Onkyo DV-C600 Assembly instructions

Final release date:01/27/02
DV-C600, Ref: 112200-3
Service Tip and Troubleshooting:
Make sure static free work environment is observed at all times when working with Laser Pickup.
Symptoms: (1) Disk Starts, Spins and DISK ERROR comes up.
(2) Disk plays with intermittent picture breaking up.
(3) Disk fails to initialize, or locks up trying to read disk.
(4) Plays DVD but fails to play CD or plays CD but not DVD.
Mandatory Solution: Replace pickup connector cables, Remove pick-up connector intermediate PCB, update
firmware with most recent version.
Part Location Old Part number New part Number Reason For change
E103 2042183512 2042184012 Improved RF (Eye Pattern)
E101 2042180512 Eliminated (Remove) RF Loss improved
U09 1H412554-2 Eliminated (Remove) RF Loss improved
E210 None 230957 RF Noise improved
Before you start work, the following process must be addressed in order to avoid damage to the pickup assembly.
Your finding may resemble the followings:
a. Powers, rotates carousel, chucks, (clamps) and LD is not ON, and immediately un-chuck.
b. Powers, chucks, and LD is on spins for a few seconds and unclamps goes to next disk.
c. Powers, chucks, LD is on, spins and spins trying to read TOC. Endless loop.
d. DVD plays but not CD or plays CD not DVD.
e. Picture breakup problem.
Access hole for shorting
pickup at the bottom.
Must return cap when done.
Fi
g
1 Fi
g
2 Fi
g
3
Lift cap with a screwdriver.
Short J019 with solder.
Fi
g
4 Remove to
p
cover
Fi
g
5
Remove front
p
anel screws
Disconnect al wires
from di
g
ital PCB.

Solution: Replace pickup connector cable. "Second time around".
Fi
g
6 Fi
g
7 Fi
g
8
Front and rear
p
anel removed Pull carousel forward with latch
p
ushed down.
Latch
Carousel removed
You may disconnect cable from
P111B
Remove two PCB mounting screws
and short pickup LD terminals.
Connect cable PN#2042184012
directly to the pick-up. Please pay
attention to the BLUE BACK.
Bend the new cable
PN#2042184012 at the point of red
marking towards the marking.
Re-assemble the unit back
and attach the cable as
illustrated next Fig14. It is
important to keep the pickup
shorted until last.
Bend cable as you see on this
picture. Please do not crush cable.
Make sure the cable at
connector CN501 is curled to a
minimum to avoid cable break.
Fi
g
9
Fi
g
10 Fi
g
11
Fi
g
12
Fi
g
14 Set the unit on its side and de-solder the
shorting from the pick up very carefully.
Fi
g
15
Core PN#230957 must be
installed at this point using
double side ta
p
e.
The bend seen in Fig11 shall match this corner
(white mark). Return the clear vinyl as it was.
Use double side ta
p
e to attach cable.
Fi
g
13

Test points and references:
A: make sure static free work environment is observed at all times when working with Laser Pickup.
With the unit totally turned OFF, confirm the impedance of the Focus Coil and the tracking coil at CN501. Between
pin 10 and 13, 8.2ohm for Focus coil and across pin 11 and 12, 8.3ohm for the Tracking Coil.
Check and verify procedure as given on page 43,44 of service manual. For disk to be recognized while carousel is
rotating but fail to spin and focus is a result of missing LD ON. This happens when one of the connectors at any of
the three points (Fig1 A, B and or Fig2 C) is lacking good contact to the ribbon.
***The laser pick needs no adjustment!!! ***
The troubleshooting guide given between pages of 43 and 50 is extremely helpful to determine the condition of the
PICKUP.
B: Disregarded Step 3 of page 45 and make correction as follows.
The reference should be:
lop = Voltage between
E522 and E523 3.3ohm
The voltage drop across R505 (3.3ohm) resistor is higher than 218~238mvDC in normal operating condition and the
LD is not on, connection (Fig1 A, B and or Fig2 C) may be loose or poor. This indicates the LD is not present as
load to the voltage rail R505.
The Individual optical output level may be monitored at the pickup connector point using an oscilloscope with no
more than 10pf input capacitance.
For location refer to manual Page 50.
D: To help reduce the break up of the video signal, remount CORE
#230957. The installation of this core should be as illustrated on Fig14.
** Since the root cause for the failure of DV-C600 and DV-C601 is
mainly noisy pick-up signal do to poor connector terminals, it is very
important all of the necessary steps mentioned are exhausted before
attempting to replace the PICKUP.
If the shorting PCB seen in Fig 3 is not in place, you
will need to keep the DSP still connected to CN501
connector until pick-up shorting is done as seen on
figure 10. Keep DSP attached to the frame with an
electrical tape.
Fi
g
16
TP-515

E103 DV-C600
PN#230957 or 230951
Picture freeze, does not play DVD, or CD or Both
related problem. Must add ferrite core
Mandatory:
Short Pick up assembly and remove
part U9 and E101. Part E103 have been replaced by
Pn# 2042184012
Before replacing a pickup assembly it is important that the
Before
replacing
a
pickup
assembly
it
is
important
that
the
following component change is adressed properly.
Do Not Attempt to Remove Optical Ribbon cable before
shorting the landing found on the pick
-
up
shorting
the
landing
found
on
the
pick up
Assembly.

DV-C600
To check the Firmware version before update is done follow this process.
Using the remote controll Press [ZOOM] ----> [606] -----> [ZOOM]
Th di l ill h th i th di l l
Th
e
di
sp
l
ay w
ill
s
h
ow
th
e vers
i
on on
th
e
di
sp
l
ay pane
l
.
If the dsiplay indicates a firmware of curent version need not update, unless
PCB has been replaced.
** Firmware runs in DOS mode only.

DV-C600
**
Firmware runs in DOS mode only.
Firmware
runs
in
DOS
mode
only.
Flash99

DV-C600
