OPPO BDP-10X Blu-ray Disc Player
Network Remote Control Protocol
Note: This document describes a preliminary version of the network remote control
protocol for OPPO BDP-103/105/103D/105D players. This feature allows a network-
connected device such as a PC or a smartphone to control the OPPO Blu-ray player.
The OPPO Blu-ray player functions as a Server, which broadcasts the message, waits
and listens to the port(s), responses to the client’s connection, receives the client’s
commands and performs the action. The network device functions as a Client, which
receives and processes the broadcasting message, sets up the TCP connection with the
Server, and sends the control commands. In the remainder of this document, we use
“Server” for BDP-103/105/103D/105D players and “Client” for the network devices.
The commands and responses listed in this document require firmware version of:
•BDP-103/105/103D/105D: Main firmware of BDP10x-79-0711 or newer, MCU
firmware of MCU103-05-0916 (BDP-103), MCU105-04-1113 (BDP-105),
MCU13D-01-0618 (BDP-103D), MCU15D-01-0930 (BDP-105D), DB10X 131030
(BDP-103D, 105D)
Please note the network remote control feature and protocol are still under development,
future revisions may not be compatible with this preliminary version, and you will need to
reprogram any controllers that use this version of protocol.
The complete client control procedure can be described in three sections: DISCOVER,
CONNECT and COMMAND.
1. DISCOVER
Once the Server is running, it will automatically broadcast the message every 10
seconds to notify any interested Client about its availability, as well as the IP address
and the port number which are required to establish the TCP connection. The Client
needs to receive this broadcasting message, extract the IP address and port number,
and establish the connection with the Server. Once the connection is done, the Client
should also discard any future broadcasting messages.
The address used for the Server’s message broadcast is: 239.255.255.251:7624
The format of the broadcasting message is:
Notify:OPPO Player Start
Server IP:
Server Port:
For example:
Notify:OPPO Player Start
Server IP:192.168.0.2
Server Port:48360
2. CONNECT

2
OPPO Digital, Inc. • www.oppodigital.com
The Client will use the IP address and port number extracted from the broadcasting
message to establish the TCP connection with the Server.
3. COMMAND
Once the connection is established between the Server and the Client, the Client could
send the commands to remotely control the Server.
Command Structure:
Each command contains a string of the command type and a 3-character command
code, separated by a space (ASCII 0x20).
The illustration of the command structure is as the followings:
<Command> = <Type of Command><sp><Command Code>
<Type of Command> =REMOTE
<sp> = space, ASCII 0x20
<Command Code> = <byte><byte><byte>
For example, to open/close the tray:
REMOTE EJT
Command Sequence:
Commands are executed in the order they are received. The host should wait for
enough time before sending the next command.
Response Structure:
Upon receiving a command, the player shall try to execute the command and send back
a response. Two response formats are supported: the short response and the verbose
response. The short response is used by default. If the verbose mode (See command
reference for SVM) is set, the verbose response will be used instead.
The response starts with an “@” sign (ASCII 0x23), followed by the original command
code and a space (ASCII 0x20) if the verbose response is in use, and a result code,
either “OK” or “ER”. If there are any parameters or additional message, the parameters
or message is given in text format, separated by a space (ASCII 0x20) from the result
code. The @ character (ASCII 0x40) must never appear in the parameters or message.
A carriage return (ASCII 0x0d) indicates the end of response. Each response must not
exceed 25 bytes including the start of response and the end of response bytes.
The illustration of the response structure is as the followings:
<Short Response> = <Start of Response><Result Code>[<sp><Parameters>]
<End of Response>
<Verbose Response> = <Start of Response><Command Code><sp><Result Code>
[<sp><Parameters>]<End of Response>
<Start of Response> = @, ASCII 0x40

