ontrac Multitrac MME Series User manual

Ontracactuators.com
ACK21-01A
MME/MOE Intelligent Electric Actuator
Operation Instruction
(for actuators with software release V5.35)
Multitrac

ACK21-01A
ontracactuators.com
01 Device Identification ................................................................................................................................................... 1
1.1 Actuator ID Lable...................................................................................................................................................................... 1
1.2 Legend.......................................................................................................................................................................................... 2
02 General ....................................................................................................................................................................................... 3
2.1 Application ................................................................................................................................................................................. 3
2.1.1 Purpose of the Manual ................................................................................................................................................. 3
2.1.2 Qualification and Training of the Personnel ......................................................................................................... 3
2.1.3 Explosive Atmosphere Zones .................................................................................................................................... 3
2.2 Safety Advice ............................................................................................................................................................................ 4
2.2.1 Introduction ....................................................................................................................................................................... 4
2.2.2 Indications of Danger .................................................................................................................................................... 4
2.3 Other Safety Advices ............................................................................................................................................................. 5
03 Receiving、Transportation and Storage .............................................................................................. 6
3.1 Condition When Supplied .................................................................................................................................................... 6
3.2 Receiving Inspection .............................................................................................................................................................. 6
3.3 Transportation .......................................................................................................................................................................... 7
3.4 Storage ........................................................................................................................................................................................ 7
3.5 Warranty ..................................................................................................................................................................................... 8
3.6 Return to Factory .................................................................................................................................................................... 8
04 Main Components ......................................................................................................................................................... 9
4.1 Introduction of main components ..................................................................................................................................... 9
4.2 Flange Structure and Valve Connection Size ........................................................................................................... 10
4.3 Operation ................................................................................................................................................................................. 11
CONTENTS

ACK21-01A
ontracactuators.com
05 General and Technical Data............................................................................................................................. 12
5.1 Specifications ......................................................................................................................................................................... 12
5.2 Mechanical Interfaces ........................................................................................................................................................ 13
5.3 Technical Data ...................................................................................................................................................................... 14
5.3.1 Multi-turn On-Off, Electric Actuators (MOE) ......................................................................................................14
5.3.2Multi-turn Modulating, Electric Actuators (MME) .............................................................................................15
5.3.3 Linear Modulating, Electric Actuators ...................................................................................................................16
5.3.4 Linear On-Off, Electric Actuators ...........................................................................................................................16
5.3.5 Part-turn Modulating, Electric Actuators ..............................................................................................................17
5.3.6 Part-turn On-Off, Electric Actuators ......................................................................................................................17
5.4 Model and Weight ................................................................................................................................................................ 19
5.5 Mechanical Dimensions...................................................................................................................................................... 20
MME806/MOE706/MME808/MOE708/ MME812/MOE712..................................................................................... 20
MME850/MOE750/MME825/MOE725.............................................................................................................................. 22
MME890/MOE790..................................................................................................................................................................... 23
LE Series Linear Thruster...................................................................................................................................................... 24
Direct Connected ASNG Reducer...................................................................................................................................... 25
Direct Connected ASNG Reducer (with Additional Reduction Gearbox)........................................................... 26
ASNG Reducer with Base...................................................................................................................................................... 27
ASNG Reducer with Base (with Additional Reduction Gearbox)........................................................................... 28
PG Multi Rotary Stroke Wheel Reducer........................................................................................................................... 29
PG Multi Turn Bevel Gear Reducer................................................................................................................................... 29
PGZ Multi Turn Bevel Gear Reducer................................................................................................................................. 30
5.6 Key Features .......................................................................................................................................................................... 31
5.7 Position Sensing ................................................................................................................................................................... 31
5.8 Sensitivity Control ................................................................................................................................................................ 32
5.9 Remote Controller ................................................................................................................................................................ 32
5.10 Serial Communications ................................................................................................................................................... 33
5.11 Smartrac for Asset Management ................................................................................................................................ 33
5.12 Cloudtrac for Asset Management ............................................................................................................................... 34
5.13 Actuator Protection ........................................................................................................................................................... 35
5.14 Motor Control Type............................................................................................................................................................ 35

