Instruction Manual
optek-sensors AF16
optek-Manual--1004-2001-02--AF16-US-2011-01-04
PN: 1004-2001-02 (-52)
optek-Danulat GmbH
Emscherbruchallee 2
45356 Essen
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.optek.com

Preface
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
Preface
This instruction manual is written to assist the user in proper procedures for
trouble-free operation.
Itis explicitlypointed out thatoptek-Danulat GmbH assumes no responsibilityfor
loss or damage caused due to improper use of this instruction manual or
products described herein.
This manual is protected by copyright. However, the user may produce copies
and translations if required for correct operation of the products.
On request, this manual is available in other languages as well as in digital
format (Acrobat®Reader 7.0 required).
Our products are being continuously improved. Technical data is subject to
change without notice.
Essen, December 2010

Table of contents
- I -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
Table of contents
Preface
1 Using the instruction manual .................................................................................................1
1.1 Validity of the instruction manual .........................................................................................1
1.2 Pictograms and signal words ...............................................................................................2
2 Returns and disposal ..............................................................................................................3
2.1 Declaration of decontamination............................................................................................3
2.2 Disposal...............................................................................................................................3
3 Intended use .............................................................................................................................4
4 Description of AF16-F / AF16-N sensors ...............................................................................5
5 Technical data and exploded views .......................................................................................7
5.1 Exploded view of AF16-F / AF16-N sensor ........................................................................10
5.2 Exploded view of AF16-HT-F / AF16-HT-N sensor.............................................................11
5.3 Exploded view of AF16-VA-F / AF16-VA-N sensor.............................................................12
5.4 Exploded view of AF16-HT-VA-F / AF16-HT-VA-N sensor.................................................13
5.5 Exploded view of AF16-VB-F / AF16-VB-N sensor.............................................................14
5.6 Exploded view of AF16-HT-VB-F / AF16-HT-VB-N sensor.................................................15
5.7 Exploded view of AF16-PV-F / AF16-PV-N sensor.............................................................16
5.8 Exploded view of AF16-HT-PV-F / AF16-HT-PV-N sensor.................................................17
5.9 Exploded view of AF16-VA-PV-F / AF16-VA-PV-N sensor.................................................18
5.10 Exploded view of AF16-HT-VA-PV-F / AF16-HT-VA-PV-N sensor .....................................19
5.11 Exploded view of AF16-VB-PV-F / AF16-VB-PV-N sensor.................................................20
5.12 Exploded view of AF16-HT-VB-PV-F / AF16-HT-VB-PV-N sensor .....................................21
6 Installation ..............................................................................................................................22
6.1 Standard sensor bodies — installation instructions............................................................22
6.2 Installation of the sensor....................................................................................................23
6.3 Airpurge.............................................................................................................................24
7 Connection to converter C4000 ............................................................................................25
8 Faults ......................................................................................................................................29

Table of contents
- II -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
9 Maintenance ...........................................................................................................................31
9.1 Preventive maintenance.....................................................................................................31
9.2 Exchange of the lamp module............................................................................................32
9.3 Exchange of detector module.............................................................................................33
9.4 Return to operation after the exchange of lamp module and detector module....................34
9.5 Validation (only for sensor options VA and VB)..................................................................35
9.6 Reference filter and certificates..........................................................................................38
9.7 Handling the reference and validation filters ......................................................................39
9.8 Spare parts and accessories..............................................................................................40
9.8.1 Lamp modules / optics modules / detector modules / wavelength modules ...........40
9.8.2 Standard window .....................................................................................................41
9.8.3 Gaskets ...................................................................................................................41
9.8.4 Screw sets ...............................................................................................................41
9.8.5 Validation retrofit sets ..............................................................................................42
9.8.6 Small part sets .........................................................................................................42
9.8.7 Installation material .................................................................................................42
9.8.8 Reference filter for validation ...................................................................................42
9.8.9 Accessories - cable sets ..........................................................................................43
10 Declaration of conformity .....................................................................................................44
11 Contacts .................................................................................................................................45