3
OPPO Digital, Inc. • www.oppodigital.com
<Command Code> = <byte><byte><byte>
<Result Code> = OK|ER
<sp> = space, ASCII 0x20
<Parameters> = command-specific
<End of Response> = CR, ASCII 0x0d
Status Update Messages Structure:
If the verbose mode is set to 2 or 3, the player will send status update messages
automatically. These messages are not a response to any particular command. Any
status change caused by commands from network remote control, front panel buttons,
IR remote control, or playback progress may trigger status update messages.
The status update messages have the following structure:
<Update> = <Start of Update><Status Code>[<sp><Parameters>]<End of Update>
<Start of Update> = @, ASCII 0x40
<Status Code> = <byte><byte><byte>
<sp> = space, ASCII 0x20
<Parameters> = status-specific
<End of Response> = CR, ASCII 0x0d
Command Sequence:
Commands are executed in the order they are received. The host should wait for a
response from the player before sending the next command.
If the player receives a new command before executing the previous command, the
player may discard the previous command.
If the host does not receive a response from the player 10 seconds after the command is
issued, the host may consider the command or response lost during transmission, and
can retransmit the command.
Command List:
A. Command that maps to a remote control button
This group of commands maps directly to the infrared remote control keys. No
parameters are needed for these commands. The player handles the commands as if it
receives the same IR remote commands. For actions that require a multiple-key
sequence, such as go to a certain chapter (GOT command followed by multiple numeric
key commands and the SEL command), the player responds to each command
individually until the last command is received. At that time the player shall respond with
either OK or ER depending on the result of the action.
Command
Code
Remote Key
Function
Response Example
POW
POWER
Toggle power STANDBY
and ON
OK ON
OK OFF
SRC
INPUT
Select input source
OK

4
OPPO Digital, Inc. • www.oppodigital.com
EJT
OPEN
Open/close the disc tray
OK OPEN
OK CLOSE
PON
ON
Discrete on
OK ON
POF
OFF
Discrete off
OK OFF
SYS
P/N
Switch output TV system:
NSTC, PAL or
MULTI(AUTO)
OK NTSC
OK PAL
OK AUTO
DIM
DIMMER
Dim front panel display
OK ON
OK DIM
OK OFF
PUR
PURE AUDIO
Pure audio mode (no video)
OK ON
OK OFF
VUP
VOL +
Increase volume
OK n (n is the volume
number, 0 –100)
VDN
VOL -
Decrease volume
OK n (n is the volume
number, 0 –100)
MUT
MUTE
Mute audio
OK MUTE
OK UNMUTE
NU1
1
Numeric key 1
OK
NU2
2
Numeric key 2
OK
NU3
3
Numeric key 3
OK
NU4
4
Numeric key 4
OK
NU5
5
Numeric key 5
OK
NU6
6
Numeric key 6
OK
NU7
7
Numeric key 7
OK
NU8
8
Numeric key 8
OK
NU9
9
Numeric key 9
OK
NU0
0
Numeric key 0
OK
CLR
CLEAR
Clear numeric input
OK
GOT
GOTO
Play from a specified
location
OK
HOM
HOME
Go to Home Menu to select
media source
OK
PUP
PAGE UP
Show previous page
OK
PDN
PAGE DOWN
Show next page
OK
OSD
DISPLAY
Show/hide on-screen display
OK
TTL
TOP MENU
Show BD top menu or DVD
title menu
OK
MNU
POP-UP MENU
Show BD pop-up menu or
DVD menu
OK
NUP
Up Arrow
Navigation
OK
NLT
Left Arrow
Navigation
OK
NRT
Right Arrow
Navigation
OK
NDN
Down Arrow
Navigation
OK
SEL
ENTER
Navigation
OK
SET
SETUP
Enter the player setup menu
OK
RET
RETURN
Return to the previous menu
or mode
OK
RED
RED
Function varies by content
OK

