Onix ABHK-014 User manual

Handsfree Speaker Kit
with Bluetooth®Wireless Technology
Instruction Manual
Model Number: ABHK-014
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS

2
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Welcome
Congratulations on choosing to buy an ONIX product.
All products brought to you by ONIX are manufactured to the highest stan-
dards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 1 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

3
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Contents
Welcome 2
General Safety Instructions 4
Product Overview 5
Getting Started 6
Instructions 8
Other Useful Information 10

4
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place for
future reference, along with the completed warranty card, purchase receipt
and carton.
• Charger: Use only the supplied charger to charge this Handsfree Kit
with Bluetooth Wireless Technology; using any other charger will be
hazardous.
• Battery: Do not attempt to force open the built-in battery since this could
damage the product.
• Protect from heat: Do not leave this Handsfree Kit exposed to strong
direct sunlight, which could warp the plastic housing.
• Sun visor: Frequent attaching and detaching of the clip that holds the kit
in place may leave a marking/indentation on a padded sun visor.
• Installation: Never place or store the Handsfree Kit above any area in the
car where a safety airbag is deployed, as it may cause serious injury if the
airbag deploys.
• Safe driving: While this product allows you the freedom to make phone
calls in your car, always ensure to operate the vehicle in a safe manner.
Do not become distracted by phone calls while driving, and always be
fully aware of all driving conditions. If a phone call is likely to distract your
attention, pull over in a safe and legal manner and location.
• Usage restriction: This product is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instructions concerning use of the appliance by a person
responsible for their safety.
• Children: Supervise young children to ensure they do not play with the
product.
• Storage: Be sure to store the Handsfree Kit in a dry place, free from
extreme temperatures, humidity and dust.

5
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Product Overview
(1) Speaker
(2) LED indicator (blue and red)
(3) Volume increase button [ + ]
(4) Volume decrease button [ - ]
(5) Multifunction button [ MFB ]
(6) Microphone
(7) Mute button
(8) Charging socket (5 Pin Mini USB)
(9) Mini USB cable
(10) Car charger
(11) Visor clip
1
6
11
7
8
2 3 4 5
Top View
Front View
Bottom View
9
10

6
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Getting Started
Introduction
This Handsfree Kit with Bluetooth®Wireless Technology gives you the
freedom to make phone calls in your car without using your hands.
The Handsfree Kit:
• Is compatible with most Bluetooth enabled mobile phones
• Can be paired with up to eight Bluetooth enabled devices
• Features Bluetooth technology for wireless communication
• Features HD-Voice and DSP technology for crystal-clear, pure sound
• Is easy to install, with the supplied visor clip, on the sun visor of your car.
• Is designed with your safety in mind. While it allows you the freedom
to make or answer important phone calls in your car, we strongly
recommend you keep your phone calls to a minimum and focus your
attention to driving and the traffic around you.
Charging
The Handsfree Kit contains a rechargeable lithium battery, which should be
fully charged before first use.
• Charging via computer: Insert the Mini USB connector of the USB cable
into the charging socket on the Handsfree Kit, and the USB connector
into the USB port on your computer.
• Charging in the car: Plug the USB connector into the supplied car
charger, then insert the charger into your car's DC connector (cigarette
lighter socket).
• The LED indicator will illuminate red and will remain on during charging. It
will turn off when the unit is fully charged; this will take approximately two
hours.
• The Handsfree Kit will need to be recharged when the LED indicator
starts flashing red once every three seconds. Continued use of the
product may reduce the battery lifespan and standby time, and eventually
the system will shut down when the battery has insufficient charge.
• We recommend charging the Handsfree Kit before the battery power is
completely drained to prolong the battery life.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.

7
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
LED Indicator Light
Mode LED Indication
Ready to be paired The red and blue LED flash alternately.
Paired The blue LED will blink twice every 5
seconds.
Standby (connected to a
Bluetooth enabled device)
The blue LED flashes once every 3 seconds.
Low voltage standby The red LED flashes once every 5 seconds.
Charging The red LED is constantly on.
Charging finished The blue LED is constantly on.
Getting Started (Cont.)
Installation
Step 1: Lightly push the supplied visor clip open and slide it from the top
down into the two grooves at the back of the Handsfree Kit until it
clicks into place.
Step 2: Clip the unit to your car's sun visor, making sure the mute button is
facing the driver.

