Onkyo HTP-980 User manual

HTP-980
SERVICE MANUAL
SERVICE MANUAL
7.1-CH THX CERTIFIED
HOME THEATER SPEAKER PACKAGE
Black model
MODEL HTP-980(B)
120V AC, 60Hz
230V AC, 50Hz
B MDC
B MPP
Ref. No. 4236
(MDC) 072010
(MPP) 102010
- - Front Speakers (L/R) - -
"SKF-980"
- - Center Speaker - -
"SKC-980"
- - Surround Speakers (L/R) - -
"SKR-980"
- - Surround Back Speakers (L/R) - -
"SKB-980"
- - Powered Subwoofer - -
"SKW-980"(MDC model)
"SKW-938"(MPP model)
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ADJUSTMENT PROCEDURE
SKW-980 : POWERED SUBWOOFER (EuP AMP.) /
ADJUSTMENT OF IDLING CURRENT
HTP-980
Test point
DC voltmeter
100 ohm
(1/4W)
P531
<Fig-1>
Test point
P631
MAIN PC board ass'y "BAAF-0491" (EuP Amp.)
Test point
P531
Trimming resistor
R544
Short
[When]
1. Exchange transistors (Q505 - Q519).
2. Exchange MAIN PC board ass'y (BAAF-0491).
[Procedure]
<Note> No speaker load and No input signal.
1. Short test point P631 for amplifier is under active mode.
2. Adjust the trimming resistor R544 so that the reading of multimeter becomes 52 ohm to 53 ohm.
3. Connect the DC voltmeter to test point P531. <Fig-1>
4. Connect the power cord into the AC outlet.
5. Press POWER button to turn on the unit. (MPP only)
6. Confirm the voltage of above point after 6 minutes to 8 minutes. (Heat running)
7. When less than 3.20 mV : Readjust the trimming resistor above so that the voltage becomes 4.5 mV to 5.0 mV.
When 3.30 mV to 5.20 mV : Not necessary to adjust.
When 5.21 mV to 10.0 mV : Readjust the trimming resistor above so that the voltage becomes 5.0 mV to 5.5 mV.
When 10.1 mV to 20.0 mV : Readjust the trimming resistor above so that the voltage becomes 5.6 mV to 6.0 mV.
8. Disconnect the power cord from the AC outlet.
9. Disconnect the DC voltmeter.

HTP-980
EXPLODED VIEWS-1
SKW-980 (MDC model) : POWERED SUBWOOFER (EuP Amp.)
HTP-980
A08
x 2 pcs.
SP11
x 10 pcs. (NSP)
A104
x 2 pcs.
A05
x 2 pcs.
A05
x 5 pcs.
A103
A102
P901
SP13
x 2 pcs.
A05
x 2 pcs.
U02
SP14 (NSP)
A11
E802
A01
U01
A07
A07
A101
A02
A02
A06
U06 A05
Q515
Q516
Q541
F901
A12
T901
A03
SP12
x 5 pcs.
(NSP)
See "EXPLODED VIEWS-3"

HTP-980
EXPLODED VIEWS-2
SKW-938 (MPP model) : POWERED SUBWOOFER (EuP Amp.)
HTP-980
A08
x 2 pcs.
SP11
x 10 pcs. (NSP)
A104
x 2 pcs.
A05
x 2 pcs.
A05
x 5 pcs.
A103
A102
P901
SP13
x 2 pcs.
A05
x 2 pcs.
U02
SP14 (NSP)
A11
E802
A01
U01
A07
A07
A101
A02
A02
A06
U06 A05
Q515
Q516
Q541
F901
A12
T901
A03
SP12
x 5 pcs.
(NSP)
U04
S901
See "EXPLODED VIEWS-3"
<Note>
Part No. of S901 ---> See "PRINTED CIRCUIT BOARD PARTS LIST".

HTP-980
EXPLODED VIEWS-3
SKW-980 / SKW-938 : POWERED SUBWOOFER
HTP-980
SP07
SP09
SP02
x 4 pcs.
SP03
x 4 pcs.
SP08
SP01a/b : SPK SYSTEM ASS’Y (All)
SP01c : SPK SYSTEM ASS’Y (Without amplifier unit, power transformer and speaker unit.)

HTP-980
EXPLODED VIEWS-4
SKF-980 <L> / SKF-980 <R>
HTP-980
SP32a/b
SP21a/b : SPK SYSTEM ASS’Y (ALL)
SP23
SP31
SP22
x 4 pcs.
SP23
SP24
SP34
Lch
TERMINAL :
White / Black
Rch
TERMINAL :
Red / Black
INPUT
(Terminal)
WOOFER
WOOFER
TWEETER

HTP-980
EXPLODED VIEWS-5
SKC-980
HTP-980
SP52
SP41 : SPK SYSTEM ASS’Y (ALL)
SP51
SP42
x 4 pcs.
SP43
SP44
SP43
SP54
TERMINAL :
Green / Black
INPUT
(Terminal)
WOOFER
WOOFER
TWEETER