5
OPPO Digital, Inc. • www.oppodigital.com
GRN
GREEN
Function varies by content
OK
BLU
BLUE
Function varies by content
OK
YLW
YELLOW
Function varies by content
OK
STP
STOP
Stop playback
OK FULL STOP
PLA
PLAY
Start playback
OK
PAU
PAUSE
Pause playback
OK
PRE
PREV
Skip to previous
OK
REV
REV
Fast reverse play
OK 1X
FWD
FWD
Fast forward play
OK 1X
NXT
NEXT
Skip to next
OK
AUD
AUDIO
Change audio language or
channel
OK
SUB
SUBTITLE
Change subtitle language
OK
ANG
ANGLE
Change camera angle
OK a/b (a: current angle
number, b: total
available angles)
ZOM
ZOOM
Zoom in/out and adjust
aspect ratio
OK (zoom ratio text)
SAP
SAP
Turn on/off Secondary Audio
Program
OK (audio track
information)
OK Off
ATB
AB REPLAY
Repeat play the selected
section
OK A-
OK A-B
OK OFF
RPT
REPEAT
Repeat play
OK Repeat Chapter
OK Repeat Title
OK OFF
PIP
PIP
Show/hide Picture-in-Picture
OK (PIP program info)
OK Off
HDM
RESOLUTION
Switch output resolution
OK
SUH
SUBTITLE
(hold)
Press and hold the
SUBTITLE key. This
activates the subtitle shift
feature
OK
NFX
NETFLIX
Stop current playback and
start the Netflix application
OK
VDU
VUDU
Stop current playback and
start the VUDU application
OK
OPT
OPTION
Show/hide the Option menu
OK
M3D
3D
Show/hide the 2D-to-3D
Conversion or 3D
adjustment menu
OK
SEH
Display the Picture
Adjustment menu
OK
DRB
DARBEE
Display the Darbee
Adjustment menu
OK
NOP
No operation.
OK
B. Query Commands

6
OPPO Digital, Inc. • www.oppodigital.com
This group of commands issues queries to the player. The player shall respond
according to its current status.
Command
Code
Function
Response Example
QVM
Query verbose mode
OK 0
OK 1
OK 2
OK 3
QPW
Query power status
OK ON
OK OFF
QVR
Query firmware version
OK BDP103-xx-xxxx
QVL
Query volume
OK 100
OK MUTE
QHD
Query HDMI resolution
OK 480P
OK 720P50
OK 1080P60
OK AUTO
OK 4K*2K
QPL
Query playback status
OK NO DISC
OK LOADING
OK OPEN
OK CLOSE
OK PLAY
OK PAUSE
OK STOP
OK STEP
OK FREV
OK FFWD
OK SFWD
OK SREV
OK SETUP
OK HOME MENU
OK MEDIA CENTER
QTK
Query Track/Title
OK 02/10
QCH
Query Chapter
OK 03/03
QTE
Query Track/Title elapsed time
OK 00:01:34
QTR
Query Track/Title remaining time
OK 01:20:23
QCE
Query Chapter elapsed time
OK 00:01:34
QCR
Query Chapter remaining time
OK 00:12:22
QEL
Query Total elapsed time
OK 00:05:12
QRE
Query Total remaining time
OK 01:34:44
QDT
Query disc type
OK BD-MV
OK DVD-VIDEO
OK DVD-AUDIO
OK SACD
OK CDDA
OK DATA-DISC
QAT
Query audio type
OK DD 1/1

7
OPPO Digital, Inc. • www.oppodigital.com
OK DD 1/5 English
OK DTS 2/5 English
OK LPCM
OK DTS-HD 1/4 English
QST
Query subtitle type
OK OFF
OK 1/1 English
QSH
Query subtitle shift
OK -5
(valid returns are -10 .. 0 ..
10)
QOP
Query OSD position
OK 0
(valid returns are 0 .. 5)
QRP
Query Repeat Mode
OK 00 Off
(OK followed by a repeat
mode code and text:
00 Off
01 Repeat One
02 Repeat Chapter
03 Repeat All
04 Repeat Title
05 Shuffle
06 Random)
QZM
Query Zoom Mode
OK 00
(OK followed by a zoom
mode code:
00 Off
01 Stretch
02 Full
03 Underscan
04 1.2x
05 1.3x
06 1.5x
07 2x
08 3x
09 4x
10 1/2
11 1/3
12 1/4)
QIS
Query Input Source (Return the current
selected input source)
OK 0 BD-PLAYER
OK 1 HDMI-FRONT
OK 2 HDMI-BACK
OK 3 ARC-HDMI-OUT1
OK 4 ARC-HDMI-OUT2
OK 5 OPTICAL
OK 6 COAXIAL
OK 7 USB-AUDIO
QDB
Query Current Darbee’s Demo mode,
Darbee mode and Level (Apply to BDP-
103D Blu-ray Player only)
OK X Y NNN
(X: current Demo mode
0 –Off
1 –Split Screen
2 –Swipe Screen

