TruSens Z-3000 User manual

OWNER’S MANUAL
Z-3000

CONTENTS
SAFETY INFORMATION
FEATURE HIGHLIGHTS
PRODUCT OVERVIEW
GETTING STARTED
CONTROL PANEL
AIR QUALITY DISPLAY
SPECIFICATIONS
CARE & MAINTENANCE
Replacing HEPA Filter
Replacing Carbon Filter
Washing the Prefilter
Replacing UV Bulb
Cleaning the SensorPod™
FAQ & TROUBLESHOOTING
WARRANTY & SUPPORT
4
6
7
8
10
11
12
13
13
14
14
15
16
17
19
Welcome to clean air with TruSens. Thank you for allowing
us to join you on your journey towards wellness.
The air you breathe should be clean, no matter where
you are in the room. TruSens SensorPod™, PureDirect™
Technology & DuPont™ Filtration ensure the whole room
benefits from cleaner air.

54
SAFETY INFORMATION
WARNING: To reduce the risk of fire or electric shock,
do not use this fan with any solid-state speed control
device.
Do not operate any purifier with a damaged cord or
plug, or if the wall socket is loose.
Do not run cord under carpeting, throw rugs, runners,
or similar coverings. Do not run cord under furniture
or appliances. Arrange cord away from traffic area and
where it will not be tripped over.
WARNING: Skin or eye damage may result from
directly viewing the light produced by the bulb in this
apparatus. Always disconnect power before replacing
or servicing. Replace bulb with UVLZ300001AU,
Manufactured by ACCO Brands.
• Remove all packaging, including the filter bag,
before use.
• Appliances that are obviously damaged must not be
operated.
• This appliance must only be connected to a wall
socket outlet matching the supply plug type and
rating stated on the rating plate.
• Locate air purifier near the outlet wall socket and do
not use extension cords.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Replace the UV bulb with the models specified within
this manual.
• Do not attempt to service or repair this product
yourself.
• Only use the purifier and SensorPod™ with the
power cable provided.
• Only clean this machine with a damp cloth, do not
use solvents or bleach.
• Ensure appliance is always placed on firm level
surface before operation.
• Do not block or obstruct the air intake or outlet vents.
• Do not insert fingers or other items into the air intake
or outlet vents.
• When the air purifier is in standby mode the
SensorPod is still transmitting a signal/data.
Z-3000: FCC ID: GV3-18Z3000 IC: 6128A-18Z3000
Sensor: FCC ID: GV3-18SP001 IC: 6128A-18SP001
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/
TV technician for help.
FCC RF Radiation Exposure Statement: This equipment
should be installed and operated with minimum
distance of 20cm between the radiator and all
persons.
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference.
(2) This device must accept any interference,
including interference that may cause undesired
operation of the device.

76
FEATURE HIGHLIGHTS PRODUCT OVERVIEW
SensorPod™
Remote air quality monitor that ensures cleaner air,
right where you need it.
Easy-carry handle
Power & signal
indicator Washable Prefilter
Air quality indicator display
Air outlet
Power cord
Carbon Filter
Simple touch control panel
Air inlet True HEPA Filter
360° air intake
Easy-access door UV Sterilisation
Filter cover & knob (underneath)
PureDirect™ Technology
Independent lab testing confirms that two airflow streams are
better than one, moving air effectively and more comfortably
throughout the room.
Informs and Adapts
Colour-coded illuminated ring provides additional
information by communicating air quality in real-time.
360° Purification
DuPont™HEPA filter captures pollutants and VOC
gases/odours from all directions. UV light kills germs
and bacteria that can get trapped in the filter.
Thoughtful Execution
Exceptional functionality wrapped in a contemporary
design that fits any environment.
Air Purifier
SensorPod™Filter & Ultraviolet Sterilisation
AQI

98
GETTING STARTED
1. Remove plastic bag from filter
Unscrew the bottom cover and remove the plastic bag from the filter.
2. Re-attach filter
Secure filter on the bottom cover and replace inside the purifier.
3. Set up
Plug-in your SensorPod™, and place upright on tabletop or counter across the
room, within line of sight of the purifier.
Plug-in your air purifier unit and power on. Place the purifier on a flat surface, free
from obstructions.
Signal strength may vary by location. In the rare occasion that it doesn’t work –
see page 18.
4. Start living with cleaner air!
The purifier will automatically adjust fan speeds based on the air quality readings
from SensorPod, and proprietary PureDirect™technology will deliver purified air
throughout the room!
up to 49' (15m)