Using the instruction manual
- 1 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
1 Using the instruction manual
1.1 Validity of the instruction manual
This instruction manual is valid for AF16-F, AF16-N sensors and their variants.
There are the following variants:
•HT
•VA
•VB
•PV
•HT-VA
•HT-VB
•HT-PV
•HT-VA-PV
•HT-VB-PV
• VA-PV
• VB-PV
Abbreviations mean the following sensor options:
• F color (NIR) sensor with application specific wavelength
measurement
• N near infrared sensor with range of wavelengths 730 – 970 nm
• HT high temperature
• VA validation on lamp side
• VB validation on detector side
• PV purge Varivent (air purge connections at sensor)
Follow the instruction manual for every operation. If the sensor is not used as
described in this instruction manual, your safety and the sensor function could
be affected.
To maintain reliability of the product, enhance its life cycle, and avoid down
times, follow the instructions given in this manual.
Furthermore, please follow the existing accident prevention and environmental
protection instructions, as well as recognized technical instructions for safe and
professional working.

Using the instruction manual
- 2 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
1.2 Pictograms and signal words
Important information in this instruction manual is marked with the following
pictograms:
Danger!
This pictogram indicates immediate danger to life and health of persons.
The text next to the symbol gives information on how to avoid bodily injuries.
If the possible cause of risk can be specified, the corresponding pictogram pre-
cedes instructions:
Danger!
Electrical voltage.
This pictogram indicates danger due to electrical voltage.
Caution!
This pictogram indicates information on how to avoid material damage.
Note!
This pictogram indicates instructional or general advice.

Returns and disposal
- 3 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
2 Returns and disposal
2.1 Declaration of decontamination
For the safety of our employees and because of legal regulations we need a
signed “declaration of decontamination” before your return can be handled.
This signed declaration must be included with the shipping documents on the
outside of the packaging.
Any returns which were exposed to hazardous substances and were not
professionally decontaminated are not accepted and will be sent back on your
cost.
optek’s declaration of decontamination and contact information can be found on
our website www.optek.com.
2.2 Disposal
Special legal regulations apply to the return and disposal of industrial waste
equipment. However, manufacturer and user can contractually agree on which
party is to fulfill these legal obligations.
Observe current national disposal regulations.
To dispose packaging material, please separate materials into the following
groups:
• Paper / paperboard
• Plastic
For disposal, disassemble the system components and separate them
according to different material groups.
Dispose of materials according to national and local regulations.
If no agreement has been made, products may be shipped to optek for disposal.

Intended use
- 4 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
3 Intended use
The optek-sensors AF16 and their variants are to be applied only as absorption
sensors for liquids and gases in inline applications according to the technical
data.
The use of the sensors in hazardous locations is prohibited. You can purchase
flameproof sensors for hazardous locations from optek. For these sensors,
special instruction manuals are delivered with the sensor.
Unauthorizedconstructionalchanges, additionalfittingsorrebuildings regarding
the sensor are prohibited. The only exception are rebuildings into one of the
variants listed in the chapter "Validity of the instruction manual". Changes to and
interference with the converter program are prohibited as well.
To lay sensor cables underground without protection is prohibited.
The manufacturer is not liable for damage resulting from misuse.
Following this instruction manual is part of the intended use.

Description of AF16-F / AF16-N sensors
- 5 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
4 Description of AF16-F / AF16-N sensors
This sensor is a high precision absorption sensor. It measures attenuation of
light passing through the process medium. The sensor was designed for direct
installation into pipelines.
Fig. 1 AF16-F / AF16-N
The following are the main sensor components:
Fig. 2 Schematic AF16-F / AF16-N
1. Sensor body
2. Windows
3. Filter (VIS or NIR)
4. Detector
5. Optics module
6. Lamp module
Its modular construction offers maximum flexibility in adapting to the process,
without affecting the property of measurement. A precisely defined, constant
light beam penetrates the process medium. A hermetically sealed silicon
photodiode measures intensity of incoming and optically filtered light and
supplies the converter with it in form of photocurrent.
1223456

Description of AF16-F / AF16-N sensors
- 6 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
Attenuation of light intensity, as a result of absorption and / or scattering of
substances in the process medium, is described by the Lambert-Beer Law. It
states, the logarithm of the transmission loss is proportional to concentration of
the substance. This is true for dissolved substances and undissolved material.
Depending on the particular material properties, concentrations can be detected
in ppm as well as in %.
According to this law, the extinction coefficient, defined through ingredient and
wavelength, affects the logarithm of the transmission loss, too. Therefore, the
choice of wavelength or range of wavelengths is of decisive importance for the
measurement and is defined for each measurement type with the help ofoptical
filters.
The third factor of influence in the Lambert-Beer Law is the path length of light
passing through the process medium. Equally proportional, the path length, too,
is an important aspect with regard to specification of a photometer. The distance
to be covered by light is defined through the optical path length (OPL), that is the
distance between the windows of a sensor body. In the technical data, OPL is
always given corresponding to window combination A-A.

