Onkyo TX-NR929 User manual

TX-NR929
RC-840M
North American models ---> “DIMMER”
European and Australian models ---> “RT/PTY/TP”
Features
Amplifier
• 135 Watts/Channel @ 8 ohms (FTC)
• 185 Watts/Channel @ 6 ohms (IEC)
• 230 Watts/Channel @ 6 ohms (JEITA)
• WRAT–Wide Range Amplifier Technology
(5 Hz to 100 kHz bandwidth)
• Optimum Gain Volume Circuitry
• H.C.P.S. (High Current Power Supply) Massive
High Power Transformer
• 3 Stage Inverted Darlington Amplifier Design
Processing
• THX Select2 Plus Certified
• Incorporates Qdeo™ technology for HDMI Video
Upscaling (to 4K Compatible)
• HDMI (Audio Return Channel, 3D, DeepColor,
x.v.Color, Lip Sync, 4K (up-scaling and
Passthrough), DTS-HD Master Audio, DTS-HD High
Resolution Audio, Dolby TrueHD, Dolby Digital Plus,
DSD and Multi-CH PCM)
• Dolby TrueHD and DTS-HD Master Audio
• Dolby Pro Logic IIz and Audyssey DSX®
• DTS Neo:X
• Non-Scaling Configuration
• A-Form Listening Mode Memory
• Direct Mode
• Pure Audio Mode
• Music Optimizer for Compressed Digital Music files
• Phase Matching Bass System
• 192 kHz/24-bit D/A Converters
• Powerful and Highly Accurate 32-bit Processing
DSP
• Jitter Cleaning Circuit Technology
• Digital Processing Crossover Network
Connections
• 9 HDMI Inputs (1 on front panel) and 2 Outputs
• 4K (up-scaling and Passthrough)-compatible HDMI
Inputs
• Zone 2 HDMI Output
• Onkyo p for System Control
• 6 Digital Inputs (3 Optical/3 Coaxial)
• Component Video Switching (2 Inputs/1 Output)
• Banana Plug-Compatible Speaker Posts
* In Europe, using banana plugs to connect speakers to an
audio amplifier is prohibited.
• Powered Zone 2/3
• Bi-Amping Capability for FL/FR with FHL/FHR
• Analog RGB Video Input (D-sub 15) for PC
• Internet Radio Connectivity
• Network Capability for Streaming Audio Files
• Wi-Fi (Wireless LAN) Connectivity
• Wireless Music Playback via Bluetooth
• Front-Panel USB Input for Memory Devices
• MHL-Enabled AUX Front Input
Miscellaneous
• 40 FM/AM Presets
• Audyssey MultEQ® XT32 to correct room acoustic
problems
• Audyssey Dynamic EQ® for loudness correction
• Audyssey Dynamic Volume® to maintain optimal
listening level and dynamic range
• Crossover Adjustment
(40/50/60/70/80/90/100/120/150/200 Hz)
• A/V Sync Control Function (up to 800 ms)
• Auto Standby Function
• On-Screen Display via HDMI
• Preprogrammed (with onscreen display setup)
RI-Compatible Learning Remote with 4 Activities
and Mode-Key LEDs
• ISF (Imaging Science Foundation) Video Calibration
Features
AV RECEIVER
Black and Silver models
MODEL TX-NR929(B)/(S)
Ref. No. 4443
062013
120V AC, 60Hz
220-240V AC, 50/60Hz
220-240V AC, 50/60Hz
B MDC
B MMP, B MMB, B MMA, S MMP
B MMR

TX-NR929
SERVICE PROCEDURE
REPLACING THE FUSE
This symbol located near the fuses indicates that the
fuse used is fast operating type. For continued protection
against fire hazard, replace with same type fuse. For
fuse rating refer to the marking adjacent to the symbol.
Ce symbole indique que le fusible utlise est a rapide.
Pour une protection permanente, n'untiliser que fusibles
de meme type. Ce darnier est la qu le present symbol
est appse.
PRECAUTIONS
1. Ground for the work-desk.
Place a conductive sheet such as a sheet of copper (with impedance lower than 10Mohm) on the work-desk and place the set on
the conductive sheet so that the chassis.
2. Grounding for the test equipments and tools.
Test equipments and toolings should be grounded in order that their ground level is the same the ground of the power source.
3. Grounding for the human body.
Be sure to put on a wrist-strap for grounding whose other end is grounded.
Be particularly careful when the workers wear synthetic fiber clothes, or air is dry.
4. Select a soldering iron that permits no leakage and have the tip of the iron well-grounded.
5. Do not check the laser diode terminals with the probe of a circuit tester or oscilloscope.
This symbol located near the fuses indicates that the
fuse used is slow operating type. For continued protec-
tion against fire hazard, replace with same type fuse. For
fuse rating refer to the marking adjacent to the symbol.
Ce symbole indique que le fusible utlise est e lent. Pour
une protection permanente, n'untiliser que fusibles de
meme type. Ce darnier est la qu le present symbol est
appse.
To initialize the unit
Refer to “Initial setting for shipping” on “OPERATION CHECK-6”.
To check version of each Firmware
Refer to “Version confirmation” on “OPERATION CHECK-1”.
Notes on repairs (Power supply board)
Some parts on BAPS-1398 may remain high voltages even after the power cord is disconnected from AC power source.
Before starting repair and any other work , please discharge C9002 by connecting resistors between its terminals.
Recommended resistor spec: 5 k ohms/ 10W
Refer to “SCHEMATIC DIAGRAMS-09-4(PART-9-4)”.

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-1
AUDIO DEBUG MODE-1/4
To set in Debug mode
1. Press twice the ON/STANDBY key while pressing the DISPLAY key.
The version number of microprocessor is displayed
only for 3 seconds.
The version number of DSP is displayed
only for 3 seconds.
AUDIO DEBUG MODE (Display mode of the audio information)
The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode.
This information will help to analysing digital audio no sound trouble.
Audio dubug mode
Step-1
Exit
e.g. Main:
1.01/13515AE8
2. Press + (TONE) button while the version number of microprocessor is displayed.
3. Press DISPLAY button while the version number of DSP is displayed.
DSP 1st/NET:
1.07/13514AEA
e.g.
0A0002: : 00
ANA: o: NON: :
4. Press DISPLAY button.
SP00F*00F00409
48 48256STB
2: o: PCM : PCM
00: x: F: OFF
1:ANA 048k048k
2/ 0. 0: 2. 0: 3/4
9. Press DISPLAY button.
8. Press DISPLAY button.
6. Press DISPLAY button.
5. Press DISPLAY button.
11. Press DISPLAY button.
12. Press DISPLAY button.
10. Press DISPLAY button.
7. Press DISPLAY button.
13. Press DISPLAY button.
LW : 0 0
RW : 0 0
LB : 0 0
RB : 0 0
LH : 0 0
RH : 0 0
LS : 0 0
RS : 0 0
C : 0 0
L : 0 0
R : 0 0
SW : 0 0
SW2 : 0 0
Step-2
Step-11
Step-10
Step-9
Step-8
Step-7
Step-6
Step-5
Step-4
Step-3
14. Press DISPLAY button.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.
e.g.

