Omnitech OMT724 User manual

4 port UHF RFID reader/writer
User manual
Connection diagram
RS232
The reader provides RS232 communication interface to communicate with PC
The data format of RS232 is 8 data bits, one start bit , one stop bit and no parity bit;
Data rate can be 9600,19200,57600 and 115200.
TCP-IP
This reader supports RJ45 (Ethernet) interface.
DB15 definition :
DB15 pin assignment
Pin 1 2 3 4 5 6 7 8
function Output 2 Output 1 GND Output 4 Output 3 GND Input 1 Input 2
Pin 9 10 11 12 13 14 15
function GND A+(RS485) B-(RS485) GND spare spare spare
4 antenna port
p
owe
r
RS232GPIO TCP/IP
OMT724 UHF Reader/writer RS232

RS485 :
RS485 can be connected with PC interface using the RS232-RS485 converter.
With this mode, RS485 interface supports all the functions as RS232 .
GPIO Port :
This reader support 4 output port （0-3）, user can set it to high or low level :
(when power up default is high level output）
Head Addr Len Cmd Parameter Parameter Check
0x0A 0x04 0x2D Num level cc
Num : IO port number (0~3)
Level : output level : 0 is low level, 1 is high level.
Baud rate is : 9600 ,
If success will return: 0x0B AA 02 00 09
Input Port :
This reader support 2 input port (1-2), please refer to below:
GND
Input 2
Input 1
Specification: PC enquiry Reader input, Input status command as below: :
Head Addr Len Cmd Check
0x0A FF 0x02 0x2E C7
When reader received, it will get response as below:
（1） When 2 Input are suspend（Input 1 and Input 2 are high level）, return
Head Addr Len Status Parameter Check
0x0B 0x03 0x00 03 cc
（2） When Input 1 in low level, Input 2 will be in high level, return
Head Addr Len Status Parameter Check
0x0B 0x03 0x00 01 cc
（3） When Input 2 in low level, Input 1 will be in high level, return
Head Addr Len Status Parameter Check
0x0B 0x03 0x00 02 cc
（4） When Input 1 and Input 2 are in low level, return
Head Addr Len Status Parameter Check
0x0B 0x03 0x00 00 cc
Remark :Input default is suspend status and is high level（5V）
PC
UHF
Reader

Tag operate
ISO18000-6B Tag :
 Multi-tag identification: search all the tags in the detection range and read the
UID of 8 bytes.
 Multi-tag reading: search all the tags in the detection range and read the 8
bytes data of the appointed address
 Single tag writing: write one byte data in the appointed tag address.
 Single tag locking: lock the data of the appointed tag address. After that, it
can not rewrite.
 Single tag locking and inquiring: inquiry the locking state of the appointed
address.
EPC GEN2（ISO18000-6C）tag
 Multi-tag identification: search all the tags in the detection range and read the
EPC. (supports 96 bits EPC)
 Single tag initialization: define the length of EPC, generally 96 bits.
 Single tag writing: write the EPC of tag, one block (16 bits) one time.
 Single tag locking: lock the EPC of tag. After that, the EPC of tag can not be
rewrite.
 Single tag killing: kill tag. After that, the tag can not be used again.
Operation mode
Command operation mode:
The reader and the controller can communicate through RS232, RS485 or Ethernet.
This working mode supports all the functions that secondary development provides.

Demo Program Guide
[1] connected the reader with PC via RS232 or RJ45
[2] Run demo program from path:\\CONFIG\UHF reader demo.exe
Close DEMO software
Click on “EXIT “ to close the program
DEMO reader operation
Connect Reader with PC through RS232 cable
a) Serial Port connection : select the correct Com Port and Baud rate（9600～
115200 optional）.
Click“Connect＂button . If success , connect button will change to be gray
color and the information list will be shown as follow :

b) TCP/IP – Setting
Before run with TCP/IP connection, pls make sure the IP address can match with
your network.
The IP address can be set through RS232 by following steps :
[1] Connect the reader with PC through RS232 .
[2] click on “connect” and select “R/W device config” as below :
[3] click “Query” to check the current IP address setting .
[4] If it is not match with your network setting, you can change the IP Address ,
Mask code & gateway
e.g 196.168.000.001 for Gateway
(need input 3 digit value / section e.g. “000”)
Below error message will be found , if input an incorrect format (e.g. “0” or “00”)
[5] click on “Set” to save after input the correct setting
[6] click on “Reset” to reset the reader to active the new setting
TCP/IP - connection
Connect the reader with the network hub through TCP/IP , then input the reader’s IP
address and port number (default 100).
Click“Connect＂button . If success , connect button will change to be gray color
and the information list will be shown as follow :

