onga Pantera II Series User manual

OWNER’S MANUAL
Should you the installer or owner be unfamiliar with the correct
installation or operation of this type of equipment you should contact
the distributor/manufacturer for the correct advice before proceeding
with the installation or operation of this product.
Pantera Series
II

Technologically advanced solutions for
moving and treating water in the Home,
Garden, Pool and Spa.
Innovative Stock and Crop water
management solutions for Primary
Industries.
Water movement products for Building
services, Emergency services and
Original Equipment Manufacturers.
Relax - you’ve bought an ...
Congratulations on your decision to purchase an Onga product.
Onga is one of the best know brands in its eld, with a proud local
and international reputation.
Onga is a brand for reliability, value for money and technological
innovation. You will nd Onga product wherever people need to
move water in 3 broad markets covering:
1

1. Continual Product Improvement
We employ the best engineers both in Australia and
around the world to develop new and better ways to
take water further.
2. Operational Excellence
There is only one standard that we set ourselves for both
product quality and the quality of our service. That standard
is excellence... to have no-one better than us at what we
do... nothing short of that is acceptable. Our commitment to
quality is reinforced with our ISO 9001:2000 accreditation.
3. A Fair Price
Onga products are neither the cheapest nor the most
expensive in their eld. Our products do, on the other hand,
always represent very good value for money; they always
have and they always will.
4. Our Team of Dealers
The hand picked authorised Onga dealer network throughout
Australia and worldwide are second to none. We invest
considerable time and resources training and supporting
them through the Onga Training Academy.
2

TABLE OF CONTENTS
Model Data 4
Installation 6
Operation 12
Service and Maintenance 14
Troubleshooting 19
Warranty 21
3

4
Model Data
The operator must be provided with the owner’s manual. This must be read
before operation and followed during operation.
These instructions are a guide only. Users not familiar with pool equipment
should seek advice for suitably qualied persons with experience in pool
equipment installation.
Manufactured in Australia, the Onga Pantera II sand lter is made from
UV stabilised polyethylene. The reputation of durability and performance
makes the PanteraII range rst choice for quality pool builders.
Technical Data
P221 P225 P229 P233
Filter Diameter (mm) 535 635 735 835
Filter Area (m2) (Internal) 0.205 0.293 0.397 0.517
Max Working Pressure (kPa) 280 280 280 280
Maximum Flow Rate (lpm) 165 235 320 415
Design Flow Rate (lpm) 145 205 280 365
Min Flow Rate for Backwashing (lpm) 125 175 240 310
Recommended Pool Volume (litres):
Minimum 30000 45000 60000 75000
Maximum 65000 90000 120000 160000
Filter Height (to top of valve)* 840 960 1090 1170
Required mass of lter media:
Sand (16/30 grade) (kg) 90 140 185 220
Zeolite (kg) 70 105 140 165
Valve Size (connection to PVC) (mm) 40 40 50 50
*It is recommended to ensure there is at least 600mm of clear space above
the top of the lter to facilitate servicing.
Due to excessive cycling, this lter is not suitable for
use on inbuilt In-oor Cleaning Systems.

Filter Application - General Information
This filter is designed for use in domestic/residential swimming pool
installations with correctly sanitised fresh or salt chlorinated water. Suitable
for use with sand or Zelbrite lter media.
1. Locate the lter system as close to the pool as practical.
2. Place the lter on a level stable foundation, preferably a concrete
pad or paving.
3. Position all equipment to provide ease of access for future
servicing.
4. Protect the lter and pump from weather and direct sunlight by
ensuring that they are properly housed.
5. Ensure there is sufcient space to provide adequate ventilation to
electric pump motor.
6. Clean a new pool as well as possible before lling pool and
operating lter. Excess dirt and large particles of foreign matter in
the system can cause serious damage to the lter and pump.
7. Ensure pump is compatible with lter specications.
5