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-2
AUDIO DEBUG MODE-2/4
Step-1
1 1 2 2 3 3 : A A : B B
C C C : D : E E E : F : G
A Muting port
D
A
DIGMUTE port
AMUTE port
Factor of muting
B
bit_2 POWMUTE
bit_5 AUDIOMUTE
bit_3 PROTECTMUTE
bit_4 AUDIOOUTMUTE
bit_1 SELMUTE
Sound state
E
STB SOUND STATE FIX
NON SOUND STATE NONE
TRS SOUND STATE UNFIX
C Input
ANA Analog
COX Caxal
OPT Optical
HDM HDMI
ARC ARC
Display inhibit
F
S
C
display_inhibit SET
display_inhibit CLR
DSP Detect
D
× DSP No Detect
○DSP Detect OK
HDMI mute
G
V HDMI MUTE
st_srd.lmd
C_LM_LAST 0x01
C_LM_PURE 0x02
C_LM_DIRECT 0x03
C_LM_STEREO 0x04
C_LM_MONO 0x05
C_LM_SURR 0x20
C_LM_THX_MUSIC 0x50
C_LM_THX_GAME 0x70
C_LM_THX_CINEMA 0x90
C_LM_THX_U2GAME 0xA0
C_LM_THX_U2MUSIC 0xA8
C_LM_THX_U2CINEMA 0xB0
C_LM_AUDYSSEY 0xD0
C_LM_DTSSS 0x48
C_LM_ORCHESTRA 0x06
C_LM_UNPLUGGED 0x07
C_LM_STUDIOMIX 0x08
C_LM_TVLOGIC 0x09
C_LM_ALLCHST 0x0A
C_LM_FULLMONO 0x0B
C_LM_TD 0x0C
C_LM_TESTTONE 0xF1
C_LM_TESTTHR 0xF2
C_LM_TESTAUTO 0xF3
C_LM_ASC 0xF4
C_LM_FLASH 0xF5
C_LM_DEBUGMODE 0xF6
C_LM_FLASH2 0xF7
C_LM_FLASH3 0xF8
C_LM_FLASH4 0xF9
C_LM_FLASH_CHECK 0xFA
C_LM_RPG 0x0D
C_LM_ACTION 0x0E
C_LM_ROCKBAND 0x0F
C_LM_SPORTS 0x10
1
st_srd.extdecmd
C_EXTDECMD_OFF 0x00
C_EXTDECMD_10 0x01
C_EXTDECMD_20 0x02
C_EXTDECMD_MOVIE 0x03
C_EXTDECMD_MUSIC 0x04
C_EXTDECMD_GAME 0x05
C_EXTDECMD_HEIGHT 0x06
C_EXTDECMD_WIDE 0x07
3
st_srd.extdec
C_EXTDEC_OFF 0x00
C_EXTDEC_20_PLII 0x01
C_EXTDEC_20_PLIIX 0x02
C_EXTDEC_20_PLIIZ 0x03
C_EXTDEC_20_NEO6 0x04
C_EXTDEC_51_MTR 0x05
C_EXTDEC_51_DSC 0x06
C_EXTDEC_51_NEO6 0x07
C_EXTDEC_51_EX 0x08
C_EXTDEC_51_PLIIX 0x09
C_EXTDEC_51_PLIIZ 0x0A
C_EXTDEC_9624 0x0B
C_EXTDEC_9624_MTR 0x0C
C_EXTDEC_71MULTI 0x0E
C_EXTDEC_20_NEURAL 0x0F
C_EXTDEC_51_NEURAL 0x10
2
FL Display

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-3
AUDIO DEBUG MODE-3/4
1 : 1 1 1 1 2 2 2 k 3 3 3 k
4 4 4 . 5 : 6 6 6 6 : 7 7 7
4
Number of input channels
for listening mode transition
2 Sampling frequency
st_srd.fs
5 Input channel
st_srd.lfe, st_srd.lfe2
0
1
2
SW 0ch
SW 1ch
SW 2ch
"10.2" "5.1" "1 +1" four-digit string
6
Number of channels for display
st_hd_display.prgfmt[4]
1 Type of input format
source_format
DDR_DSD
DDR_DDPLUS
DDR_DTSEXP
DDR_DTSHD
DDR_DTSCD
DDR_AAC
DDR_MCHPCM
DDR_MCH
DDR_TRUE
DDR_MSTR
DDR_DATA
DDR_UNKNOWN
DDR_NOT_READY
DDR_NOT_PCM
DDR_FS96
DDR_NOT_DETECT
PLUS
EXPR
DTSH
ANA
DDR_UNLOCK
DDR_ANALOG
DDR_PCM
DDR_AC3
DDR_DTS
DDR_MPEG
AAC
MPCM
MCH
TRUE
MSTR
DSD
UNKW
NORD
NPCM
FS96
NODT
DTSC
UNLK
PCM
AC3
DTS
MPEG
DATA
3 Sampling frequency for display
st_hd_display.fs
176.4kHz
192kHz
32kHz
44.1kHz
48kHz
64Hz
88.2kHz
96kHz
12kHz
16kHz
22kHz
24kHz
??? unknown
8kHz
11kHz
032
044
176
192
048
064
088
096
008
011
012
016
022
024
7 Number of channels after
the decoding process
hd_dec_prgfmt
C_FMT_22
C_FMT_32
C_FMT_23
C_FMT_33
C_FMT_24
C_FMT_34
C_FMT_UNKNOWN
C_FMT_10
C_FMT_20
C_FMT_30
C_FMT_21
C_FMT_31
C_FMT_42H
4H4
4H2
5H2
4W2
5W2
C_FMT_52H
C_FMT_42W
C_FMT_52W
C_FMT_44H
???
10
20
30
23
33
21
31
22
32
24
34
C_FMT_44W
4H3 C_FMT_43H
5H4 C_FMT_54H
5W3 C_FMT_53W
11 C_FMT_11
4W3 C_FMT_43W
5W4 C_FMT_54W
5H3 C_FMT_53H
4W4
Step-2