Technical data and exploded views
- 7 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5 Technical data and exploded views
Tab. 1 Technical data AF16-F
AF16-F AF16-VA-F AF16-VB-F AF16-PV-F AF16-VA-PV-F AF16-VB-PV-F AF16-HT-F AF16-HT-VA-F AF16-HT-VB-F AF16-HT- PV-F AF16-HT-VA-PV-F AF16-HT- VB- PV-F
Material sensor body made of stainless steel 1.4571; SS 316 Ti (standard)
Special materials 1.4435 (SS 316 L),1.4539, 1.4462, TFM 4215, Hastelloy®C4, Hastelloy®C22, Titanium, Tantalum,
Monel®400, Inconel®625, PP, others on request
Line size 1/4" to 8", (DN 6 to DN 200)
Process connections ASME-Flange, DIN-Flange, Varivent, JIS-Flange, Tri-Clamp, BBS-Clamp, Female Thread NPT, Female Thread DIN ISO 228/1 G,
Sanitary Thread (DIN 11851), others on request
Gaskets Viton®, EPDM (FDA / USP Cl. VI), Kalrez®, Chemraz®, Fluoraz®,
Buna (NBR), Silicone, Viton®/ FEP (FDA), others on request
Windows Pyrex®, Sapphire
Optical path length 1 mm – 1000 mm
Process pressure 10 mbar to 325 bar, (0.15 psi to 4713 psi),
depending on process connection, material and design
Process temperature
Data is only valid for appropriate choice of mate-
rial of sensorbody and gaskets! No ice formation
on sensor!
permanent:
0 – 120 °C, (32 – 248 °F)
peak (15 min/day):
0 – 150 °C, (32 – 302 °F)
high temperature version
permanent:
-30 – 240 °C, (-22 – 464 °F)
peak (15 min/day):
-30 – 240 °C, (-22 – 464 °F)
Ambient temperature
operation:
0 – 40 °C, (32 – 104 °F)
(elevated or reduced ambient temperatures may require restrictions to
the admissible process temperature!)
transport:
-20 – 70 °C, (-4 – 158 °F)
Airpurge connectors available as standard, air purge pressure 0.5 bar max.
Light source incandescent tungsten lamp: 5,0 V DC, 775 mA, typical lamp life 3 to 5 years
Range of wavelengths specific to application from 385 nm - 1100 nm
Detector silicon photodiode, hermetically sealed
Calibration basic calibration in CU (concentration units)
Measuring range any measuring range between 0 - 0.05 to 3 CU (depending on the filter used)
Resolution < ± 0.05 % of respective measuring range
Repeatability < ± 0.5 % of respective measuring range
Linearity specific to application, < ± 1 % of respective measuring range
Protection all optical parts protected according to IP65 if sensor is constructed as intended, valid for installation
of connector or protection cap
Cable lengths standard: 2, 3, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90, 100 m (7, 10, 16, 33, 49, 66, 82, 98, 115, 131, 148, 164, 197, 230, 262, 295, 328 ft.),
Cable sets length > 100 m (328 ft.) on request; maximum: 250 m (820 ft.)
Cable material non-metallic sheathed cable with finely stranded copper conductor according to IEC 228 CL.5, insu-
lation PVC (-40 °C … +70 °C, -40 °F ... +158 °F)
SS plug protector special high shielded cable sets, optional rigid stainless steel connector
Certificates ISO 9001:2008, Pressure Equipment Directive, CE, HP0

