Optical Solutions FiberPath 500 Installation and operating manual

The FiberPath 500 System meets or exceeds the FSAN standard for distance of 20 km and optical
loss of 25 dB.
FiberPath Optical Plant Specifications
The FiberPath system must adhere to certain optical specifications. Any optical plant has inherent
loss characteristics and with these losses certain optical levels must be met. The information
found below can be used to help with the turn-up and troubleshooting process.
NOTE: Verify all optical power levels before connections are made. If excessive loss
is noted, the use of an optical time domain reflectometer (OTDR) may be
required. Also, clean all optical connections when handling them. Use proper
cleaning techniques to ensure minimal throughput losses.
Table 1 depicts the expected optical transmit and receive windows for the FiberPath 500 system.
These readings are measured with an optical power meter at a wavelength of 1550 nm. The
assumed optical output of the GPON is 1 dBm @1550 nm; VPON output is 20 dBm @ 1550 nm.
NOTE: The GPON actually operates at 1490 nm however optical power meters capable
of measurements at this wavelength may not be readily available.
Table 1: Launch and Receive Windows for FiberPath 500
Voice and Data
GPON TRANSMIT DOWNSTREAM (1490 nm) ONT RECEIVE
MAX MIN MAX MIN
+1 dBm +1 dBm -17 dBm -25 dBm
GPON RECEIVE UPSTREAM (1310 nm) ONT TRANSMIT
MAX MIN MAX MIN
-19 dBm -27 dBm -1 dBm -1 dBm
Video Overlay
HEADEND TRANSMIT DOWNSTREAM (1550 nm) ONT RECEIVE
MAX MIN 20 Port EDFA MAX MIN
+20 dBm +20 dBm +2 dBm -5 dBm
MAX MIN 4 Port EDFA MAX MIN
+23 dBm +23 dBm +2 dBm -5 dBm
FiberPath 500 Installation Reference Guide
Figure 1: Bi-Directional PON
G
P
O
N
1 X 32
FiberPoint
# 1
FiberPoint
# 32
32 way split/merge
6 Miles
TAC Center
1-866-388-4669

- 2 -
FiberPath Optical Plant Specifications (cont.)
Table 2 depicts typical throughput losses for optical splitters/combiners and optical fiber.
Table 2: Throughput Losses by Splitter/Combiner
Splitters
Splitter Loss (dB) Type
1 x 2 3.7 SC/APC
1 x 3 5.1 SC/APC
1 x 4 7.25 SC/APC
1 x 8 10.38 SC/APC
1 x 16 14.1 SC/APC
1 x 32 17.45 SC/APC
Optical Loss per Mile/Km
Fiber Type Loss/km Min
(dB)
Loss/Mile
Max (dB)
1550 0.25 0.4
1310 0.4 0.64
CWDM Loss (Nominal)
Insertion Loss @ 1310 nm (.8) dBm
Insertion Loss @ 1550 nm (1.2 dBm)
FiberPoint Electrical Connections
During the installation process, the DC power cable must be run into the house and terminated
at the UPS. Table 3 shows the color coding for the power cable:
Table 3: DC Power cable color coding
DC Power Connection for UPS
Pin # Color Function
1 Brown +12 VDC Supply (Vo+)
2 Blue +12 VDC Return (Vo-)
3 Black Signal Return
4 Green Operating in Battery Mode
5 Red Replace Battery
6 Yellow Battery Missing
7 Orange Low Battery
8 Gray Not Used
Pin 1
Ethernet and T1 connections are shown in Table 4 (RJ45 connectors):
Table 4: Pin-out Information
Ethernet RJ-45
Pin # Strand Color Name
1 white/orange TX+
2 orange TX-
3 white/green RX+
4 blue
5 white/blue
6 green RX-
7 white/brown
8 brown
Top View Front View T1 RJ-45
Pin # Name
1T
2R
3
4T1
5R1
6
7
8
2906
3341

