OmniBus Monkey MILO User manual

MONKEY MILO
Monkey compressor (piston) nebulizer
Manual
CARREFULY READ MANUAL BEFORE FIRST USE.
Model nr: BR-CN001
Monkey MILO

Table of Contents
IEC Symbols……………………………………………………............. 3
Important Safeguards…………………………………………............. 3
Introduction………………………………………………………...........
Specifications……………………………………………………...........
Description………………………………………………………............ 5
Accessories …................................................................................. 5
Operation Instruction……………………………………………........... 6
Cleaning…………………………………………………………............ 6
Maintenance………………………………………………………......... 6
Troubleshooting …........................................................................... 7
Warranty…………………………………………………………............ 7
Technical data ….............................................................................. 8
Disposal…………………………………………………………............ 8
Manufacturer …............................................................................... 8

IEC Sy bols
Caution: Attention or consult accompanying documents.......
Type BF equipment …...........................................................
Alternating current …............................................................. ~
Double insulation ... …...........................................................
Indoor use only …..................................................................
I portant safeguards
Warning:
1. The medical equipment is for use only after consultation with a doctor or a physiotherapist.
2. Follow the instruction manual and the instruction of your physician or doctor to operate unit.
3. Inhalations should be recommended by the doctor who is able to prescribe the suitable medicine, its dose and the
way of administering.
. The equipment is intended for the aerosoltherapy only. Another usage than pointed out in this
instruction is inadvisable.
5. Do not untwist the container for medicine (a nebuliser) during the inhalation.
6. Do not pour more than 6ml of solution into the container (nebuliser jet).
Danger! Electrical protection
1. Always unplug the device from power after the inhalation.
2. Do not use the nebulizer under the shower, in the bath, etc.
3. Use and storage the nebulizer far from baths, sinks, washbasins and other moisture sources.
. Do not immerse in water and other liquids. Do not swich on the wet nebulizer!
5. If some water get into the apparatus – immediately unplug the power and do not use!
Warning: Mini izing the risk of the electric shock, fire and other da age.
1. The risk of electric shock! Do not remove the cabinet or open the cover.
2. Always disconnect the power cord from the electrical outlet before cleaning or servicing.
3. Do not storage and use the nebulizer within easy reach of gas, flammable, explosive materials or open fire.
. Do not use any greases and oils.
5. Always switch off the apparatus after finihshing the inhalation.
6. Storage the power cord far from the warmed, hot places.
7. Do not throw, do not put any other elements into the holes of the nebulizer.
8. Do not cover, clog air intake grilles on the enclosure.
9. Do not use in the wet or moisture rooms.
10. Unplug the power before filling the container with a medicine.
11. Using the nebulizer near TV sets, microwave ovens, mobile phones or other devices which emit strong magnetic
field. It can disturb their working.
Warning: To reduce the risk of infection:
1. The equipment predicted for administering medicines by the way of nebulisation. Due to its small size and friendly
appearance it is recommended for children and adult patients.
2. It is recommended to clean the accessories after each aerosol treatment. Conduct the disinfection one a
day.Please follow cleaning and disinfecting instructions in this manual.
This unit is not suitable for use in anaesthetic breathing systems
This unit is not suitable in suspension or high viscosity form. In such cases information should be sought from the drug
supplier.

Introduction
The nebulizer is designed to deliver a prescribed medicine in prophylactic and therapeutic aims for treatment of the
respiratory tracts such as asthma, allergies, pulmonary, colds and others.
The nebuliser converts the medicine solution into an aerosolized mist, which is inhaled through the mask or mouthpiece.
The apparatus is a modern and very efficient device for using at home.
Read this anual thoroughly before using the nebulizer and save for future reference.
Specification
Power 230V AC/50Hz
Power consumption below 60W
Rated current below 0.7 A
Dimensions 190 mm x 150 mm x 190 mm h
Weight 1,6 kg (3.53 lbs)
Noise level below 55 dB (A)
Maximum compressor pressure 2, 1 – 3, 5 bar (2 1-3 5 kPa) / 35 Psi to 50 Psi
Neb. operating pressure 0,62 – 1,10 bar (62 – 110 kPa) / 9 – 16 Psi
Maximum flow 7 – 11 l/min.
Liter flow range 5 - 7 l/min
Partical size less than 3 microns
Maximum nebulizer solution capacity 6 ml
Maximum residual medicine volume 0.50 ml
Operation conditions temperature:+10°C to + 0°C
humidity : 30% do 85% RH
Storage conditions temperature: - 20°C to + 70°C
humidity: 10% do 95% RH
Protection against electric shock
Type BF applied parts: Mouthpiece, masks
Classified as Type ll
Degree of safety in the presence of flammable anesthetics or oxygen.
—No AP/APG (not suitable for use in the presence of flammable anesthetics or oxygen).
Mode of operation—Continuous
IPX0—Protection against harmful in gress of water is ordinary.