HTP-980
EXPLODED VIEWS-6
SKR-980 <L> / SKR-980 <R>
HTP-980
SP72a/b
SP61a/b : SPK SYSTEM ASS’Y (ALL)
SP74
SP64
SP71
SP63
SP62
x 4 pcs.
SP65
INPUT
(Terminal)
WOOFER
TWEETER
Lch
TERMINAL :
Blue / Black
Rch
TERMINAL :
Gray / Black

HTP-980
EXPLODED VIEWS-7
SKB-980 <L> / SKB-980 <R>
HTP-980

HTP-980
SCHEMATIC DIAGRAMS-1
SKW-980 (MDC model) : POWERED SUBWOOFER (EuP AMP with protection.)
A
1
2
3
4
5
BCDEFGH
HOT
COLD
AGND
-10V
+10V
GND
+10V
-10V
GND
GND
27mA(MAX70mA)
5mAMAX
AC8.89V
ADJUST. IDLING
SPEAKER
POWER NEED TO CONFIRM
BAAF-0491
Vin=6.7Vmin
BLUE RED
LED
<Note>
NC : No mount of parts.
Latch
relay
GND
SP
+B
BAETC-0493
1mA
F901 BASW-0494
BAPS-0492
ONLY FOR FILTER CONTROL SKW-204/208
ONLY FOR FILTER CONTROL SKW-204/208
OUTPUT LEVEL
D917
1SS133
J996
J997
J998
C915
224J
P903C 1
P903D 1
R981
470(1W) C919
104J
D911
1SS133
D913
1SS133
D920
MTZJ9.1B
D918
1SS133
R983
470(1W)
R954 33(1/2W)
R982
470(1W)
P908B
NPLG-5P133
1
2
3
4
5
C914
1000/25
C911
1000/25
C912
1000/25
P903B 1
R604
180
R603
150K
C602
10/50
R605
22
R609
39K
R610
560K
R611
820K
R614
120K
Q602
KRC103M
Q605
2SA933S
Q606
KRA103M
R620
100K
R626
2.2M
R624
100K
R627
680K
0.6
Q609
NC
R625
180K
R629
NC
R628
330K
R701
NC
Q505
2SA949-Y(TPE6_F)
R612
39K
R522
220
D501
MTZJ5.6B
R504
2.2K
R510
100K
R521
220
R507
33K
R509
1K
-0.6
R511
82(1/4W)
R505
1K(1/4W)
R506
1K(1/4W)
Q510
Q507
2SA949-Y(TPE6_F)
2SC2229-Y(TPE6_F)
R508
47(1/4W)
R512
68(1/4W)
R527
270
R516
12K
R515
12K
R543
180
R542
150
0
R517
3.3K
Q517
2SA933S-S
+1.6
Q518
2SC2235-Y(TPE6_F)
R528
390(1/2W)
R526
82(1/2W)
R533
3.3(1W)
-1
1
0.05
5.0
Q506
2SC2229-Y(TPE6_F)
R514
82(1/4W)
C506
CERA C
070D
C514
101J
R906
22(1/2W)
R907
22(1/2W)
R905
0.47(1/2W)
R616
100K
R621
1K
D607
1SS133
R617
1K
Q509
2SA949-Y(TPE6_F)
C519
TF C
224J
C520
TF C
224J
R319
100K
D901 D3SBA20
R544
100B
1
2
3
R301
1K
R322
47K
R601
5.6K
R602
100K
Q502
2SC2240-BL(TPE2_F)
C505
CERA C
020C
2.1V
+39V
-39V
D651
1SS133
2.7V
C527
1/50
R904
0.22(1/2W)
C918
NC
+8.6V
C917
22/50
Q604
2SA933S
R531 0.22(5W)
C903
104J/100
C904
104J/100
P531
NPLG-2P29
1
2
P631
NPLG-2P29
1
2
Q302:A
NJM4558LD
4
2 3
8
1
Q302:B
NJM4558LD
6
5
7
D919 RL1N4003
D951
MTZJ15B
D952
MTZJ15B
R501
1K
Q503
2SC2240-BL(TPE2_F)
0
C502
NC
Q501
2SC2240-BL(TPE2_F)
C501
47/50
C503
224J
-33.5V
-1.6
