One Talk CP860 User manual

Quick Install
Guide.
www.verizonwireless.com/Support/One-Talk
One Talk SM
T46G IP Desk Phone, Medium

A
B
Packaging contents
T46 Desk Phone T46
Handset
Quick Reference
Guide & Quick
Install Guide
Handset cord Ethernet cable
T46 Power
Adapter
T46 Stand
T46 Wall
Mount Bracket
(not included)
Assembling the phone
2. Connect the handset and optional headset.
Note: You can also mount the phone to a wall. Purchase of the optional T46G Wall mount bracket is required.
Note: If you find anything missing, contact your system administrator.
Note: The headset, Bluetooth USB Dongle BT40 and wireless headset adapter EHS36 must be purchased
separately. The EXT port can also be used to connect the expansion module EXP40. For more information on
how to use the EHS36, EXP40 and Bluetooth USB Dongle, refer to the respective Meet Your Device.
A
B
A
B
Higher angle position
B
1. Attach the stand.
A
Bluetooth USB
Dongle BT40
Wireless headset
adapter EHS36
Lower angle position
A
B
A
B
A
B
40°
45°
A
B
Insert the handset cord with the longer straight end
into the back of the phone and affix into the channel.

A
B
AC power option
PoE (Power over
Ethernet) option
3. Connect to broadband and power.
You have two options for broadband and power connections. Your system administrator will
advise you on which one to use.
Note: If inline power (PoE) is provided, you don’t need to connect the power adapter.
Make sure the hub/switch is PoE-compliant.
Startup
When the One Talk phone is connected to the
network and powered on, it automatically begins the
initialization process. After startup, and confirming
the 911 address, the phone is ready for use.
Welcome
Initializing... Please wait
During initializing:
The Power light will start as a steady red light, will then blink, and then turn off when initialization
is complete.
B
A
PC connection (optional)
PC connection
(optional)
Power adapter
(DC 5V)
IEEE 802.3af compliant
PoE hub/switch
Note: Ethernet cable
from either Wall jack
or data router.

© 2016 Verizon.