8
OPPO Digital, Inc. • www.oppodigital.com
Y: current Darbee mode
0 –Off
1 –High Definition
2 –Gaming
3 –Full Pop
NNN: current Darbee level
in percentage, 0 –120)
C. Advanced Commands
This group of commands instructs the player to perform an advanced operation in a
single step.
Command
Code
Parameters
Function
Response
Example
SVM
0
1
2
3
0 –Set Verbose Mode to off
1 –Commands are echoed back in
the response
2 –Enable unsolicited status update.
Only major status changes are
reported.
3 –Enable detailed status update.
When content is playing, the player
sends out playback time update
every second.
OK 0
OK 1
OK 2
OK 3
SHD
SDI
SDP
720P
1080I
1080P
SRC
AUTO
4K2K
Set HDMI output resolution.
SDI –Standard definition interlaced
(480i/576i)
SDP –Standard definition
progressive (480p/576p)
SRC –Source Direct
4K2K –Ultra high definition 4Kx2K
OK 480P
(OK followed by the
original parameter)
SPN
NTSC
PAL
AUTO
Set output TV system
OK NTSC
OK PAL
OK AUTO
SZM
1
AR
FS
US
1.2
1.3
1.5
2
1/2
3
4
1/3
1/4
Set zoom ratio.
AR –Aspect ratio correction
(Stretch, Letterbox or Pillarbox)
FS - Full Screen
US - Underscan
For HDMI Output: 1, AR, FS, US,
1.2, 1.3, 1.5, 2, 1/2;
For Component Ouput: 1, 2, 3, 4,
1/2, 1/3, 1/4)
OK 1.2
(OK followed by the
zoom ratio)
ER INVALID

9
OPPO Digital, Inc. • www.oppodigital.com
SVL
0 –100
MUTE
Set volume control
OK 100
OK MUTE
SRP
CH
TT
ALL
OFF
SHF
RND
Repeat chapter
Repeat title or CD track
Repeat all
Repeat off
Shuffle
Random
OK CH
(OK followed by the
repeat mode)
ER INVALID
SRH
T3
C10
C 0:00:34
T 0:12:13
0:12:13
Search to Title 3
Search to Chapter 10
Search to 0:00:34 of the current
chapter or track
Search to 0:12:13 of the current title
or disc
Search to 0:12:13 of the current title
or disc
OK
ER INVALID
DPL
Direct play
OK
RST
Reset Command –Clean all
command buffers, do not wait for
any pending/executing commands.
Start over again.
OK
SSH
-10 ... 10
Set subtitle shift
OK -10…10
SOP
0 … 5
Set OSD position
OK 5 (OK followed
by the position
value)
ER INVALID
STC
E
R
T
X
C
K
Set the time information display:
E –Total Elapsed time
R –Total Remaining time
T –Title Elapsed time
X –Title Remaining time
C –Chapter/track Elapsed time
K –Chapter/track Remaining time
OK E
(OK followed by the
display type)
ER INVALID
SIS
0
1
2
3
4
5
6
7
Select the input source:
0 –Blu-Ray Player
1 –HDMI/MHL IN-FRONT
2 –HDMI IN-BACK
3 –ARC on HDMI OUT1
4 –ARC on HDMI OUT2
5 –OPTICAL IN
6 –COAXIAL IN
7 –USB AUDIO IN
OK 0 BD-PLAYER
OK 1 HDMI-FRONT
OK 2 HDMI-BACK
OK 3 ARC-HDMI-
OUT1
OK 4 ARC-HDMI-
OUT2
OK 5 OPTICAL
OK 6 COAXIAL
OK 7 USB-AUDIO
APP
NFX
YOU
VUD
PAN
PIC
RHA
Stop current playback and start the
corresponding application:
NFX - Netflix
YOU - YouTube
VUD - VUDU
PAN - Pandora
OK NFX
OK YOU
OK VUD
OK PAN
OK PIC
OK RHA