- 3 -
FiberPoint Data Testing
When using DHCP, ensure that you release the IP address you are using before disconnecting
from the FiberPoint.
To Release the IP Address, at the command prompt, type the following:
c:\>IPCONFIG /RELEASE
NOTE: In the above string, there is a space after the IPCONFIG command.
FiberPoint 502/504/522/524 Indicators
A properly installed FiberPoint will go through a sequence of operation as follows (see Table 5):
• A Lamp test will occur to verify all LEDS work (all LEDs will illuminate)
• After a two second delay, the Power LED will illuminate and stay on.
• The CPU light will also come on and begin blinking indicating the processor in the
FiberPoint is functioning properly and is ready to transmit and receive information.
• The TRANS LED will come on and begin blinking as the unit begins its ranging
function. Once ranging is complete, the TRANS LED should stay on continuously.
Table 5: MOD-FP-502/504/522/524 LED Status
MOD-FP-502/504/522/524 LED Status
AGC Blink: The video signal is too high
On: The Automatic Gain Control is functioning and providing output power in the
specified range
Off: The output power is out of range
LINK On: Ethernet Port has a connection
Off: No Ethernet connection is present
CPU Blink: The processor is loaded and operating (heartbeat)
On: The processor is not operating properly
Off: The processor is not operating properly
OFF HK On: One or more of the POTS lines are off-hook
Off: No POTS lines are being used
TRANS Blink: The FiberPoint has downstream sync and is currently attempting to “range”
(sync up) on the upstream
On: The FiberPoint has ranged (upstream and downstream) and is communicating
with the HeadEnd
Off: The FiberPoint has not accomplished downstream sync and has quit trying to
“range”
PWR On: 3.3 VDC is appliced to the MOD-FP-502/504/522/524
Off: Power is off or the supply is not functional

- 4 -
FP560 Indicators
A properly installed FP 560’s sequence of operation is as follows (see Table 6):
• A Lamp test will occur to verify all LEDS work (all LEDs will illuminate)
• After a two second delay, the Power LED will illuminate and stay on.
• The Processor Health LED will also come on and begin blinking indicating the
processor in the FiberPoint is functioning properly and is ready to transmit and
receive information
• The PON Health LED will come on and begin blinking as the unit begins its
ranging function. Once ranging is complete, the PON HEALTH LED should stay on
continuously.
Table 6: MOD-FP-560 LED Status
MOD-FP-560 First LED Segment
POWER On: DC power applied to the MOD-FP-560
Off: No Power (no battery power either)
PROCESSOR
HEALTH
Blink: The MOD-FP-560 is loaded and operating (heartbeat)
On: Malfunction of the main electronics
Off: Malfunction of the main electronics
PON
HEALTH
Blink: The FiberPoint has downstream sync and is currently attempting to “range”
(sync) on the upstream
On: The FiberPoint has ranged (upstream and downstream) and is communicating
with the HeadEnd
Off: The FiberPoint has not accomplished downstream sync
TEL OFF HOOK On: One or more of the POTS lines are off-hook
Off: No POTS lines are being used
BATTERY PRESENT Blink: A battery is connected to the MOD-FP-560 and the battery is powering the
unit
On: A battery is connected to the MOD-FP-560 and AC power is powering the unit
Off: No battery is connected to the MOD-FP-560 and AC power is powering the
unit (assuming it’s on)
VIDEO AGC Blink: The video signal is too high
On: The video signal is within acceptable levels
Off: The video signal is off or too low
MOD-FP-560 2nd and 3rd Segments (Expansion)
PRESENT On: An expansion module is plugged in
Off: No expansion module present
STATUS On: The expansion module is functional
Off: Malfunction to an expansion module (if present)
PORT 1 (UVG)* On: At least one POTS line is off hook
Off: POTS service not currently in use
PORT 2-4 (UVG)* On: Not applicable - LED not functional
Off: Not applicable - LED not functional
PORT 1-4 (T1) On: Port is provisioned and running
Off: Port is not provisioned or connected
PORT 1-4 (QUAD
VIDEO)
On: Port is provisioned and running
Off: Port is not provisioned or connected
MOD-FP-560 4th Segment - Ethernet Data
PORT 1-4 On: Ethernet data connected to appropriate port
Off: No Data transmission possible
* - The LED in the Port 1 position indicates the status of any of the UVG ports (4 or 8, depending on the
module installed). LED Ports 2-4 are present but not used in this configuration.
Optical Solutions, Inc. • 16305 - 36th Avenue North • Suite 300 • Minneapolis, MN 55446
F
orm 361011-0001B • 06-28-04 • Printed in USA • © 2004 Optical Solutions, Inc.
