Oppo udp-203 User manual

USER MANUAL
READ CAREFULLY BEFORE OPERATION
ULTRA HD Blu-ray Disc Player
UDP-203

i
Table of Contents
IMPORTANT INFORMATION ..................................................... 1
Important Safety Instructions .................................................................................... 1
Precautions.................................................................................................................. 2
FCC Statement ............................................................................................................ 2
Trademarks.................................................................................................................. 3
Compatible Disc Types ............................................................................................... 3
Discs that cannot be played..........................................................................................................4
Notes about BD-ROM compatibility ..............................................................................................4
Disc care and handling.................................................................................................................4
Cinavia Notice ............................................................................................................. 4
Region management information ............................................................................... 4
Accessories ................................................................................................................. 5
INTRODUCTION ........................................................................ 6
Front Panel Controls ................................................................................................... 6
Front Panel Display Window ....................................................................................... 6
Rear Panel Connectors ............................................................................................... 7
Remote Control ........................................................................................................... 8
Remote Control Buttons...............................................................................................................8
Back Side.....................................................................................................................................9
Battery Installation........................................................................................................................9
Using the Remote Control ............................................................................................................9
Changing the Remote Code.......................................................................................................10
Motion Sensitive Backlight..........................................................................................................10
Common Connection Methods ............................................... 12
Connecting to an A/V Receiver via HDMI ................................................................. 12
Connecting to a TV via HDMI.................................................................................... 13
Connecting to a TV and A/V Receiver via Dual HDMI .............................................. 14
Connecting to an A/V Receiver or Amplifier via Analog Outputs ............................ 15
Connecting to an A/V Receiver or Amplifier via S/PDIF (Coaxial / Optical) ............ 16
HDMI INPUT to UDP-203 ........................................................................................... 17
Connecting to the Internet ....................................................................................... 18
Internet Connection via Ethernet Cable......................................................................................18
Internet Connection via Wi-Fi .....................................................................................................19
RS232 Control............................................................................................................ 20
BASIC OPERATIONS............................................................... 21
Disc Playback ............................................................................................................ 21
OPTION Menu ............................................................................................................ 21
Fast Forward and Reverse........................................................................................ 22

ii
Pause and Frame-by-Frame ...................................................................................... 23
Slow Playback ........................................................................................................... 23
Blu-ray Disc Menu Navigation................................................................................... 23
DVD Menu Navigation................................................................................................ 24
On-Screen Display ..................................................................................................... 24
Volume Control.......................................................................................................... 25
Mute ........................................................................................................................... 25
Audio Language/Track Selection.............................................................................. 25
Subtitle Selection...................................................................................................... 26
HDMI INPUT Selection .............................................................................................. 26
Audio Return Channel (ARC) Selection .................................................................... 26
BD-Live....................................................................................................................... 27
ADVANCED OPERATIONS....................................................... 28
Zooming and Aspect Ratio Control .......................................................................... 28
Zoom Levels for HDMI Output....................................................................................................28
Subtitle Shift.............................................................................................................. 30
Repeat Playback ....................................................................................................... 30
Repeat a Selected Section ....................................................................................... 31
Shuffle and Random Playback .................................................................................. 31
Playback by Chapter or Track Number .................................................................... 31
Playback from a Specific Location........................................................................... 32
DVD and Blu-ray Discs...............................................................................................................32
CD and SACD discs...................................................................................................................33
Memory and Automatic Resume............................................................................... 34
Viewing Pictures on DVD-Audio Discs...................................................................... 34
Pure Audio Mode ....................................................................................................... 35
MEDIA FILE PLAYBACK.......................................................... 36
Playback from a USB Flash Drive ............................................................................. 36
Playback from a Home Network............................................................................... 37
HOME Menu ............................................................................................................... 38
Playing Music Files.................................................................................................... 38
Playing Movie Files.................................................................................................... 40
Viewing Photo Files................................................................................................... 41
Adding Background Music ........................................................................................ 42
SETUP MENU OPTIONS .......................................................... 43
Using the Setup Menu System.................................................................................. 43
Playback Setup.......................................................................................................... 46
Video Output Setup ................................................................................................... 49
Picture Adjustment.....................................................................................................................53
Select the Best Output Resolution..............................................................................................54