C504
220/25
C951
220/25
C952
220/25
Q541
2SC3423
47/50
C314
R503
5.6K
R306
NC
C302
47/50
C601
10/50
Q902
78M05AHF
1
I
2G
3O
R311
100K
C312
334J
C315
334J
R313
3.3K
R314
3.3K
R315
3.3K
R317
2.2K
R502
33K
C316
104J
C313
104J
R316
4.7K
C317
473J
P301pinjack
NPJ-1PDB556
1
2
C955
223J
E801
-10V
Q303:A
NJM4558LD
4
2
3
8
1
R303
47K
Q303:B
NJM4558LD
7
6
5
R321
270
R307
270
1.0V
R613
470K
R615
22K
R619
22K
D605
1SS133
Q612
2SC1740S-S
Q610
2SA933S
D601
MTZJ3.6B
D602
MTZJ3.6B
Q603
2SC1740S-S
D652
1SS133
C907
220/25
C908
220/25
P535A
P535B
R630
10K
R631
10K
R320
5.6K
R312
100K
D603
1SS133
C311
25/100
C604
4.7/50
C605
4.7/50
R653
680K R652 470K
+5.0V
P903A
NPLG-4P151
1
2
3
4
R951
3.3K(2W)
R952
3.3K(2W)
Q513
2SC5171(ONK_Q)
C301
221J
C950
NC
Q301:B
NJM4558LD
5
6
7
Q301:A
NJM4558LD
3
2
4
1
8
R302
N17RGL20KB15M
1
2
3
R651
10K(1W)
J390
R513
82(1/4W)
R541
820
P908A
NSAS-10P1152
5
4
3
2
1
R654
330K
C526
22/100
C528
22/100
C517
22/100
R623
22K
Q607
2SA933S
R622
10K
Q608
2SC1740S-S
D606
1SS133
P632A
NPLG-3P131
1
2
3
C603
470/10
Q901
DTC123JS
D709
1SS133
Q704
2SC1740S-S
Q705
2SA933S
R717
10K
R716
1K
R715
10K
D708
1SS133
C704
470/10
Q703 2SC1740S-S
+10V
Q519
2SA965-Y(TPE6_F)
Q514
2SA1930(ONK_Q)
Q706
DTC123JS
S101
SLIDESW
8
6 3
4 1 5 2
7
R101A
20K
8
9
6
7 5
R101B
20K
3
2
1
P302ANSAS-18P1831
1
2 3
4
5 6 7
8
9
J999
D707
1SS133
R704
100K
C707
223J
C709
223J
S901
NRC-11007P
2 1
C920 DE1007E472M-KY
P906A
NPLG-2P632
1
2
2
1
P902A
NPLG-2P632
2
1
AC_CORD
P302BNPLG-9P137
9 8
7
6
5
4
3
2 1
C916
MKP_R46_103M
R304
LIST
R305
LIST
R984
LIST
R714
LIST
C303
LIST
LIST
C921
LIST
J316
LIST
T902
LIST
6 5
8
9 4
1
T901
TRANS
LIST
14
12
10
7
1
5
6
8
J995
LIST
Q515
LIST
Q516
LIST
C905
LIST
C906
LIST
J991 LIST
P906C
4
3 2
1
RL901
NRL-1P5A-DC9-179
4
3 2
1
J992 LIST
P906B
LIST
R984T901(MAIN)F901 J995 Q515T902(SUB) Q516 C905,C906 R305 J316(FILTER)C921ACNIS-PWB Output Power C303MODEL
120V 5A/125V NPT-1539D NPT-1520JQ 150W 470(1W) NC 2SC5359-O/R 2SA1987-O/R 5600/71 104M TA10 223J TA7.5BAAF-0491-2F
J991,J992(AC SW)
2.2K 8.2K 2009991199UL
R304 R714
68KSKW-980DMDD (Eup AMP. Version)
P535A(SP CABLE)
INPUT
This protection circuit has been applied from the 1st lot
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE
MAIN PC BOARD
U01
POWER TRANS. PC BOARD
U02