6
Installation
Hazardous Pressure
Incorrectly installed or tested equipment may fail, causing severe
injury or property damage. Read and follow instructions in owner’s
manual when installing and operating equipment.
Have a trained pool professional perform all pressure tests.
All glued ttings and pipe work should be allowed to dry to
atmosphere for 24 hours before closing the installation. Failure
to do so could cause injury or installation failure.
The ttings on these lters are constructed of ABS. Some PVC
jointing compounds are incompatible with ABS possibly causing
failure to the product. Check compound suitability prior to use.
Installation & Assembly of Internal Components
Installation of lter should be only carried out by qualied personnel. Ensure
that the under-drain assembly (hub, laterals & tube) are properly assembled
& installed prior to adding lter media (sand).
Hazardous Pressure!
Can cause severe
injury or major property
damage from tank
explosion.
BEFORE WORKING ON
THE FILTER:
1. Stop Pump
2. Release all pressure from
system, by turning valve
handle to waste.
WARNING
Filter pumps require
hazardous voltage
which can shock, burn,
or cause death.
BEFORE WORKING ON
THE PUMP OR MOTOR:
Disconnect power to
motor.

7
1. The lter internals comprise of a collector hub and eight (8) laterals,
which are supplied packaged seperately with the collector hub and
are stored inside the lter tank prior to shipment.
2. Carefully inspect the laterals and hub prior to assembly for any
visible defects.
3. To assemble the laterals and hub please use the following steps.
(The connection between the hub and the lateral is completed
inside the lter tank - refer to diagram on following page)
For P221100 & P225100 Models only:
Push in and align the male tab on the lateral with the female slot in the hub.
Rotate the lateral clockwise until the tabs engage with an audible “click”.
Repeat this process for all 8 laterals.
For P229200 & P233200 Models only:
Begin by assembling each of the Y-Pieces and the end caps. Place a washer
into the socket of the end cap then align the female slot on the end cap with
the male tab on the lateral. Push the end cap onto the branch of the Y-piece.
Rotate the Y-piece clockwise until the tabs engage with an audible “click”.
Push in the tapered pin (16 supplied) to lock the end caps in place. Repeat
this process for all 16 end caps on the 8 laterals (2 per lateral).
To assemble the Y-piece to the Hub place a washer into the socket of the Y-
piece, then align the female slot on the lateral with the male tab on the hub.
Push the Y-piece onto the Hub. Rotate the lateral clockwise until the tabs
engage with an audible “click”. Push in the tapered pin (8 supplied) to lock
the lateral in place. Repeat this process for all 8 laterals.
Hub Lateral Model P229 & P233
Hub Lateral Model P221& P225

8
Important: Ensure slotted side of laterals face downwards from hub after
nal assembly, and prior to lling with sand.
Steps for Installation of Filter Internals
.
B. Insert assembly
into top of filter
tank.
C. Hold assembly up near
top of tank and add remining
laterals.
After all
laterals are
securely in
sockets,
position
assembly in
the centre
on the
bottom of
the tank.
A. Insert first lateral into socket; twist
clockwise 1/4 turn to lock lateral into
hub. Lateral is correctly installed when
slots face down.

9
Loading Sand Media
1. To keep sand out off collector assembly, place plastic sand shield
over top of collector tube before pouring sand into lter (See
diagram below).
2. To support laterals and prevent
lateral breakage during loadings, ll
tank about half full of water before
loading sand.
3. Pour sand into lter, making sure
that the sand is of the correct type
and quantity for the particular lter
model (Refer lter label).
Make sure gasket area on top of tank is free of sand before installing valve.
4. Before installing valve, double-check that the correct quantity of
sand has been loaded.
5. Remove plastic sand loading shield and keep for future use.
Installation of Multi-Port Valve
1. Install o-ring on valve ange; make sure o-ring is clean, and
has no nicks, tears, or scrapes and lubricate with silicon based
lubricant.
2. Make sure tank and valve anges are clean and free of sand; put
valve on top of tank. Vertical pipe of collector assembly inserts into
base of valve.
3. Install clamp; make sure knob is positioned for easy access for
lter maintenance. Valve port labelled “Pump” should point toward
pump.

