Omron Sysmac F430-F Series Instruction Manual

Machine Automation Controller
NX Series
General Ethernet (TCP/IP) Connection
Guide
Smart camera
F430-F Series
Z443-E-01

About Copyrights and Trademarks
Screenshots of elements of Microsoft products are used with permission from Microsoft
Corporation.
Windows is a registered trademark of Microsoft Corporation in the USA and other countries.
ODVA、EtherNet/IPTM are trademarks of ODVA.
Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in
Japan and other countries for OMRON factory automation products.
Company names and product names in this d
ocument are the trademarks or registered
trademarks of their respective companies.

Contents
1. Related Manuals ........................................................................................ 3
2. Terms and Definitions ............................................................................... 4
3. Restrictions and Precautions................................................................... 5
4. Overview .................................................................................................... 6
5. Applicable Devices and Device Configuration ....................................... 7
5.1. Applicable Devices............................................................................. 7
5.2. Device Configuration.......................................................................... 8
6. Ethernet Settings..................................................................................... 10
6.1. Ethernet Communications Settings .................................................. 10
6.2. Communication Verification Example................................................11
7. Steps for Connecting .............................................................................. 12
7.1. Operation Flow................................................................................. 12
7.2. Smart Camera Setup ....................................................................... 13
7.3. Controller Setup ............................................................................... 18
7.4. Check the Connection Status........................................................... 24
8. Initializing the System............................................................................. 27
8.1. Controller ......................................................................................... 27
8.2. Smart camera .................................................................................. 27
9. Project file ................................................................................................ 28
9.1. Overview .......................................................................................... 28
9.2. Partner Device Command................................................................ 32
9.3. Error Judgment Processing.............................................................. 35
9.4. Variables Used ................................................................................. 37
9.5. Program (ST Language) .................................................................. 42
9.6. Timing Chart..................................................................................... 60
9.7. Error Processing .............................................................................. 66
10. Revision History .................................................................................. 70

3
1. Related Manuals
To ensure system safety, make sure to always read and follow the information provided in all
Safety Precautions and Precautions for Safe Use in the manuals for each device which is
used in the system.
The following Omron Corporation (hereinafter referred to as "Omron") manuals are related to
this document:
Manual No. Model Manual Name
W535 NX Series NX Series CPU Unit User's Hardware Manual
W593
NX Series
NX Series NX102 CPU Unit Hardware User's Manual
W578 NX Series NX Series NX1P2 CPU Unit Hardware User's Manual
W501 NJ/NX Series NJ/NX Series CPU Unit Software User's Manual
W506 NJ/NX Series NJ/NX Series CPU Unit Built-in EtherNet/IP Port User’s
Manual
W504 SYSMAC-SE2□□□ Sysmac Studio Version 1 Operation Manual
W502 NJ/NX Series NJ/NX Series Instructions Reference Manual
Z433
F430-F Series
Smart Camera F430-F Series User Manual
Z444
F430-F Series
Smart Camera F430-F Series User Manual for
Communications Settings

4
2. Terms and Definitions
Below is a list of terms used in this manual and their definitions.
Term
Description / Definition
IP Address Ethernet communicates using an IP address.
An IP address (Internet Protocol address) is an address for identifying a
node (host computer, controller, etc.) on Ethernet.
IP addresses must be set and managed so that there are no duplicate
addresses on the network.
Socket A socket is an
interface that allows you to directly use TCP or UDP
functions from the user program.
The NJ/NX Series machine automation controller performs socket
communication using the standard socket service instruction.
To use the socket service, you need to establi
sh and disconnect a
connection with the other node. In this document, the establishment
process is called "socket open" or "TCP open", and the disconnection
process is called "socket close" or "close".
Socket service allows you to send and receive arbitrary data with another
node.
Active and Passive
When a TCP socket connection is established, open processing is
executed on each node.
Currently
, the open method differs depending on whether the node
becomes a server or a client.
In this document, processing
when opening as a server is called
"Passive Open", and processing when opening as a client is called
"Active Open" or "Open Processing (Active)".
Keep-alive Function If the TCP / IP socket service does not communicate with the other node
(server or client) for longer than the set time, the keep-alive
communication frame is used to check the connection with the other
node.
If there is no response, confirmation will be performed at regular
intervals, and if there is no response to all confirmations, the connection
will be disconnected.
Linger It is an option of TCP socket that enables open processing by the same
port number immediately without sending RST data at TCP socket close
and waiting for port number release.
If the linger option is not specified, FIN data will be issued when TCP is
closed, and termination management such as delivery confirmation will
be performed with the other node in about 1 minute. For this reason, it
may not be possible to use the TCP socket of the same port number
immediately.