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-4
AUDIO DEBUG MODE-4/4
2 : 8 : 9 9 9 9 : 10 10 10 10
11 11 : 12 : 13 : 14 14 14 15 15
12 DIRINT
The return value of ddr
Request_dir (DDC_STATUS)
9 Details of input format
st_srd.source
10 Details of input format
st_hd_display.source
13 DIR busy or free
The return value of ddr Request_dir
(DDC_BUSY)
14 Emphasis information
f_dir_empha_mode
15
HDDVD/BLUE(Only DDPLUS)
Busy
ON
OFF
o
k
LOCK
UNLOCK
F Free
B
ON
OFF
BD Bluray
HD HDDVD
11 Dialog Norm
st_srd.dnorm
Dialog Norm value of 0 to 31
8
Audio output OK?
f_dsp_detect_ok
o
x
Decode OK
Decode NG
ANA
PCM
DLB
DEX
AAC
MCH
DSP
DTS
MTR
DSC
D96
C_SRC_DTS_96M96M
C_SRC_ANA
C_SRC_PCM
C_SRC_DD
C_SRC_DD_EX
C_SRC_DTS
C_SRC_DTS_MTR
C_SRC_DTS_DSC
C_SRC_DTS_96
C_SRC_AAC
C_SRC_MCH
C_SRC_DSP
MSTR
PLUS
PLEX
EXP
MPCM
DSD
TRUE
TREX
C_SRC_MCHPCM
DTSH
C_SRC_DDPLUS_SUR
C_SRC_TRUE_SUR
DSUR
DPSR
TRSR
C_SRC_DDPLUS
C_SRC_DDPLUS_EX
C_SRC_DTSEXP
C_SRC_DTSHD
C_SRC_DD_SUR
C_SRC_DSD
C_SRC_TRUE
C_SRC_TRUE_EX
C_SRC_MSTR
L :
R :
C :
:
L S :
R S :
L B :
R B :
L H :
R H :
L W :
R W :
S W :
S W 2 :
The sum of the values of Volume correction related to the DSP.
The sum of the values of Volume correction, including correction
of the Analog stage.
Step-3
Step-5 to Step-11

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-5
HDMI DEBUG MODE-1/4
HDMI-related operations can be checked to some extent by displaying HDMI debug mode.
To enter this mode
Hold down DISPLAY button for 3 seconds. Information display will last for about 8 seconds.
The first line : Input resolution
The second line :Output resolution
List of standard resolution
1 0 8 0 i / 6 0 →
1 0 8 0 i / 6 0
Display of Input Resolution ---> The first line
DVI input signal
VGA input signal
No input
“I” and “P” will be capitalized.
Display the ” ” in column 1
4 8 0 I / 6 0 →
4 8 0 P / 6 0 →
V G A →
U n k n o w n →
Resolution display method
U N K N O W N
4 8 0 i / 6 0
4 8 0 p / 6 0
1 0 8 0 i / 6 0
7 2 0 p / 6 0
1 0 8 0 p / 6 0
2 4 0 p / 6 0
# 4 8 0 i / 6 0
# 4 8 0 p / 6 0
# 2 4 0 p / 6 0
5 7 6 i / 5 0
5 7 6 p / 5 0
1 0 8 0 i / 5 0
7 2 0 p / 5 0
1 0 8 0 p / 5 0
2 8 8 p / 5 0
# 5 7 6 i / 5 0
# 5 7 6 p / 5 0
# 2 8 8 p / 5 0
1 0 8 0 p / 2 4
1 0 8 0 p / 2 5
1 0 8 0 p / 3 0
U N K N O W N
V G A
1 0 8 0 i 1 0 0
7 2 0 p 1 0 0
5 7 6 p 1 0 0
5 7 6 i 1 0 0
1 0 8 0 i 1 2 0
7 2 0 p 1 2 0
4 8 0 p 1 2 0
4 8 0 i 1 2 0
5 7 6 p 2 0 0
5 7 6 i 2 0 0
4 8 0 p 2 4 0
4 8 0 i 2 4 0
4 8 0 p / 6 0
5 7 6 p / 5 0
7 2 0 p / 2 4
7 2 0 p / 2 5
7 2 0 p / 3 0

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-6
HDMI DEBUG MODE-2/4
i / p will be
capitalized.
Display the ” ”
in column 5
Display the ” ”
in column 14
Display the ” # ”
in column 14
Display the ” x ”
in column 14
Display the ” ”
in column 4
4K Upscaling
Display of Output resolution
Display of Input resolution
If the three-digit numbers
are refrate
List of resolution
Resolution Error
EDID_READ_NG
Dislay of Output Resolution ---> The second line
For a video processor
DVI input signal
VGA input signal
RSEN is OFF
EDID_READ is NG
Resolution Error
No output
(Signal output destination
can not be found.)
Hot-plug of Sink equipment
can not be detected.
Via VSP
VSP skip
→1 0 8 0 i / 6 0
1 0 8 0 i / 6 0
4 8 0 I / 6 0
4 8 0 P / 6 0
4 8 0 p / 6 0
4 8 0 p / 6 0
4 8 0 p / 6 0 #
4 8 0 p / 6 0 x
- - - - -
O F F
1 0 8 0 i / 6 0 →
x p /
3 8 4 0 x 2 1 6 0 p / 3 0
3 8 4 0 x 2 1 6 0 p / 2 5
3 8 4 0 x 2 1 6 0 p / 2 4
4 0 9 6 x 2 1 6 0 p / 2 4
3 8 4 0 x 2 1 6 0 p / 3 0 x
3 8 4 0 x 2 1 6 0 p / 3 0 #
→
3D Display
Display the ” ”
in column 14
Display the ” # ”
in column 9
Display the ” x ”
in column 13
RSEN OFF
EDID READ NG
Resolution Error
The first line : Resolution display
The second line : Status Display
1 0 8 0 p / 2 4 ( 3 D )
H D M I 4 4 4 3 6 b i t
1 0 8 0 p / 2 4 ( 3 D )
H D M I 4 4 4 # 3 6 b i t
1 0 8 0 p / 2 4
(
3 D
)x

DEBUG MODE-7
HDMI DEBUG MODE-3/4
TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
Status
Input Mode HDMI input 1 0 8 0 p / 2 4 ( 3 D )
H D M I 4 4 4 3 6 b i t
DVI Input 1 0 8 0 p / 2 4 ( 3 D )
D V I 4 4 4 3 6 b i t
No Input 1 0 8 0 p / 2 4 ( 3 D )
- - - 4 4 4 3 6 b i t
Input Color RGB 1 0 8 0 p / 2 4 ( 3 D )
H D M I R G B 3 6 b i t
422 1 0 8 0 p / 2 4 ( 3 D )
H D M I 4 2 2 3 6 b i t
444 1 0 8 0 p / 2 4 ( 3 D )
H D M I 4 4 4 3 6 b i t
Deep Color 24bit 1 0 8 0 p / 2 4 ( 3 D )
H D M I R G B 2 6 b i t
30bit 1 0 8 0 p / 2 4 ( 3 D )
H D M I R G B 3 0 b i t
36bit 1 0 8 0 p / 2 4 ( 3 D )
H D M I R G B 3 6 b i t
3D format
Frame Packing F r a m e P a c k i n g
Field alternative F i e l d
a l t e r n a t i v e
Line alternative L i n e
a l t e r n a t i v e
Side-by-Side(Full) S i d e - b y - S i z e
( F u l l )
L+depth L + d e p t h
L+depth + graphics L + d e p t h
+ g r a p h i c s
S ide by Side(Harf) S i d e - b y - S i z e
( H a r f )
Top and Bottom T o p - a n d - B o t t o m
unknown U N K N O W N
INPUT/OUTPUT I N P U T :
O U T P U T :