1110
CONTROL PANEL AIR QUALITY DISPLAY
Fan Speed Settings
Select fan speed or AUTO mode. In AUTO mode,
purifier automatically adjusts fan speed based on air
quality readings from SensorPod™.
Timer Mode
Purifier will automatically turn off aer 2, 4, 8, or 12
hours. To cancel this countdown, simply press button
until no timer setting is displayed.
UV Mode
UV bulb within the purifier’s filter chamber is on when
the symbol is white. The symbol will glow red
when it is time to replace the UV bulb.
Filter and UV Indicator Reset
HEPA, Carbon and UV indicators glow red when it is
time for each to be replaced.
When 1 indicator is on, simply hold Reset button for 3
seconds to reset that indicator. When 2+ indicators are
on, tap the Reset button to select the correct indicator
(selected indicator will blink) before holding 3 seconds
to reset that indicator.
Dimmer Mode
Display illumination turns off – for use while sleeping –
without sacrificing the effectiveness of the purifier.
Simply press the button again to bring back all
display features.
Power Button
(AUTO mode only available when purifier is paired with
SensorPod and receiving signal)
(See page 15 for replacement instructions)
(See pages 13-15 for replacement instructions. Follow above Reset
button instructions aer replacing filter.)
Real-time Feedback
The revolutionary SensorPod™evaluates the condition of your air by measuring
both small (PM2.5) and larger (PM10) particulate matter. It calculates the overall
air quality using a proprietary algorithm that is reactive to genuine increases in
pollutants without overreacting to someone entering the room or settling into
the couch.
The illuminated, colour-coded display communicates good, moderate or poor
air quality and a numeric value provides a greater level of detail.
In AUTO mode, the purifier automatically adjusts the fan speed in response to
these air quality readings.
TruSens utilizes the Air Quality Index (1-500) created by the U.S. Environmental Protection Agency (EPA).
GOOD
BLUE | 0 - 50
MODERATE
YELLOW | 50 - 100
POOR
RED | 100 - 500

1312
Air Inlet 360°
Air changed 2 times per hr 750 ² (70 m²)
Air Delivery Type PureDirect™
Sensor SensorPod™, works up to 49  (15 m) from purifier
Fan Speed Settings Whisper, 1, 2, 3, Turbo
Purification Levels Washable Prefilter, Carbon, True HEPA, UV
Timer Settings 2, 4, 8, 12 hr
Filter Change Indicators Carbon, HEPA, UV
Noise 32 - 66 dB
Dimensions 10.3" x 10.4" x 28.6" (263 x 263 x 726 mm)
Weight 12.6 lbs (5.7 kg)
Motor Type DC motor
Power Requirements 220-240V 50/60Hz 0.5A
Power Consumption 120 W
Warranty 2 years
Replacement Filters & UV Bulb
3-in-1 HEPA drum filter AFHZ300001AU
Carbon filter (3-pack) AFCZ300001AU
UV Bulb UVLZ300001AU
SPECIFICATIONS CARE & MAINTENANCE
REPLACING HEPA FILTER
Accessing the filter chamber
1. Always power off the purifier by pressing the Power
Button and unplugging the power cord.
2. Gently place the unit on its side on the floor so that
the filter chamber cover and knob are exposed.
3. Turn the knob counter-clockwise and remove the
filter cover and 360° HEPA filter drum (Fig. A).
1. The HEPA indicator will glow red when it is time to
change the entire HEPA drum filter.
2. Gently pull the HEPA drum filter away from its place
secured to the filter cover (Fig. B).
3. Secure the replacement HEPA filter onto the filter
cover (Fig. C).
4. Gently replace the filter cover with filter drum into
the filter chamber and onto the threading, and turn
the knob clockwise until the knob and filter chamber
cover are securely tightened (Fig. D).
5. Plug-in and power on your purifier, and hold the
Reset button until the red HEPA indicator turns off.
Note: HEPA drum filter (on page 12) will include 3 layers: Washable
Prefilter, Carbon and True HEPA
Fig. A
Fig. B
Fig. C
Fig. D