HTP-980
SCHEMATIC DIAGRAMS-2
SKW-938 (MPP model) : POWERED SUBWOOFER (EuP AMP with protection.)
A
1
2
3
4
5
BCDEFGH
HOT
COLD
AGND
-10V
+10V
GND
+10V
-10V
GND
GND
27mA(MAX70mA)
5mAMAX
AC8.89V
ADJUST. IDLING
SPEAKER
POWER NEED TO CONFIRM
BAAF-0491
Vin=6.7Vmin
BLUE RED
LED
<Note>
NC : No mount of parts.
Latch
relay
GND
SP
+B
BAETC-0493
1mA
F901 BASW-0494
BAPS-0492
ONLY FOR FILTER CONTROL SKW-204/208
ONLY FOR FILTER CONTROL SKW-204/208
OUTPUT LEVEL
D917
1SS133
J996
J997
J998
C915
224J
P903C 1
P903D 1
R981
470(1W) C919
104J
D911
1SS133
D913
1SS133
D920
MTZJ9.1B
D918
1SS133
R983
470(1W)
R954 33(1/2W)
R982
470(1W)
P908B
NPLG-5P133
1
2
3
4
5
C914
1000/25
C911
1000/25
C912
1000/25
P903B 1
R604
180
R603
150K
C602
10/50
R605
22
R609
39K
R610
560K
R611
820K
R614
120K
Q602
KRC103M
Q605
2SA933S
Q606
KRA103M
R620
100K
R626
2.2M
R624
100K
R627
680K
0.6
Q609
NC
R625
180K
R629
NC
R628
330K
R701
NC
Q505
2SA949-Y(TPE6_F)
R612
39K
R522
220
D501
MTZJ5.6B
R504
2.2K
R510
100K
R521
220
R507
33K
R509
1K
-0.6
R511
82(1/4W)
R505
1K(1/4W)
R506
1K(1/4W)
Q510
Q507
2SA949-Y(TPE6_F)
2SC2229-Y(TPE6_F)
R508
47(1/4W)
R512
68(1/4W)
R527
270
R516
12K
R515
12K
R543
180
R542
150
0
R517
3.3K
Q517
2SA933S-S
+1.6
Q518
2SC2235-Y(TPE6_F)
R528
390(1/2W)
R526
82(1/2W)
R533
3.3(1W)
-1
1
0.05
5.0
Q506
2SC2229-Y(TPE6_F)
R514
82(1/4W)
C506
CERA C
070D
C514
101J
R906
22(1/2W)
R907
22(1/2W)
R905
0.47(1/2W)
R616
100K
R621
1K
D607
1SS133
R617
1K
Q509
2SA949-Y(TPE6_F)
C519
TF C
224J
C520
TF C
224J
R319
100K
D901 D3SBA20
R544
100B
1
2
3
R301
1K
R322
47K
R601
5.6K
R602
100K
Q502
2SC2240-BL(TPE2_F)
C505
CERA C
020C
2.1V
+39V
-39V
D651
1SS133
2.7V
C527
1/50
R904
0.22(1/2W)
C918
NC
+8.6V
C917
22/50
Q604
2SA933S
R531 0.22(5W)
C903
104J/100
C904
104J/100
P531
NPLG-2P29
1
2
P631
NPLG-2P29
1
2
Q302:A
NJM4558LD
4
2 3
8
1
Q302:B
NJM4558LD
6
5
7
D919 RL1N4003
D951
MTZJ15B
D952
MTZJ15B
R501
1K
Q503
2SC2240-BL(TPE2_F)
0
C502
NC
Q501
2SC2240-BL(TPE2_F)
C501
47/50
C503
224J
-33.5V
-1.6
C504
220/25
C951
220/25
C952
220/25
Q541
2SC3423
47/50
C314
R503
5.6K
R306
NC
C302
47/50
C601
10/50
Q902
78M05AHF
1
I
2G
3O
R311
100K
C312
334J
C315
334J
R313
3.3K
R314
3.3K
R315
3.3K
R317
2.2K
R502
33K
C316
104J
C313
104J
R316
4.7K
C317
473J
P301pinjack
NPJ-1PDB556
1
2
C955
223J
E801
-10V
Q303:A
NJM4558LD
4
2
3
8
1
R303
47K
Q303:B
NJM4558LD
7
6
5
R321
270
R307
270
1.0V
R613
470K
R615
22K
R619
22K
D605
1SS133
Q612
2SC1740S-S
Q610
2SA933S
D601
MTZJ3.6B
D602
MTZJ3.6B
Q603
2SC1740S-S
D652
1SS133
C907
220/25
C908
220/25
P535A
P535B
R630
10K
R631
10K
R320
5.6K
R312
100K
D603
1SS133
C311
25/100
C604
4.7/50
C605
4.7/50
R653
680K R652 470K
+5.0V
P903A
NPLG-4P151
1
2
3
4
R951
3.3K(2W)
R952
3.3K(2W)
Q513
2SC5171(ONK_Q)
C301
221J
C950
NC
Q301:B
NJM4558LD
5
6
7
Q301:A
NJM4558LD
3
2
4
1
8
R302
N17RGL20KB15M
1
2
3
R651
10K(1W)
J390
R513
82(1/4W)
R541
820
P908A
NSAS-10P1152
5
4
3
2
1
R654
330K
C526
22/100
C528
22/100
C517
22/100
R623
22K
Q607
2SA933S
R622
10K
Q608
2SC1740S-S
D606
1SS133
P632A
NPLG-3P131
1
2
3
C603
470/10
Q901
DTC123JS
D709
1SS133
Q704
2SC1740S-S
Q705
2SA933S
R717
10K
R716
1K
R715
10K
D708
1SS133
C704
470/10
Q703 2SC1740S-S
+10V
Q519
2SA965-Y(TPE6_F)
Q514
2SA1930(ONK_Q)
Q706
DTC123JS
S101
SLIDESW
8
6 3
4 1 5 2
7
R101A
20K
8
9
6
7 5
R101B
20K
3
2
1
P302ANSAS-18P1831
1
2 3
4
5 6 7
8
9
J999
D707
1SS133
R704
100K
C707
223J
C709
223J
S901
NRC-11007P
2 1
C920 DE1007E472M-KY
P906A
NPLG-2P632
1
2
2
1
P902A
NPLG-2P632
2
1
AC_CORD
P302BNPLG-9P137
9 8
7
6
5
4
3
2 1
C916
MKP_R46_103M
R304
LIST
R305
LIST
R984
LIST
R714
LIST
C303
LIST
LIST
C921
LIST
J316
LIST
T902
LIST
6 5
8
9 4
1
T901
TRANS
LIST
14
12
10
7
1
5
6
8
J995
LIST
Q515
LIST
Q516
LIST
C905
LIST
C906
LIST
J991 LIST
P906C
4
3 2
1
RL901
NRL-1P5A-DC9-179
4
3 2
1
J992 LIST
P906B
LIST
R984T901(MAIN)F901 J995 Q515T902(SUB) Q516 C905,C906 R305 J316(FILTER)C921ACNIS-PWB Output Power C303MODEL
230V NPT-1539P NPT-1520GQ 150W 470(1W) NC 2SC5359-O/R 2SA1987-O/R 5600/71 104M TA10 223J NCBAAF-0491-1F
J991,J992(AC SW)
2.2K 8.2K 2009991199UL
R304 R714
68KSKW-938MPP (Eup AMP. Version)
P535A(SP CABLE)
INPUT
This protection circuit has been applied from the 1st lot
1.6A/250V
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE
MAIN PC BOARD
U01
POWER TRANS. PC BOARD
U02