5
3. Restrictions and Precautions
(1) Understand the specifications of devices which are used in the system. Allow some
margin for ratings and performance.
(2) Provide safety measures, such as installing a safety circuit, in order to ensure safety and
minimize the risk of abnormal occurrence.
(3) To ensure system safety, make sure to always read and follow the information provided in
all Safety Precautions and Precautions for Safe Use in the manuals for each device which
is used in the system. The user is encouraged to confirm the standards and regulations
that the system must conform to.
(4) It is prohibited to copy, to reproduce, and to distribute a part or the whole of this document
without the permission of OMRON Corporation.
(5) The information contained in this document is current as of January 2020.
It is subject to change for improvement without notice.
The following notations are used in this document.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or may result in serious
injury or death. Additionally, there may be severe property
damage.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury, or property damage.
Precautions for Safe Use
Precautions on what to do and what to avoid doing to ensure the safe use of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Note
Additional information to read as required.
This information is provided to increase understanding and make operation easier.

6
Symbols
● This indicates operations that you must do.
The specific operation is shown in the circle and
explained in text.
This example shows a general precaution for
something that you must do.
4. Overview
This document describes the procedures for connecting the Omron smart camera (F430-F
Series) to the NX Series Machine Automation Controller (hereinafter referred to as Controller)
via EtherNet/IP), and for verifying their connections.
Ethernet communication connection can be made by understanding the setting procedure and
the point in setting through Ethernet communication setting of the project file prepared in
advance.
In this project file, the Ethernet connection is checked by sending a measurement execution
command to the smart camera and receiving the measurement data from it.
Please prepare the latest file of "Sysmac Studio project file" from Omron beforehand.
Name Filename Version
Sysmac Studio Project File
(Extension: SMC2)
OMRON_F430_NX_ETN(TCP)
_V100.SMC2
Ver.1.00
The purpose of this document is to explain the wiring method, the
communication settings required for
connection of the devices and the step by
step setting procedure. The program included with the document was created
using the same procedures and can be used to confirm that all the settings have
been made correctly and that a connection can be establishe
d (Confirm
Connection). It is not a program created on the premise of constant use in the
field, so its functionality and performance aspects have not been fully
considered. When building an actual system, it is necessary to refer to the wiring
method and
communication setting contents and setting procedures described
in this document, and to design a new program according to the customer's
purpose for the program.

7
5. Applicable Devices and Device Configuration
5.1. Applicable Devices
The applicable devices that can be connected are as follows:
Manufacturer Name Model Version
OMRON
NX Series CPU Unit
NX701-□□□□
NX102-□□□□
NX1P2-□□□□
Same or
higher
version as
indicated in
section 5.2.
OMRON Smart camera F430-F□□□□□□□-□□□
Note
This document describes the procedure for establishing the communication connection of the
device, and does not describe the operation, installation and wiring method of the device.
For detailed information on the above products (other than communication connection
procedure), please refer to the instruction manual of the product or contact OMRON.
Note
In this document, from among the above target devices, connection confirmation is
performed using the devices listed in section 5.2. When using a device that is not described
in section 5.2. Among the above target devices, check the connection referring t
o the
contents of this document.
Precautions for Correct Use
In this document, the devices with models and versions listed in section 5.2.
You cannot use devices with versions lower than the versions listed in section 5.2.
To use the above devices with models not listed in 5.2. or versions higher than those listed in
5.2., check the differences in the specifications by referring to the manuals before operating
the devices.

8
5.2. Device Configuration
The system components required for reproducing the connection procedures described in this
document are as follows.
Manufactur
er
Name
Model
Version
OMRON
NX Series CPU Unit
(Built-in EtherNet/IP Port)
NX1P2-9024DT
Ver.1.16
OMRON
Switching hub
W4S1-05C
OMRON
Sysmac Studio
SYSMAC-SE2□□□
Ver.1.29
OMRON
Sysmac Studio Project File
OMRON_F430_NX_EIP_
V100.csm2
Ver.1.00
-
Computer (OS: Windows 10)
-
-
LAN cable (STP (shielded,
twisted-
pair) cable of Ethernet
category 5 or higher)
-
OMRON
Smart camera
F430-F000M12M-SWA
Ver.5.2.0
OMRON
I/O cable
V430-W8-3M
OMRON
Ethernet cable
V430-WE-3M
-
DC24V Power supply (Smart
camera)
-
Precautions for Correct Use
Please prepare the latest file of "Sysmac Studio project file" from Omron Corp. beforehand.
(Contact Omron for information on how to obtain these files.)
Note
If the device configuration or versions are different, it may not be reproducible. After
confirming the configuration, models and versions, if it is different from your configuration,
please contact Omron.
Note
In this document, a USB connection is described. For information on how to install the USB
driver, refer to A-1 Driver Installation for Direct USB Cable Connection in Appendices of the
Sysmac Studio Version 1 Operation Manual (Cat. No. W504).
Ethernet cable
V430-WE-3M
F430-F000M12M-SWA
I/O cable
V430-W8-3M
DC24V
DC24V
PC/
(Windows 10, with
Sysmac Studio installed
OS: Windows 10)
LAN cable
NX1P2-9024DT
(Built-in EtherNet/IP Port)
Switching
hub
W4S1-05C

