ONE PLANET Goondie Series User manual

PITCHING INSTRUCTIONS
1. Start by pegging out one or
two inner corners to stop the
tent inner blowing away. Put
the tent bags in your pocket
so they don’t fly away! Insert
pegs into the ground on a
45° angle, pushing them all
the way in, don’t use your
foot to push in pegs.
2. Put together all three tent poles carefully, making sure
each section is fully inserted into the next.
TIP: Do not flick or release the pole while holding the end
section this can fracture the section ends.
3. Take the two long
poles and cross them
over the inner, placing
the ends into the
corner eyelets.
4. Clip these poles together using the top hub. There is a clear/
translucent hub* on one pole and a black ring on the other.
*Non-structural hubs may dier slightly between models.
5. Place the shorter ridge pole over the top of the two long
poles. Clip to the inner using the ball (on ridge pole) and
socket (on inner) joint.
6. Secure inner to poles
using the clips.
7. Secure the top inner hook
to the higher long pole
(not the top ridgepole)
this maximises internal
height without creating a
wear/rub point on the fly.
FINDING THE IDEAL SPOT
›Look around! Select a site that is flat, clear of rocks,
twigs and other hard or sharp objects.
›Look down! Find a position that will drain well if it rains.
›Look up! Check that nothing can fall on your tent.
(Stay away from tree limbs, especially Australian gums)
TIP: if you arrive to camp early and the sun is shining
bright, consider pitching your tent closer to dusk.
UV exposure deteriorates all fabrics and keeping your
fly out of the blazing sun will maximise its useable life.
POSITIONING THE TENT
›Goondies are tapered rectangular in shape – the head end is
wider than the foot. The webbing on the fly and inner is colour
coded for easy identification, with grey webbing at the head.
›For the optimum pitch, position the tent so the prevailing wind
hits the tent foot or corner.
GOONDIE SERIES
PITCHING, CARE AND
STORAGE INSTRUCTIONS
Scan the QR code
to view instruction
video on YouTube
WURLEY 3 3.5kg
Direction of
prevailing wind

TO ATTACH THE FLY
1. Place the fly over the tent, making sure the webbing
colour matches on fly and inner. Eg. grey on grey
2. Starting at the ridgepole,
clip the DAC® SQ ring over
the ball-and-socket joint.
Use the finger loops to
secure firmly. (The SQ ring
links the inner, pole and fly
for a precise pitch.)
3. Clip the fly to the inner using
the side-release buckles
located on the bottom
corners. Adjust tension to
remove any slack.
4. In windy conditions, we
recommend fastening the
hook-and-loop connections
(behind the guy lines pockets
on the inside of the tent fly)
around the poles. This joins
the fly to the poles and, with
the use of guy lines, helps to
stabilise the tent.
5. Peg out the vestibules, then
peg the head and foot to
increase airflow (if applicable).
Next is pegging in guy lines
if required.
6. In windy conditions, we
recommend using the guy
lines. Pitch guy lines directly
out from the tent corners on
an angle. Follow the angle of
the guy line pocket and the
pole crossover.
PACK-DOWN INSTRUCTIONS
Empty the tent, remove your belongings and any foreign
materials. Remember to empty all the pockets – side, torch,
and loft! Do up all zips on the fly. Check for ants and bugs,
these critters if inadvertently rolled into a tent will try to
chew their way to freedom. Never spray insect repellent on
any part of the tent.
There are lots of ways to pack up your tent, including
the simplest – simply stu it into the bag. The approach
outlined below keeps things neat and tidy, and makes life
easier next time.
Start with the fly
1. Unpeg the fly and all guy lines. Tuck guy lines back into
their storage pockets.
2. Unclip the fly connections (corners and ridgepole) and lift
the fly from the tent. (If you have fastened the hook-and-
loop connectors around the pole, undo them.)
3. Grab the two vents and fold in half.
4. Continue to fold, keeping it neat and creating a large
rectangle the width of the fly bag.
5. Roll the tent fly up, Just before finishing the roll, fold
the end with webbing and peg points to the inside.
This creates a neat squared finish.
6. Slide and twist neatly into fly bag.
Inner and poles
1. Close the doors and windows, leaving the door zip
slightly open. This allows air to escape quickly when
rolling – especially helpful with Nylon inners!
2. Unclip the inner from the poles, starting with the ridge
pole and working down.
3. Then remove the poles ends from the eyelets. Fold poles
carefully and place them in the pole/peg bag.
TIP: When folding the poles, split first in the centre.
This will create a more even tension on the interior elastic,
maximising its useable lifespan.
4. Unpeg all corners and place all pegs into the pole/peg bag.
Keeping it pegged in until this stage ensures it won’t blow
away, remember to count your pegs, so none are left behind.
5. Fold into a neat rectangle the width of the folded poles
a. Brush o mud and dirt as you fold
b. 1 and 2 person tents fold neatly three times,
3 person tents fold neatly four times
c. Just before finishing the roll, fold the end with
webbing and peg points to the inside. This creates
a neat squared finish.
6. Slide and twist neatly into fly bag.
STORAGE AND AFTER TRIP MAINTENANCE
After each trip, spend a few minutes looking after your tent: it will help it last longer and be in better shape for the next trip.
›Never put your tent away damp
›Clean poles and pegs by washing them in warm water using a soft cloth. If you’ve been in a salty location, soak and then
wash thoroughly, ensuring you run fresh water though the pole ends.
›Clean zips and sliders, checking for grime and grit. Brush and lubricate.
›Remove debris from the inside of the tent by turning the inner inside out and brushing.
›Wipe down the inside and outside of both inner and fly with a soft cloth to remove visible dirt.
›Hang your tent up (or pitch it – your call) in a warm, dry and preferably shady area until it is completely dry.
›Store in a cool dry place. We recommend storing the fly and inner in a loose bag rather than tightly rolled.
›During long-term storage remember to air your tent regularly (every 4-6 months) or more often in humid environments.
GUYLINE POCKET
GUYLINE
PEG
GROUND
Adventure One Pty Ltd | 650 Somerville Road, Sunshine West VIC 3020 P| 03 9311 5244 E | [e-mail] www.oneplanet.au