10
Hazardous pressure. Clamp will not hold unless it is
seated properly! DO NOT START PUMP until clamp
ends are 1/4” (6mm) apart or less.
4. Tighten clamp knob until clamp ends (under bolt) are 1/4” (6mm)
apart. Tap around outside of clamp with a mallet to help seat
clamp.
5. Connect pipe from pump discharge to valve port labelled “PUMP”;
use union half provided. Assemble union as follows for leak free
operation:
- o-ring and sealing surfaces must be clean.
- Assemble hand tight only (No wrenches).
- NO pipe compound or teon tape on unions.
6. Complete all plumbing connections, using 1 1/2” (P221100 &
P225100) or 2” (P229200 & P233200) pipe to reduce pressure
losses as much as possible.
- Pipe from valve RETURN port to pool return.
- Pipe from valve WASTE port to waste.
- Suction piping from pool to trap inlet on pump.
7. System is ready to start up.

8. If you notice a leak around the clamp area after 15-30 minutes of
running, repeat steps 3-4.
If there are leaks from beneath valve/clamp
area, STOP PUMP, release all pressure by
turning valve handle to ‘waste’, remove clamp
and valve and clean sealing surfaces.
11

Operation
The lter operator or owner must be provided with this owner’s
manual. This must be read before operation, and followed during
operation.
Incorrectly installed or tested equipment may fail, causing severe
injury or property damage. Read and follow instructions in owner’s
manual when installing and operating equipment. Have a trained
pool professional perform all pressure tests.
Hazardous Pressure. To avoid explosion and possible severe or
fatal injury, lter system pressure must not exceed 40psi (280kPa)
under any circumstances. NEVER test this lter system with
compressed air; never operate system with water temperature
above 350C.
To prevent equipment damage and possible injury, turn pump
OFF before changing valve position.
Do not add chemicals directly into the pool skimmer. Adding
undiluted chemicals may damage equipment and void
warranty.
Multi-Port Valve Settings
12

Startup/Operation
1. Open system valve and make sure pump is lled with water. Make
sure pool water level is 2” (50mm) above bottom of skimmer
opening.
2. With pump OFF, set valve to
‘BACKWASH’ position.
3. Start pump, circulating water through lter to waste.
NOTE: To prevent pump running dry, be sure water level
never drops below bottom of skimmer inlet. Add water to pool
if necessary to keep skimmer ooded while back-washing and
rinsing.
4. Backwash until water runs clear (1-5 minutes)
5. Stop Pump; set valve to
‘RINSE’ position.
6. Start pump; run pump for 1 minute.
Note: for Zelbrite repeat steps 1 through to 6 three times.
7. Stop pump; set valve to ‘FILTER’
Position.
8. Filter is now ready for service.
9. Record clean starting lter pressure gauge reading as a reference.
10. For new pools, backwash once a day until pool water is sparkling
clear. Backwash when pressure gauge shows 5 to 7 psi (35 to
50kPa) higher than clean starting pressure (refer to step 9).
13

Service & Maintenance
Hazardous pressure. Stop pump and release all pressure from
system before working on lter, valve, or clamp.
General: Wash outside of lter with a mild detergent and water. Rinse off
with hose.
DO NOT use solvents to clean lter; solvents may
damage components in system.
Inspect sand/media bed at least once a year to remove foreign material which
has not been back-washed out of the system.
NOTE: When the sand/media bed gets hard and crusty on top, remove all
the old sand/media and replace it with new sand/media. Alternatively, if the
pressure gauge does not return to within 40kPa of clean lter pressure after
back-washing it is time to replace the lter media.
Weekly Pool Equipment Inspection
1. Check pressure during operation. When pressure is 5 to 7 psi (35
to 50 kPa) higher than clean operating pressure, backwash lter
(see instructions under Startup/Operation, page 12).
2. Except during hot weather with heavy skimmer loads, operating
lter 6 to 12 hours per day should be sufcient. Carefully monitor
water chemical balance and follow recommendations of your local
pool professional.
Water Maintenance
Keep water level at least 2” (50mm) above bottom of skimmer opening. Failure
to do so can allow air to enter system, causing pump to lose prime and air
to enter lter.
Maintain pH between 7.2 and 7.6 in pool.
14

