifications:
1. Pair with OMNIA Smart Wall Switch WiFi/RF (OWS-US 1/2/3)
Troubleshooting:

Wireless RF Wall Panel
OSYT-C01,2,3
User Manual
smartomniacrsmart.omnia
www.smartomnia.com
