Onyx MPAD-800 User manual

Last Updated: January 23, 2018
MPAD-800
Medical Tablet
User’s Manual 1st Ed

Preface II
Tablet Computer MPAD-800
Copyright Notice
This document is copyrighted, 2018. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, We assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
We reserves the right to make changes in the product design without notice to its
users.

Preface III
Tablet Computer MPAD-800
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
Cortex is the registered trademark of ARM Holdings
Android is the trademark of Google Inc.
All other product names or trademarks are properties of their respective owners.

Preface IV
Tablet Computer MPAD-800
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
MPAD-800 with Android 6.0.1
1
AC/DC power adapter
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
Tablet Computer MPAD-800
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver
installation instructions (if any), to facilitate users in setting up their product.

Preface VI
Tablet Computer MPAD-800
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware.
5. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure
to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and contain all electronic components
in any static-shielded containers.

Preface VII
Tablet Computer MPAD-800
17. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
Tablet Computer MPAD-800
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received including interference that may
cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et
les directives gouvernementales de recyclage.

Preface IX
Tablet Computer MPAD-800
Table of Contents
Chapter 1 - Product Specifications........................................................................................1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Getting Started...................................................................................................4
2.1 Product Overview ................................................................................................... 5
Chapter 3 –Setting Up...........................................................................................................9
3.1 System Setup.......................................................................................................... 10
3.1.1 Wireless & Networks.......................................................................... 12
3.1.2 Device Settings.................................................................................... 14
3.1.3 Personal Settings ................................................................................ 18
3.1.4 Accounts Settings ............................................................................... 20
3.1.5 System Settings................................................................................... 21
Chapter 4 –Optional Accessories.......................................................................................23
4.1 1D/2D Code Scanner ........................................................................................... 24
4.2 Magnetic Stripe Reader (MSR) ........................................................................... 26
Chapter 5 –Frequently Asked Questions...........................................................................27
5.1 Frequently Asked Questions (FAQ).................................................................... 28
Appendix A - Statements .....................................................................................................30
A.1 Statements.............................................................................................................. 31
A.2 Canadian Notice.................................................................................................... 33
A.3 Safety Caution........................................................................................................ 34
A.4 Battery Disposal..................................................................................................... 36
A.5 Battery Caution...................................................................................................... 38
A.6 Adapter Caution.................................................................................................... 39
A.7 FCC Interference Statement................................................................................ 40

Tablet Computer MPAD-800
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
Tablet Computer MPAD-800
1.1 Specifications
System
Processor
ARM®Cortex® Quad-Core up to 1.6 GHz
System Memory
2 GB SDRAM
LCD Display
8” (1280 x 800) TFT LCD with 2-point P-cap
Communication
WiFi b/g/n
Bluetooth 4.0 (EDR) with integrated class 1 PA
and BLE Support
I/O Port USB Type C x 1
USB Type A x 1
Volume Up/Down

3.5 mm Stereo Headphone Jack x 1
DC-In Jack x 1
Built-In Speaker & Microphone
nanoSIM Card Slot
Micro SD card slot
Storage
16 GB eMMC Flash
Camera Front 2MP, Rear 8MP with Flash LED
Sensor
Built-in Light Sensor
Built-in G-Sensor
Built-in Vibration Motor
OS
Android 6.0.1

Chapter 1 –Product Specifications 3
Tablet Computer MPAD-800
Mechanical
Color
White
Dimension (W x H x D)
136.6 x 219 x 21 mm (5.38 x 8.58 x 0.83”)
Gross Weight
0.67 Kg (1.48 lb)
Environmental
Operating Temperature
0°C ~ 40°C
Storage Temperature
-20°C ~ 60°C
Operating Humidity 10 ~ 75%
Water/ Dust Protection
Rating
IP54
Vibration
Random Vibration: 5Hz~500Hz, 0.5grms
(operating & non-operating)
Drop
80cm within packing
ESD
Air +/- 8KV, Contact +/- 4KV
EMI/ Safety
FCC Class B/ UL
Power Supply
AC/DC Adapter
AC Power Input: 100 ~ 240 V, 50 ~ 60 Hz, 36 W
output: 12 V, 3 A
Battery
Lithium-Polymer High Capacity Battery

Tablet Computer MPAD-800
Chapter 2
Chapter 2 –Getting Started

Chapter 2 –Getting Started 5
Tablet Computer RTC-700M
2.1 Product Overview
Front View

Chapter 2 –Getting Started 6
Tablet Computer RTC-700M
Side View (Left)

Chapter 2 –Getting Started 7
Tablet Computer RTC-700M
Side view (Right)
Internal Microphone
Status
Indicator

Chapter 2 –Getting Started 8
Tablet Computer RTC-700M
Rear View

Tablet Computer MPAD-800
Appendix A
Appendix A - Statements

Appendix A –Statements 31
Tablet Computer RTC-700M
A.1 Statements
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following conditions: (1) This device may not cause harmful interference (2) This device
must accept any interference received, including interference that may cause undesired
operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment causes harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Appendix A –Statements 32
Tablet Computer RTC-700M
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government.
The exposure standard employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are
conducted using standard operating positions accepted by the FCC with the EUT
transmitting at the specified power level in different channels.
The highest SAR value for the device as reported to the FCC is 1.37 W/kg when placed
next to the body.
The FCC has granted an Equipment Authorization for this device with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information
on this device is on file with the FCC and can be found under the Display Grant section
of www.fcc.gov./oet/ea/fccid on the FCC ID: 2AOOUMPAD800WBL
This device is in compliance with SAR for general population/uncontrolled exposure
limits in ANSI/IEEE C95. 1-1999 and has been tested in accordance with the
measurement methods and procedures specified in applicable FCC KDB guidance.