Technical data and exploded views
- 8 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
Detailed technical information about the armature is given in the armatures in-
struction manual and the sensor body data sheet of your sensor body.
Tab. 2 Technical data AF16-N
AF16-N AF16-VA-N AF16-VB-N AF16-PV-N AF16-VA-PV-N AF16-VB-PV-N AF16-HT-N AF16-HT-VA-N AF16-HT-VB-N AF16-HT-PV-N AF16-HT-VA-PV-N AF16-HT-VB- PV-N
Material sensor body made of stainless steel 1.4571; SS 316 Ti (standard)
Special materials 1.4435 (SS 316 L), 1.4539, 1.4462, TFM 4215, Hastelloy®C4, Hastelloy®
C22, Titanium, Tantalum, Monel®400, Inconel®625, PP, others on request.
Line size 1/4" to 8", (DN 6 to DN 200)
Process connections ASME-Flange, DIN-Flange, Varivent, JIS-Flange, Tri-Clamp, BBS-Clamp, Female Thread NPT, Female Thread DIN ISO 228/1 G,
Sanitary Thread (DIN 11851), others on request
Gaskets Viton®, EPDM (FDA / USP Cl. VI), Kalrez®, Chemraz®, Fluoraz®,
Buna (NBR), Silicone, Viton®/ FEP (FDA), others on request
Windows Pyrex®, Sapphire
Optical path length 1 mm – 1000 mm
Process pressure 10 mbar to 325 bar, (0.15 psi to 4713 psi),
depending on process connection, material and design
Process temperature
Data is only valid for appropriate choice of mate-
rial of sensorbody and gaskets! No ice formation
on sensor!
permanent:
0 – 120 °C, (32 – 248 °F)
peak (15 min/day):
0 – 150 °C, (32 – 302 °F)
high temperature version
permanent:
-30 – 240 °C, (-22 – 464 °F)
peak (15 min/day):
-30 – 240 °C, (-22 – 464 °F)
Ambient temperature
operation:
0 – 40 °C, (32 – 104 °F)
(elevated or reduced ambient temperatures may require restrictions to
the admissible process temperature!)
transport:
-20 – 70 °C, (-4 – 158 °F)
Airpurge connectors available as standard; air purge pressure 0.5 bar max.
Light source incandescent tungsten lamp: 5,0 V DC, 775 mA, typical lamp life 3 to 5 years
Range of wavelengths 730 nm – 970 nm
Detector silicon photodiode, hermetically sealed
Calibration basic calibration in CU (concentration units)
Measuring range any measuring range between 0 - 0.05 to 5 CU
Resolution < ± 0.05 % of respective measuring range
Repeatability < ± 0.5 % of respective measuring range
Linearity specific to application, < ± 1 % of respective measuring range
Protection all optical parts protected according to IP65 if sensor is constructed as intended, valid for installation
of connector or protection cap
Cable lengths standard: 2, 3, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 70, 80, 90, 100 m (7, 10, 16, 33, 49, 66, 82, 98, 115, 131, 148, 164, 197, 230, 262, 295, 328 ft.),
Cable sets length > 100 m (328 ft.) on request; maximum: 250 m (820 ft.)
Cable material non-metallic sheathed cable with finely stranded copper conductor according to IEC 228 CL.5, insu-
lation PVC (-40 °C … +70 °C, -40 °F ... +158 °F)
SS plug protector special high shielded cable sets, optional rigid stainless steel connector
Certificates ISO 9001:2008, Pressure Equipment Directive, CE, HP0

Technical data and exploded views
- 9 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
Tab. 3 Cable weights
Cable Weight
Lamp cable (1.5 mm2)0.9 kg / 10 m
Lamp cable (2.5 mm2)1.2 kg / 10 m
Lamp cable (4.0 mm2)1.5 kg / 10 m
Detector cable (AF16) 0.6 kg / 10 m

Technical data and exploded views
- 10 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.1 Exploded view of AF16-F / AF16-N sensor
Fig. 3 Photo and exploded view AF16-F / AF16-N
16 15 7
8 765
11 10
93422
7
5312 76
17 16
13 9
10 14
1
Tab. 4 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 10 4 screws M3 x 6 (DIN 7985), 1.4571 (316 Ti)
2 Window ring M24 x 1.5, incl. 8 screws M5 11 Lamp cable AF16
3O-Ring 25.12 x 1.78, Viton®12 Detector adapter AF16, 1.4571 (316 Ti)
4Lamp adapter AF16, 1.4571 (316 Ti),
incl. optics module AF16 13 Detector module AF16-F or AF16-N
5O-Ring 31.47 x 1.78, Viton®14 Detector cable AF16
6 Optical housing OP06, 1.4571 (316 Ti) 15 Lamp cable with SS plug protector
7O-Ring 21.95 x 1.78, Viton®16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
8 Lamp module AF16 17 Detector cable with SS plug protector
9O-Ring 10.10 x 1.60, Viton®

