OMS-i Sanity Air User manual

Sanity Air User manual

2
index
01. The device
• general
• Manufacturer identification
• Equipment identification
02. Precautions for use
• feeding
03. General Warnings
• Before using the device
• elimination
04 Technology
• Technical data
05 Installation and Use

3
Sanity Air reserves the right to modify the product and its technical
documentation without incurring any obligation to third parties and
assumes no responsibility for errors or inaccuracies in the content of this
manual. This document describes serial device features from the date
this publication is licensed for printing.
In case of equipment failure and/or malfunction, turn it off (disconnect
the power supply). Any repair of the products must be performed only
by a manufacturer-authorized Service Center, using original spare parts.

4

5
Sanity Air S.L.
Calle Valdemorillo, 6
28925 Alcorcón. Madrid
[e-mail]
www.sanity-air.com

6
•
•

7
Always follow the precautions below to avoid the risk of serious injury,
serious damage to people or things, due to electric shocks, short
circuits, fires or other hazards!
CAUTION: Under no circumstances open or alter the device. Maintenance
or repair operations must be performed exclusively by authorized technical
personnel, other than doing so automatically will result in the IMMEDIATE
SUSPENSION OF THE WARRANTY.

8
ELECTRIC NETWORK DANGER
Always disconnect the power supply from the device before doing any
work on it to avoid health risks and damage. Do not pull the power cord
to unplug or transport it.
Any handling, maintenance, repair and hygiene of the systems must be
carried out by authorized technicians duly trained and authorized by the
manufacturer.

9
The room that will house the systems, materials, accessories and consumer products must
comply with the storage, use and safety requirements of the regulations in force. The
equipment should be used for the specific use for which it was intended. The manufacturer is not
responsible for the consequences of incorrect use of the equipment. The manufacturer
assumes no responsibility for the consequences of incorrect use of the equipment. Any
malfunction of the systems should be reported immediately to the nearest Support Center or
distributor.
Sanity Air is not responsible for the consequences of prolonged use of the device that
has revealed anomalies. Any maintenance or repair work must be performed only by
authorized personnel. The manufacturer disclaims all liability for any damage to
persons or things caused by non-compliance with what is reported in this
manual.
The manufacturer disclaims all liability for any damage caused to persons or things
for repairs not performed by professionally qualified and authorized personnel, this
would imply the cancellation of the warranty; it will cease without the necessary periodic
care and maintenance of the device and the replacement of original components
by others that are not, nor are they recommended by the manufacturer.
In accordance with current legislation, the device must be connected to a power outlet equipped
with an efficient pounding. The device operates at 230Vac-50Hz; voltage variations greater than
5% of the nominal value can damage electrical parts. The device is free of radio interference in
accordance with EEC Directive 87/308 of 14/04/1989. The device should be intended for use
only for which it was designed, i.e. for air treatment.
To carry out any type of operation on the equipment, the following safety
precautions should be followed for people and things.
In particular, note the following points:
• Read carefully everything reported in the manual.
•Read the reference rules.
The manufacturer disclaims all liability with respect to the use of the equipment in case
of non-compliance with the requirements of the manual provided as an integral
part of the supply.
1. The device should only be used by adults. Make sure the children do not touch the
This device requires regular periodic maintenance to ensure the
requirements declared by the manufacturer.

10
controls and do not play with the device.
2. Packaging elements should not be left within reach of children as a potential source of
danger.
3. During the warranty period, no intervention can be performed without the prior
authorization of the Assistance Center, distributor or manufacturer. If this is not
accounted for, the warranty will end automatically.
4. The manufacturer reserves the right to modify the product and related technical
documentation without incurring any obligation to third parties.
Waste
The "WEEE Decree" (Waste electrical and electronic equipment) is
italy's transposition of European Directives 2002/95/EC, 2002/96/EC and
2003/108/EC on restricting the use of certain hazardous substances in
electrical and electronic equipment and in end-of- life management.
The WEEE logo (shown on this paper) on the product or sales package
indicates that the product in question should not be disposed of or disposed of in household
waste.
It is the user's responsibility to dispose of disused system components or that can
no longer be used in accordance with current regulations.
The product must not be disposed of as special waste and must be delivered to a
collection centre suitable for recycling electrical and electronic equipment.
For more information on the management, disposal and waste collection points of
electrical and electronic equipment, please contact local administrations.
The UVC lamp inside the equipment is made up of materials that we can recover and
recycle in order to defend the environment. They consist of a quartz glass tube,
two tungsten or wolfram (W) electrodes, two ceramic supports and two
connections. The glass tube is sealed and contains a small amount of mercury (a
few milligrams) and a series of gases (mainly nitrogen). Once their service life is
complete, it is recommended that they be placed in closed containers, avoiding
breakage and then sending them to an authorized waste manager.