ACK21-01A
ontracactuators.com
06 Installation .......................................................................................................................................................................... 37
6.1 Actuator Check ...................................................................................................................................................................... 37
6.2 Installation Hints ................................................................................................................................................................... 37
6.3 Hand Crank Force ............................................................................................................................................................... 38
6.3.1 Operation of the Hand Crank................................................................................................................................... 38
6.3.2 Hand Crank Force........................................................................................................................................................ 38
6.3.3Assembly of the Hand Crank................................................................................................................................... 39
6.4Special Assembly.................................................................................................................................................................. 40
07 Electrical Connection ............................................................................................................................................. 41
7.1 Functional Block ................................................................................................................................................................... 41
7.2 Electrical Wiring Diagram ................................................................................................................................................. 42
7.2.1 Equipment Wiring Diagram ...................................................................................................................................... 42
7.2.2 Profibus DP Wiring Diagram ................................................................................................................................... 44
7.2.3 Split Wiring Diagram (Electronic Unit and Actuator)....................................................................................... 45
7.3 Cable Entries ......................................................................................................................................................................... 46
7.4 Wiring Steps ........................................................................................................................................................................... 46
7.4.1 Electrical Wiring ............................................................................................................................................................ 46
7.4.2 Wiring Installation of Bus Board (optional) ........................................................................................................ 47
7.4.3 Wiring Installation of Frequency Conversion Board ...................................................................................... 48
7.4.4 Wiring Installation of Channel Expansion Board ............................................................................................. 49
7.4.5 Wiring Installation of Electric Motor ...................................................................................................................... 49
7.5 Anti-condensation Heater ................................................................................................................................................. 50
7.6 Wire Cross Section .............................................................................................................................................................. 50
7.6.1 Wire Cross Section (Terminal Connection) ....................................................................................................... 50
7.6.2 Wire Cross Section (Plug)........................................................................................................................................ 50
7.7 Thread Size for Cable Glands ........................................................................................................................................ 50

ACK21-01A
ontracactuators.com
08 Adjustment ........................................................................................................................................................................ 51
8.1 Mode Selector Switch Instruction .................................................................................................................................. 51
8.2 Panel Instruction ................................................................................................................................................................... 52
8.3 Operation Menu .................................................................................................................................................................... 53
8.3.1 Introduction to Menu Operation ............................................................................................................................. 53
8.3.2 Menu Structure.............................................................................................................................................................. 53
09 Alarms and Failures ................................................................................................................................................. 61
9.1 Failure Messages ................................................................................................................................................................. 61
9.2 Alarm Messages ................................................................................................................................................................... 62
10 Product Maintenance .............................................................................................................................................. 63
10.1 General .................................................................................................................................................................................. 63
11 Lubrication and Vent Valve .............................................................................................................................. 63
11.1 Lubricating Oil ...................................................................................................................................................................... 63
11.2 Vent Valve ............................................................................................................................................................................ 64
12 Service .................................................................................................................................................................................... 64

ACK21-01A
ontracactuators.com 1
01 Device Identification
1.1 Actuator ID Label
Actuator: Ontrac MME/MOE
No:
Year
M=
n=
T=
IP67
Oil:
U=
f=
Pmax= , Imax=
S4-25%..........
Fuse 3 x 16 A slow
SW Version
Factory setting of M max= , n max=
M open=
M close=
n open=
n
close=
Made by Ontrac
line 1: actuator type
line 2: serial no. / year of construction
line 3: max. switch-off torque/ max. output speed
line 4: permissible ambient temperature / protection classification
line 5: oil type
line 6: rated voltage range / perm. mains frequency
line 7: power input / perm. operating mode
line 8: external fuse
line 9: no. of non-standard version / software index
line 10: Ex-classification data (if available)
line 11: switch-off torque (factory setting)
line 12: operating torque for OPEN / CLOSE (factory setting)
line 13: operating speed for OPEN / CLOSE (factory setting)