8
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Powering On/Off
Turning on: In OFF mode, press and hold the MFB for 1 second until
you hear a short beep. The product will then automatically
connect with the last mobile phone it connected with.
Turning off: In STANDBY mode (when the product is connected to a
mobile phone), press and hold the MFB for 5 seconds until
you hear a short beep. The product will then shut down.
NOTE: After being disconnected from a mobile phone, the product will shut
down automatically after 10 minutes.
Pairing and Connecting a Mobile Device
Prior to using the product for the first time, the Handsfree Kit must be paired
and connected manually with a Bluetooth enabled mobile phone. To do so,
proceed as follows:
• In OFF mode, press and hold the MFB for 5-6 seconds until the blue and
red LED indicator flashes alternately. This indicates that the Handsfree Kit
is ready for pairing.
• With your mobile phone turned ON, activate the Bluetooth function and
search Bluetooth enabled devices (for more instructions, consult your
phone's user guide).
• When your phone has found the Handsfree Kit, it will stop searching.
Select "ABHK-014" on the phone's list of found devices.
• If a password is required, enter "0000" to confirm pairing.
• If pairing cannot be completed within ten minutes, the Handsfree Kit will
automatically power off. In that case, repeat the steps above to attempt
pairing again.
• After successful connection to the host (Handsfree Kit), you can now
answer or make phone calls, or play music, from your mobile device via
the Handsfree Kit.
• When using the Handsfree Kit, ensure the distance between the kit and
the phone is within 10 metres and there are no obstacles between the
two devices.
• If the Handsfree Kit had paired with your phone but disconnected, the kit
will connect the paired phone automatically next time you turn it on again
within operation range.
Instructions

9
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Instructions (Cont.)
Making Phone Calls
To answer an incoming call Press the MFB once.
(If the Handsfree Kit is in OFF mode, it
will power on automatically, connect to
the paired device and answer the call.)
To end a call Press the MFB once.
To reject an incoming call Press and hold the MFB for one second.
To dial the last dialled number Press the MFB twice in quick
succession.
To adjust the volume While talking, press and hold the [ +] or
[ - ] buttons to increase or decrease the
volume.
Playing MP3 Music Files
When you are playing music from your mobile device, you can operate
playback controls via the Handsfree Kit.
In STANDBY mode:
• Press the MFB twice to start music play.
While music is playing:
• Press the MFB to pause playback.
• Press and hold the [ +] or [ - ] button to go to the next or previous music
track.
• Press the [ +] or [ - ] button to adjust the volume.

10
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Other Useful Information
Important Note
While the Handsfree Kit complies with the Bluetooth version specified below,
compatibility of all functions on every Bluetooth enabled device cannot be
guaranteed. Please check your device's user manual for compatibility and
functionality.
Technical Specifications
Bluetooth specification V2.1+A2DP
Operating frequency 2.4GHz~2.48GHz
Output power Class 2, 10 metres
Protocols supported HSP and HFP, A2DP
Standby time Up to 800 hours
Talk time Up to 8 hours
Charging time 2-3 hours (approximately)
Charging voltage DC 5.0V, 400 mA
Battery 650mAh (BL-5B)
Responsible disposal
At the end of its working life, do not throw this appliance out with your
household rubbish. Electrical and electronic products contain substances
that can have a detrimental effect on the environment and human health
if disposed of inappropriately. Observe any local regulations regarding the
disposal of electrical consumer goods and dispose of it appropriately for
recycling. Contact your local authorities for advice on recycling facilities in
your area.

11
1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS

1300 886 649 Model: ABHK-014 Product Code: 47487 08/2015
www.tempo.org
AUS
Warranty returns
Should you for any reason need to return this product
for a warranty claim, make sure to include all accessories
with the product.
Product does not work?
If you encounter problems with this product, or if it fails
to perform to your expectations, make sure to contact
our After Sales Support Centre on 1300 886 649 before
returning it to the store for a refund.