1514
REPLACING UV BULB
WASHING THE PREFILTER
1. The indicator will glow red when it is time to
replace the UV bulb.
2. Remove HEPA filter drum (Fig. A), and use a
screwdriver to remove the 4 screws securing the UV
housing (Fig. I).
3. Gently remove the UV housing (Fig. J).
4. Disconnect the UV bulb from the socket within the
purifier (Fig. K).
5. Your replacement UV bulb (on page 12) will plug
directly into the same socket (Fig. L).
6. Replace the UV housing and use a screwdriver to
tighten the fastening screws.
7. Once the purifier is powered-on, hold the Reset
button until the indicator turns white.
1. The Carbon indicator will glow red when it is time to replace
the Carbon layer.
2. Gently peel away the Prefilter from the fastener strips (Fig. E).
3. Gently peel away the used Carbon layer from the fastener
strips (Fig. F).
4. Wrap a new Carbon layer around the filter drum and attach
to the same fastener strips (Fig. G).
5. Replace the Prefilter by wrapping it around the Carbon layer
and attach to the fastener strips (Fig. H).
6. Once the purifier is powered-on, hold the Reset button until
the red Carbon indicator turns off.
1. We recommend that you visually inspect the Prefilter every
month, and clean as needed. At minimum, you should
hand wash the Prefilter every time you change the Carbon
filter.
2. Gently peel away the Washable Prefilter from the fastener
strips (Fig. E).
3. Gently rinse with running water – allow Prefilter to air dry
before re-installing.
4. Replace the Prefilter by wrapping it around the filter drum
and attach to the fastener strips (Fig. H).
Note: Carbon filter 3-pack (on page 12) will cover 3 Carbon changes
between replacing the entire HEPA drum filter assemly (on page 13).
Fig. E
Fig. F
Fig. G
Fig. H
Fig. I
Fig. K
Fig. J
Fig. L
REPLACING CARBON FILTER

1716
Cleaning the air quality sensor
The SensorPod™uses an infrared light to detect particulate
matter, so it is important that you clean the viewing
chamber every 1-2 months to remove any dust or particles
that may affect the accuracy of the sensor’s readings.
1. Turn-off the SensorPod by unplugging the power cord.
2. Open the easy-access door on the front side by pulling
the door up at a 90° angle.
3. Use a damp cotton swab to wipe the lens and intake
area of the dust sensor (Fig. M).
4. Use a dry cotton swab to wipe away any remaining
moisture.
5. Close the cover by rotating the door back down and
sliding it back into place until you hear a click.
Where do I place the SensorPod™?Anywhere you want to measure the air quality within the room!
For optimal results, place the SensorPod™up to 49  (15 m) away from the
air purifier on a counter or table, within line of sight of the purifier. In Auto
Mode, the purifier will work to distribute clean air until the SensorPod reads
an acceptable level of air quality.
How oen do I need to change the
filters?
That’s easy! The purifier’s replacement indicators will notify you when it is
time to replace the Carbon or HEPA filters, or the UV bulb.
Plan on replacing the Carbon every 3-4 months, HEPA every 12-15 months,
and UV bulb every 1-3 years.
How oen do I need to wash the
Prefilter?
The Prefilter captures larger particles and preserves the efficiency of the
other filters, so we recommend that you visually inspect the prefilter every
month and wash as needed. Another good habit is to wash the prefilter
every time you replace the Carbon filter.
How oen do I need to clean the
dust sensor within SensorPod™?
For the most accurate measurement of your air quality, we’d recommend
you clean the surface of the dust sensor every 1-2 months.
Purifier won’t turn on. Check that the power cord is connected securely to both the wall outlet and
the purifier. Check if there is a power outage in the outlet by trying a nearby
light or device, or by trying a working device in the same outlet.
Check that the HEPA filter is fitted properly into filter chamber.
Please contact us if you’re still having a problem! (page 19)
FAQ & TROUBLESHOOTING
CLEANING THE SENSORPOD™
Fig. M

