Opitec Rocket Vehicle with Reverse Propulsion User manual

1
Pricking Awl
Wood Glue
Pencil Ruler Phillips
Screwdriver
104.966
Rocket Vehicle with
Reverse Propulsion
Components List Quantity Size (mm) Description Part No.
Wooden Strip 1 200x50x10 Base Plate 1
Wooden Strip 1 50x50x10 Blowpipe Structure 2
Steel Spring Clamp 1 14-17 Blowpipe Support 3
Screw 1 ø3x16 Fixing Steel Spring Clamp 4
Ring Screw 4 12 Axle Support 5
Metal Axle 2 ø3x70 Axle 6
Steering Wheel 4ø37 Wheels 7
Blowpipe 1 Blowpipe 8
Balloon 1 Propulsion 9
Required Tools:
Please Note:
The OPITEC handicraft packs are not toys in a typical off-the-shelf sense,
but rather additional teaching and learning material for educational pur-
poses. This craft pack may only be constructed by children and ado-
lescents under the guidance and supervision of experienced adults. Not
suitable for children under 36 months. Choking hazard!
WARNING !
Balloons are NOT suitable for inflation by children under eight years
old. In certain conditions they can be swallowed. Children under eight
years old can suffocate from not properly inflated or burst balloon pi-
eces. Therefore children should be kept under adult supervision at all
times when inflating them. Store all non inflated balloons out of the
reach of young children.
Remove all burst balloon pieces at once and dispose of them safely.
Keep balloons away from the eyes and always use a pump to inflate
them! It should be noted that balloons are made with a natural rubber
that can in some cases cause allergies. Store the balloons in a cool
place away from sunlight. Keep these instructions and the balloons to-
gether in the original packing until its time to use them.

2
1
1
On the base plate (1), mark the position for the axle supports (ring screws 5) according to the dimensions. Then precut with the pricking awl.
2
Screw in the ring screws (5) at the marked positions as shown.
3
Insert the axles through the ring screws, as shown, and fix a steering
wheel (7) from both sides.
4
Center the wooden strip (2) and glue it onto the base plate (1) flush
with the edge.
5
Fasten the steel spring clamp (3) in the middle of the wooden struc-
ture (2) using the screw (4). See picture! Precut the screw hole.
5
6
6
7
7
7
7
2
3
4
Instructions 104966
Rocket vehicle with reverse propulsion

3
6
Insert the blowpipe (8) centered into the steel spring clamp (3), as
shown above.
87
Place the balloon (9) on the end of the blowpipe so that it is
stuck.
9
8Done!
Functioning:
Blow up the balloon through the blowpipe. Place the vehicle on the
ground and let it go.
The vehicle is propelled by the outflowing air recoil.
Driving direction
Instructions 104966
Rocket vehicle with reverse propulsion