1/24 PAGE
HTP-980
EXPLODED VIEWS PARTS LIST <Notes>
<L> : Lch
<R> : Rch
<MDC> : Canadian model only
<MPP> : European model only
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED SKW-980 / SKW-938 (B) : POWERED SUBWOOFER
EXPLODED AMPLIFIER SECTION
EXPLODED [SEMI CONDUCTOR]
EXPLODED Q515 TR 2SC5359-R 1 2203082 !
EXPLODED Q515 or TR 2SC5359-O ( 1) 2203083 !
EXPLODED Q516 TR 2SA1987-R(Q) 1 2203072 !
EXPLODED Q516 or TR 2SA1987-O ( 1) 2203073GR !
EXPLODED Q541 TR 2SC3423-Y 1 2202104
EXPLODED Q541 or TR 2SC3423-O ( 1) 2202103
EXPLODED <Note>
EXPLODED When replacement the following the transistor, made from the same HFE rank as the original type.
EXPLODED Q515, Q516, Q541
EXPLODED [CHASSIS SCREW]
EXPLODED A01 HEAT SINK 230 1 27160591
EXPLODED A02 CUSHION --- 2 28141682
EXPLODED A03 CUSHION --- 1 28141691
EXPLODED A05 SCREW 3TTB+8B(3BC) 10 838430088GR
EXPLODED A06 TAPE TAPE(CLOTH-16U) 1 29110083
EXPLODED A07 ISO SHEET AC262 2 223025
EXPLODED A08 SCREW 3SMS8W.SW+14B(CU) 2 801634
EXPLODED A11 RETAINER (PCB) 1 27142025
EXPLODED A12 RETAINER (TRANS)SKW-538 1 27142177
EXPLODED A101 REAR PANEL SKW-980DAMP(X)MDD/MDC 1 27124184A <MDC>
EXPLODED A101 REAR PANEL SKW-938(X)MPP 1 27124199 <MPP>
EXPLODED A102 BUSHING S-RELIEF #2271 1 27300750 !
EXPLODED A103 KNOB (VOL) 1 28326463
EXPLODED A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
!ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