10
OPPO Digital, Inc. • www.oppodigital.com
CIN
PIC –Picasa
RHA –Rhapsody
CIN - CinemaNow
OK CIN
ER INVALID
SDB
X Y NNN
Set the parameters for Darbee video
processor (Apply to BDP-103D Blu-
ray Player on HDMI 1 OUT only)
(X: Demo mode
0 –Off
1 –Split Screen
2 –Swipe Screen
Y: Darbee mode
0 –Off
1 –High Definition
2 –Gaming
3 –Full Pop
OK X Y NNN
ER INVALID
Status Update Messages:
The following status update messages are sent by the player automatically when the
verbose mode is set to 2 or 3.
Verbose Mode 2:
UPW - Power Status Update:
Sent when there is a change of power on/off status.
Possible parameters: 1 digit
1 –Player is turned on
0 –Player is going off
Example: @UPW 1
UPL - Playback Status Update:
Sent when there is a change of playback status.
Possible Parameters: 4 chars
DISC –No disc
LOAD –Loading disc
OPEN –Tray is open
CLOS –Tray is closing
PLAY –Playback is starting
PAUS –Playback is paused
STOP –Playback is stopped
STPF –Forward frame-by-frame step mode
STPR –Reverse frame-by-frame step mode
FFWn –Fast forward mode. Where n is a number of 1... 5 to indicate the
speed level
FRVn –Fast reverse mode. Where n is a number of 1… 5 to indicate the
speed level
SFWn –Slow forward mode. Where n is a number of 1…4 to indicate the
speed level (1 = ½, 2 = ¼, 3 = 1/8, 4 = 1/16)
SRVn –Slow reverse mode. Where n is a number of 1…4 to indicate the
speed level (1 = ½, 2 = ¼, 3 = 1/8, 4 = 1/16)
HOME –in home menu

11
OPPO Digital, Inc. • www.oppodigital.com
MCTR –in media center
Example: @UPL PLAY
UVL - Volume Level Update:
Sent when there is a change in volume level or mute status.
Possible Parameters: 3 chars
MUT –Mute is engaged
000 .. 100 –Current volume level. Also sent when mute is cancelled.
Example: @UVL 095
UDT - Disc Type Update:
Sent when a new disc type is detected.
Possible Parameters: 4 chars
BDMV - Blu-ray Disc
DVDV –DVD-Video
DVDA –DVD-Audio
SACD
CDDA
HDCD
DATA –Data disc
VCD2 –VCD 2.0
SVCD - SVCD
Example: @UDT DVDV
UAT - Audio Type Update:
Sent when a new audio track is encountered.
Parameters: Type (2 chars), space, number (01/99, 5 chars), space, language (3
chars), space, channels (2 chars)
Type code:
DD –Dolby Digital
DP –Dolby Digital Plus
DT –Dolby TrueHD
TS –DTS
TH –DTS-HD High Resolution
TM –DTS-HD Master Audio
PC –LPCM
MP –MPEG Audio
CD –CD Audio
UN –Unknown
Number: current audio track / available audio tracks in 2-digit number format.
For example, 01/99 means the first of 99 available tracks; 02/05 means the
second of 5 available tracks. If only one track is available, it is 01/01.
Language: Three-character language code: ENG for English, FRA for French,
and so on (ISO3166). UNK for unknown.
Channels: 1.0 for mono, 2.0 for stereo, 5.1 or 7.1 for 5.1-channel or 7.1-ch
surround, 0.0 for unknown.
Example: @UAT DD 01/05 ENG 5.1
UST - Subtitle Type Update:
Sent when a new subtitle is selected.
Parameters: number (01/99, 5 chars), space, language (3 chars)