DEBUG MODE-8
HDMI DEBUG MODE-4/4
TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
PC Resolution
Display of Input resolution
Display of Output resolution
Display the ” # ” in
column 13
Display the ” x ” in
column 13
The first line : Input resolution
The second line :Output resolution
Horizontal resolution Vertical resolution Referat
Horizontal resolution Vertical resolution Referat
DVI input
HDMI input
No input
Three-digit numbers
are Referat
Display uppercase P/I
Display lowercase p/i
INPUT/ OUTPUT
DVI output
HDMI output
Display”-----”
Three-digit numbers
are Referat
EDID READ NG
Resolution through
Display uppercase P/I
Display lowercase p/i
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 p / 6 0
x p / →
1 0 2 4 x 7 6 8 p / 6 0
1 0 2 4 x 7 6 8 P / 6 0 →
1 0 2 4 x 7 6 8 p / 6 0
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 p / 6 0
1 0 2 4 x 7 6 8 P 1 2 0 →
1 0 2 4 x 7 6 8 p / 6 0
U N K N O W N
1 0 2 4 x 7 6 8 p / 6 0
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 P / 6 0
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 p / 6 0
1 0 2 4 x 7 6 8 p / 6 0 →
→- - - - -
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 P 1 2 0
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 P / 6 0 #
1 0 2 4 x 7 6 8 p / 6 0 →
1 0 2 4 x 7 6 8 P / 6 0 x
I N : *
O U T : *
1 0 2 4 x 7 6 8 p / 6 0 →
x p /

TX-NR828/ 929/ DTR-50.5/ 60.5/ DHC-60.5
DEBUG MODE-9
SERVICE INFORMATION MODE
Displaying Service information
This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off.
Pay attention that the status will change if a button is pushed.
0 1 : 2 3 1 0 h
e.g.
1. Press twice the ON/ STANDBY key while pressing the DISPLAY key.
Listening Mode Code List
- 8 0 F 2 7 D D
e.g.
Power off Cause
T : Thermal Protect
V : Voltage Protect
I : Current Protect
- : Other
Temperature
: xx F or xx C
Volume Level Listenning Mode
---> Refer to the code list below.
Time after Power on
xx : xx
Time after Initialize
xx hour
1.01/13515AE8 The version of main microprocessor is
displayed only for 3 seconds.
e.g.
C_LM_LAST01
C_LM_PURE02
C_LM_DIRECT03
C_LM_STEREO04
C_LM_MONO05
C_LM_SURR20
C_LM_THX_MUSIC50
C_LM_THX_GAME70
C_LM_THX_CINEMA90
C_LM_THX_U2GAMEA0
C_LM_THX_U2MUSICA8
C_LM_THX_U2CINEMAB0
C_LM_ASCF4
C_LM_FLASHF5
C_LM_DEBUGMODEF6
C_LM_FLASH2F7
C_LM_FLASH3F8
C_LM_FLASH4F9
C_LM_FLASH_CHECKFA
C_LM_RPG0D
C_LM_ACTION0E
C_LM_ROCKBAND0F
C_LM_SPORTS10
3. Press HOME button again. The following information are displayed.
2. Press HOME button within 3 seconds above.
C_LM_AUDYSSEYD0
C_LM_DTSSS48
C_LM_ORCHESTRA06
C_LM_UNPLUGGED07
C_LM_STUDIOMIX08
C_LM_TVLOGIC09
C_LM_ALLCHST0A
C_LM_FULLMONO0B
C_LM_TD0C
C_LM_TESTTONEF1
C_LM_TESTTHRF2
C_LM_TESTAUTOF3
Information Displayed (Record this Information)
Information Displayed (Record this Information)
4. Press ON/STANDBY button to exit the display of service information.
(Ref.: Press RETURN button to initialize the data in the service information.)
ProtectData CLR
Normal display

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-1
1.VERSION CONFIRMATION
2.CONFIRMATIONS OF OPERATIONS
2-1. OPERATIONS OF SPEAKER RELAYS
The relay shall be ON about 10 seconds after POWER is ON and shall be OFF immediately after POWER is OFF.
2-2. OPERATIONS OF VOLTAGE-DETECTION PROTECTORS.
See OPERATION CHECK-7 for TEST MODE operation.(Except DHC-60.5)
(How to check in test mode)
a. Change the state to "TEST 4-24".
b.
c. It will complete, if displayed on FL TUBE as "TEST 4-42."
NOTE : Don't connect load nor short speaker terminals.
2-3. OPERATIONS OF CURRENT-DETECTION PROTECTORS (Except DHC-60.5)
(How to check in test mode)
Change the state to "TEST 4-42".
Even if you connect 3-ohm load for every channel of L, R, C, SL, SR, SBL and SBRch, a relay should not cut off.
If 1-ohm load is connected for every channel of L, R, C, SL, SR,SBL and SBRch, a relay should hold the state of ON.
2-4 CONFIRMATION OF REMOTE CONTROL OPERATION
a. Confirm that the specified operations for each button are made.
b. Connect a casette deck etc. with the unit, and confirm it's operations.
a.
b.
1. During the POWER ON, please push ON/STANDBY button two times while pushing down DISPLAY button.
2. The version of main micom is displayed at FL tube.
3. While the version of main micom is displaying, please push (TONE) + button.
4. FL tube displays by rotation as follows.
Main micom→1'st DSP→2'nd DSP→Video micom→Video processor→OSD