ACK21-01A
ontracactuators.com 2
1.2 Legend
Warning symbols for safety
ELECTRICAL WARNING
An instruction with reference to electrical components or equipment. It draws attention to
the risk of injury or death to persons or damage to the product, process or surroundings
WARNIG
General instruction that draws attention to the risk of injury or death to persons or damage to
the product, process or surroundings
INFORMATION
Further reference for more detailed information or technical details.
Weremind you that the classification of the zone (REF. ATEX 2014/34/EU former 94/9/CE
directive) for potentially explosive atmosphere zones has to be done by the end user and
communicated to the vendor for the right choice of classification of the equipment to work in
these zones.
This symbol signals a danger or a situation that requires the maximum attention of the personnel. It's
important to respect the instructions stated at the margin of this symbol and proceed very carefully.
It's necessary to inform all the personnel and/or users that the rules indicated prevent injuries.

ACK21-01A
ontracactuators.com 3
02 General
2.1 Application
2.1.1 Purpose of the Manual
The main purpose of this manual is to assure that the activities of installation, operation and maintenance of
the pumps are executed in a correct and safe way by all the personnel in charge of these operations. This
document offers also indications useful for the customer to solve the problems, order spare parts and contact
Ontrac service.
ATTENTION: check on our website www.ontracactuators.com if there are further revisions to this
manual.
Actuators are exclusively used for the operation of final control elements (valves, flaps, etc.). If they are used
for other purposes, people may be injured or the actuator may be damaged. This instruction contains all
necessary information concerning the operating elements, handling, start-up and maintenance and repair
work, as well as all of the relevant technical data. The operating instructions are a component of the
machine.
Please therefore keep the instructions ready to hand to ensure easy access to the necessary information at
all times. Read the operating instructions thoroughly. All of the points presented in these instructions must be
understood and observed by those persons responsible for the installation, operation, maintenance and
repair of the machine. Ontrac does not accept any liability for damage resulting from failure to comply with
these maintenance and operating instructions.
2.1.2 Qualification and Training of the Personnel
Those in charge of the installation, operation and maintenance of the actuator have to be qualified to carry
out the actions indicated in this manual. Ontrac is not responsible for the inadequate qualification and
training of the customer's staff or for the lack of information of the staff regarding the contents of this manual.
It's compulsory to always show this manual to the workers in charge of the installation, operation and
maintenance of the Actuator. Assembly, electrical connection, commissioning, operation, and maintenance
must be carried out by suitably qualified personnel authorized by the end user or contractor of the plant only.
Prior to working on this product, the staff must have thoroughly read and understood these instructions and,
furthermore, know and observe officially recognized rules regarding occupational health and safety. Keep
this manual in a safe place for future consultations.
2.1.3 Explosive Atmosphere Zones
The uses in in potentially explosive atmospheres require special models that Ontrac manufactures
with particular materials and precautions. Customers who want to use actuator in these kinds of
zones have to contact Ontrac technical office for the correct choice of the product. The actuator
manufactured by Ontrac for these kinds of applications belong to the series EX-Proof Version. We
remind you that the classification of the zone (REF. ATEX 2014/34/EU former 94/9/CE directive) for
potentially explosive atmosphere zones has to be done by the customer and communicated to Ontrac
for the right choice of the kind of actuator suitable to work in these zones.