iii
Determine the Display Aspect Ratio ...........................................................................................55
Audio Output Setup ................................................................................................... 56
Audio Signal Reference Chart ....................................................................................................59
Recommended Audio Format Options........................................................................................60
Audio Processing Setup ............................................................................................ 62
Speaker Configuration................................................................................................................64
Device Setup ............................................................................................................. 68
Network Setup........................................................................................................... 72
Useful Notes........................................................................... 76
Troubleshooting ..................................................................... 76
Specifications......................................................................... 78
User Manual Updates Online.................................................. 78
Language Code List................................................................ 79
RS-232 Control Protocol ......................................................... 80
LIMITED WARRANTY .............................................................. 90
OPPO Digital, Inc. Limited Two Years Warranty...................................................... 90

1
IMPORTANT INFORMATION
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product's enclosure that may be of sufficient magnitude to
constitute arisk ofelectric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operation and maintenance
(servicing) instruction in the literature
accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN
THE CABINET. REFER SERVICING TO QUALIFIED
PERSONNEL ONLY.
THE APPARATUS SHALL NOT BE EXPOSED TO
DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES SHALL BE
PLACED ON THE APPARATUS.
CAUTION:
DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR
EQUIVALENT TYPE.
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS
OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
CLASS I LASER
PRODUCT
This label is located on the laser protective housing inside the
product.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched, particularly at plug, receptacle, and the point
where it exits from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the
cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
15) Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the
like.

I M P O R T A N T I N F O R M A T I O N
2
Precautions
Before connecting the AC power cord to the appliance,
make sure the voltage designation of the appliance
corresponds to the local electrical supply. If you are
unsure of your power supply, contact your local power
company. The acceptable power input range is AC
100V-240V~, 50/60Hz.
The apparatus with CLASS I construction shall be
connected to a MAINS socket outlet with a protective
earthing connection.
The player is still receiving power from the AC power
source as long as it is connected to the wall outlet,
even if the player itself has been turned off.
Unplug the power cord if you are not going to use the
product for an extended period of time. Hold the power
plug when unplugging. Do not pull on the cord.
The main plug is used as the mechanism for cutting off
power, therefore make sure it is easy to unplug.
To ensure proper ventilation around this product, do not
place this product on a sofa, bed or rug. When installing
this product on a wall or bookshelf, you need to provide
appropriate space: we recommend leaving 4 inches (10
cm) of free space at the top, the sides and the rear.
High temperature will lead to abnormal operation of this
unit. Do not expose this unit or batteries to direct sunlight
or near other heating objects.
When moving the player from a cold location to a warm
one, or vice versa, moisture may condense on the laser
pickup unit inside the player. Should this occur, the
player may not operate properly. In such a case please
turn the unit on for 1-2 hours (without a disc) to facilitate
moisture evaporation.
FCC Statement
This equipment has been tested andfound tocomply withthe
limits for a ClassB digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordancewith the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur ina particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determinedby turning
the equipment off and on, the user is encouraged to tryto
correct the interference by one ormore of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Any unauthorizedchanges or modifications to this equipment would
void the user’s authority to operate this device.
This device complies with Part 15of the FCC Rules. Operation is
subject tothe following two conditions: (1) This device may not cause
harmful interference, and (2) this devicemust accept any interference
received, including interference that may causeundesired operation.

I M P O R T A N T I N F O R M A T I O N
3
Trademarks
“ULTRA HD Blu-ray”, “Blu-ray Disc”, “Blu-ray 3D”,
“BONUSVIEW” and “BD-Live” are trademarks of Blu-ray
Disc Association.
Java and all Java-based trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and other
countries.
DVD Logo is a trademark of DVD Format/Logo Licensing
Corp., registered in the U.S., Japan and other countries.
Super Audio CD, SACD and the SACD logo are joint
trademarks of Sony Corporation and Philips Electronics
N.V. Direct Stream Digital (DSD) is a trademark of Sony
Corporation.
“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.
“480i/480p/720p/1080i/1080p” up-converting arrow logo,
“Source Direct” and “True 24p” logos are trademarks of
OPPO Digital, Inc.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS Licensing
Limited. DTS, the Symbol, DTS in combination with the
Symbol, the DTS-HD logo, and DTS-HD Master Audio
are registered trademarks or trademarks of DTS, Inc.
in the United States and/or other countries. © DTS,
Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
“Cinavia” is trademark of Verance Corporation.
All other trademarks are the properties of their
respective owners.
Compatible Disc Types
Logo
Features
Manual Icon
BD: Supports 4K Ultra HD Blu-ray and Blu-ray with Bonus View and BD-Live
content, including Blu-ray 3D discs. A 3D-capable display with compatible
glasses is required for 3D playback. BD-R/RE, both single- and dual-layer are
also supported.
DVD: Plays commercially-released DVDs, as well as finalized DVD±R/RW.
DVD-A: High-resolution stereo or multi-channel audio. Some DVD-Audio discs
also contain a DVD-Video portion.
SACD: High-resolution stereo or multi-channel audio. Note: some SACDs use
a hybrid format with both a CD and a high resolution DSD layer.
CD: Supports standard Red Book CDs, as well as CD-R/RW.
AVCHD: High-definition digital video camera format, often in the form of a
DVD±R or flash memory.

