Folding Windshield Installation Guide
On the Rox Fabrication
Ontheroxfab.com
406-967-2189
*READ INSTRUCTIONS THOROUGHLY BEFORE BEGINNING. OTR IS NOT
RESPONSIBLE FOR INCORRECT INSTALLATION OR LOCAL LAWS
REGARDING AFTERMARKET ACCESSORIES. THE USER IS RESPONSIBLE FOR
ALL LIABILITIES ASSOCIATED WITH THE INSTALLATION AND USE OF THIS
PRODUCT.
ALWAYS UTILIZE PERSONAL SAFETY EQUIPMENT WHEN YOU ARE
WORKING IN THE SHOP.
DISCONNECT BATTERY BEFORE YOU BEGIN.

●First, begin by installing the catch tab onto the top of the folding
windshield. Earlier models may require the holes to be drilled. Make
sure the acorn nuts are facing outward towards the front of the Roxor.
Image shown below.
●Next, begin by measuring and finding the center of the hood. Do not
use the hinges as their mounting location may vary. Use a body line on
the hood.

●Use masking tape to mark the center, and the upcoming
measurements as you make them. (If your measurements vary from
ours in order to make the acorn nuts holding the catch tab land
perfectly onto the rubber bumpers, that is alright. Just make sure that
the mounting locations are symmetrical.) (Also, verify that the T
Handle hook will grab onto the catch tab.
●From the center, mark 9 3/8” outwards on both sides.
●Use a framing square to map and mark out the rest of the holes as
shown below. Make sure to align the framing square with the back
edge of the hood (not the cowl) and use the back edge of the hood for
reference as you mark out the remailing holes.

●Mark the next holes out at 11 ½”, 13 ½” and make a perpendicular
mark at 16 5/8”.
●At 16 5/8” you will make two hole marks 7/8” on each side of the
vertical line, on your perpindicular line as shown below.

●Your map of measurements and holes to drill should look the same as
below.
●Verify that your hole sets are 18 ¾” apart.
●Verify that the windshield catch tab lands in the correct spot to be
securely fastened when the windshield frame is folded down.

●Once all measurements are verified, drill the holes out with a ¼” drill
bit. MAKE SURE NO OBJECTS IN THE ENGINE BAY WILL BE HIT
WITH YOUR DRILLBIT.
●You may now mount the hold down hardware in the locations as shown
below with the included hardware.