ACK21-01A
ontracactuators.com 4
2.2 Safety Advice
Preliminary remarks
All the references to the manual have to be considered applicable also to environment and system that
use these actuators unless it's specified otherwise.
2.2.1 Introduction
ATTENTION: the non-observance of the indications stated in this manual or the inappropriate use
of the equipment by unqualified or unauthorized staff, can cause serious personal injuries or death
and damages to products and apparatus! The technical assistance office is at the complete
disposal; in case of doubts or problems you can contact us at www.ontracactuators.com If these
warnings are not observed and followed, the Certification and the Warranty of the actuator can be
invalidated.
2.2.2 Indications of Danger
For the safety of those in charge of the installation of the actuator, it's necessary to use safety
clothing and individual safety devices approved by the current provisions of the law and regulation
(e.g. Safety glass, gloves and safety insulating-shoes).
Always shut down the power to actuator before touching or proceeding with any intervention on it
like wiring /circuit of installation. Make sure that the electrical system to which the actuator will be
connected to has the adequate power and has the correct protection devices (e.g. Grounding, Life
safe). Always switch off the electrical supply before working on the actuator for open box
maintenance or part substitution.
Actuators are exclusively used for the operation of final control elements (valves, flaps, etc.). If they
are used for other purposes, people may be injured or the actuator may be damaged.
The responsible institution should take protective measures if the actuator is installed in an area
where non-authorized personnel might have access to it.
- Metallic components can become hot at high ambient temperatures. In order to avoid injuries,
the operating personnel should use suitable gloves
- Depending on the intended purpose actuators make swivelling movements to drive flaps,
valves etc. Improper operation of the actuator can endanger the operating person.
- Oil which may have spilled during an oil change must be carefully cleared away to avoid
accidents. Waste oil must be disposed of according to local regulations. Make sure it does not
pollute the water supply
- All installation and setting works as well as the electrical connection may only be carried out by
qualified persons.
- Take care of safety rules and regulations for set-up of electric equipment while working at the
actuator. Prior to any work at electrical components switch off the voltage supply. Protect the
connection against inadvertent switching on.
.

ACK21-01A
ontracactuators.com 5
2.3 Other Safety Advices:
1. If the content of this manual conflicts with laws and regulations of local country or area, then
follow relevant local and area laws and regulations.
2. Appropriate protection is needed in some poor operating environment.
3. All installation and commissioning work as well as electrical connection may only be
carried out by trained technicians and qualified personnel.
4. Installation or maintenance can not be carried on when actuator is powered on, prior to
any work at actuator. switch off the power.
5. When the actuator is installed at hights and/or in confined space, please pay extra
attention to safety. Please do not operate hand crank when not necessary.
6. Please do not operate hand crank when not necessary.
7. Temperature of motor's surface can exceed 70° C under normal working condition. Please
do not touch to avoid personal damage.
8. Main power supply can be three phases or one phase. please be careful with wiring.
9. Before commissioning, check whether all settings meet the requirements. Incorrect
settings may bring danger.
10. If you need to make changes to the equipment, you need to consult the manufacturer in
advance.

ACK21-01A
ontracactuators.com 6
03 Receiving、Transportation and Storage
3.1 Condition When Supplied
The actuators feature protection class IP 40 when supplied. Protection class IP 67 canbe guaranteed once the
cable glands and the cable entries are installed.
If not other specified Ontrac actuators are supplied with the following standard configuration:
Local operate mode: …………… Inching Mode (In the local state, the knob is in inching mode. Once the
knob is released, the equipment stops running.)
Remote operate mode: ………… Inching Mode (In the remote state, the port is level driven. Once the
actuator BE Port does not receive the level signal, the equipment stops
running)
BE1 ………………………………..Operation command in “OPEN” direction
BE2 ………………………………. Operation command in “CLOSE” direction
BE3 ………………………………..Shutdown command
BE4 ………………………………..Fault alarm reset command
BA1 ………………………………..Ready to run
BA2 ………………………………..Fault alarm
BA3 ………………………………..Open to the end position
BA4 ………………………………..Close to the end position
BA5 ………………………………..Exceeded torque in “OPEN” direction
BA6 ………………………………..Exceeded torque in “CLOSE” direction
BA7 ………………………………..Intermediate valve position indication 1
BA8 ………………………………..Intermediate valve position indication 2
Digital input ports (BE1 ~ BE4) and digital output ports (BA1-BA4) are standard configurations;
Digital output ports (BA5 ~ BA8) are optional.
3.2 Receiving Inspection
Upon receiving, check whether the outer package is unsealed, damaged or damp, and open the package to
check whether the parts are lost. If the above conditions are found, please be sure to contact the factory within
one week after receiving the actuators.
Our products have been packed in special packing boxes before ex factory delivery. We use the following
packaging materials: Wood + anti-collision film. If you need to dispose of packaging materials, we recommend
sending them to the local waste recycling center.