11
04 TECHNOLOGY
The device is intended only for the use for which it was expressly provided,
STERILIZATION OF ENVIRONMENTS to reduce the bacterial, fungal and viral load of the
environment. This allows you to reduce the chance of cross infections. The device can be used
in all environments where it is important to reduce microbial contamination (hospitals,
nursing homes, medical offices, public environments, means of transportation, motor
vehicle accessories, food companies, pharmaceutical companies, etc.). It should always be
used strictly in compliance with the provisions and warnings contained in this manual.
The process is to attract and circulate the air inside Sanity Air filter and disinfect it: the
suspended droplets are purified by active carbon filters while the entire volume of air is
sterilized by ultraviolet rays (UVC), thus ending with any pathogens it may contain, all
without adding chemicals or biocides that may be harmful to our health.
The result is a clean air, free of infectious appends, totally harmless to health and the
environment.
The operation of Sanity Air is a highly tested and widely used solution in places especially
sensitive to possible infections such as laboratories, operating rooms, water purification,
etc.
In addition to being safe for the environment and health it is designed to make its energy
consumption low, allowing its continued use and an incomparable profit-cost ratio.

12
SANITY AIR M
SANITY AIR L
SANITY AIR XL
SANITY AIR
TRANSPORT
SANITY AIR
VAGOON
SANITY AIR
ELEVATOR
230V AC
230V AC
230V AC
12-24V DC
12 - 24V DC
230V AC
ELECTRIC
CONSUMPTION
35/41W
70/150W
230
35/41W
34/41 W
20/25 W
AIR SUPPLY
50 m3/h
100 m3/h
150 m3/h
50 m3/h
53 m3/h
10m3/h
SURFACE MAX.
ADVISABLE
202 m3 (75m2
x 2.7m)
150m2 x 2.7m
675 m3 (300m2
x 2.7m)
202 m3 (75m2 x
2.7m)
72 m2
lift
99.97% Filtered
Air
99.97% Filtered
Air
99.97% Filtered
Air
99.97% Filtered
Air
99.97% Filtered
Air
99.97% Filtered
Air
ACTIVE AND
CELLULOSE
CARBON
ACTIVE AND
CELLULOSE
CARBON
ACTIVE AND
CELLULOSE
CARBON
ACTIVE AND
CELLULOSE
CARBON
ACTIVE AND
CELLULOSE
CARBON
ACTIVE AND
CELLULOSE
CARBON
CARBON STEEL
EPOXI
COATING
CARBON STEEL
EPOXI COATING
CARBON STEEL
EPOXI COATING
CARBON STEEL
EPOXI COATING
CARBON STEEL
EPOXI COATING
CARBON STEEL
EPOXI COATING
DIMENSIONS
(mm)
570 X 200 X
160
570 X 335 X 165
1070 X 370 X
290
500 X 300 X 100
500 x 300 100
134 x 134 x 383
DIMENSIONS
WITH BOX
(mm)
600 X 205 X
205
590 X 340 X 175
1132 X 395 X
320
APPROX.
WEIGHT WITH
PACKAGING
6.8KG
10.15 KG
27KG
4.5KG
4.5 KG
3 KG
40.5 Dba at 2
meters
Note:
In the Netherlands we have Sanity Air BASIC (M) and Sanity Air Plus (L).

13
Handle the device with the necessary precautions to be taken when
handling fragile materials. Be careful not to throw away parts of the
device
The manufacturer declines all responsibility with respect to the
installation of the device, therefore, any damage to things and / or
persons attributable to them IS NOT IN ANY CASE attributable to the
manufacturer. The device is not intended for use by persons (including
children) whose physical or mental abilities are reduced, or lack of
experience or knowledge, unless they have been able to benefit, through
the intermediation of a person responsible for their safety, surveillance
or instructions on the use of it.
The manufacturer disclaims all liability for any damage caused to persons
or things arising from modifications, accessories or the use of non-
original spare parts, not expressly provided for in this manual.
The manufacturer medleys all liability for any damage attributable to
transportation. In case of damages, accept with reservation so that you
can initiate the claim by accident.
The packaged device must be stored in a dry (non-condensing)
environment, protected from bad weather. The allowed temperature is
+0oC + 40oC.

14
The device must be installed by authorized technicians in accordance
with current legislation (Ministerial Decree 37/08 and subsequent
amendments, instead hygienically, appropriate protected from freezing
and direct spraying of water and in a space that allows easy extraction
of parts, parts, for necessary maintenance and checks.

15
Bottom (Clean
Air)
Top (Contaminated
Air)

16
STEP 4. Position the equipment on the surface where the installation is to be
carried out and mark the position of the holes to be performed.
STEP 5. Anchor the equipment to holes made using fixing plugs or
similar.
STEP 6. Make sure that the equipment is firmly installed, in case you have decided to install it on
a wall or similar, at a height of approximately 1.9 m from the ground, you can also use the
equipment on a flat surface as long as its immobility is ensured.
STEP 7. Connect the equipment to the grounded power grid
STEP 8. Press the switch by takin it to position "I"
STEP 9. The equipment is already in operation, it can be ensured that the lamp is
operational by a visual inspection (remote and punctual) of the side indicator
viewfinder
STEP 10. To stop the machine, press the switch to position "0"

17






