HD CVI/AHD Optical Transceiver
Model:ONV-4HDCVI
Summary
HDCVI optical transceiver is designed by Beyond for long-distance fiber transmission of
HDCVI HD compound video, adopt the compressed digital photoelectric conversion
technology by their research and development, use fiber to transfer Millions of pixel HD
video by dot to dot, and realize video transmission without delay and with high reliability.
Single fiber can transfer 1-4 CH HDCVI HD compound video at the same time.
HDCVI HD optical transceiver supports two HD video format 1280H and 1920H, supports
two resolution ratio 1280×720 and 1920×1080,four frame rate 25,30,50,60, six HD format
1280H/25f, 1280H/30f, 1280H/50f, 1280H/60f, 1920H/25f, 1920H/30f.

HDCVI Fiber Optical Transceiver User Guide
Copy right by ONV www.onvcom.com Page 2of 4
Feature
Aluminum alloy shell wall or 1 u case
Support 1280H and 1920H two HD video format
All interface adopts three-level anti-static, lightning protection
Ultra-wide optical dynamic range and advanced adaptive technology , and
transmission distance is up to 40 km
Surface Mount Optical Device, and ensure small volume of products, high stability,
high reliability
Very low electromagnetic interference （EMI）, adio-frequency interference （RFI）
and a total of ground loop interference
Rich LED lights, diagnostics indicator
Plug and play, support hot plug
The advantage of small dimension,small power,strong anti-interference ability, high
fidelity
Industrial-grade ultra wide temperature range （-40℃～+85℃）, adapt to the more
environment
Support user customization and OEM
Application
City traffic monitoring system
Public security and safe city monitoring system
Security and charging system on the highway
Building, campus monitoring network.
Industrial monitoring (airport, chemical, steel, petroleum, railway, water
conservancy, mining, etc.)
Military monitoring (w, arehouse, frontier defense, the guards, national
defense, etc.)
Television transmission system
Gymnasium (live video and audio transmission)
Optical Properties :
Wavelength 1310nm&1550nm
Fiber Power -8~ -3dBm / -3~+2dBm
Fiber Mode 50/125um Multimode, 62.5/125um Multimode, 9/125um
Single-Mode
Receiver Sensitivity -22dBm
Fiber Interface FC, ST , SC (Optional)
Transmission Distance 0~500M(Multimode) / 0~40KM(Single-Mode)

HDCVI Fiber Optical Transceiver User Guide
Copy right by ONV www.onvcom.com Page 3of 4
Video Parameters :
Transmitter Input Level >500mVp-p
Receiver Output Level 1Vp-p
Input & output Impedance 75
Receiver Rise & Fall Time <0.8ns
Receiver Max Jitter <0.2 UI
Physical Interface BNCInterface
Input/aoutput Interface Number 1~4
LED Light Light Chain, Power Supply, Data and Video Source Lights
Power Supply DC5V 2A
Power Consumption ≤5W
Power Adapter: 100V~240V AC Adaptive
Working temperature: -40℃~ +85℃;
Storage temperature:-40℃~ +85℃
Working humidity: 0~95% No Condensation;
MTBF: ≥100,000 Hours
Dimensions :

HDCVI Fiber Optical Transceiver User Guide
Copy right by ONV www.onvcom.com Page 4of 4
Applications:
