P/No.:MFL31040033
PS-N550 Series
• Read before using product (safety instruction), use properly.
• About ensuring users’ safety and property.
• Product warranty card is enclosed with the user manual.
• After careful read through the user manual, do keep it in a handy place.
0026/1.824.51

2Air Purifier
The advantages are
It’s grateful to use our LG air purifier.
After reading through this manual, using this product for a long-term would be safe and convenient.
- 99.9% highly purified platinum catalyst filter completely removes those factors which could cause the sick
house syndrome such as VOCs, harmful chemical element and its smell.
- Sterilized by Washable HEPA filter Inside, once again sterilized by NPI(Nano Plasma Ion) outside.
Only LG air purifier can sterilize perfectly both inside and outside.
- Easy to check out the filter status immediately through the convenient filter separating system.
- Don't worry about the filter becomes dirty. Use again after cleaning by water.
The Platinum Sterilization System
Easy-use refreshing HEPA filter system.
- The anti-allergic filter could absorbs and decomposes the ingredients which causes the allergy, having the
allergy preventive effect also removing the odor and anti-bacteria effect.
- The most advanced photo-catalyst plasma system not only removes various polluted particles within indoor
air but also utilize the static power to strengthens the HEPA filter.
- HEPA(High Efficiency Particulate Arrestor)
Powerful anti-allergic filter
Photo-catalyst plasma system
- It's a natural and harmless filter to the human body which is made with lactic ferments in global health food kimchi.
And its strong sterilization is effective against various harmful bacteria and Avain Infulenza.
(It's a filter for prevention not a medical appliances for cure.)
LG KAV-HEPA Filter

Table of Contents
❏ The advantages are .............................................................2
❏ Cautions for Safety.........................................................4~13
❏ Installation ..........................................................................14
❏ Air purifier Start Guide........................................................15
❏ Name of Each Part.......................................................16~19
– Mainframe
– Display and Controller
– Filters System
– Remote Controller
❏ Remote Controller Guide....................................................20
– Battery Installation
– Caution
3
Owner’s Manual
Before Use
❏ Exterior and Dust Sensors Cleaning Method .....................27
❏ Filter Cleaning ..............................................................28~29
❏ Maintainance ......................................................................30
❏ Confirming Items Before Reporting Defect...................31~32
❏ Product Specification..........................................................33
After Use
❏ Operation Mode............................................................21~23
– Air Purifying Mode
– Speed Mode
– Automatic Mode
– Yellow Sandstorm Mode
– Sleeping Mode
❏ Additional Functions.....................................................24~26
– Off timer Mode Function
– Negative Ion / sterilization function
– Filter Checking Function
During Use
Before Use During Use After Use

4Air Purifier
Cautions for Safety
The following precautions related to safety marked as follows are to prevent unexpected danger or damage by
safely and accurately using the product.
WARNING If not followed, it can cause death or major injury to the user.
If not followed, it can cause injury to the user or property damage.
This is the symbol to get attention focused for the details and operations that can cause
any type of danger. To prevent any danger, observe carefully and follow the directions
appropriately.
CAUTIONS
Warning / Caution

Cautions for Safety
5
Owner’s Manual
Before Use
Warning
Installation
Do not change or extend power
cords at random.
Otherwise, it may cause fire or
electrical shock.
Do not use the product a place
where there are much moistures
or oils such as toilet, bathroom
or washing room.
Otherwise, it may cause fire or
electrical shock.
Do not disassemble or repair the
product at random.
It will cause fire and electrical shock.
Never use an octopus feet-type
of socket.
Unreasonable use of power may cause
fire or electrical shock.
Never use the damaged or loose
power cords.
Otherwise, it may cause fire or
electrical shock.
Open the window for air
ventilation before operating
the air purifier when gas leaks.
Otherwise, it may cause explosion, fire
and physical injury.

6Air Purifier
Cautions for Safety
If abnormal noise comes or smell
or smoke emits from the product,
pull the power plugs out and call
our service center.
Otherwise, it may cause fire or electrical
shock.
Don’t put heavy things on power
cords or take care so that they
should not be pressed under the
product.
Otherwise, it may cause fire or electrical
shock.
Don’t keep and use combustible
gas, flammable substance
around the product.
Otherwise, it may cause fire and
failure of product.
Do not lay fire appliances around
the product.
Otherwise, it may cause fire.
Keep this product out of the direct
rays of the sun, heating source and
moisture.
Otherwise, it may cause electric shock, fire
or failure of product.