To prevent damage to system components, keep water
temperature below 380C at all times.
Vacuum Pool
(Refer cleaner operating manual or consult your local pool professional)
1. Fill vacuum hose by submerging in water from one end to the other.
2. To vacuum, insert hose into skimmer suction manifold or into
vacuum line in pool wall. See instructions provided by the pool
builder or pool manufacturer. Start pump, making sure it is primed
and pumping.
3. After vacuuming, clean pump trap basket to remove accumulated
debris, then check lter pressure gauge. If reading is 5 to 7 psi (35
to 50 kPa) higher than initial operating pressure, backwash lter.
Lower or Drain Pool
1. Turn pump ‘OFF’ ; set valve handle to ‘WASTE’.
2. Use Vaccuum cleaner hose and head.
3. Start pump; run until pool is lowered to desired level.
4. Turn pump ‘OFF’ set valve handle to ‘FILTER’
5. Start pump.
Multi-Port Valve Service
If valve is leaking during normal operation it will need
to be repaired by an authorised Pentair Water service
technician.
Valve Removal
Hazardous pressure. Stop pump and release all pressure
from system before working on lter, valve, or clamp.
15

16
NOTE: If Multi-Port Valve is below pool water level, close suction and discharge
valves before disassembly to prevent draining pool.
1. Disconnect piping from pump and pool.
2. Remove clamp.
3. Remove valve from lter top.
4. To re-install valve, follow instructions, BE SURE to follow clamp tightening
instructions.

17
Tank Assembly
1
2
4
5
6
7
3
1
2
3
4
5
6
7
P221 P225

18
Item Description P221 P225 P229 P233
1 Multiport Valve assembly 1 1 1 1
2o-ring - tank ange 1 1 1 1
3 Handle - vee clamp 1 1 1 1
4 Vee Clamp 1 1 1 1
5 Filter Tank assembly 1 1 1 1
6 Collector hub 1 1 1 1
7 Lateral assembly 8 8 0 0
8Lateral ‘Y’ Piece 0 0 8 8
9 Locking Pin - lateral 0 0 24 24
10 End Cap - lateral 0 0 16 16
lWasher (Laterals) 0 0 24 24
P229 P233
12
4
3
5
6
9
10
8
12
4
3
5
6
9
10
8
l Not Shown on diagram

19
Symptom Cause Remedy
No Water
Discharge
Pool water level too
low
Fill Pool to correct level.
Air leaks in inlet
ttings to pump.
Check and tighten all connections.
Teon tape ttings.
Short Filter Cycles
Filter Dirty Filter not backwashed for long
enough period.
Replace Media (Sand or Zelbrite)
Algae present in Pool
water.
DON’T RUN FILTER WITH LIVE
ALGAE IN POOL. Check the
chemical condition of pool water
and refer to Pool Water Chemical
Treatment. Note: Incorrect chemical
treatment will greatly shorten lter
cycle.
Filter Startup
Pressure High and
Water Flow Low
Filter requires
backwash
Follow backwash procedure outlined
in Manual.
Return Line restricted Check for ow at return.
Filter Startup
Pressure Low and
Water Flow High
Skimmer Basket full
of leaves or debris
Clear Skimmer Basket of all foreign
matter and debris.
Pump Strainer Lid not
sealed corectly.
Refer to pump Owners Manual
for correct procedure for sealing
strainer lid correctly.
Pool water level too
low.
Fill Pool correct level.
Pump Impeller
Blocked
Call an authorised service agent to
service pump.
Blockage in suction
line
Air Leak in suction
line
Troubleshooting