ACK21-01A
ontracactuators.com 7
3.3Transportation
The product shall be transported to the installation site in strong packaging.
Risk of death or serious injury from suspended weight.
1. Do not stand under the suspended weight.
2. When lifting the equipment, the rope or hook shall be fixed on the shell, not on the hand crank.
3. Actuator installed on the valve:
when lifting the equipment, the rope or hook shall be fixed on the valve, not on the actuator.
4. Actuator installed on the gearbox:
when lifting the equipment, fix the rope or hook on the gearbox instead of the actuator.
5. Actuator installed on the control device: when lifting the equipment, fix the rope or hook on the
actuator, not on the control device.
3.4Storage
1. Improper storage will cause the risk of equipment corrosion!
2. Store in a well ventilated and dry room.
3. Store on shelves or wooden pallets to prevent moisture on the ground.
4. Cover the equipment to prevent dust and dirt.
5. Wipe the uncoated surface with a suitable preservative.
6. If the temperature is lower than the allowable range, the display screen will be damaged!
Ontrac actuators’ control devices cannot be stored at temperatures below - 30 ° C.
Long term storage
If the equipment needs long-term storage (more than 6 months), the following points shall also be
observed:
1. Before storage:
Wipe uncoated surfaces, especially output drive components and assembly surfaces, with a long
term corrosion inhibitor.
2. After every 6 months:
Check for rust. If there are signs of rust, please take new anti-corrosion measures.

ACK21-01A
ontracactuators.com 8
3.5 Warranty
The warranty period is 12 months after putting into operation or 18 months after shipping out from factory. This
actuator has been designed and manufactured to be used in specific conditions and within defined limits. The
use outside these specifications has to be agreed and approved by Ontrac. It must be considered also that, if
the actuators are used outside their technical specifications, the factory warranty are no longer valid.
The actuator has to be used only for the applications specified in the
order for which Ontrac has selected the model, the materials of
construction and has tested the actuator to respect the specifications.
For other uses different from those stated in the order, the customer
has to send always a written request to the Ontrac technical office,
which on its part will reply in a written form. There will not be any
warranty for repairs or alterations on the product done by the users or
third parties not specifically authorized by Ontrac.
3.6 Return to Factory
Please send your request to [e-mail] for return policy and approval from factory
prior to any action.

ACK21-01A
ontracactuators.com 9
04 Main Components
Advanced frequency converter
and electronics technologies
The gear unit provides high
efficiency, maintenance free
operation.
Motor in insulation class F. Measuring
and monitoring of both current and
temperature provide full protection.
Introduction of efficient Man-machine
interface simplifies commissioning with
user guidance.
Motor and control cables are connected by
using screw type terminals or PCB plug-in
terminals to ensure reliable electrical
contact.
Magnetic angle sensors for contact-less
position detection, are operated by means
of the signaling gear to detect the current
valve position and torque.
A centrifugal lock prevents the hand wheel
from engaging before the motor has come
to a standstill.
4.1Introduction of main components

ACK21-01A
ontracactuators.com 10
Type B1 interface
Type B3 interface
4.2 Flange Structure and Valve Connection Size
The output axis has two interface modes:
1、Type B1 interface
2、Type B3 interface
Application：
1、For rotating, non rising stem
2、Cannot bear thrust
The connecting flange shall comply with the standard ISO 5210
Model
MOE706
MME806
MOE708
MME808
MOE712
MME812
MOE725
MME825
MOE750
MME850
MOE790
MME890
Size of connecting flange
F10
F10
F10
F14
F14
F16
Note: 1. Bosses on flanges shall be clearance fit.
2. The flange specification and interface mode have been determined in the procurement stage.
Interface size: (unit: mm)
A
B
C
D
E
F
G
H
I
J
K
L
F10
45.3
12
6
24.3
40
50
14
7
54
42
20
64
F14
64.4
18
8
33.3
57.5
53
20
8
74
60
30
65
F16
74.9
20
12
43.3
70
93
24
12
98
70
40
80

ACK21-01A
ontracactuators.com 11
4.3Operation
The power electronic controlled motor drives the worm shaft, which is mounted
on a hollow shaft. This can be coupled to the valve either directly or using an
additional gearing..
A position sensor next to the worm shaft detects speed and the direction of
rotation.
A hand crank is provided for manual operation. Please refer to 6.3 for specific
operation steps.
The actuator is equipped with a local control panel with various elements for
operation and display. Switch the mode selector switch to LOCAL in order to
drive the actuator with the + / - push buttons.