Accessories:
Nebulizer
machine Air tube Pediatric/
adult mask
Nebulizer
cup with
nozzle
Mouthpiece Air filters (5
psc.) Option infant mask
WARNING! VERY IMPORTANT:
There should be close attention that without the spraying nozzle, the
nebulizer DOES NOT WORK !
Nebulizer cup consists of three parts: upper part of cup, lower part of
cup and spraying nozzle (see picture) .
You have to fix spraying nozzle to the upper part of nebulizer cup -
fro the botto .

Operation instruction
1.Place compressor on a stable, strudy and flat surface, so that the unit can be easily reached when you are seated.
2.Pull the power cord from the base of the unit, make sure that the device is switched off (position O of the power switch ).
3.Plug power cord into the wall-socket.
.Connect one end of the air tube into the air outlet connector on a nebulizer's body.
5.Unscrew the nebulizer cup (medicine container), check if the SPRAYING NOZZLE is inside. Pour the measure dose of
medicine, prescribed by the doctor.
The sign 6 cc on the container points out the maximum container`s capacity. Do not pour more than maximum level of
medication solution. Tighten the container.
WITHOUT THE THE SPRAYING NOZZLE the NEBULIZER WILL NOT SPRAY A MEDICINE!
DO NOT LOSE THE COVER PLATE OF THE NOZZLE.
6.Put the mouthpiece or the mask on the medicine’s container (nebulizer cup).
7.Put the second end of the air tube on the bottom part of the nebulizer cup, from the bottom. Sit down.
8.Switch on the device (position I of the power switch).
9.Put the mouthpiece between teeth, clench lips around the mouthpiece and breath deeply with a mouth.
10.When you use the mask, close attention to suit it to your face. Breath slowly and deepley, doing short breaks after
each inspiration and doing fast expiration.
Inhalations should be conducted on the pitting position!
After finishing operations, the device should be switched off and taken out the plug from the socket.
Cleaning
1. Turn the power off and unplug from the wall outlet .
2. Remove the tubing from the air inlet.
3. TO CLEAN: Disassemble mouthpiece, nosepiece, nebulizer cup, chamber and nozzle, and wash this items in hot
water with dish-washing detergent.Rinse these items thoroughly to remove the detergent and let air dry.
4. TO DISINFECT: Mix one part of white vinegar with 3 parts hot water in a clean container. Submerge mouthpiece,
nebulizer cap, chamber and baffle for half an hour in the solution. Remove from solution and let air dry.
5. There is no need to clean the tubing. If necessary wipe the surface regularly.
WARNING: The nebulizer cup ( edicine container) should be changed if it got dirty or plugged.
WARNING: Do not boil, do not scald out the edicine container and the other accessories.
It is recommended to replace accessories every 6 months or 3 months- if used intensively.
Maintenance
1. The air filter in the compressor should be changed if it only starts to darken. In order to do that raise up the filter’s
cover, take out the used filter, put inside the new filter and shut the cover.Use only original filters and accessories!
Additional filters are available at the Seller or on the website: www.sklep-omnibus.pl
2. Repairs can be made only by the authoised service. The service in Poland: Omnibus Medical Equipment, 9
Grunwaldzka St., 82-500 Kwidzyn, www.omnibus-med.com.pl
WARNING: The nebulizer can be da aged, if it is used with the dirty or unoriginal filter.
DO NOT USE WITHOUT THE AIR FILTER.

