Installation Manual
Push Button SW-1
Specifications
SW-1 Push button
Current rating at 250V Nominal 5A
Thermal 12A
Material Stainless steel 304, mat polished
Dimensions 250 * 75 * 15mm (L * W * H)
Operating temperature 0°C to +85°C
Protection degree IP 66
Mechanical lifecycle ca. 2 million switches
Warranty 2 years
Cable 3 x 0.75 mm, 500 mm length
lledwaterproof 
Accessories 3 stickers
Thespecicationshereinaresubjecttochangewithoutpriornoticedue
to improvements.
Version 1.09
BLACK
BLUE
BROWN
75mm
Ø 6mm
Ø 20mm
Ø 6mm
40mm
30mm50mm125mm
250mm
45mm
25mm
50mm
Place label here for efcient use
and optimal switching
OPTEX Technologies B.V.
Henricuskade 17
2497 NB The Hague
The Netherlands
TEL.: [phone]
E-MAIL: [email protected]
WEBSITE: www.optex.eu

Installation Manual
Push Button SW-2
Specifications
SW-2 Push button
Current rating at 250V Nominal 5A
Thermal 12A
Material Stainless steel 304, mat polished
Dimensions 150 * 55 * 15mm (L * W * H)
Operating temperature 0°C to +85°C
Protection degree IP 66
Mechanical lifecycle ca. 2 million switches
Warranty 2 years
Cable 3 x 0.75 mm, 500 mm length
lledwaterproof 
Accessories 3 stickers
Thespecicationshereinaresubjecttochangewithoutpriornoticedueto
improvements.
Version 1.09
BLACK
BLUE
BROWN
55mm
Ø 6mm
Ø 18mm
Ø 6mm
26mm
23mm18mm88mm
150mm
21mm
20mm
10mm
Place label here for efcient use
and optimal switching
OPTEX Technologies B.V.
Henricuskade 17
2497 NB The Hague
The Netherlands
TEL.: [phone]
E-MAIL: [email protected]
WEBSITE: www.optex.eu