Technical data and exploded views
- 11 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.2 Exploded view of AF16-HT-F / AF16-HT-N sensor
Fig. 4 Photo and exploded view of AF16-HT-F / AF16-HT-N
Note!
For AF16-HT-F / AF16-HT-N, the cable set always has to be equipped with plug
protector.
16 15 7
8 76593422
7
5312 76
17 16
13 9
1
Tab. 5 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 10 -
2 Window ring M24 x 1.5, incl. 8 screws M5 11 -
3O-Ring 25.12 x 1.78, Viton®12 Detector adapter AF16-HT, PEEK
4Lamp adapter AF16-HT, PEEK,
incl. optics module AF16-HT 13 Detector module AF16-HT-F or AF16-HT-N
5O-Ring 31.47 x 1.78, Viton®14 -
6 Optical housing OP06, 1.4571 (316 Ti) 15 Lamp cable with SS plug protector
7O-Ring 21.95 x 1.78, Viton®16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
8 Lamp module AF16 17 Detector cable with SS plug protector
9O-Ring 10.10 x 1.60, Viton®

Technical data and exploded views
- 12 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.3 Exploded view of AF16-VA-F / AF16-VA-N sensor
Fig. 5 Photo and exploded view of AF16-VA-F / AF16-VA-N
16 15 7
8 765
11 10
93422
7
5312 76
17 16
13 9
10 141819 7
20
1
Tab. 6 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 11 Lamp cable AF16
2 Window ring M24 x 1.5, incl. 8 screws M5 12 Detector adapter AF16, 1.4571 (316 Ti)
3O-Ring 25.12 x 1.78, Viton®13 Detector module AF16-F or AF16-N
4Lamp adapter AF16-HT-VA, PEEK,
incl. optics module AF16-HT 14 Detector cable AF16
5O-Ring 31.47 x 1.78, Viton®15 Lamp cable with SS plug protector
6 Optical housing OP06, 1.4571 (316 Ti) 16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
7O-Ring 21.95 x 1.78, Viton®17 Detector cable with SS plug protector
8 Lamp module AF16 18 Sealing cover FH01
9O-Ring 10.10 x 1.60, Viton®19 4 screws M3 x 10 (DIN 7985), 1.4571 (316 Ti)
10 4 screws M3 x 6 (DIN 7985), 1.4571 (316 Ti) 20 Validation filter in FH01

Technical data and exploded views
- 13 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.4 Exploded view of AF16-HT-VA-F / AF16-HT-VA-N sensor
Fig. 6 Photo and exploded view of AF16-HT-VA-F / AF16-HT-VA-N
Note!
For AF16-HT-VA-F / AF16-HT-VA-N, the cable set always has to be equipped
with plug protector.
16 15 7
8 76593422
7
5312 76
17 16
13 9
1819 7
20
1
Tab. 7 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 11 -
2 Window ring M24 x 1.5, incl. 8 screws M5 12 Detector adapter AF16-HT, PEEK
3O-Ring 25.12 x 1.78, Viton®13 Detector module AF16-HT-F or AF16-HT-N
4 Lamp adapter AF16-HT-VA, PEEK, incl. optics
module AF16-HT 14 -
5O-Ring 31.47 x 1.78, Viton®15 Lamp cable with SS plug protector
6 Optical housing OP06, 1.4571 (316 Ti) 16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
7O-Ring 21.95 x 1.78, Viton®17 Detector cable with SS plug protector
8 Lamp module AF16 18 Sealing cover FH01
9O-Ring 10.10 x 1.60, Viton®19 4 screws M3 x 10 (DIN 7985), 1.4571 (316 Ti)
10 - 20 Validation filter in FH01