I M P O R T A N T I N F O R M A T I O N
4
Discs that cannot be played
BDs with cartridge
DVD-RAMs
HD-DVDs
Data portion of CD-Extras
DVDs / Blu-Rays with a region code not matching the
player’s region code
Some Dual-Discs: A Dual-Disc is a two-sided disc with
DVD-video on one side and digital audio on the other
side. The digital audio side does not meet the technical
specifications of the Red Book CD format so playback is
not guaranteed.
Audio discs with copy-protection may not be playable.
Notes about BD-ROM compatibility
Since the Blu-ray Disc specifications are new and evolving, some discs may not play properly depending on the disc type, version
and encoding. It is possible that a Blu-ray Disc manufactured after the player uses new features of the Blu-ray Disc specifications.
To ensure the best possible viewing experience, the player may need a firmware or software update from time to time. Please visit
OPPO Digital’s web site www.oppodigital.com to check if updates are available.
Disc care and handling
To keep the disc clean from scratches or fingerprints,
handle the disc by its edge. Do not touch the recorded
surface.
Blu-ray Discs record data in very high density and the
recorded layer is very close to the disc surface. For this
reason, Blu-ray Discs are more sensitive to dust and
fingerprints than DVD. Should you encounter playback
problems and see dirty spots on the disc surface, clean
the disc with a cleaning cloth. Wipe the disc from the
center out along the radial direction. Do not wipe the
disc in a circular motion.
Do not use record cleaning sprays or solvents such as
benzene, thinner and anti-static spray.
Do not attach labels or stickers to discs as this may
cause the disc to warp or become too thick, resulting in
playback issues and a potentially stuck disc.
Avoid exposing the discs to direct sunlight or heat
sources.
Do not use the following discs:
oDiscs with exposed adhesive from removed stickers
or labels. The disc may get stuck inside the player.
oWarped or cracked discs.
oIrregularly shaped discs, such as heart or business
card shapes.
Cinavia Notice
This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their
soundtracks. When a prohibiteduse of an unauthorized copyis detected, a message will bedisplayed and playback or copying will be
interrupted.
This product incorporates proprietarytechnology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and
other U.S. and worldwide patents issued and pending as well as copyright and tradesecret protection for certain aspects of such
technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2013 Verance Corporation. All rights reserved byVerance.
Reverse engineering or disassembly is prohibited.
This update includes Cinavia®content protection technology. Information about Cinaviatechnology is providedat the Cinavia Online
Consumer Information Center at http://www.cinavia.com.
More information about Cinaviatechnology is providedat the Cinavia Online Consumer Information Center at http://www.cinavia.com. To
request additional information about Cinavia by mail, send a postcardwith yourmailing address to: Cinavia ConsumerInformation Center,
P.O. Box 86851, SanDiego, CA, 92138, USA.
Region management information
This player is designed and manufactured to respond to the region management information. If the region number of a BD-Video
or DVD disc does not correspond to the region number of this player, this player cannot play the disc.

I M P O R T A N T I N F O R M A T I O N
5
BD-Video: Blu-Ray Discs with marks containing the region code A.
DVD-Video: DVDs with marks containing the region code 1 and ALL.
Accessories
Please check that thefollowing parts are includedin your UDP-203 package:
User Manual
Premium HighSpeed HDMI Cable, about 6 feet
PowerCable, about 4.5 feet
RemoteControlwith AABatteries