ACK21-01A
ontracactuators.com 12
05 General and Technical Data
5.1 Specifications
Voltage supply:
3-phase AC, 220/380/460/550V±10%, 50/60Hz±5%;
1-phase AC, 110/220V±10%, 50/60Hz±5%;
Duty mode:
On-off (MOE series,) a complete stroke, S2 - 15 min;
Modulating (MME series), separate strokes, S4 - 25%, Number of starts ≤1200/h
Motor control:
Variable frequency control technology
Voltage input:
24V. DC (18-33V), max 500mA;
Voltage output:
24V. DC (18-33V), max 40mA; short circuit protection.
Input Signal:
(1) Analogue input: 4...20 mA; 250Ω inherent resistance; rising characteristic
(2) Digital input: pulse width≥50ms, the number 0 is - 3 ~ + 5V or open circuit, and the
number 1 is + 12 ~ + 35V
Output Signal:
(1) Analogue output: 4...20 mA; load impedance≤750Ω;
temperature effect≤0.1%/10K; rising characteristic;
(2) Digital output: 4 pairs of basic potential-free contacts, which can be added to 7 or
8 pairs (all output contacts can be configured), and the contact
capacity is 30V.DC, 1A or 125V.AC, 0.5A, 4 pairs of basic
potential-free contacts, 250V.AC 8A specification is also optional.
(3) Profibus-DP or MODBUS
Strokes range:
Minimum 1 circle for Multi-turn.
Torque tripping:
40%...100% adjustable, step 5%
Output Speed:
40%...100% adjustable, step5%
Accuracy:
(1) Multi-turn stroke≥1 circle ≤±0.5%
(2) Part-turn ≤±0.5%
(3) Linear stroke≥25mm ≤±0.5%
Dead zone:
1%（0.5...10% adjustable)
Enclosure protection:
IP67 (IP68 optional)
Explosive protection:
ExdIIBT4 ( ExdIICT4 optional)
Ambient conditions:
(1) Temperature: On-off duty, MOE series, – 25 °C to +70 °C
Modulating duty, MME series, –25 °C to +60 °C
Separate type, MME series, –40°C to +85 °C
(2) Humidity ≤95%
(3) Air media without corrosive, flammable or explosive gas
Anticondensation:
Anticondensation heater inside
CE standard:
(1) EN 61000-6-4: 2007, EN 61000-6-2: 2005
(2) EN 61000-3-2:2006 +A1: 2009+A2: 2009, EN 61000-3-3: 2008
(3) EN 60204-1:2006+A1:2009
(4) ATEX: CML 14ATEX1108
Fatigue strength:
0.75g within 5...200Hz; extended strength proof with 5...150Hz,2g sinusoidal
(Split type: acceleration 3g: X-28.97Hz, Y-96.68Hz, Z-149.6Hz)
Coating
All Ontrac actuators are epoxy enamel coated as standard to ISO 12944-2. Our standard
color is black to RAL 9005.
We are also able to provide enhanced paint protection in accordance with ISO 12944
C5-M (Marine) for offshore environments.
Any coating requirement for corrosion environment, please consult the factory or our
sales representive.

ACK21-01A
ontracactuators.com 13
5.2 Mechanical Interfaces
According to the mechanical interfaces, Ontrac electric actuators are divided into three categories:
1、Multi-turn:
Actuator outputs at least 360°of angular displacement and torque. If equipped with A type output shaft
can realize a linear thrust motion.
2、Linear:
Equipped with a linear thrust, actuator can output linear displacement and thrust, and valve stem directly
connected to the linear thrust rod.
3、Part-turn:
Equipped with worm gear, actuator can output 90° of angular displacement and torque. Part-turn are
divided into two categories according to their installation.
3.1 Direct mounting: Worm gearbox is connected with the flange and output shaft hole.
3.2 With base and lever: Worm gearbox is mounted on the base, and valve is drived by lever and rod.
PG Gearbox
“A” output shaft
Linear thrust unit Worm gearbox
for direct
mounting
Worm gearbox with
base and lever
SG Gearbox