Cautions for Safety
7
Owner’s Manual
Before Use
Operation
Securely insert power
plugs to the end so that
they should not shake.
Incomplete connection may
cause fire.
Pull power plugs by
grasping the head and
never touch with power
plugs with the wet hands.
Otherwise, it may cause
electrical shock or physical
injury.
Take care that water could not run
into the product.
Otherwise, it may cause electrical shock
or fire.
Never damage, process,
forcedly bend, twist, pull,
lay between gaps or heat
power cords.
Damaged cords may cause fire
and electrical shock.
Do not hold the power
cable to pull out the
power plug.
May cause fire or electric
shock.
Do not install a place where there
are much industrial Oil dust or
metallic dust.
If may cause fire and failure of product.
When the power code is damaged,
it should be repaired by the
qualified person to prevent any
risk.
Otherwise, it may cause electric shock,
fire or failure of product.

8Air Purifier
Cautions for Safety
Do not use this product when is
in moving.
May cause fire or electric shock or
damage to some parts of the product.
Do not use thermal appliances
near power cords.
Otherwise, it may cause fire or electrical
shock.
Do not lay obstacles around the
product.
Otherwise, it may cause failure.
Do not cover with a rug, cushion etc
over power cords.
Power cords may be damaged and result in
fire and electrical shock in case of putting
heavy things on in the manner power cords
cannot be seen.
Do not sprinkle in insecticide or hair
spray.
It may cause damage or accident.
Do not allow children to climb up
this product.
May cause the breakdown, injury.

Cautions for Safety
9
Owner’s Manual
Before Use
Do not move the product by hold
the front-panel.
May cause electric shock or damage to
some parts of the product.
Do not put coffee or all types of
beverage on the air discharge
outlet.
Otherwise, it may cause fire or
electrical shock.
Contact with the service center
for repairing the product.
Any arbitrary disconnection or repairing
may cause electric shock or fire.
Do not put pressure on the front
glass.
It can cause injury and product damage
or cause electric shock.
Do not insert the hands or bars
into the suction inlet or the outlet.
Otherwise, it may cause failure of product
or physical injury.
If the product is submersed in
the water, you must contact the
service center.
It can cause electric shock or fire.

10 Air Purifier
Cautions for Safety
Cautions
Installation
Maintain distance of more than
1m when installing the product
near TV or audio.
Do not use the product for
removing toxic gas as CO.
Otherwise, it may cause failure.
Do not use the product as
ventilation fan or range hood
at the kitchen.
It may cause shorten the lifetime of
the product.
Install the product at a flat place
and do not fall the product down
or give shock.
Otherwise, it may cause damage or
accident.
Maintain distance over 1.5m for
illumination devices and
maintain distance 10cm or so.
Avoid a place near fire arms or
heating devices or subject to
direct sunlight.
It will cause fire.

Cautions for Safety
11
Owner’s Manual
Before Use
Do not use except AC 220V.
Otherwise, it may cause fire or electrical
shock.
When using the product with a
burner within the airtight room,
sometimes let fresh air into the
room.
Some toxic substances such as carbon
dioxide may not be removed.
Do not install the air purifier on
the transportation vehicle (car,
ship etc.).
It may cause failure.

12 Air Purifier
Cautions for Safety
Do not use the product for
special purpose such as
animals or vegetables,
precision machine or
conservation of art articles.
Otherwise, it may cause damage
of property.
Don’t use strong detergent
like solvent, etc but use a
soft cloth.
Otherwise, fire or distortion of
the product may occur.
Secure all filters and
regularly clean them.
Otherwise, it may cause failure
of product.
Never operate or stop the
product while inserting or
removing power plugs.
Otherwise, it may cause
electrical shock or fire.
Pull power plugs out
when not using the
product for a long time.
Otherwise, it may cause
failure of product or fire.
Use the filter securely
inserted, and clean the
filter about once a month.
Otherwise, it may cause
failure.
Start cleaning after
turning off the power and
when the fan stops.
It can cause electric shock or
injury.
Do not touch the filter
part with wet hands.
The cleaning filter part,
especially, is dangerous to
cause electric shock from high
voltage.
Operation

Cautions for Safety
13
Owner’s Manual
Before Use
Pull power plugs out for
cleaning.
Otherwise, it may cause fire
and electrical shock.
Do not open the front
panel during the
operation of the product.
Opening the front panel stops
the operation.
Do not let the moisture
from the humidifier
directly touch the product.
Otherwise, it may cause electric
shock, fire or failure of product.
Do not use this product
as ventilating fan or so.
It may cause shorten the
lifetime of the product.
Keep batteries out of the reach
of children after removing
batteries from remote controller.
Ensure batteries out of the reach of
children. If children swallow the
batteries, contact the doctor
immediately.
Wash the washing filter and dry it
completely in the shade.
Otherwise, it may cause failure.
Do not insert any inflammable
into the product.
Otherwise, it may cause fire or failure of
product.

