Onkyo TX-8050 User manual

A PLIFIER AND CONNECTION
FEATURES
• 130 W/Ch at 6 Ω, 1 kHz, 1%, 1 Channel Driven, IEC
• WRAT (Wide Range Amplifier Technology)
• Discrete Amplifier Design with assive EI
Transformer
• Two Large 8,200 µF Capacitors
• TI Aureus™DSP Chip (DA830) for Network Audio
and Digital Audio Processing
• Direct Digital Connection of iPod/iPhone via
Front-Panel USB Port
• Handles Playback of ass Storage Class USB
emory
• Compatible with UWF-1 Wireless LAN Adapter
(via USB)
• Playback of Audio Files Through Local Network
( P3, W A, W A Lossless, FLAC, WAV, Ogg Vorbis,
AAC, LPC )
• Internet Radio and usic Streaming Service
Connectivity (vTuner, Last.fm*, Napster*)
• Certified with Windows®7 and DLNA Version 1.5
• Universal Port for Onkyo Peripheral Devices Such
as UP-A1 Dock for iPod/iPhone or UP-DT1 DAB+
Radio Tuner
• Pure Audio ode
• Direct ode
• 4 Composite Video Inputs and 2 Outputs
• 4 Digital Audio Inputs (2 Optical and 2 Coaxial)
• 6 Analog Audio Inputs and 2 Outputs
• Phono Input
• Zone 2 Pre Outs for Distributed Audio Playback in
Another Room
• Audio L/R and Subwoofer Pre Outs
• Speaker A/B Drive
• IR Input and Output
• Headphone Jack
* Availability f services depends n regi n.
TUNER FEATURES
• 40 F /A Random Presets
• RDS (PS/PTY/RT/TP)
• Direct Access Tuning with 10 Key Buttons
• Preset Station Naming (Up to 10 Characters)
OTHER FEATURES
• Aluminum Front Panel
• Anti-Vibration Oval Chassis
• Gold-Plated Audio and Video Terminals
• Banana Plug-Compatible Speaker Posts
• Independent Bass, Treble, and Balance Control
• 3- ode Display Dimmer (Normal/Dim/Dimmer)
• Sleep Timer (via Remote)
• Battery-Free emory Back-up
• Compatible with RI (Remote Interactive) Dock for
the iPod/iPhone
• Full-Function RI Remote Control
Quality Stereo Audio with Added Network Functionality
Onkyo’s hi-fi revolution gathers pace with the TX-8050. This finely sculpted stereo receiver delivers two channels
of audio precision to entertainment spaces where you don’t need advanced video processing or multichannel
audio. Analog A/V inputs on the TX-8050 are augmented by digital optical and coaxial audio inputs, a Universal
Port for Onkyo peripherals, and a front-side USB input for direct digital connection of iPod/iPhone. The receiver’s
network capability, meanwhile, lets you stream internet radio or play audio from a PC or network audio storage
device. Behind the smart aluminum façade lies a massive transformer and large capacitors that provide clean
amplification power and help push performance well beyond the norm.
BLACK
TX-8050 NETWORK STEREO RECEIVER
2011 NEW PRODUCT RELEASE
SILVER
TX-8050_EU_TX-8050 11/03/18 17:03 ページ 1Downloaded from www.Manualslib.com manuals search engine

TX-8050 NETWORK STEREO RECEIVER
Due to a policy of continuous product improvement, Onkyo reser ves the right to change specifications and appearance without notice. iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. " ade
for iPod" and " ade for iPhone" mean that an electronic accessory has been designed to connect specifically to iPod or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or
its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may affect wireless performance. Windows 7 and the Windows logo are trademarks or registered trademarks of icrosoft Corporation in the United States and/or
other countries. Aureus is a trademark of Texas Instruments. WRAT is a trademark of Onkyo Corporation. All other trademarks and registered trademarks are the property of their respective holders.
NPR No. 11N37 03/11
WRAT (Wide Range Amplifier Technology)
The TX-8050 employs a host of proprietary Onkyo
technologies to ensure optimal audio performance.
Low Negative-Feedback Design
T much NFB makes a system susceptible t c unter-electr m tive
frce fr m the speakers, resulting in a dr p in perceived s und
quality. T av id this, Onky f cuses n impr ving the frequency
resp nse and reducing dist rti n, with ut relying s much n NFB.
