OmniFlow OMNILED 07 User manual

SMART IoT
PLATFORM
www.omniflow.io

OMNIFLOW OWNER’S MANUAL 2
Owner’s Manual
installation | operation | maintenance
Version: 2020.10 (US)
OMNILED
Smart IoT Platform
with Wind/Solar
and Energy storage
The OMNILED® smart energy platform for IoT is based on the award winning wind & solar hybrid
electrical power generation OMNIFLOW® concept. It is a multifunctional a device designed for
street lighting while being a power and location platform for urban monitoring, internet access
and mobile telecommunications 1.
Please read this Owner’s Manual prior to Installation and Operation of the Product.
1 Characteristics and functionalities dependent on markets and models.

OMNIFLOW OWNER’S MANUAL 3
Introduction
Welcome to the OMNILED® smart IoT platform!
This owner manual includes notes on the installation, operation and regular
maintenance instructions for safe and regular care of the OMNILED® hybrid
wind & solar smart system.
Trained and properly equipped personnel, using appropriate lifting/handling
equipment and tools, should do the installation of the pole.
If maintenance or installation/setup of any custom purpose functionality is in-
tended, the appropriate Electrical/Electronic Supplements are required
to complement this manual.
In the manual, you might have checklists to guide you through the intervention
on the OMNILED. Following these step-by-step instructions, you will insure your
installation is completed correctly.
As soon as you finish the installation, do not forget to activate the warranty,
by sending an email with the serial number(s) of the installed equipment’s and
its location(s) to info@omniflow.pt.
For any questions or comments, feel free to contact your OMNIFLOW reseller
or directly our company through info@omniflow.pt.

OMNIFLOW OWNER’S MANUAL 4
OMNILED® smart system should be installed [and maintained] by qualified
personnel using appropriate safety gear.
Never touch any stripped cable ends or un-insulated connections. The elec-
trical installation must be done by a qualified professional in accordance with
the rules in force in each country.
Never move body parts or objects through the turbine because even if this is
not in operation is easily actionable with a slight breeze.
Dont loose the rotor until all instalation is complete.
Please only install this product in open spaces without solar shading in the
device and with “clear” wind flow as suggested in page 6 diagram
Motion sensor is easy damaged if the device is not handled with care. Do
not remove the protective foams until the installation is complete and do not
touch the LED/optic lens with your bare hands.
Check communications in OmniConnect platform. This should be done
1-5min after connection the fuse with the lifting equipment still in place in
case anything is not correct. Do the LED test if unit has LED’s.
Safety Instructions
Caution: Please read these instructions carefully before installation

OMNIFLOW OWNER’S MANUAL 5
Technical Data OMNILED 07
Dimensions (W/H/D) ft [m] 3.94 [1.2] / 1.0[0.3] / 3.94 [1.2]
Generator Direct drive, ironless stator permanent magnet generator
DC controller Hybrid wind/solar regulator
Power Wind - 100Wp / Solar - 60Wp + (optional Extra solar 60Wp PV)
Weight lb [kg] 77.16 [35] – 132.28 [60]
Device type Grid connected or O-Grid ( depending on the load)
Battery 500Wh C10 Lead Crystal (optional extension to 1000Wh)
Pole height ft [m] 20 [6] or 26 [8] or 40 [12]
Lighting power 30 W or 45W (up to 120W on-grid)
Luminance lumen 5100 lm or 6800 lm (18600 lm @120W]
Color temperature 4000K
Optional equipment
(if detailed in the packing list):
Wi-Fi Router
IP Camera
Extra Solar PV
Extra Battery
Grid-Tie.
In the OMNILED box there should the complete functional platform and a plastic bag with (1) a
set of fixing screws, bolts and washers, (2) a fuse, and this manual with the serial number of the
equipment.
Take the OMNILED out of the box, while keeping the protecting foam spacers in place.
Specifications
Caution: Please read these instructions carefully before installation
Unpacking

OMNIFLOW OWNER’S MANUAL 6
Use a safe lifting device to
position the OMNILED in to the
top of the mast previously fixed
to the foundations.
Only use masts/foundations or
projects provided or approved
by Omniflow.
Installation

OMNIFLOW OWNER’S MANUAL 7
Insert the fuse
1
4
Install the Omniled.
Keeping the protections.
Verify communications
2
5
Insert the bolts into
the holes and tighten
Drill the mast
Using the mold
(Recommended drill size M11 / Metal thickness 4mm)
3
6
Remove the protections
after installation
Install the Omniled after mast installation
PIR sensor
Bolt tightening torque
Bolt Size (mm) Strength Grade (N·m)
10 33
The OMNIFLOW® should be ready for operation

OMNIFLOW OWNER’S MANUAL 8
Grid-Tie cable will come out of the center metallic structure
Live Earth Neutral
Optional Equipment (GRID-TIE):

2H
2H
H
20H
Region
of highly
turbulent
OMNIFLOW OWNER’S MANUAL 9
Situation Solution
Lights don’t turn on Check if the fuse was installed or it is damaged
Normal if it is the first time running and batteries are not charged
Rotor spins faster than usual Normal if there is high wind
Rotor spins at low speed Check if there is enough wind
Rotor spins at low speed Check for tall buildings or trees in the direction
of the prevailing wind *** (check diagram)
Rotor spins at low speed Normal when the batteries are fully-charged
Frequently asked questions
Eect on the wind of an obstruction
(buildings or trees)

OMNIFLOW OWNER’S MANUAL 10
The warranty is 24 months from the date that equipment becomes in Client responsibility.
Client should also communicate by email the serial number(s) of the installed equipment’s
and its working location to info@omniflow.pt, with a subject line “Warranty OMNIFLOW”.
Warranty may be void in the following situations:
•If the product is used with an accessory, equipment or part that does not meet product
specifications.
• Manufacturer warranty if the products are not supplied by Omniflow S.A. representatives
and/or its accredited reseller/installer.
•If the products are not used or maintained in accordance with the instructions provided
by Omniflow with respect to placement, operation and maintenance.
•Any defect arising from intended damage, negligence, abnormal working conditions,
failure to fulfill Omniflow instructions, misuse or alteration or repair of Products without
Omniflow’s approval.
•If the products are not used in normal operation conditions.
•If damages are from normal wear or tear.
• If the products are repaired, altered or modified not in accordance with Omniflow
manufacturer’s instructions.
• If the products are opened and altered with other electronics not supplied by Omniflow.
Equipment’s being returned to distributor/manufacturer should be properly packaged to protect
from damage during transportation. Shipping and insurance costs required to return to Omniflow,
SA or its Distributor(s) are the solely responsibility of customer.
Before returning the product, we require the following information:
•Product Serial Number
•Description of the problem
•The location of the installation
Upon verification of failure due to defects in materials or workmanship,
Omniflow will either repair or replace the product at our discretion.
Periodic visual inspection of the equipment should be taken, in particular to check whether:
• The rotor rotates freely;
•There is accumulated dirt in the Photovoltaic panel;
•Any sign of corrosion of the metallic components;
•Any visible damage especially after a storm;
Please check the maintenance manual for more information
In the event of any irregularities, please contact nearer Omniflow distributor
Maintenance
Warranty

Contacts
Omniflow SA,
Rua Delfim Ferreira, 776-C
4100-199 Porto | Portugal
info@omniflow.pt
www.omniflow.io