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-2
2.CONFIRMATIONS OF OPERATIONS
2-5. CONFIRMATION OF IR OPERATIONS
a. Connect the designated circuit(XANTECH) to IR IN and confirm operations of the unit. (only TX-NR929 except MJJ)
b. Connect the designated circuit(XANTECH) to IR IN A and confirm operations of the unit. (only DTR-60.5/DHC-60.5)
c. Connect the designated circuit(XANTECH) to IR IN B and confirm operations of the unit. (only DTR-60.5/DHC-60.5)
d. Connect the designated circuit(XANTECH) to OUT and confirm operations of the unit.
(only TX-NR929 except MJJ,DTR-60.5/DHC-60.5)
2-6. CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION
(applies to ( MMA/MMB/MMP/MMR Type.)
a. Input 98MHz,30dBμ signal modurated with RDS data.
b. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds
instead of the frequency.
2-7. CONFIRMATION OF HEAD PHONE OPERATION.
Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted
into the PHONES jack.
2-8. CONFIRMATION OF 12V TRIGGER OPERATIONS .
a. After checking that there is no output from 12V TRIGGER ZONE2(Integra model is TRIGGER A) terminal, confirm that
there is an output of 12V±10%/150mA mmediately switched the "TEST2-11". (except TX-NR929MJJ )
b. After checking that there is no output from 12V TRIGGER ZONE3 (Integra model is TRIGGER B) terminal, confirm that
there is an output of 12V±10%/ 25mA after 2 seconds switched the "TEST2-12".
(except TX-NR929MJJ )
d. After checking that there is no output from 12V TRIGGER C terminal, confirm that
there is an output of 12V±10%/ 25mA after 2 seconds switched the "TEST2-13". (only DTR-60.5/DHC-60.5)
2-9. CONFIRMATION OF OUTPUT VOLTAGE SENSOR AND THERMAL PROTECTOPERATION.(Except DHC-60.5)
a. Set the TEST MODE to "TEST 4-43". Confirm to lit "FM STEREO" on FL displaythe .
Confirm the relays RL6901/6902 is OFF immediately .
b. Push STANDBY/ON button two times while pushing down DISPLAY button to display CPU PROGRAM version.
Push TONE button while displaying CPU PROGRAM version to display value of temparature sensor.
Regarding to "AT" and "DT" of display value, confirm outside temperature ±20C is displayed immediately after energizing.
Note that the error margin is caused by the rise of the temperature of the heat sink when time passes.
No singal condition (Ex. Display)
V:>00 F:x S:H
AT:020 DT:020
V: Output signal level
F: FAN condition
S: Amplifier power supply voltage condition
AT: Temparature sensor of Amplifier
DT: Temparature sensor of HDMI PWB

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-3
2.CONFIRMATIONS OF OPERATIONS
2-10. CONFIRMATION OF HDMI MAIN OUTPUT OSD(ON SCREEN DISPLAY) OPERATION
a. Confirm that display SET-UP MENU for push SET UP buttons.
b. Confirm that specified operations for ENTER(with 4-cursor) buttons are made.
c. Confirm whether the screen displayed at the POWER ON is correct.
Refer to OPERATION CHECK-12.
2-11. MISCELLANEOUS
a. Confirm SELECTOR MUTING operation.
b. Check the action of Left, Right, Center, L-Sur., R-Sur., Subwoofer, Sur.Back-L,Sur.Back-R, Front High-L, Front High-R , Level Up/Down.
c. Confirm analog, digital and video REC SELECTOR operation.
d. Confirm Video output signal as shown Table 2., while Video signal are input as shown Table 1.
*refer to table1,2 of OPERATION CHECK-10.
e. Confirm HD-AUDIO test by OAE QC sampling inspection.
f. Confirm the video signal from BD/DVD Composite in is output to HDMI monitor out at the initial setting.
Then, input video signal to Component IN1, confirm change to Component IN1 signal from composite video signal.
g. Confirm the firmware combination check.
1. Push STANDBY/ON button while pushing down TV/CD button to display
"TEST-__".
2. Next, if Enter keys are pushed, FL display "F/W Set OK" or "F/W Set NG" after it becomes a F/W COMBINATION TEST MODE.
2-12. CONFIRMATION OF COOLING FAN OPERATION *Only TX-NR929,DTR-60.5
a. When no input signal, confirm to fan no rotate.
b. When TEST4-43, confirm to fan slow speed rotate.
c. When TEST4-46, confirm to fan fast speed rotate.
2-13. CONFIRMATION OF H DMI AUDIO OPERATION. *OPERATION CHECK-10. of Video & HDMI Test mode.
a. The sound of HDMI are confirm in the following disk.
DVD:TEAC DVD TEST Disk MDVD-111 T2-C1
DVD:ABX DVD TEST Disk TDV-540 T2-C1
SACD:PHILIPS SUPER AUDIO CD (Channel Configuration Test Disc) Ver 1.2 / May 2001
Blu-ray:ALMEDIO ABD-500
b. Confirm the HDMI Video output by the Component video input.
c. (CONFIRMATION OF HDMI I2S SIGNAL.)
1. Input the signals below from HDMI1 terminal.
ABD-500 NO.12 (LPCM7.1ch)
2. Change the state to TEST 6-00. Confirm the signal is output from L/R,SW/C,SL/SR,SBL/SBR.
d. (CONFIRMATION OF HDMI SPDIF SIGNAL.)
4. SPDIF signal is input from HDMI3 terminal.
5. When TEST 6-06, confirm the soun d(HDMI IN3)outp uts from the speaker(except DHC-60.5)/ from preout(only DHC-60.5).
6. When TEST 6-07, confirm the sound(DVD analog input) outputs from the TV of Main HDMI OUT and Sub HDMI OUT.
e. (CONFIRMATION OF HDMI DSD SIGNAL.)
7. When TEST 6-04, confirm the sound of DSD 5.1ch input HDMI IN 2, output from the speaker(except DHC-60.5)/
from preout(only DHC-60.5).
(CONFIRMATION OF HDMI ARC SIGNAL.)
f. Hook up ARC-jig to HDMI Output on AVR, and input SPDIF (less than or equal to fs: 96kHz) signal to ARC-jig.
g. When TEST 6-09, confirm the sound outputs from the speake r. *On ly DHC-60.5 from BALANCE OUT
Note 1) During ARC testing, do not connect to the other HDMI inputs.
2-14. CONFIRMATION OF MHL
a. After set the "TEST 6-10", connect the MHL JIG. Confirm that "OK" of FL display lights.
b. After set to the "TEST 6-11", confirm that LED of MHL JIG does not shine.
c. After set to the "TEST 6-12", confirm that LED of MHL JIG sh ines.
And confirm that P1 connector voltage of MHL JIG is within the limits of 2.35V to 2.61V.
e. Confirm real MHL check by QC sampling inspection.
Noets
Use HDMI cable that is not connected shielded case to 2PIN.