9
Note
Refer to "Industrial Switching Hub W4S1 Series User Manual" (0969584-7) for power supply
specifications that can be used for 24 VDC power supply (for switching hub).
Note
Refer to the "Smart Camera F430-F Series User Manual" (Z433
) for the power supply
specifications that can be used for DC24V power supply (for Smart camera).

10
6. Ethernet Settings
This manual explains communication parameter specifications and cable wiring.
Note
This document and this project file can only operate with the settings and commands
described in this chapter. For communication other than this setting, it is necessary to modify
the project file.
6.1. Ethernet Communications Settings
The settings for establishing Ethernet communication are as follows.
6.1.1. Communication setting between setting PC and Smart Camera
In this document, the setting procedure of the smart camera by the setting PC is explained
using the setting contents in the table below as an example.
Setting item On PC used for settings Smart camera
IP Address 192.168.188.100 192.168.188.2 (default)
Subnet mask 255.255.0.0 255.255.0.0 (default)
Gateway Blank ( default) 0.0.0.0 (default)
* For the use cases in this document, setting the gateway is unnecessary because the
devices are connected within the same segment of the network.
6.1.2. Communication Setting Between Ethernet Unit and Smart Camera
The connection procedure of the Ethernet unit and the smart camera is explained using the
settings in the table below as an example.
Setting item NX1P2-9024DT
(Built-in EtherNet/IP Port)
Smart camera
IP Address 192.168.188.1 192.168.188.2 (default)
Subnet mask
255.255.0.0
255.255.0.0 (default)
Gateway - 0.0.0.0 (default)
Port number (Set in the software) 49211 (Default)
* For the use cases in this document, setting the gateway is unnecessary because the
devices are connected within the same segment of the network.

11
6.2. Communication Verification Example
In this document, a program in structured text (hereinafter, ST) language is used as an
example when executing "socket open", "send / receive" and "socket close" from the controller
to the smart camera.
The controller sends an “inspection trigger command” to the smart camera. The smart camera
sends its output data to the controller.
The Overview of the operation is shown below.
CPU EtherNet/IP Port Ethernet Smart camera
Project file
ST Language Program
Local_
SrcData
Variable
Local_
RecvData
Send Data
Area
Socket
Socket Open
Receive Measurement
data
Send serial command
TRIGGER (Measurement
trigger command)
Send Data
Socket Close
Measurement data
Measure
Received
data area

12
7. Steps for Connecting
This section describes the procedures for setting up an Ethernet connection on the controller
(PCL).
The explanations of procedures for setting up the PLC and smart camera given in this
document are based on the use of the factory default settings. If re-initializing the devices is
required, refer to Section 8. Initialization Method.
7.1. Operation Flow
Use the following procedures to set up an Ethernet connection on the controller (PLC).
7.2. Smart Camera Setup
Set up the Smart camera.
▼
7.2.1. Install the (AutoVision) software
Install the (AutoVision) software application used for
setting up the Smart camera.
▼
7.2.2. Set Parameters
Set the parameters for the Smart camera.
▽
7.3. Controller Setup
Set up the Controller.
▼
7.3.1 Start Sysmac Studio and load the
project file
Start the "Sysmac Studio" (Automation Software)
and load the Project File in to Sysmac Studio.
▼
7.3.2 Verify parameters and execute
builds
Check the configuration parameters and execute
program check and build of the project data.
▼
7.3.3 Connect online and transfer
project data
Connect online in Sysmac Studio and transfer the
project data to Controller.
▽
7.4 Check the Connection Status
Execute the transferred project file and check that
Ethernet communication is performed correctly.
▼
7.4.1. Run the project file and confirm
the receive data
Run the project file and check that the correct data is
written to the controller variable.
Precautions for Correct Use
Please prepare the latest file of "Sysmac Studio project file" from Omron Corp. beforehand.
(Contact Omron for information on how to obtain these files.)