ACK21-01A
ontracactuators.com 14
5.3Technical Data
5.3.1 Multi-turn On-Off, Electric Actuators (MOE)
Multi-turn Actuators (On-Off)
Combination
Switch-off
torque
(Nm)
Speed
(r.p.m)
Rising
valve stem
(mm)
Flange
(ISO5210)
Power
(kW)
Current
(A)
Fuse
(A) Weight (kg)
MOE706S
6···15
72-180
38
F10
1
2.52
3×16A
24
MOE706R
10···25
36.8-92
38
F10
1
2.52
3×16A
24
MOE706M
25···50
14-35
38
F10
0.55
1.45
3×16A
24
MOE708S
12···30
72-180
38
F10
1
2.52
3×16A
24
MOE708R
20···50
36.8-92
38
F10
1
2.52
3×16A
24
MOE708M
32···80
14-35
38
F10
0.55
1.45
3×16A
24
MOE712S
24···60
72-180
38
F10
1.7
3.83
3×16A
29
MOE712M
60···150
14-35
38
F10
0.75
2.1
3×16A
29
MOE725S
50···125
72-180
55
F14
4
11.58
3×16A
39
MOE708S+PG80/4S-1
41···102
18-45
41.8
F12/F14
1
2.52
3×16A
36
MOE708R+PG80/4S-1
68···170
9.2-23
41.8
F12/F14
1
2.52
3×16A
36
MOE725R
80···200
36.8-92
55
F14
4
11.58
3×16A
39
MOE708M+PG80/4S-1
109···272
3.52-8.8
41.8
F12/F14
0.55
1.45
3×16A
36
MOE712S+PG80/4S-1
82···204
18-45
41.8
F12/F14
1.7
3.83
3×16A
41
MOE708R+PG80/6S-1
100···250
6-15.33
41.8
F12/F14
1
2.52
3×16A
36
MOE725M
120···300
14-35
55
F14
2.2
3.97
3×16A
39
MOE708M+PG80/6S-1
160···400
2.32-5.8
41.8
F12/F14
0.55
1.45
3×16A
36
MOE712S+PG80/6S-1
120···300
14.4-36
41.8
F12/F14
1.7
3.83
3×16A
41
MOE750R
120···300
36.8-92
55
F14
6.8
15.64
3×16A
41
MOE712R+PG80/4S-1
136···340
9.2-23
41.8
F12/F14
1.7
3.83
3×16A
41
MOE750P
160···400
28.8-72
55
F14
6.8
15.64
3×16A
41
MOE712M+PG80/4S-2
204···510
3.52-8.8
48.1
F14/F16
0.75
2.1
3×16A
47
MOE712R+PG80/6S-2
200···500
6-15.33
48.1
F14/F16
1.7
3.83
3×16A
47
MOE725S+PG80/4S-2
170···425
18-45
48.1
F14/F16
4
11.58
3×16A
57
MOE712M+PG80/6S-2
300···750
2.32-5.8
48.1
F14/F16
0.75
2.1
3×16A
47
MOE725S+PG80/6S-2
250···625
12-30
48.1
F14/F16
4
11.58
3×16A
57
MOE725R+PG80/4S-2
272···680
9.2-23
48.1
F14/F16
4
11.58
3×16A
57
MOE790M
480···1200
14-35
68
F16
7.5
15.02
3× 25A
63
MOE725R+PG80/6S-2
400···1000
6-15.33
48.1
F14/F16
4
11.58
3×16A
57
MOE750R+PGZ/4-1 (4:1)
408···1020
9.2-23
54
F16/F25
6.8
15.64
3×16A
83
MOE750P+PGZ/4-1 (4:1)
544···1360
7.2-18
54
F16/F25
6.8
15.64
3×16A
83
MOE750R+PGZ/4-1 (6:1)
600···1500
6-15.33
54
F16/F25
6.8
15.64
3×16A
83
MOE750P+PGZ/4-1 (6:1)
800···2000
4.8-12
54
F16/F25
6.8
15.64
3×16A
83
MOE790P+PGZ/6-1
1480···3700
4-10
60.32
F25/F30
11
23.43
3×30A
137
MOE790PL+PGZ/8-1
3240··8100
2.18-5.45
82.55
F30/F35
13
23,43
3×30A
218