Troubleshooting
Check the following if your unit should fail during operation. You can also refer to the pages of this manual for complete
instructions.
Proble Reason Solution
After switching on- the device
does not wok
Does the conduct plug to the socket? Check and plug the power cable to the socket
The lack or the weak
nebulisation during
the device`s operation
Is the medicine in the container? Pour the suitable amount of the medicine
to the container.
Minimum 2 ml maximum 6 ml
Too much or too little of medicine in
the container?
Lost, un ounted the spraying
nozzle in the edicine container?
Mount the spraying nozzle inside the
medicine container.
Is the set of accessories compunded
correctly?
Check and mount the accessories in
accodance with the instruction manual.
Is the air outlet hole in the lower part
of the medicine container plugged?
Check and clean the outlet hole (nozzle) in
the lower part of the medicine container.
Is the medicine container with the
mask or the mouthpiece tilted at the
acute angle?
Make sure, that accessories set (nebulizer
cup + mask or mouthpiece) is not tilted at the
angre more than 5 degrees
Is the air tube connected right to the
compressor?
Plug air tube properly to the compressor and
to the lower part of nebulizer cup.
Is the air tube folded or damaged? Make sure, that the air tube is correct, not
folded. I necessary- replace the tube.
Is the air tube plugged? Make sure that there are no contaminations
in the air tube.
Is the air filter dirty? Replace dirty filter for a new one.
The nebulizer woks unnaturally
loudly?
Does the filter’s cover on the
compressor’s mounted corectly?
Mount correctly the air filter’s cover plate on
the compressor.
The nebulizer hits up very much Are air vents holes (air intake) in the
compressor body covered?
During operation- don't cover air vents (air
intake) in the compressor body.
If none of the solutions bought the result , do not ty to repair the device on your own!
The rep air must be made by the manufactuer or the authrised service.
Service contact: tel.[phone]– before sending the equip ent to repair, phone and consult with the
technician!
WARRANT Y
Omnibus Medical Equipment provides 3- year warranty from the date of the nebulizer’s purchase.
In this time the change of elements which submit guaranty repairing and labour are free.
Only original spare parts are covered by the warranty. All modernizations, modifications without the agrement of the
manufacturer and the importer are
forbidden under penalty of loss of the warranty!
The manufacturer and the importer are not responsible for damages which are the result of the improper use of the
apparatus and using unoriginal accessories.
The warranty does not cover the normal consumption of the equipment duing usage and individual plastic accessories
such as masks, a fastener, a mouthpiece, an air tube, a medicine container, filters.
The product should be delivered on the own cost together with the warranty card, the proof of purchase and the damage
description directly to the firm Omnibus-Serwis, 9, Grunwaldzka St., 82-500 Kwidzyn, Poland.
All costs connected with the safe packaging, security, transport and another risk are incurred by the user.
The nebulizer is predicted for the home use and therefore the waranty does not cover the apparatus used in a
professional way in health centres, clinics, hospitals, etc.
The warranty time is prolonged in case of the necessity of import the necessary parts on the base of the written
information sent to the Customer by the Service.
In the range of matter which is not regulated by the conditions of herein warranty, the provisions of the Civil Code are
applied.

Technical data
Particle Size: **MMAD * approximately 3 microns
Appropriate Medication Quantities: 2ml minimum -6 maximum
Nebulization rate: 0.33 ml/min (by weight loss)
Aerosol Output: **0.33 ml (2ml,1%NaF)
Aerosol Output Rate: **0.06 ml/min (2ml,1%NaF)
OMNIBUS compressor nebulizer the particle size distribution curve as well:
Result of cascade impactor **measurements for particle size with OMNIBUS compressor nebulizer and
nebulizer kits:
MMAD = Mass Median Aerodynamic Diameter
Disposal
The used equipment should be utilized in accordance with the European Directive 2002/96/EC.
The device should be delivered to the special container or the specialized waste utilization point.
Marking with the emblem of the crossed – waste bin informs about the ncessity separate storage.
This product does not contain any hazardous substances.
Manufactured for:
Omnibus Sprzęt Medyczny
A.Kozłowska-Laskowska i A.Laskowski s.c.
ul.Grunwaldzka , 82-500 Kwidzyn
Poland
www.inhalatory.com.pl
tel.[phone]
Shenzhen Bi-rich Medical Devices Co. td,
No. 10th, Hongqian 2nd Road ,ShangNan, Shajing street, Bao'An district,
518125 Shenzhen City, Guangdong Province,P.R.China
EC REP: (autoryzowany przedstawiciel):
Trinium, Hakakatu 16A 1 0120 Oulu, Finland