2/24 PAGE
EXPLODED [TRANS COIL]
EXPLODED T901 P TRANS NPT-1539D 1 2301863 !<MDC>
EXPLODED T901 P TRANS NPT-1539P 1 2301864 !<MPP>
EXPLODED [SW TRM]
EXPLODED F901 FUSE 5A-UL/T-233 1 252326GR !<MDC>
EXPLODED F901 FUSE 1.6A-SE-EAK IECFUSE 1 252073GR !<MPP>
EXPLODED F901 or FUSE 1.6A-SE-TL250V ( 1) 252273GR !<MPP>
EXPLODED F901C LABEL 5A/125V 1 29360462 !<MDC>
EXPLODED P901 AC CORD AS-UC-2 1 253368BLTK !<MDC>
EXPLODED P901 or AC CORD AS-UC-2 ( 1) 253368AYUN !<MDC>
EXPLODED P901 AC CORD AS-CEE-2 1 253374YUN !<MPP>
EXPLODED P901 or AC CORD AS-CEE-2 ( 1) 253306VOL !<MPP>
EXPLODED [OTHERS]
EXPLODED E802 WIRE TIE BSK-1 1 260208

3/24 PAGE
EXPLODED [TUNER UNIT]
EXPLODED --- U01+U02+U06 BAAF-0491-2F * ( 1) 1B139591-2F <MDC>
EXPLODED U01 MAIN PC BOARD ASS'Y BAAF-0491-2F 1 1B1395491-2F <MDC>
EXPLODED U02 POWER TRANS. PC BOARD ASS'Y BAPS-0492-2F 1 1B1395492-2F <MDC>
EXPLODED U06 HOLDER PC BOARD BAETC-0498-2F 1 --- NSP
EXPLODED --- U01+U02+U04+U06 BAAF-0491-1F * ( 1) 1B249591-1F <MPP>
EXPLODED U01 MAIN PC BOARD ASS'Y BAAF-0491-1F 1 1B2495491-1F <MPP>
EXPLODED U02 POWER TRANS. PC BOARD ASS'Y BAPS-0492-1F 1 1B2495492-1F <MPP>
EXPLODED U04 POWER SWITCH PC BOARD ASS'Y BASW-0494-1F 1 1B2495494-1F <MPP>
EXPLODED U06 HOLDER PC BOARD BAETC-0498-1F 1 --- NSP
EXPLODED SPEAKER SECTION (SKW-980 / SKW-938)
EXPLODED SP01a SPK SYSTEM ASS'Y(ALL) SKW-980 (B) MDC (Completed) 1 000-SKW980BMDCCSER <MDC>
EXPLODED SP01b SPK SYSTEM ASS'Y(ALL) SKW-938 (B) MPP (Completed) 1 000-SKW938BMPPCSER <MPP>
EXPLODED SP01c SPK SYSTEM ASS'Y SKW-980 (B) / SKW-938 (B) 1 000-SKW980BESER
EXPLODED <Note>
EXPLODED SP01c = Without amplifier unit, power transformer and speaker unit.
EXPLODED SP02 FOOT (PLASTIC) 4 D249-W54001B-00
EXPLODED SP03 CUSHION Dia17.5 x 2T 4 442-902133-00
EXPLODED SP07 WOOFER 12 inch (30cm) (FPI) 1 300-DNS4243000
EXPLODED SP08 LED HARNESS ASS'Y --- 1 335-SKW750-01
EXPLODED SP09 CLOTH FRAME ASS'Y --- 1 113-0BW980-10
EXPLODED SP13 CUSHION RUBBER PAD 19 x 89 T2 RUBBER (FOR P-TRANS) 2 442-902138-00
EXPLODED SKF-980 (B) <L> / <R> : FRONT SPEAKERS
EXPLODED SP21a SPK SYSTEM ASS'Y(ALL) SKF-980 (B) <L> MDC 1 000-SKF980LBCSER <L>
EXPLODED SP21b SPK SYSTEM ASS'Y(ALL) SKF-980 (B) <R> MDC 1 000-SKF980RBCSER <R>
EXPLODED SP22 CATCHING HOLDER --- 4 D230-DN3X01B-01
EXPLODED SP23 WOOFER W1277C (ONKYO ELE M) 2 W1277C
EXPLODED SP24 TWEETER TW3208B (ONKYO ELE M) 1 TW3208B
EXPLODED SP31 CROSSOVER SKF/SKC NETWORK PCB ASS'Y 1 311-SKF940-00
EXPLODED SP32a TERMINAL WHITE / BLACK 1 332-H8107B-41 <L>
EXPLODED SP32b TERMINAL RED / BLACK 1 332-H8107B-01 <R>
EXPLODED SP34 CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-F96001B-50
EXPLODED SKC-980 (B) : CENTER SPEAKER
EXPLODED SP41 SPK SYSTEM ASS'Y(ALL) SKC-980 (B) MDC 1 000-SKC980BCSER
EXPLODED SP42 CATCHING HOLDER --- 4 D230-DN3X01B-01
EXPLODED SP43 WOOFER W1277C (ONKYO ELE M) 2 W1277C
EXPLODED SP44 TWEETER TW3208B (ONKYO ELE M) 1 TW3208B

4/24 PAGE
EXPLODED SP51 CROSSOVER SKF/SKC NETWORK PCB ASS'Y 1 311-SKF940-00
EXPLODED SP52 TERMINAL GREEN / BLACK 1 332-H8107B-31
EXPLODED SP54 CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-C96001B-50
EXPLODED SKR-980 (B) <L> / <R> : SURROUND SPEAKERS
EXPLODED SP61a SPK SYSTEM ASS'Y(ALL) SKR-980 (B) <L> MDC 1 000-SKR980LBCSER <L>
EXPLODED SP61b SPK SYSTEM ASS'Y(ALL) SKR-980 (B) <R> MDC 1 000-SKR980RBCSER <R>
EXPLODED SP62 CATCHING HOLDER --- 4 D230-DN3X01B-01
EXPLODED SP63 WOOFER W1367B (ONKYO ELE M) 1 W1367B
EXPLODED SP64 TWEETER TW3223A (ONKYO ELE M) 1 TW3223A
EXPLODED SP65 S. ABSORBER 25t x 50 x 50 1 443-925404-00
EXPLODED SP71 CROSSOVER SKM/SKB NETWORK PCB ASS'Y 1 311-SKM940-00
EXPLODED SP72a TERMINAL BLUE / BLACK 1 332-H8107B-81 <L>
EXPLODED SP72b TERMINAL GRAY / BLACK 1 332-H8107B-21 <R>
EXPLODED SP74 CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-M96001B-50