Closed Ground-Loop Circuits
The TX-8050 empl ys a s phisticated cl sed-circuit design in which
each circuit has a separate link t the p wer supply. This helps t
cancel individual circuit n ise and keep the gr und p tential free
f dist rti n.
HICC (High Instantaneous-Current Capability)
HICC enables an amplifier t immediately cancel the speakers’
reflex energy and instantane usly send ut the next signal. The
same high current required t achieve this als supp rts the
amplifier’s ability t handle speaker impedance fluctuati ns.
Network Capability Delivers Internet Radio and
Network Audio Streaming via Ethernet
As one of Onkyo’s new breed of receivers that can link
directly to the internet or to your home PC via a local
network, the TX-8050 takes streaming audio and internet
radio to a whole new level. P3, W A, W A Lossless,
FLAC, WAV, Ogg Vorbis, AAC, and LPC audio files can
now be played back through your main system with
unprecedented power and fidelity. The TX-8050 also brings
to life a huge array of internet radio channels from Last.fm*
and vTuner, plus on-demand music streaming from
Napster*. As well as being compatible with earlier
platforms, the receiver is compatible with icrosoft’s
Windows®7 platform, which includes the DLNA
1.5-specified “Play To” media-streaming feature.
*Availability f services depends n regi n.
SPECIFICATIONS
Amplifier Section
Power Output 130 W + 130 W
(6 Ω, 1 kHz, 1%, 1 channel driven, IEC)
Dynamic Power 180 W + 180 W (3 Ω)
160 W + 160 W (4 Ω)
100 W + 100 W (8 Ω)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half power)
Damping Factor 60 (1 kHz, 8 Ω)
Input Sensitivity and Impedance
Line 200 mV/47 kΩ
Phono 2.5 mV/47 kΩ
Rated RCA Output Level and Impedance
Rec out 200 mV/2.2 kΩ
aximum RCA Output Level and Impedance
Rec out 2.0 V/2.2 kΩ
Phono Overload 60 mV ( , 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz (+1 dB, -3 dB)
Tone Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio
Line 106 dB (IHF-A)
Phono 80 dB (IHF-A)
Speaker Impedance 4 Ω–16 Ω(A or B), 8 Ω–16 Ω(A + B)
Video Section
Input Sensitivity/Output Level and Impedance
1.0 Vp–p/75 Ω(Composite)
Tuner Section
T
uning Frequency Range
F 87.5 Hz–108 Hz
A 522 kHz–1,611 kHz
530 kHz–1,710 kHz
General
Power Supply AC 230 V~, 50 Hz
Power Consumption 295 W
Dimensions (W x H x D) 435 x 149.5 x 328 mm
Weight 8.8 kg
CARTON
Dimensions (W x H x D) 572 x 264 x 419 mm
Weight 11.4 kg
Supplied Accessories
• Indoor F antenna • A loop antenna • Instruction manual
• Remote controller • AAA (R03) batteries x 2
Direct Digital Connection of iPod/iPhone via
Front-Panel USB Port
The TX-8050’s front-panel USB port lets you access P3,
WA, W A Lossless, FLAC, WAV, Ogg Vorbis, and AAC
audio files stored on a USB flash drive or iPod/iPhone. As
the audio signals are transported in digital form, rather than
analog, there is much less chance for signal degradation. End
result: your music sounds cleaner and more faithful to the
original. A further benefit of the USB input is that it lets you
use the system’s remote controller to play back audio files
on the connected device.
Play Your Audio Sources in Two Different Rooms
Zone 2 pre-outs on the TX-8050 allow you to send a
stereo audio signal to a second room equipped with an
amplifier and a pair of speakers. You can either enjoy the
same source in both rooms, or play a different source in
Zone 2.
Universal Port for Single-Cable Connection of
Onkyo Peripheral Devices
A proprietary Universal Port located on the rear side of
the TX-8050 lets you connect an optional UP-A1 Dock for
iPod/iPhone or UP-DT1 DAB+ Radio Tuner. A key
advantage of the Universal Port is that it accepts video and
audio signals through the same cable that sends a power
supply from the receiver to the device. Net result: more
connectivity, less cable clutter.