Setting（query）reader power and frequency
Query reader’s power and frequency : click“Query＂button, it will show the
reader current power and frequency as chart A :
Set reader’s power and frequency : first select power parameter and frequency
（China:902-928MHz, AMERICA:ISM902-928MHz, EUROPEAN:ISM865-868MHz）,
then click“Set＂button as chart B
Chart A chart B
Antenna set and query
Query working antenna :click“Query＂button, it show reader current
working antenna ,
set working antenna :select working antenna, click“Set＂button
ISO18000-6B tag operate
Click “ISO6B Tag operate” from menu as follow :
Identify Tag

Select identity tag times（default as continue）, tag identify the time（default is
10ms）then click “Start” button, reader get to tag identify status, when read the
tag will show as below:
6B6B identify and details record
Read the tag total numbers
Tag read and write
Tag read : Read ISO18000-6B tag’s data
First select one tag(identify the tag first, and then select), select the tag’s content
start address (Address), data length（Data Length）, then click“Read Data＂button,
if read success , the data will be shown in as below information bar :
Remark :ASCII option is valid, read the data is ASCII code, if not valid then it is hex
data format.
Tag Write : write ISO180006B tag’s Data
First must select one tag（identify the tag first, and then select）, select the tag’s
content start address（Address）, data length（Data Length）, in“Data Input＂
bar input the data want to write（can be Chinese character, number or letter）, then
click“Write Data＂button, after write success, successful information will be show
in the bar as below :
Tag lock operate
Query tag lock : select query address, then click“Query Lock＂, if query
success the information will show in the information bar ,
Lock tag operate : select the address that want to lock, then click“Lock Tag＂,
if lock success the information bar will show below ,

ISO18000-6C(EPC-G2) tag operate
Click “EPCTag operate” from menu as follow :
Tag Identify
Select identity tag times（default as continue）, tag identify the time（default is
10ms）then click “Start” button, reader get to tag identify status, when read the tag
will show as below:
EPC multi tag identify success and detail record
Identify tag total quantity
EPC GEN2 Read and Write
Need Stop “Identify Tag” operation before to read/write data to the tag

EPC-G2 read
Select Membank（Membank）, option include“KILL PWD＂,“ACCESS PWD＂,
“EPC CODE” ,“TID CODE＂
“USER DATA＂, then select address“Address＂and data length“Data Length＂,
click“Read Data＂button, if read success the data will show in the information bar
as below :
EPC read success
EPC-GEN2 Write
Select membank（Membank）, option include“KILL PWD＂,“ACCESS PWD＂,
“EPC CODE” ,“TID CODE＂
“USER DATA＂, （different tag with different memeory）then select address
“Address＂and data length“Data Length＂, in“Data Input＂bar input the write
data（HEX format）, click“Write Data＂button, if write success the data will be
show in the information bar（when write success the reader will send out short
beep）as below :

EPC-GEN2 Initialize
Put the tag in the reader reading range, then click“Initalize Tag Data＂button,
See below information bar to show the result :
PC-G2 tag lock
Select the write bank“Bank＂, then click“Lock Tag＂button, if lock success the
information bar will show below, as below :
Note :once the tag locked, it can’t unlock, only can lock the bank.
EPC-G2 KILL
Select bank“Bank＂to[KILL PWD], in“Passeord＂bar input kill password, then click
“Kill Tag＂button, if the kill success it will show you below information :
Remark : if the tag password is 0, it can’t be kill, once the tag be kill it can’t be use
any more
