Onyx 175S User manual

Medical Station ONYX-175S/195S
ONYX-175S/195S
17”/19” Intel Core 2 Duo
Processor
High Performance
Low Power Consumption
Medical Station
ONYX-175S/195S Manual 2st Ed
September, 2010

Medical Station ONYX-175S/195S
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor
for any infringements upon the rights of third parties, which may
result from its use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, ONYX Healthcare Inc., assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein
ONYX Healthcare Inc. reserves the right to make changes in the
product design without notice to its users

Medical Station ONYX-175S/195S
Acknowledgments
Intel®and Core 2 Duo and Core Solo are registered
trademarks of Intel®Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft®Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIATechnology, Inc.
All other product names or trademarks are properties of their r
espective owners.

Medical Station ONYX-175S/195S
Packing List
Before you begin installing your Medical Station, please
make sure that the following items have been shipped:
Onyx-175S or ONYX-195S Super Medical Station
HDD screws
Utility CD-ROM (Please insert the ONYX-175S/195S
CD-ROM into external CD-ROM drive.) which
Contains User’s Manual (in PDF format), Drivers and
Utilities
If any of these items are missing or damaged, you should contact
your distributor or sales representative immediately.
Headquarters
Onyx Healthcare Inc.
2F, No.135, Lane 235, Pao-Chiao Rd.,
Hsin-Tien City, Taipei 231, Taiwan, R.O.C.
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
http://www.onyx-healthcare.com

Medical Station ONYX-175S/195S
Worldwide Offices:
Onyx Healthcare, USA Inc.
2663 Saturn street, Brea, CA92821, USA
Tel : [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare EUROPE B.V.
Ekkersrijt 4002, 5692 DASon, The Netherlands
Tel : [phone]
Fax: [phone]
Email: [e-mail]
Onyx Healthcare Technology GmbH
An der Trift65d
63303 Dreieich , Germany
TEL: [phone]
Fax: [phone]
Email: [e-mail]

Medical Station ONYX-175S/195S
Onyx Healthcare (SU ZHOU) INC.
Room 12, 2F, Building B, No.5 Xing Han Street, Suzhou Industrial
Park, Jiang Su Province, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare Singapore PTE LTD
57 Genting Lane, #07-00, Singapore 349564
Tel: [phone]
Fax [phone]
Email: [email protected]

Medical Station ONYX-175S/195S
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from anyAC outlet before cleaning.
Do not use liquid or spray detergents for cleaning. Use a damp
cloth.
4. For pluggable equipment, the power outlet must be installed
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect
the equipment from overheating. DO NOT COVER THE
OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from
the power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified

Medical Station ONYX-175S/195S
service personnel should open the equipment.

Medical Station ONYX-175S/195S
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it
to work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.
16. External equipment intended for connection to signal
input/output or other connectors, shall comply with
relevant UL / IEC standard (e.g. UL 1950 for IT equipment
and UL 60601-1 / IEC 60601 series for systems – shall
comply with the standard IEC 60601-1-1, Safety
requirements for medical electrical systems. Equipment
not complying with UL 60601-1 shall be kept outside the
patient environment, as defined in the standard.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

Medical Station ONYX-175S/195S
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX0
3. Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment

Medical Station ONYX-175S/195S
FCC Safety
This device complies with Part 15 FCC
Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received including interference that may
cause undesired operation.

Medical Station ONYX-175S/195S
UL Module Description
Onyx-175S/195S AC modules are developed
to suitable for the Classification Mark
requirement

Medical Station ONYX-175S/195S
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
Attention, consult ACCOMPANYING
DOCUMENTS.
Ground wire
Protective Ground wire.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1

Medical Station ONYX-175S/195S
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
ONYX Panel PC/ Workstation
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
液晶模块 ×○○○○○
光驱 ×○○○○○
触控模块 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Medical Station ONYX-175S/195S
Contents
Chapter 1 General Information
1.1 Introduction .............................................................................1-1
1.2 Feature......................................................................................1-3
1.3 Specification.............................................................................1-4
1.4 Dimension.................................................................................1-8
Chapter 2 Hardware Installation
2.1 Safety Precautions...................................................................2-2
2.2 A Quick Tour of the ONYX-175/195......................................2-3
2.3 Removing the rear maintenance cover ..................................2-6
2.4 2.5” Hard Disk Drive (HDD) Installation..............................2-6
2.5 COM5 RS-232/422/485 Selection............................................2-9
2.6 RS-232/422/485 Serial Port Connector..................................2-9
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization... .............................................3-2
3.2 Award BIOS Setup..................................................................3-3
Chapter 4 Driver Installation
4.1 Installation................................................................................4-3
4.2 Card Reader Driver Installation............................................4-4
4.3 Touch Screen Driver Installation...........................................4-4
4.4 Smart Card Driver Installation..............................................4-4
4.5 RFID Driver Installation.........................................................4-5

Medical Station ONYX-175S/195S
Appendix A Programming the Watchdog Timer
A.1 Programming.........................................................................A-2
A.2 IT8712 Watchdog Timer Initial Program ...........................A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................................B-2
B.2 Memory Address Map...........................................................B-3
B.3 IRQ Mapping Chart ............................................................B-4
B.4 DMA Channel Assignments..................................................B-4
Appendix C Miscellanea
C.1 General Cleaning Tips...........................................................C-2
C.2 Cleaning Tools........................................................................C-3
C.3 Scrap Computer Recycling .................................................C-5

Medical Station ONYX-175S/195S
General
Chapter
1
Information

Medical Station ONYX-175S/195S
Chapter 1 General Information 1-1
1.1 Introduction
The ONYX-175S/195S Medical Stations are based on Intel Core 2
Duo processors which deliver a performance improvement of more
than 100﹪compared to systems running traditional single-core
processors. With two cores, or computing engines, ONYX can
simultaneously execute two computing tasks. It accommodates one
2.5” SATA hard disk drive and up to 2GB DDR SODIM.
The high brightness LCD, Low Noise solution, integrated
multimedia functions and extensive expansion options make them
the perfect platform upon which to build comprehensive surgical
computing applications.
The ONYX-175S/195S includes all the features of a powerful
computer into a slim chassis. The ONYX-175S/195S have 17”/19”
high brightness TFT display with 1280 x 1024 resolutions for easier
DICOM image analysis. This model is equipped with side slim 8-in-
card reader, slim DVD ROM, and smart card reader to support vivid
storage read/write and ID check by smart card reader. The most
important function of the ONYX-175S/195S is the isolated COM
ports design.
Combining the ONYX-175S/195S into your system can achieve
both cost-saving and efficiency improvements. Common

Medical Station ONYX-175S/195S
Chapter 1 General Information 1-2
applications include Surgical, Radiology, PACS (Picture Archiving
Communication Systems), LIS (Lab Information Systems) and
Electronic Medical Record. The ONYX-175S/195S are definitely
your perfect choices.

Medical Station ONYX-175S/195S
Chapter 1 General Information 1-3
1.2 Feature
17”/ 19” Intel Core 2 Duo Processor
300 nits high brightness to X-ray films
Latex-free
Two Isolation COM Ports
Built-in RFID and Finger Printer Security (Optional)
Mini capture card support Non-DICOM CAM to DICOM
(optional)
PCI Expansion
Highest performance and low power system solution
802.11g/b/g and Bluetooth Wireless Solution (optional)
Plastic construction with medical outlook color