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-4
2.CONFIRMATIONS OF OPERATIONS
2-15. CONFIRMATION OF CEC OPERATION.
a. When TX-SR805 is used as CEC JIG.
1.When TX-SR805 is used as CEC JIG, this TX-SR805 JIG is set as follows.
2.After SETUP button is pushed, select next menu "Hardware Setup", "HDMI", "Control", "Enable".
3. HDMI Output(Main) of the set for inspection is connected with HDMI Input of the set for TX-SR805 JIG.
4. When the set for inspection is Power on, then change the state to "TEST 6-00".
5.FL is displayed "OK" or "NG".
b. When Panasonic TV (TH-20LX70) is used as CEC JIG.
1.HDMIOutput(Main) of the inspection is connected with Panasonic TV(TH-20LX70).
2. When the set for inspection is Power on, then change the state to "TEST 6-00".
3.FL is displayed "OK" or "NG".
2-16. COMFIRMATION OF NETWORK
1. PC and the set are connected through the router.
2.When set to TEST 3-18 confirm that the display of AVR change IP adress.
*Please wait for about 20 seconds after turning on the power supply of the set when you use from TEST 3-18.
3.Change the state to "TEST 3-09"(Front) ".
4.When Connect USB storage to AVR USB front port ,
confirm this USB storage is shown on FL display and HDMI main out of AVR .
5.Confirm the audio signal is output, when TEST MODE is set from TEST 3-11 to TEST 3-17.
(Confirm at Zone2 Preout/Line out terminal.)
2-17. CONFIRMATION OF Zone2 HDMI SIGNAL. *CONNECT HDBaseT RX box to AVR(DTR-60.5(exceptMJJ),DHC-60.5)
1. When TEST 5-14, confirm the sound outputs of HDMI IN4 input from the Powered Zone2 speakers(except DHC-60.5).
When TEST 5-14, confirm the sound outputs of HDMI IN4 input from Zone2 PRE/LINE OUT(only DHC-60.5).
And confirm the HDMI video and audio output of HDMI IN4 input from the TV connected OUT Zone2 HDMI terminal.
2. WAfter set to the "TEST 6-13", confirm that LED of HDMI Zone2 CEC JIG does not shine.JIG use is carried out and it inspects.
3.After set to the "TEST 6-12", confirm that LED of HDMI Zone2 CEC JIG shi nes. JIG u se is carried out and it inspects.
4.When 6-15 , The check of Zone2 HDMI CEC of operation. FL is displayed "OK" or "NG".JIG use is carried out and it inspects.
a. When TX-SR805 is used as CEC JIG.
1.When TX-SR805 is used as CEC JIG, this TX-SR805 JIG is set as follows.
2.After SETUP button is pushed, select next menu "Hardware Setup", "HDMI", "Control", "Enable".
3. HDMI Output(Main) of the set for inspection is connected with HDMI Input of the set for TX-SR805 JIG.
4. When the set for inspection is Power on, then change the state to "TEST 6-15".
5.FL is displayed "OK" or "NG".
b. When Panasonic TV (TH-20LX70) is used as CEC JIG.
1.HDMIOutput(Main) of the inspection is connected with Panasonic TV(TH-20LX70).
2. When the set for inspection is Power on, then change the state to "TEST 6-15".
3.FL is displayed "OK" or "NG".
HDMI IN1 HDMI IN2 HDMI IN3 HDMI Front
HDMI
Main OUT

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-5
2.CONFIRMATIONS OF OPERATIONS
2-18. CONFIRMATION OF ETHER CONTROL./RS-232C
1. PC and the RS-232C terminal are connected.
2. Confirm the RS-232C operation by using the E-Control Check Tool
2-19. CONFIRMATION OF I/O OPERATION.
a. Confirm all input and output terminals operate normally.
b. Confirm the output by using a specified JIG or special player for DSD .
c. When use TEST MODE for DSD , "TEST 6-04" is confirmed to be output from FL,FR,C,SW,SL,SR and not to be output SBL,SBR.
2-20. CONFIRMATION OF Wi-Fi CONNECTION
1. After setting wifi routers, change the state to "IDLING TIMER MODE".
2. It connects an access point automatically. Wi-Fi LED flashes during connection.
3. When connection is completed and IP address is able to be acquired, Wi-Fi LED lights up and the value of RSSI to an access point
is displayed per dbm.
If the connection failed, NG is displayed.
If the connection failed, exit the idle mode by pressing the TV/CD button and please try again from [a].
*When check DHC-60.5,it is also same as TX-NR929,DTR-60.5.
Please be as NG if FL display doesn't even after 4 minutes in idling mode.
2-21. CONFIRMATION OF HD BASE-T.(ONLY DTR-60.5 ( EXCEPT MJJ /DHC-60.5)
1. AVR and the HD BASE-T RX BOX are connected with ETHERNET cable.
2. HD BASE-T RX BOX and TV are connected with HDMI cable.
3. Confirm the VIDEO FUNCTION CHECK of page10
You must use ethernet cable more than CAT5.
1-45d 00:10:00
SSID No RSSI(dbm) Time Counter

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-6
3.INITIAL SETTING FOR SHIPPING
a. Initialization of memories.
Press ON/STANDBY button while pressing down CBL/SAT button when the unit is POWER ON, then the FLT displays
"CLEAR", and turn to STAND-BY. Remove power cord from power line.
b. (Please pull out the AC cord at the standby mode.)
4.TEST MODE
4-1 TEST MODE FOR FL DISPLAY
a. Push ON/STANDBY key while pushing down TV/CD button button to display "TEST-".
b. Then push DIMMER (or RT/PTY/TP) button and get the FL test mode.
c. In the FL test mode, TONE - button is FL TEST UP and TONE + button is FL TEST DOWN.
d. REC OUT and ZONE2 button's originally operation can't work when it is in FL test mode.
e. The contents of the step are as follows.
1. Lit all segment
2. Lit upper 'EDCBA987654321', lower '23456789ABCDEF'.
3. Lit a even number segment
4. Lit an odd number segment
5. The Destination is displayed.
Please see the below for detail.
To close the FL test, push ON/STANDBY button.
Display of Destination on TEST MODE.
N R 9 2 9 D 2 0 0 0
MODEL Name Destination A B C D
TX-NR929 : NR929 Dx: USA A: Value of AD port of BAND
DTR-60.5 : DTR605 xx: OTHER B: Value of AD port of INIT1
DHC-60.5: DHC605 JJ : JAPAN C: Value of AD port of INIT2
D: Value of AD port of INIT3
MODEL Name NR929 DTR605
Destination Dx xx JJ Dx xx JJ
MA
MR
ABCD 2400 8400 4400 2460 8460 4460
MODEL Name DHC605
Destination
ABCD 2480
NOTE :
If VOL value is not 30 (-52dB) (initial setting), test mode cannot be set.
Dx
MA
MB
MP
MR

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-7
4.TEST MODE
4-2. TEST MODE FOR OPERATION
a. Push STANDBY/ON button while pushing down TV/CD button to display "T EST-__".
b. Next, if the following keys are pushed, it becomes a each TEST MODE.
TEST MODE
1-00 2-00 3-00 4-00 5-00 6-00 KEY TEST FIRMWARE
VERSION
BD/DVD CBL/SAT STB/DVR GAME
GAME1 TUNER TV/CD MEMORY (Re-EQ) TONE
TEST MODE
c. In the test mode, (TONE)- button is TEST MODE DOWN and (TONE)+ button is TEST MODE UP.
d. The unit receives the following remote control signals, the set will be the test mode or be changed the step No.
D22F K113(D0) --- Got out of the test mode.
D22F K114(D1) --- Got the"TEST 1-00".
D22F K115(D2) --- Got the"TEST 2-00".
D22F K116(D3) --- Got the"TEST 2-00".
D22F K117(D4) --- Got the"TEST 4-00".
D22F K112(CF) ---
Got the"TEST 5-00".
D22F K111(CE) ---
Got the"TEST 6-00".
D22F K118(D5) --- Made the 1st position of a figure of the step No. "1", and call the setting.
D22F K119(D6) --- Made the 1st position of a figure of the step No. "2", and call the setting.
D22F K120(D7) --- Made the 1st position of a figure of the step No. "3", and call the setting.
D22F K121(D8) --- Made the 1st position of a figure of the step No. "4", and call the setting.
D22F K122(D9) --- Made the 1st position of a figure of the step No. "5", and call the setting.
D22F K123(DA) ---
Made the 1st position of a figure of the step No. "6", and call the setting.
D22F K124(DB) ---
Made the 1st position of a figure of the step No. "7", and call the setting.
D22F K125(DC) ---
Made the 1st position of a figure of the step No. "8", and call the setting.
D22F K126(DD) --- Made the 1st position of a figure of the step No. "9", and call the setting.
D22F K127(DE) -- Made the 1st position of a figure of the step No. "0", and call the setting.
D22F K128(DF) ---
Made the 2st position of a figure of the step No. increment.
e. "TEST 1-00" are used to check a protection circuit, and the relay recovered in one second.
f. All test modes except for "TEST 3-00" are used to check an AF section.
g. "TEST 3-00" is used to check an RF section, at this time the unit receives the following remote control signals,
they change the operation from really doing and they can made the operation in tuner section.
D26DK26(19) --- TUNING UP
D26DK27(1A) --- TUNING DOWN
D26DK20(13) --- FM MUTE ON/OFF
h. When the unit receives the following remote control signals, they can made the step No. up and down.
D26DK30(1D) --- STEP UP
D26DK31(1E) --- STEP DOWN
IDLING TIMER FL TEST
FIRMWARE COMBINATION CHECK
ENTER When the MPU version is displayed,
push "MEMORY(Re-EQ)"
CHECK SUM
TUNING MODE
(LATE NIGHT)
DIMMER
(RT/PTY/TP)

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-8
4.TEST MODE
j. Test mode is as follows.
In all test modes, it is not concerned with detection of VOLH but SEC1H are made "H" fixation. (Except TEST 2-25,4-43.)
*1 All SP-RELAYs are turned ON only at the time of this STEP.
Moreover, whether make RELAY restoration time at the time of protection operation into 1 second, and PROTECT input "H" is detected
how many times or it continues 1 second or more, RELAY is not held at OFF or POWER OFF is not carried out, either.
When "H" is 1 seconds or more to PROTECT input and it is set to "L", RELAY is turned ON again.
Moreover, not any MUTE is outputted at the time of this STEP.
*2 Use USB memory whitch stored only following signals.
In addition,measure using application.
1.44.1kHz_16bit_1kHz_0dBfs_L&R.wav Reference
2.44.1kHz_16bit_-∞dBfs_L&R.wav SN ratio
3.44.1kHz_16bit_20Hz_0dBfs_L&R.wav Freq. resp.
4.44.1kHz_16bit_20kHz_0dBfs_L&R.wav Freq. resp.
5.44.1kHz_16bit_1kHz_0dBfs_Lch.wav Separation
6.44.1kHz_16bit_1kHz_0dBfs_Rch.wav Separation
7.48kHz_16bit_1kHz_0dBfs_L&R.wav Operation check
TEST Analog Input Lstn Mode/ VIDEO Input
Compo-
HDMI 12V Digital Input Config. Master Vol. Speaker etc.
No /Rec Sel Input Format (Zone2) nent V Trigger /Output /Zone2 Vol. Relay
(Zone2/Zone3)
1-00 BD/Source ADC DSP 11ch Thru. BD/DVD IN1 IN1 - - - Max (+18dB)
F/C/S/SB/FH
*1 PROTECT
1-01 BD/Source ADC DSP 11ch Thru. BD/DVD IN1 IN1 - - - Min (-82dB)
F/C/S/SB/FH
2-00 BD/Source Stereo(Direct) BD/DVD IN1 IN1 - - - Max (+18dB) F SW=NO
2-01 BD/Source Stereo(Direct) BD/DVD IN1 IN1 - - - 82 (0dB) F SW=NO
2-02 BD/Source Analog All Ch Stereo BD/DVD IN1 IN1 - - Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH ?Hi-B
2-03 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 82 (0dB) F/C/S/FW
2-04 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 82 (0dB) F/C/S/FH
2-05 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L Max (+18dB)
F/C/S/SB/FH
2-06 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-07 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 70 (-12dB)
F/C/S/SB/FW
SW:MUTE
2-08 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 70 (-12dB)
F/C/S/SB/FH
SW:MUTE
2-09 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L Min (-82dB)
F/C/S/SB/FH
2-10 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 IN1 - - Y/L/L/L/L 82 (0dB) C/S/SB SPRLF OFF
2-11 CBL/Source Automatic CBL/SAT IN2 IN2 Zone2/A OPT1 Y/L/L/L/L 82 (0dB) F/C/S/SB
2-12 CBL/Source Automatic CBL/SAT IN2 IN2 Zone3/B COAX1 Y/L/L/L/L 82 (0dB) F/C/S/SB
2-13 STB/Source DIR DSP 12ch Thru STB/DVR -IN3 C OPT1 Y/L/L/L/L Max (+18dB)
F/C/S/SB/FH
2-14 GAME/Source DIR DSP 12ch Thru GAME - IN4 - OPT1 Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-15 AUX/Source DIR DSP 12ch Thru AUX - - - COAX1 Y/L/L/L/L Max (+18dB)
F/C/S/SB/FH
2-16 PC/Source DIR DSP 12ch Thru Last - - - COAX1 Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-17 TV/Source Automatic Last - - - OPT2 Y/L/L/L/L 82 (0dB) F/C/S/SB
2-18 TV/Source DIR DSP 12ch Thru Last - - - OPT2 Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-19 AUX/Source DIR DSP 12ch Thru AUX - - - FRONT OPT Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-20 MIC ADC DSP 12ch Thru. BD/DVD - - - - Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
2-21 MIC ADC DSP 12ch Thru. BD/DVD - - - - Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
MICMUTE ON
2-22 PHONO/Source Direct BD/DVD - - - - - Max (+18dB) F
2-23 PHONO/Source Direct BD/DVD - - - - - 62 (-20dB) F
2-24 BD/Source Bi AMP BD/DVD IN1 IN1 - - - 82 (0dB) F/C/S/FH Bi AMP
2-25 BD/Source(Source) Whole House Mode BD/DVD IN1 - - - - 82 (0dB)
F/C/S/SB/FH
Whole House Mode
2-26 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 - - - Y/L/L/L/L 82 (0dB)
F/C/S/SB/FH
EXT AMP(SB) EXT AMP OUT=SB
2-27 BD(BALANCE) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L/L 82 (0dB) F/C/S/SB BALANCE
2-28 BD/Source ADC DSP 12ch Thru. BD/DVD IN1 - - - Y/L/L/L/L 82 (0dB) F/C Diffential signal mode
2-29 BD(BALANCE) ADC DSP 8ch Thru. BD/DVD IN1 - - - Y/L/L/L/L 82 (0dB) F/C/S/SB BALANCE: MONO
3-00 FM/Source Stereo(Direct) Last - - - - - 84 (+2dB) F
3-01 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - Max (+18)/Max(+18) F/Z2/Z3 Z2/Z3 Powered
3-02 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2/Z3 Powered
3-03 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2/Z3 MUTE ON Z2/Z3 Powered
3-04 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2 BASS MAX Z2/Z3 Powered
3-05 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2 BASS MIN Z2/Z3 Powered
3-06 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2 TREBLE MAX Z2/Z3 Powered
3-07 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/0dB F/Z2/Z3 Z2 TREBLE MIN Z2/Z3 Powered
3-08 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - Min/Min F/Z2/Z3 Z2/Z3 Powered
3-09 USB(Front)/(Source) Stereo(Direct) Last - - - USB(Front) - -25dB/-25dB
F
3-10 USB(Rear)/(Source) Stereo(Direct) Last - - - USB(Rear) -25dB/-25dB
F
3-11 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Output Level / Distortion WAV,44.1kHz,16bit,1kHz,0dBfs,
3-12 USB(Front)/(Source) Stereo(Direct) Last - - - NET - 0dB/0dB
F SN Ratio WAV,44.1kHz,16bit,-∞dBfs,
3-13 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Freq. Resp. WAV,44.1kHz,16bit,20Hz,0dBfs,
3-14 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Freq. Resp. WAV,44.1kHz,16bit,20kHz,0dBfs,
3-15 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Separation WAV,44.1kHz,16bit,1kHz,0dBfs,Lch
3-16 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Separation WAV,44.1kHz,16bit,1kHz,0dBfs,Rch
3-17 USB(Front)/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB
F Output Level / Distortion WAV,48kHz,16bit,1kHz,0dBfs,
3-18 NET/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB F Net connection Display IP address
3-19 NET/(Source) Stereo(Direct) Last - - - NET - -20dB/-20dB F Net connection Display IP address
3-20 TV(BD/GAME) Stereo(Direct) Last(BD) - - Z2/Z3 - - 0dB/FIX F/Z2/Z3 Z2/Z3 FIX