12
OPPO Digital, Inc. • www.oppodigital.com
Number: current subtitle track / available subtitle tracks in 2-digit number format.
For example, 01/99 means the first of 99 available tracks; 02/05 means the
second of 5 available tracks. If subtitle is set to off, use 00/xx where xx is the
number of available subtitle tracks. If no subtitle is available, use 00/00.
Language: Three-character language code: ENG for English, FRA for French,
and so on (ISO3166). UNK for unknown.
Example: @UST 02/05 ENG
UIS –Input Source Update:
Sent when there is a change in the input source selection.
Possible Parameters: source number (1 digit), space, source name (13 chars)
Source number and the corresponding source name:
0 - BD-PLAYER
1 - HDMI-FRONT
2 - HDMI-BACK
3 - ARC-HDMI-OUT1
4 - ARC-HDMI-OUT2
5 - OPTICAL
6 - COAXIAL
7 - USB-AUDIO
Example: @UIS 0 BD-PLAYER
@UIS 2 HDMI-BACK
Verbose Mode 3:
UTC - Time Code Update:
Sent every second when the playback time advances. The time information is the
same as the front panel display. To switch to a different type of time information,
please refer to the STC command.
Parameters: Title (3 digits), space, Chapter (3 digits), space, Type (1 chars),
space, time (8 chars HH:MM:SS)
Title: Current title number. For example, 001. For discs without title numbers
(CD), 001 is always used.
Chapter: Current chapter or track number. For example, 003.
Type Code:
E –Total Elapsed time
R –Total Remaining time
T –Title Elapsed time
X –Title Remaining time
C –Chapter/track Elapsed time
K –Chapter/track Remaining time
Example: @UTC 001 001 C 00:01:23
UVO - Video Resolution Update:
Sent when the source content resolution or the output resolution is changed.
Parameters: Source resolution (7 chars), space, Output resolution (7 chars)
Resolution Names:
_480I60 –480i 60/59.94Hz
_480P60 –480p 60/59.94Hz
_576I50 –576i 50Hz
_576P50 –576p 50Hz

13
OPPO Digital, Inc. • www.oppodigital.com
_720P60 –720p 60/59.94Hz
_720P50 –720p 50Hz
1080I60 –1080i 60/59.94Hz
1080I50 –1080i 50Hz
1080P60 –1080p 60/59.94Hz
1080P50 –1080p 50Hz
1080P24 –1080p 24Hz
1080P23 –1080p 23.97Hz
Examples:
The following are examples of playing a Blu-ray movie using the network remote control
protocol. The comments are placed after the semicolon.
Example 1 –No verbose mode in use. Backwards compatible to the original version of
the network remote control protocol.
REMOTE PON ; Turn on power
@OK ON ; Player is turned on
REMOTE QPW ; Check power status
@OK OFF ; Player is still doing power-on initialization(Wait for a
while)
REMOTE QPW ; Check power status
@OK ON ; Player is powered on and ready
REMOTE EJT ; Eject the tray
@OK OPEN ; Tray opens(Place a disc on the tray)
REMOTE PLA ; Start playback
@OK PLAY ; You may get “ER OVERTIME” message due to the
mechanical delay. This is normal
REMOTE QDT ; Check disc type
@OK LOADING ; Player is still loading(Wait for a while)
REMOTE QDT ; Check disc type again
@OK BD-MV : Disc is a Blu-ray disc.
REMOTE QPL ; Check playback status
@OK PLAY : Playback is in progress(Watch the movie)
REMOTE STP ; Stop playback
@OK STOP : Playback has stopped
REMOTE EJT ; Eject the tray
@OK OPEN ; Tray opens(Take out the disc)
REMOTE POF ; Turn off power
@OK OFF ; The player turns off
Example 2 –Verbose mode 2. The player provides important status updates.
REMOTE SVM 2 ; Set verbose mode to level 2
@SVM OK 2 ; Response to confirm the verbose mode. Notice the
SVM command code is now included in the response.
REMOTE PON ; Turn on power
@PON OK ON ; Player is turned on
@UPW 1 ; Player provides a status update to indicate the new power
status