Technical data and exploded views
- 14 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.5 Exploded view of AF16-VB-F / AF16-VB-N sensor
Fig. 7 Photo and exploded view of AF16-VB-F / AF16-VB-N
16 15 7
8765
11 10
93422
7
5312 76
17 16
13 9
10 1418 19 20
21
1
Tab. 8 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 12 Detector adapter AF16-HT-VB, PEEK
2 Window ring M24 x 1.5, incl. 8 screws M5 13 Detector module AF16-F or AF16-N
3O-Ring 25.12 x 1.78, Viton®14 Detector cable AF16
4Lamp adapter AF16, 1.4571 (316 Ti),
incl. optics module AF16 15 Lamp cable with SS plug protector
5O-Ring 31.47 x 1.78, Viton®16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
6 Optical housing OP06, 1.4571 (316 Ti) 17 Detector cable with SS plug protector
7O-Ring 21.95 x 1.78, Viton®18 O-Ring 18.77 x 1.78, Viton®
8 Lamp module AF16 19 Sealing cover FH03
9O-Ring 10.10 x 1.60, Viton®20 2 screws M3 x 10 (DIN 7985), 1.4571 (316 Ti), (M3 x
12 permitted)
10 4 screws M3 x 6 (DIN 7985), 1.4571 (316 Ti) 21 Validation filter in FH03
11 Lamp cable AF16

Technical data and exploded views
- 15 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.6 Exploded view of AF16-HT-VB-F / AF16-HT-VB-N sensor
Fig. 8 Photo and exploded view of AF16-HT-VB-F / AF16-HT-VB-N
Note!
For AF16-HT-VB-F / AF16-HT-VB-N, the cable set always has to be equipped
with plug protector.
16 15 7
876593422
7
5312 76
17 16
13 9
18 19 20
21
1
Tab. 9 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 12 Detector adapter AF16-HT-VB, PEEK
2 Window ring M24 x 1.5, incl. 8 screws M5 13 Detector module AF16-HT-F or AF16-HT-N
3O-Ring 25.12 x 1.78, Viton®14 -
4 Lamp adapter AF16-HT, PEEK,
incl. optics module AF16-HT 15 Lamp cable with SS plug protector
5O-Ring 31.47 x 1.78, Viton®16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
6 Optical housing OP06, 1.4571 (316 Ti) 17 Detector cable with SS plug protector
7O-Ring 21.95 x 1.78, Viton®18 O-Ring 18.77 x 1.78, Viton®
8 Lamp module AF16 19 Sealing cover FH03
9O-Ring 10.10 x 1.60, Viton®20 2 screws M3 x 10 (DIN 7985), 1.4571 (316 Ti),
(M3 x 12 permitted)
10 - 21 Validation filter in FH03
11 -

Technical data and exploded views
- 16 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
5.7 Exploded view of AF16-PV-F / AF16-PV-N sensor
Fig. 9 Photo and exploded view of AF16-PV-F / AF16-PV-N
16 15 7
8 765
11 10
93422
7
5312 76
17 16
13 9
10 14
18 19
18 20
19 18
20 18
1
Tab. 10 Exploded view explanations
No. Explanation No. Explanation
1 Sensor body 11 Lamp cable AF16
2 Window ring M24 x 1.5, incl. 8 screws M5 12 Detector adapter AF16, 1.4571 (316 Ti)
3O-Ring 25.12 x 1.78, Viton®13 Detector module AF16-F or AF16-N
4 Lamp adapter AF16, 1.4571 (316 Ti),
incl. optics module AF16 14 Detector cable AF16
5O-Ring 31.47 x 1.78, Viton®15 Lamp cable with SS plug protector
6 Optical housing OP06 Purge, 1.4571 (316 Ti) 16 4 screws M3 x 12 (DIN 7985), 1.4571 (316 Ti), incl.
washer
7O-Ring 21.95 x 1.78, Viton®17 Detector cable with SS plug protector
8 Lamp module AF16 18 O-Ring 4.00 x 1.00, Viton®
9O-Ring 10.10 x 1.60, Viton®19 Screw M5 x 6 (DIN 84), 1.4571 (316 Ti)
10 4 screws M3 x 6 (DIN 7985), 1.4571 (316 Ti) 20 Purge connection M5, Ms / Ni