5/24 PAGE
EXPLODED SKB-980 (B) <L> / <R> : SURROUND BACK SPEAKERS
EXPLODED SP81a SPK SYSTEM ASS'Y(ALL) SKB-980 (B) <L> MDC 1 000-SKB980LBCSER <L>
EXPLODED SP81b SPK SYSTEM ASS'Y(ALL) SKB-980 (B) <R> MDC 1 000-SKB980RBCSER <R>
EXPLODED SP82 CATCHING HOLDER --- 4 D230-DN3X01B-01
EXPLODED SP83 WOOFER W1367B (ONKYO ELE M) 1 W1367B
EXPLODED SP84 TWEETER TW3223A (ONKYO ELE M) 1 TW3223A
EXPLODED SP85 S. ABSORBER 25t x 50 x 50 1 443-925404-00
EXPLODED SP91 CROSSOVER SKM/SKB NETWORK PCB ASS'Y 1 311-SKM940-00
EXPLODED SP92a TERMINAL BROWN / BLACK 1 332-H8107B-91 <L>
EXPLODED SP92b TERMINAL TAN / BLACK 1 332-H8107B-A1 <R>
EXPLODED SP94 CLOTH FRAME ASS'Y (WITH GRILLE CLOTH and LOGO) 1 D201-M96001B-50
HTP-980
PRINTED CIRCUIT BOARD PARTS LIS
T
<Notes>
<MDC> : Canadian model only
<MPP> : European model only
SKW-980 (MDC model)
PWB U01 MAIN PC BOARD (BAAF-0491-2F)
PWB U02 POWER TRANS. PC BOARD (BAPS-0492-2F)
PWB CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB [SEMI CONDUCTOR]
PWB D501 ZENER D MTZJ5.6B 1 224470562T <MDC>
PWB D601 ZENER D MTZJ3.6B 1 224470362T <MDC>
PWB D602 ZENER D MTZJ3.6B 1 224470362T <MDC>
PWB D603 DIODE 1SS133 1 223163T <MDC>
PWB D605 DIODE 1SS133 1 223163T <MDC>
PWB D606 DIODE 1SS133 1 223163T <MDC>
PWB D607 DIODE 1SS133 1 223163T <MDC>
PWB D651 DIODE 1SS133 1 223163T <MDC>
PWB D652 DIODE 1SS133 1 223163T <MDC>
PWB D707 DIODE 1SS133 1 223163T <MDC>
PWB D708 DIODE 1SS133 1 223163T <MDC>
PWB D709 DIODE 1SS133 1 223163T <MDC>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
!ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

6/24 PAGE
PWB D901 DIODE D3SBA60 1 22380272F <MDC>
PWB D901 or DIODE RBV402 ( 1) 22380022F <MDC>
PWB D911 DIODE 1SS133 1 223163T <MDC>
PWB D913 DIODE 1SS133 1 223163T <MDC>
PWB D917 DIODE 1SS133 1 223163T <MDC>
PWB D918 DIODE 1SS133 1 223163T <MDC>
PWB D919 DIODE RL1N4003 1 22380260T <MDC>
PWB D920 ZENER D MTZJ9.1B 1 224470912T <MDC>
PWB <Note>
PWB When replacement the following the transistor, made from the same HFE rank as the original type.
PWB Q301 IC NJM4558L-D 1 22240293 <MDC>
PWB Q501 TR 2SC2240-BL(TPE2_F) 1 2211406T <MDC>
PWB Q502 TR 2SC2240-BL(TPE2_F) 1 2211406T <MDC>
PWB Q503 TR 2SC2240-BL(TPE2_F) 1 2211406T <MDC>

7/24 PAGE
PWB Q505 TR 2SA949-O(TPE6_F) 1 2211353T <MDC>
PWB Q505 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T <MDC>
PWB Q505 or TR KTA1024-Y ( 1) 2215844T <MDC>
PWB Q506 TR 2SC2229-O(TPE6_F) 1 2211633T <MDC>
PWB Q506 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T <MDC>
PWB Q506 or TR KTC3206-Y ( 1) 2215854T <MDC>
PWB Q507 TR 2SA949-O(TPE6_F) 1 2211353T <MDC>
PWB Q507 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T <MDC>
PWB Q507 or TR KTA1024-Y ( 1) 2215844T <MDC>
PWB Q509 TR 2SA949-O(TPE6_F) 1 2211353T <MDC>
PWB Q509 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T <MDC>
PWB Q509 or TR KTA1024-Y ( 1) 2215844T <MDC>
PWB Q510 TR 2SC2229-O(TPE6_F) 1 2211633T <MDC>
PWB Q510 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T <MDC>
PWB Q510 or TR KTC3206-Y ( 1) 2215854T <MDC>
PWB Q513 TR 2SC5171(ONK_Q) 1 2203010 <MDC>
PWB Q513 or TR KTD2061-Y ( 1) 2203434 <MDC>
PWB Q514 TR 2SA1930(ONK_Q) 1 2203000 <MDC>
PWB Q514 or TR KTB1369-Y ( 1) 2203424 <MDC>
PWB Q517 TR 2SA933S-S 1 2213355T <MDC>
PWB Q517 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q517 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q518 TR 2SC2235-Y(TPE6_F) 1 2211654T <MDC>
PWB Q519 TR 2SA965-Y(TPE6_F) 1 2211644T <MDC>
PWB Q602 TR KRC103M 1 2215810T <MDC>
PWB Q602 or TR DTC124ES ( 1) 2213160T <MDC>
PWB Q603 TR 2SC1740S-S 1 2213285T <MDC>
PWB Q603 or TR 2SC1740S-R ( 1) 2213284T <MDC>
PWB Q603 or TR KTC3199-GR ( 1) 2215864T <MDC>
PWB Q604 TR 2SA933S-S 1 2213355T <MDC>
PWB Q604 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q604 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q605 TR 2SA933S-S 1 2213355T <MDC>
PWB Q605 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q605 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q606 TR KRA103M 1 2215780T <MDC>
PWB Q606 or TR DTA124ES ( 1) 2212600T <MDC>