TX-NR929/ DTR-60.5/ DHC-60.5
OPERATION CHECK-9
4.TEST MODE
Auto Measurement Mode
TEST DSP Output ch DSP Output DSP Config. Speaker etc.
No. Frequency Output Relay
Voltage
4-00 ALL 1kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH DSP Gain
4-01 ALL 30Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH DSP Freq.Response
4-02 ALL 20kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH DSP Freq.Response
4-03 FL,FR/SW 30Hz -20dBFS N/L/L/L/L F/C/S/SB DownMix(1) Characteristic(1)
4-04 F,C,SUR,SRB,High,RW,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:LW Separation
4-05 F,C,SUR,SRB,High,LW,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:RW Separation
4-06 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:FL Separation
4-07 FL,C,SUR,SRB,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:FR Separation
4-08 F,SUR,SRB,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:C Separation
4-09 F,C,SR,SBR,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:SL Separation
4-10 F,C,SL,SBR,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:SR Separation
4-11 F,C,SUR,SBRR,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:SBL Separation
4-12 F,C,SUR,SBRL,High,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:SBR Separation
4-13 F,C,SUR,SBR,HR,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:LH Separation
4-14 F,C,SUR,SBR,HL,Wide,SW 10kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:RH Separation
4-15 F,C,SUR,SRB,High,Wide 30Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH Mute:SW Separation
4-16 ALL 1kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH *mute on Muting
4-17 ALL 30Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH *mute on Muting
4-18 ALL 1kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH Volume Max.Attenuation
4-19 ALL 30Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH Volume Max.Attenuation
4-20 ALL 20Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH BASS ALL:+10 BASS Max.
4-21 ALL 20kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH TREBLE ALL+10 TREBLE Max.
4-22 ALL 20Hz -20dBFS Y/L/L/L/L F/C/S/SB/FH BASS ALL:-10 BASS Min.
4-23 ALL 20kHz -20dBFS Y/L/L/L/L F/C/S/SB/FH TREBLE ALL-10 TREBLE Min.
4-24 FL +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-25 FR -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-26 C +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-27 SL -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-28 SR +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-29 SBL -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-30 SBR +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-31 FHL -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-32 FHR +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-33 FL -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-34 FR +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-35 C -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-36 SL +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-37 SR -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-38 SBL +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-39 SBR -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-40 FHL +DC +Max Y/L/L/L/L F/C/S/SB/FH *1,*2 +DC Protect
4-41 FHR -DC -Max Y/L/L/L/L F/C/S/SB/FH *1,*2 -DC Protect
4-42 ALL Pulse Max Y/L/L/L/L F/C/S/SB/FH *1,*3 Current Protect
4-43 ALL 1kHz 0dBFS Y/L/L/L/L F/C/S/SB/FH *6,*4 VOLH DETECT,SEC1H="L"
4-46 ALL 1kHz 0dBFS Y/L/L/L/L F/C/S/SB *5 FAN TEST
*2
*3 The following signal is putted out at all channel continuously in TEST4-42
Max
-Max
2mS
2mS
*4 The cooling fan rotate slow speed.
*5 The cooling fan rotate fast speed. Only TX-NR929,DTR-60.5.
*6 VOLH is detected and H/L of SEC1H is changed.
A detection level is the same as the normal mode.
75(-7dB)
Min.(-∞dB)
Max
Max
Max
78(-4dB)
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
82 (0dB)
Max
Max
Max
Min.(-∞dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
Min.(-∞dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
72(-10dB)
82 (0dB)
82 (0dB)
Master Vol.
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
82 (0dB)
20mS20mS