1918
Pairing SensorPod™and Purifier
The SensorPod communicates with the purifier using
radio frequency signals, and will be paired on the
production line and ready for use when you open the
box. In the rare event that the signal is interrupted, the
purifier’s sensor indicator light will blink. You can
repair the connection in just a few easy steps.
1. Unplug the SensorPod.
2. HOLD the Power Button on the purifier for 3
seconds, when you should hear two chimes.
3. Plug-in the SensorPod and use an item with a small
point (paper clip) to press and HOLD the pairing
button underneath the SensorPod for 5-7 seconds
(Fig. N).
4. The connection is established when the purifier’s
sensor indicator light is lit with no blinking, and the
air quality indicators turn on.
Purifier won’t go into Auto Mode.
OR
Air quality indicators are off.
OR
Purifier’s sensor signal indicator is
blinking.
First, check that the SensorPod is plugged-in and that its light is solid.
Next, check that the SensorPod is within range of the purifier (up to
49/15m).
If both are true and the connection is still failing, see below instructions on
repairing the SensorPod’s connection.
I’ve lost my SensorPod™!Don’t worry! Please contact our customer support team and you can order a
replacement SensorPod. Follow the easy pairing instructions below to pair
your replacement SensorPod with your existing air purifier!
FAQ & TROUBLESHOOTING WARRANTY
Fig. N
What this Warranty Does Not Cover
If ACCO Brands reasonably considers that any of the following situations are present, this warranty does not apply:
• any cosmetic damage;
• where the product’s serial number is no longer present or visible;
• loss or damage caused by factors beyond the control of ACCO Brands including, but not limited to, damage or failure due to power fluctuations, overload, excessive heat or
humidity;
• where the product has not been installed, operated, used, stored and/or maintained in accordance with any instructions provided with the product;
• where damage or defects are due to unusual, abnormal, non-recommended or negligent use, handling or maintenance of the product;
• any alterations or repairs to the product not authorised in writing or performed by ACCO Brands;
• liability based on any service or other agreement or arrangement entered with any third party; or
• normal wear and tear including deterioration of any wearable components or consumables in any product, including but not limited to base boards, blades, cutters, cutting
disks, cutting sticks, drill bits, feed wheels, fuses, light bulbs, manual punches, separators, slitters and staple inserts.
Statutory Guarantees and Your Other Rights and Remedies
This warranty is provided in addition to other rights or remedies that you, as a consumer, may have under Australian or New Zealand consumer law, or any other applicable law.
For Australia: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
For New Zealand: Our Goods come with guarantees that cannot be excluded under the Consumer Guarantees Act 1993. This guarantee applies in addition to the conditions
and guarantees implied by that legislation.
Warranty Against Defects
This product is provided with a 2 year warranty limited to defects in material and workmanship from the date of original purchase (you must retain proof of purchase) (Warranty
Period). This warranty is offered by ACCO Brands Australia Pty Ltd (ABN 16 000 265 047) if the product was purchased in Australia or ACCO Brands New Zealand Limited (26589)
if the product was purchased in New Zealand (each referred to individually, as ACCO Brands). ACCO Brands will, at its own discretion, either repair or replace this product (with a
new or refurbished product) if the defect is deemed by ACCO Brands to be the result of faulty materials or workmanship but subject to the conditions set out in this warranty.
Any other representation contained on this product’s packaging or provided with this product which constitutes or appears to constitute a warranty is hereby excluded and is not
given by ACCO Brands (except for the statutory warranties as indicated below).
You may claim on this warranty only within the Warranty Period in the manner set out below and provided that you have complied with all the other conditions of this warranty. This
warranty can only be exercised by the original purchaser of the product and is not transferrable to any other person or entity under any circumstances.
How to Make a Claim
To make a claim under this warranty please contact your place of purchase within the Warranty Period (from the date of purchase). Proof of your purchase of this product, such
as your receipt or invoice, must be provided in addition to a detailed description of the defect in the product. Your claim will be assessed under the terms and conditions of this
warranty and the laws applicable to your place of purchase.
Distributor Contact Details Australian Customers New Zealand Customers
ACCO Brands Australia Pty Ltd ACCO Brands New Zealand Limited
Locked Bag 50, Blacktown BC, NSW 2148 PO Box 11-677, Ellerslie, Auckland 1542
Phone: [phone] Phone: [phone]
Email: enquiry[email protected] Email: enquiry[email protected]
SUPPORT
Thank you for welcoming TruSens into your home. Our
customers are at the heart of what we do, and we strive
to design products that fit your lifestyle. If you have any
questions or feedback, please reach out!
Visit our website at www.trusens.com
Email us at [e-mail]
Call us at 1300 278 546

©2019 ACCO Brands. All rights reserved. TruSens™, U™ & Design,
SensorPod™ and PureDirect™ are trademarks of ACCO Brands. DuPont™
& the Oval logo are trademarks or registered trademarks of E.I. du Pont de
Nemours and Company used under license.
21973P004
ACCO Brands Australia
2 Coronation Avenue
Kings Park, NSW, 2148
Tel: [phone]
www.trusens.com
& Follow us @TruSensANZ
Subscribe to our YouTube channel TruSens