14
OPPO Digital, Inc. • www.oppodigital.com
@SVM OK 2 ; This is a repeat of the SVM response because the main
processor comes on line.
@UPL DISC ; Player indicates that there is no disc
REMOTE EJT ; Eject the tray
@EJT OK OPEN ; Tray opens
@UPL OPEN ; Player indicates that the tray is open(Place a disc on
the tray)
REMOTE PLA ; Start playback
@PLA OK PLAY ; Player confirms playback action
@UPL CLOS ; Player indicates that the tray is closing
@UPL LOAD ; Player indicates that the disc is loading
@UDT BDMV ; Player indicates that the disc type is Blu-ray
@UAT DT 01/01 ENG 5.1 ; Current audio is Dolby TrueHD English 5.1ch
@UST 00/00 UNK ; Current subtitle is none
@UPL PLAY ; Current status is playing(Watch the movie)
REMOTE STP ; Stop playback
@STP OK STOP ; Player confirms stop action
@UPL STOP ; Player indicates that playback has stopped
@UPL STOP ; It is normal to see repeated status update
REMOTE EJT ; Eject the tray
@UPL STOP
@EJT OK OPEN ; Tray opens
@UPL OPEN ; Status update to show that the tray is open
(Take out the disc)
REMOTE POF ; Turn off power
@POF OK OFF ; Player confirms the action
@UPL CLOS ; The tray is closing
@UPL LOAD ; Player is trying to read the disc
@UPW 0 ; Player reports that the power is turned off
Example 3 –Verbose mode 3. The player provides more detailed status updates.
REMOTE SVM 3 ; Set verbose mode to level 2
@SVM OK 3 ; Response to confirm the verbose mode. Notice the
; SVM command code is now included in the response.
REMOTE PON ; Turn on power
@PON OK ON ; Player is turned on
@UPW 1 ; Player provides a status update to indicate the new power
status
@SVM OK 3 ; This is a repeat of the SVM response because the main
processor comes on line.
@UPL DISC ; Player indicates that there is no disc
REMOTE EJT ; Eject the tray
@EJT OK OPEN ; Tray opens
@UPL OPEN ; Player indicates that the tray is open(Place a disc on
the tray)
REMOTE PLA ; Start playback
@PLA OK PLAY ; Player confirms playback action
@UPL CLOS ; Player indicates that the tray is closing
@UPL LOAD ; Player indicates that the disc is loading
@UDT BDMV ; Player indicates that the disc type is Blu-ray

15
OPPO Digital, Inc. • www.oppodigital.com
@UTC 000 000 T 00:00:00 ; Player indicates that the current counter is all 0 and
play back is about to begin
@UVO 1080P23 1080P60 ; Player indicates that the source program resolution is
1080p 23.976Hz, and the output resolution is 1080p60
@UAT DT 01/01 ENG 0.0 ; Current audio is Dolby TrueHD English with unknown
number of channels
@UST 00/00 UNK ; Current subtitle is none
@UTC 126 002 T 00:01:27 ; Playback resumes at Title 126, Chapter 2, title elapsed
time 00:01:27
@UPL PLAY ; Current status is playing
@UAT DT 01/01 ENG 5.1 ; Current audio is Dolby TrueHD English 5.1ch
@UTC 126 002 T 00:01:28 ; Player provides continuous counter updates
@UTC 126 002 T 00:01:29
@UTC 126 002 T 00:01:30
@UTC 126 002 T 00:01:31
@UTC 126 002 T 00:01:32
@UTC 126 002 T 00:01:33
@UTC 126 002 T 00:01:34
@UTC 126 002 T 00:01:35
@UTC 126 002 T 00:01:36
@UTC 126 002 T 00:01:37
@UTC 126 002 T 00:01:38
@UTC 126 002 T 00:01:39
REMOTE PAU ; Pause
@PAU OK PAUSE ; Confirm pause operation
@UPL PAUS ; Current status is paused
REMOTE PLA ; Play again
@PLA OK PLAY ; Confirm play operation
@UPL PLAY ; Current status is playing
@UTC 126 002 T 00:01:40 ; Counter updates continue(Watch the movie)
@UTC 126 002 T 00:01:41
@UTC 126 002 T 00:01:42
REMOTE STP ; Stop playback
@STP OK STOP ; Player confirms stop action
@UPL STOP ; Player indicates that playback has stopped
@UPL STOP ; It is normal to see repeated status update
REMOTE EJT ; Eject the tray
@UPL STOP
@EJT OK OPEN ; Tray opens(Take out the disc)
@UPL OPEN ; Status update to show that the tray is open
@UVO 1080P60 1080P60 ; Resolution change –the background screen is 1080p60
and the output is also 1080p60
REMOTE POF ; Turn off power
@POF OK OFF ; Player confirms the action
@UPL CLOS ; The tray is closing
@UPL LOAD ; Player is trying to read the disc
@UPW 0 ; Player reports that the power is turned off