14 Air Purifier
Installation
Mainframe • places with handy power connections
• places with no obstacle to clog air inlet
• places with horizontal surface and rich air circulation
Warning Install the air purifier on moving objects (car or ship etc)
may cause the product defect, therefore do not install on
those places.
Places to Install
tuob
a
mc01

Air Purifier Start Guide
Turn off air purifier when cleaning.
• Cleaning the air purifier with opened windows would disturb the natural air circulation to cause
intake too much particles, it may shorten the filter life. After complete cleaning process with
enough air circulation, close the windows, turn on the air purifier is the appropriate way to purify air.
Use after enough air circulation when cooking
• When roast meat or fishs, remove the smell by air purifier is not appropriate. The oil particle will
block cells on filter, it may cause filter life shorten or filter polluting etc. negative effects. Under this
circumstance enough air circulation is necessary. Remove leftover odors by air purifier after no
oil particle is the correct and effective way to use product in long-term scale.
Do not stay too closed when sleeping.
• Air purifier fan speed is not strong, before fallen asleep feel cool, after fallen asleep would feel
cold. The appropriate way is to keep at least 1 meter distance with air purifier.
Do not place in the corner edge.
• Avoid to install at places surrounded by furniture, appliances etc. or in the edge corner. Install in the
edge corner may cause difficulty to purify indoor air from the rest space.
Ensure air circulate 30 minutes at least everyday.
• For those families use the air purifier, air circulation is the prerequisite to ensure enough oxygen
supply. Ensure air circulation 30 minutes at least everyday could brings fresh air inflow. Keep
opposite windows open may gain a better result for air circulation. In case of being lazy may
weaken air refreshing function, therefore it is necessary to ensure clean and maintanance.
15
Owner’s Manual
Before Use

16 Air Purifier
Name of Each Part
Mainframe
Dust Sensor
Power Plug
Safety Net:
The inside of air outlet
Filter case
(Allergen filter + HEPA filter +
deodorizing filter)
Odor sensor
Photo-Catalyst Plasma Filter
Pre-filter
Front panel

Name of Each Part
17
Owner’s Manual
Before Use
Display and controller
Time reservation display
Power On/Off button
Off timer button
Purity level indicator
Analyse and display dust/odor purifier level, higher
volume of indicator reflects better air quality.
Negative ion/ sterilization
indicator
Operation mode indicator
Fan speed indicator
Operation indicator
Fan speed button
Operation mode button
ION button
Remote controller receiver
Dust/Odor indicator
Higher level of dust/odor indicator reflects
higher air clogging level.
Filter self-checking indicator
Check the filter when light is on.

anti-bacteria filter case
anti-bacteriaa
filter net
replace washable washable
washablewashable
washable
{
Combinded
18 Air Purifier
Name of Each Part
󱎲󱎳󱎴 󱎵󱎶 󱎷󱎸 󱎹 󱎺 󱎻󱎼
󱎲
󱎳
󱎴
Filter system( include the filter part only)
Remove big particles
Anti-bacteria function
Anti- mildew function
󱎵
󱎶
Plasma dust-absorb filter
Plasma deodorant filter
Absorb big particles, acarid deadbody, pollen, soot, mildew.
Decompose odor, absorb dust.
Target on big particles and odor sterilization, twice remove allergic and mildew particles.
Remove odor particles, VOCs, smoke smell, musty smell, decompose malodor ingredients and chemicals.
This filter has anti-bacteria, anti- mildew, big particles filtering fuctions.
These 3 functions may extend the filter replacement frequency.
Pre-filter
Plasma filter
󱎷
󱎸
Photo-catalyst anti-bacteria filter
Photo-catalyst deodorant filter
󱎹
Anti-allergic filter Adsorb and decompose allergic ingredients.
• It is a filter which is effect to prevention of the various germ and Avian Influenza.
󱎺
Washable HEPA filter
(LG KAV-HEPA filter)
• Washable HEPA filter removes the acarid deadbody, pollen, soot(particles), small dust and
float mildew, animal bodyhair etc.
Comprehensive odor removing filter removes the soot (smell), putrid food smell, animal body
odor, NO2, toilet odor, alkali & acid smell, organic compound(VOCs).
Filter made by platinum from jewellery industry may effectively, professionally remove those
organic compounds which could cause air pollution and building symptom.
Photo-
catalyst
filter
󱎻
󱎼
Washable carbon
Catalyst function
Nano Platinum filter
※After washing the washable deodorization filter,please dry the filter completely under a shade.(If it is not dried completely,it may cause a malfunction or a bad odor)
※You can purchase a replacement filter (Anti-allergic filter)at a service center nearby you.
Washable
deodorization
filter
Filter name Function Washing/Replacement cycle
About a month washing
cycle
About a month washing
cycle
6~12 months replacement cycle
About 6 months washing cycle
About 6 months washing cycle

Name of Each Part
19
Owner’s Manual
Before Use
Remote Controller
Power On/Off button
button uses to start or close this product
Operation mode button
button used to set operation mode(speed, auto,
sand, sleep)
ION button
button used to set negative ion and
sterilization function
Fan speed button
Set Fan speed
Off timer button
button used to set operation time
How to use the remote controller
When using the remote controller, direct the remote controller to
the remote controller receiver part of the main unit.