8/24 PAGE
PWB Q607 TR 2SA933S-S 1 2213355T <MDC>
PWB Q607 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q607 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q608 TR 2SC1740S-S 1 2213285T <MDC>
PWB Q608 or TR 2SC1740S-R ( 1) 2213284T <MDC>
PWB Q608 or TR KTC3199-GR ( 1) 2215864T <MDC>
PWB Q610 TR 2SA933S-S 1 2213355T <MDC>
PWB Q610 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q610 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q612 TR 2SC1740S-S 1 2213285T <MDC>
PWB Q612 or TR 2SC1740S-R ( 1) 2213284T <MDC>
PWB Q612 or TR KTC3199-GR ( 1) 2215864T <MDC>
PWB Q703 TR 2SC1740S-S 1 2213285T <MDC>
PWB Q703 or TR 2SC1740S-R ( 1) 2213284T <MDC>

9/24 PAGE
PWB Q703 or TR KTC3199-GR ( 1) 2215864T <MDC>
PWB Q704 TR 2SC1740S-S 1 2213285T <MDC>
PWB Q704 or TR 2SC1740S-R ( 1) 2213284T <MDC>
PWB Q704 or TR KTC3199-GR ( 1) 2215864T <MDC>
PWB Q705 TR 2SA933S-S 1 2213355T <MDC>
PWB Q705 or TR 2SA933S-R ( 1) 2213354T <MDC>
PWB Q705 or TR KTA1267-GR ( 1) 2215995T <MDC>
PWB Q706 TR DTC123JS 1 2213640T <MDC>
PWB Q901 TR DTC123JS 1 2213640T <MDC>
PWB Q902 IC 78M05AHF(MPC78M05AHF) 1 222780055NEC <MDC>
PWB Q902 or IC 78M05(NJM78M05FA) ( 1) 222780055JRC <MDC>
PWB [TRANS COIL]
PWB T902 P TRANS NPT-1520JQ 1 2301812A !<MDC>
PWB [CAPACITOR]
PWB C301 UPZ C 2AUPZTF221JE 1 376332214T <MDC>
PWB C302 UTSP C CE04W50V 47M(UTSP) 1 397584707T <MDC>
PWB C303 TF C ECQ-V50V-223J 1 374722234T <MDC>
PWB C501 UTSP C CE04W50V 47M(UTSP) 1 397584707T <MDC>
PWB C503 TF C ECQ-V50V-224J 1 374722244T <MDC>
PWB C504 UTSP C CE04W25V-220M(UTSP) 1 397552217T <MDC>
PWB C505 CERA C CC45CH50V-020C 1 345340201T <MDC>
PWB C506 CERA C CC45CH50V-070D 1 345340702T <MDC>
PWB C514 UPZ C 2AUPZTF101JE 1 376331014T <MDC>
PWB C517 VR C CE04W100V-22M(VR) 1 394692207T <MDC>
PWB C519 TF C ECQ-V50V-224J 1 374722244T <MDC>
PWB C520 TF C ECQ-V50V-224J 1 374722244T <MDC>
PWB C526 VR C CE04W100V-22M(VR) 1 394692207T <MDC>
PWB C527 UTSP C CE04W50V-1M(UTSP) 1 397580107T <MDC>
PWB C528 VR C CE04W100V-22M(VR) 1 394692207T <MDC>
PWB C601 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MDC>
PWB C602 UTSP C CE04W50V-10M(UTSP) 1 397581007T <MDC>
PWB C603 UTSP C CE04W10V-470M(UTSP) 1 397534717T <MDC>
PWB C604 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T <MDC>
PWB C605 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T <MDC>
PWB C704 UTSP C CE04W10V-470M(UTSP) 1 397534717T <MDC>
PWB C707 TF C ECQ-V50V-223J 1 374722234T <MDC>
PWB C709 TF C ECQ-V50V-223J 1 374722234T <MDC>