13
7.2. Smart Camera Setup
Set up the Smart camera.
Precautions for Correct Use
Use a PC (personal computer) to set the parameters for the smart camera.
Note that there may be some changes required for the PC settings depending on the current
state of PC.
7.2.1. Install the (AutoVision) software
Install the (AutoVision) software application used for setting up the Smart camera. For
more details on installing the Autovision software, please refer to the “AutoVision Quick
Start Guide” (Z434).
7.2.2. Set Parameters
Set the parameters for the Smart camera.
Set the IP address of your computer to "192.168.188.100" and its subnet mask to
"255.255.0.0".
1
Connect the [Ethernet
connector] of the smart camera
to the switching hub with the
[Ethernet cable].
Connect the [I/O cable] to [I/O
connector] and turn on the
24VDC power supply.
*This document is only for
verification of the power
supply wiring of the I/O cable
connection. Be careful not to
short-circuit any other wires.
*Ground the shielded wire as
needed. For more information
on Grounding, please refer to
the "Smart Camera F430-F
Series User Manual” (Z433) -
"2-7 Grounding and Power"
2
Connect the computer to the
switching hub
with the LAN
cable.
Connect 24 VDC power supply
(for Switching hub) to Switching
hub.
DC24V Power Supply
DC24
V
I/O
Connector
Switching
hub
Ethernet
Connector
I/O cable
V430-W8-3M
Ethernet cable
V430-WE-3M
LAN Cable

14
3
Set the IP Address of the PC.
Set the IP Address to
"192.168.188.100"
set the subnet mask to
"255.255.0.0".
Refer to Step 4 for the
procedure to open the dialog on
the right on a Windows 7
system.
4
(1) From the Windows Start menu, select Control Panel - Network and
Internet - Network and Sharing Center.
(2) Click on Local Area Connection. The Local Area Connection Status Dialog Box is
displayed. Click Properties.
(3) In the [Local Area Connection Properties] dialog box, select [Internet Protocol Version 4
(TCP / IPv4)], and click the [Properties] button.
(4) Click the "OK" button
5
Launch the AutoVision software.
6
After starting AutoVision, if the
smart camera is displayed in the
device selection list, proceed to
Step 8.
If the AutoVision startup screen
does not appear, go to step 7.
7
If the AutoVision startup screen does not appear, it means that communication between the
smart camera and the PC has not been established so please check the following.
・
Does the F430 and the PC have a proper physical (cable) connection?

15
・
Are the respective IP Addresses on the PC and on the F430 smart camera set correctly?
→ Refer to 4. for setting the IP Address of the PC.
・Do a hardware reset of the F430.
→ When turning the power on, press and hold the setup button on the smart camera body
until its light turns on.
8
After selecting the smart
camera, the settings screen will
display.
Check the settings indicated by
the red boxes.
If you need to change the IP
address, for example when
connecting multiple F430
devices, change the setting
from [IP address] as necessary.
9
Create a new job and set the
"Locate Shape", "OCR" and
"Decode" tools.
* In this chapter, you will create
a job to output the detection
points from the Locate Shape
tool, the text string read by the
OCR tool and
character text
decoded from a 2D Code using
Serial(TCP/IP) communications.
10
Select the camera tool and set
the trigger to "Serial Trigger",
"TCP / IP 1: (Port 49211)", "T".

16
11
Click on Inspection Outputs and
in its menu select “TCP/IP and
Serial Out”.
12
In the popup dialog, set "String
output port" to "TCP1 (49211)".
13
Click the
icon in the
Output String and select Output
Value.

17
14
Click the icon in the red frame
and select the data to output.
Here, select the location from
“Locate Shape”.
When selected, the current
value is displayed in the "Output
String" part of the red frame.
15
Repeat steps 13-14 to build the
output string.
16
Go to Run view and download
the job to smart camera.

18
17
The download is complete when
you can successfully transition
to the Run screen.
7.3. Controller Setup
Set up the Controller.
7.3.1. Start Sysmac Studio and Load the Project File
Start the "Sysmac Studio" (Automation Software) and load the Project File in to Sysmac
Studio.
Install Sysmac Studio and USB driver on the computer beforehand. Also, connect the USB
cable to the PC and the controller, and turn on the controller power.
1
Start Sysmac Studio.
Click Import.
* If the User Account Control
Dialog Box is displayed at
startup, select the option to
start.

19
2
The [Import project] dialog is
displayed. Select
[OMRON_F430_NX_ETN (TCP)
_V100.SMC2] (Sysmac Studio
project file), and click [Open].
* About Sysmac Studio Sample
project file for Smart camera
F430-F Series Machine
Automation Controller NX
Series General Ethernet
(TCP/IP) Connection Guide,
contact your OMRON
representative.
3
The
[OMRON_F430_ETN(TCP)_V1
00] project screen is displayed.
The left side of the screen is
called "Multiview Explorer", the
right side is called "Toolbox",
and the center is called "Edit
window".
Multiview
Explorer
Edit PaneEdit Pane
Tool Box