ACK21-01A
ontracactuators.com 15
5.3.2 Multi-turn Modulating, Electric Actuators (MME)
Note 1 ： All actuators are self-locking except MOE7…S.
Note 2: Switch-off torque 10% variations due to mechanical efficiency alteration, 40% to 100% adjustable.
Equipped with "A" output shaft, actuator can drive valve rod to have a linear
motion. All axial force is sustained by "A" output shaft. The following table is
the transmission factor for stem trapezoidal thread.
Valve transmission factors （Output torque=Axial forces*Factor）
Thread size
Factor
Thread size
Factor
Thread size
Factor
Thread size
Factor
Tr18x4
0.00190
Tr32x6
0.00323
Tr46x8
0.00457
Tr70x10
0.00666
Tr20x4
0.00205
Tr34x6
0.00339
Tr48x8
0.00472
Tr75x10
0.00704
Tr22x5
0.00234
Tr36x6
0.00354
Tr50x8
0.00487
Tr80x10
0.00741
Tr24x5
0.00250
Tr38x6
0.00369
Tr52x8
0.00502
Tr85x12
0.00806
Tr26x5
0.00265
Tr40x6
0.00384
Tr55x8
0.00525
Tr90x12
0.00844
Tr28x5
0.00279
Tr42x6
0.00399
Tr60x8
0.00563
Tr95x12
0.00882
Tr30x6
0.00309
Tr44x8
0.00441
Tr65x10
0.00628
Tr100x12
0.00920
Note: For inside screw non-rising gate valve, factors will be multiplied by 1.5, and the sluice, factors be
multiplied by 1.25, to ensure that the thrust 3 times larger than the weight of valve.
Multi-turn Actuators (Modulating)
Combination
Tripping
torque
(Nm)
Switch-off
torque
(Nm)
Speed
(r.p.m)
Rising
valve stem
(mm)
Flange
(ISO5210) Power (kW) Current (A) Fuse (A) Weight (kg)
MME806
25
20···50
14-35
38
F10
0.55
1.45
3×16A
24
MME808
40
32···80
14-35
38
F10
0.55
1.45
3×16A
24
MME812
75
60···150
14-35
38
F10
0.75
2.1
3×16A
29
MME825
150
120···300
14-35
55
F14
2.2
3.97
3×16A
39
MME850
300
240···600
14-35
55
F14
4
8.03
3×16A
41
MME808+PG80/4S-1
136
109···272
3.52-8.8
41.8
F12/F14
0.55
1.45
3×16A
36
MME808+PG80/6S-1
200
160···400
2.32-5.8
41.8
F12/F14
0.55
1.45
3×16A
36
MME812+PG80/4S-2
255
204···510
3.52-8.8
48.1
F14/F16
0.75
2.1
3×16A
47
MME812+PG80/6S-2
375
300···750
2.32-5.8
48.1
F14/F16
0.75
2.1
3×16A
47
MME890
600
480···1200
14-35
68
F16
7.5
15.02
3×25A
63
MME825+PGZ/4
750
600···1500
2.32-5.8
54
F16/F25
2.2
3.97
3×16A
81
MME850+PGZ/4
1020
816···2040
3.52-8.8
54
F16/F25
4
8.03
3×16A
83
MME850+PGZ/6
1500
1200···3000
2.32-5.8
60
F25/F30
7.5
15.02
3×25A
115
MME890+PGZ/8
2550
2040··5100
2.32-5.8
82.55
F30/F35
7.5
15.02
3×25A
218
MME890L+PGZ/8
3060
2448··6120
2.30-5.8
82.55
F30/F35
7.5
18.4
3×25A
218
